Wireless Headset

Instruction Manual

SCEH-00075

SCEH-00087 7012483

WIRELESS HEADSET INSTRUCTION

MANUAL

CONTENTS

Wireless Headset

Charging cradle

USB cable

Replacement earpiece ring

PRECAUTIONS

Before using this product, carefully read this manual and retain it for future

reference. Also refer to the instructions for your PLAYSTATION®3 system for

further precautions and information.

USE AND HANDLING

– Stop using this product immediately if it causes discomfort or pain.

– Do not expose the product to high temperatures, high humidity or direct

sunlight.

– Do not allow the product to come into contact with liquids.

– Do not put heavy objects on the product.

– Do not throw or drop this product, or physically damage it in any way.

– Do not touch or insert foreign objects into the connectors of this product.

– Do not attempt to disassemble or modify this product.

– Do not twist the supplied USB cable or pull it forcibly.

– When using this product, it is recommended that you limit volume to help

avoid harm to your ears and danger resulting from being unable to hear

what is going on around you.

– Do not place any rubber or vinyl materials on the product exterior for an

extended period of time.

– Use a soft, dry cloth to clean the product. Do not use solvents or other

chemicals. Do not wipe with a chemically treated cleaning cloth.

– Small parts. Not suitable for children under six years.

ABOUT THE WIRELESS HEADSET

1. Power button

2. Volume + button

3. Volume – button

4. Mic muting button

5. Mic muting indicator

6. Power indicator

7. Ear clip

8. Charging cradle

The Wireless Headset is designed to be used with the PLAYSTATION®3

system. It will also work with most Bluetooth®-enabled mobile phones

and audio devices.

This Quick Start Guide will help you start using the Wireless Headset

right away. For further reference, a full User Manual is available online at

playstation.com

NOTE: Before using the Wireless Headset for the ﬁrst time, it must be fully charged and

“paired” with the PS3™ system. The USB connector on the Wireless Headset is protected

by a cover which must be opened before the mini-B connector of the supplied USB cable

can be inserted.

CHARGING THE WIRELESS HEADSET

1. Check that the PS3™ system is turned on.

2. Insert the mini-B connector of the supplied USB cable into the charging

cradle, and insert the other end of the cable into a USB connector on the

PS3™ system.

3. Place the Wireless Headset into the charging cradle. The mic muting

indicator on the headset lights up and remains solid red for two seconds.

It will then ﬂash to indicate that the headset is charging. Charging is

complete when the indicator stops ﬂashing. You can also charge the

Wireless Headset by connecting it directly to the PS3™ system or any

powered USB port – such as on a PC – using a USB cable.

NOTE: The headset will be fully charged in approximately three hours.

PAIRING THE WIRELESS HEADSET WITH THE PS3™ SYSTEM

To pair with the PS3™ system using a USB cable, your PS3™ system

software must be updated to version 2.50 or higher.Additional features will

be available on your headset when you update the PS3™ system software

to version 2.50 or higher, but only if you pair your headset with the PS3™

system using a USB cable.These features will not be available if you pair

using Bluetooth®Discovery Mode. Pairing using Bluetooth®Discovery

Mode only allows you to use your headset in the same way as a standard

Bluetooth®headset.

NOTE: Further information on pairing using Bluetooth®Discovery Mode can be found later

in this manual.

USB connector

PS3™ system

Charging cradle

USB connector

mini-B connector USB cable

Bluetooth®Wireless Headset

PAIRING WITH THE PS3™ SYSTEM USING A USB CABLE

1. Check that the PS3™ system is turned on.

2. Insert the mini-B connector of the supplied USB cable directly into the

USB connector on the Wireless Headset, and insert the other end of the

cable into a USB connector on the PS3™ system.

The power indicator on the Wireless Headset lights up in solid green for

two seconds to indicate that the headset and the PS3™ system have

been successfully paired. If pairing is not successful, the headset’s power

indicator will remain lit in solid red for two seconds.

PAIRING WITH THE PS3™ SYSTEM IN BLUETOOTH®DISCOVERY

MODE

1. Press and hold the power button on the Wireless Headset until the

power indicator ﬂashes alternately in green and red, indicating that

Bluetooth®Discovery Mode is enabled.

2. On the PS3™ system’s Home Menu, go to Settings, then Accessory

Settings and select Manage Bluetooth®Devices.

3. An on-screen message will ask if you would like to register a

Bluetooth®device. Select Yes when prompted.

4. Select Start Scanning. Your PS3™ system begins to scan for the

Wireless Headset. A list of Bluetooth®devices within range of your

PS3™ system will be displayed.

5. Select the Wireless Headset from the list of displayed devices.

If prompted for a pass key, enter “0000”.The headset is now paired

with the PS3™ system.

