Sony DVP-NS50P/S - Cd/dvd Player Manual de usuario

Key Technologies

Key Features

DVP-NS50P/S

DVD Player



Precision Cinema Progressive™ Technology 480P Output



12 Bit Video DAC with 108Mhz Processing



DVD-RW (Video Mode/VR Mode

w/CPRM)/DVD-R/DVD+RW/DVD+R Playback1



MP3 (CD-R/RW, DVD+RW/+R/-R/-RW) and JPEG (CD-R/RW,

DVD+RW/+R/-R/-RW, Kodak) Playback1



Fast/Slow Playback with Sound



Precision Drive™ 3 System compensates for flaws in DVD

discs



Dolby® Digital and dts® Decoding Compatible



192 KHz/24bit Audio DAC/96KHz/24bit Digital Out



Multi-Disc Resume -6 disc



Coaxial Digital Outpout



TV Virtual Sound



Video Equalizer

Precision Drive™ 3 System Past generations of Precision Drive systems were only able to compensate for

warped discs by moving the entire optical block, which took more time and limited the amount of correction

possible. Sony's new Precision Drive™ 3 system simplifies the process by moving the lens-instead of the entire

optical block-for faster and more accurate error correction.

Precision Cinema Progressive™ Technology·Other DVD players detect image changes at the scan line

level-Sony's Precision Cinema Progressive (PCP) system detects them at the pixel level. The picture is more

faithful to the source-whether film or video-because separate, optimized algorithms are used to handle the

differing pixel behavior. Separate algorithms are also used to process the moving and still parts of an image,

resulting in sharp backgrounds with moving objects that are virtually free from motion artifacts.

MP3 Playback1Playing MP3 Music on a Sony DVD player is easy. Just insert an MP3 encoded disc and press

MENU. A blue screen pops up to display your folders. Scroll down the list using the remote or front panel cursor

control to select the folder you want. The green files screen pops up to show the files in the selected folder.

Select the file you want to hear and you're done. Finding music couldn't be easier.

Specifications

Video

DAC (D/A Converter): 12 bit/108MHz

Format(s) Supported: DVD-RW (Video Mode/VR Mode

w/CPRM)/DVD-R/DVD+RW/DVD+R/+R Dual Layer

Playback1,

JPEG(CD-R/RW,DVD+RW/+R/-R/-RW,Kodak)Play

Audio

Digital-to-Analog Converter: 192kHz/24 bit

Sound Mode: Dolby® Digital and dts®

Format(s) Supported: MP3 on CD-R/-RW

DVD+RW/+R/-RW/-R Playback1, CD

(CD/CD-R/CD_RW), VCD,SVCD Playback1

Inputs and Outputs

Analog Video Output(s): Component x1, S-Video x1,

Composite x1

Analog Audio Output(s): (R+L) x1

Digital Video Output(s): Coaxial x1

Digital Output(s): 96KHz/24bit

Power

Power Requirements: AC120V, 60 Hz

DVP-NS50P/S

Weight

4 lbs, 4 oz (1.9 Kg)

Dimensions (WHD)

17 x 1 9/13 x 9 1/3" (430 x 43 x 237.2mm)

UPC Code

0272426675320

1. DVD-R/RW, DVD R/RW, MP3, JPEG, and CD-R/RW playback may

not be compatible with all discs, depending on recording

conditions.

Sony, Precision Cinema Progressive, Precision Drive and SmoothScan

are trademarks of Sony. Dolby and ProLogic are a registered trademark

Dolby Laboratories and dts is a trademark of Digital Theater Systems,

L.P. All other trademarks are property of their respective owners.

Features and specifications are subject to change without notice.

Non-metric weights and measures are approximate.

DVD Player

DVP-NS50P/S

®Sony Electronics Inc. • 16450 West Bernardo Drive • San Diego, CA 92127 • 1-800-222-7669 • www.sony.com/dn Last Updated 2005-07-25