USING THE WIRELESS HEADSET WITH WIRELESS CONTROLLERS

After pairing the Wireless Headset with the PS3™ system, a maximum of four

wireless controllers can be used.

PAIRING THE WIRELESS HEADSET WITH A MOBILE PHONE

1. Press and hold the power button on the Wireless Headset until the power

indicator ﬂashes alternately in green and red, indicating that Bluetooth®

Discovery Mode is enabled.

2. Turn on the Bluetooth®feature on your mobile phone and start scanning

for the headset.

3. Select the Wireless Headset from the list of displayed devices.

If prompted for a pass key, enter “0000”.

The headset is now paired with the mobile phone.

NOTE: See your mobile phone’s instruction manual for further information on activating the

phone’s Bluetooth®functionality.

TURNING THE WIRELESS HEADSET

ON AND OFF

To turn on the Wireless Headset:

Press and hold the power button for

approximately three seconds. The power

indicator will be lit in solid green for two

seconds to indicate that the headset is

turned on.

To turn off the Wireless Headset:

Press and hold the power button for at least ﬁve seconds, until the power

indicator begins to ﬂash green to indicate that the headset is turning off.

WEARING THE WIRELESS HEADSET

1. Gently push open the ear clip.

2. While holding the ear clip open, slide it behind your ear.

3. Adjust the headset until it ﬁts comfortably on your ear.

3a. The ear clip shape is adjustable.Change the shape of the ear clip

to maximise comfort.

NOTE: An additional earpiece ring is included – use the one that feels most comfortable.

CHANGING FOR USE ON YOUR OTHER EAR

The Wireless Headset is supplied ready to wear on the right ear, but can

be worn on either ear.

To adjust for the left ear:

1. Gently pull the bottom of the ear clip off the hinge pin.

2. Flip the clip over so that it is symmetrically opposite from its original

position.

3. Hook the bottom of the clip onto the hinge pin.

BASIC OPERATIONS WHEN CONNECTED TO A PS3™ SYSTEM

Operation Action

Turn on Press and hold the power button for

approximately three seconds

Turn off Press and hold the power button for at least

ﬁve seconds

Mute sound Press the mic muting button

Raise volume Press the volume + button

Lower volume Press the volume – button

BASIC OPERATIONS WHEN CONNECTED TO A MOBILE PHONE

Operation Action

Turn on Press and hold the power button for

approximately three seconds

Turn off Press and hold down the power button for at

least ﬁve seconds

Mute the microphone Press the mic muting button

Raise volume Press the volume + button

Lower volume Press the volume – button

Answer a call Brieﬂy press the power button

Reject a call Press the power button for two seconds

End a call or cancel an

outgoing call

Brieﬂy press the power button

Transfer a call from

headset to phone

Press the power button for two seconds

Transfer a call from phone

to headset

Press the power button for two seconds

Redial the last number Press the power button for two seconds

NOTE: For additional operating information please refer to the full User Manual available at

eu.playstation.com

SPECIFICATIONS

Bluetooth®version Bluetooth®2.0 compliant

Supported Bluetooth®

proﬁles

Bluetooth®headset and hands-free proﬁles

Operating range Up to 33 feet (10 metres)

Talk time Up to 8 hours

Standby time Approximately 12.5 days or 300 hours

Charging time Approximately 3 hours

Weight 58g

Battery type Lithium-ion polymer battery

Voltage DC 3.7 V

Capacity 190 mAh

Operating temperature 5°C – 35°C (41°F – 95°F)

Design and speciﬁcations are subject to change without notice.

LIMITED WARRANTY

Where a 1-year warranty is supplied with your PLAYSTATION®3

system, such warranty also applies to this product. For details, please

see the PLAYSTATION®3 Safety and Support Guide, available online at

eu.playstation.com/ps3, or call the PLAYSTATION®3 Customer Service

number, which can be found within every PLAYSTATION®3 format

software manual.

TA-2008/737

Approved

RECYCLING INSTRUCTIONS FOR

CUSTOMERS IN EUROPE

For further information, please refer to the

PLAYSTATION®3 Safety and Support Guide,

available online at eu.playstation.com/ps3

LITHIUM-ION BATTERY IN WIRELESS HEADSET

The Lithium-ion polymer battery included in this product is permanently

built-in for safety, performance or data integrity reasons. The battery should

not need to be replaced during the lifetime of the product and should only

be removed by skilled service personnel. To ensure the correct waste

treatment of the battery, please dispose of this product as electrical waste.

, PLAYSTATION and PlayStation are registered trademarks of Sony

Computer Entertainment Europe.

Manufactured by Namtai under agreement with Sony Computer

Entertainment Europe
