Sony Walkman D-NE511 Manual de usuario

Portable

CD Player

3-252-419-42 (1)

D-NE511

Operating Instructions GB

Használati útmutató HU

Инcтpyкция по экcплyaтaции RU

“WALKMAN” is a registered trademark of Sony Corporation to represent Headphone

Stereo products. is a trademark of Sony Corporation.

2-GB

WARNING

To prevent fire or shock

hazard, do not expose the unit

to rain or moisture.

Do not install the appliance in a confined

space, such as a bookcase or built-in

cabinet.

To prevent fire, do not cover the ventilation

of the apparatus with newspapers, table-

cloths, curtains, etc. And don’t place lighted

candles on the apparatus.

To prevent fire or shock hazard, do not place

objects filled with liquids, such as vases, on

the apparatus.

CAUTION

The use of optical instruments with this

product will increase eye hazard.

Certain countries may regulate disposal of

the battery used to power this product. Please

consult with your local authority.

CAUTION

•INVISIBLE LASER RADIATION

WHEN OPEN

•DO NOT STARE INTO BEAM OR

VIEW DIRECTLY WITH OPTICAL

INSTRUMENTS

The validity of the CE marking is restricted

to only those countries where it is legally

enforced, mainly in the countries EEA

(European Economic Area).

ATRAC3plus and ATRAC3 are trademarks

of Sony Corporation.

3-GB

Table of Contents

Enjoy your ATRAC CD

Walkman!

Create original ATRAC CDs! ...................... 4

Music sources playable on this CD player .. 6

ATRAC3plus and ATRAC3 ......................... 6

MP3 files ..................................................... 6

Difference between ATRAC3plus/ATRAC3

and MP3 .................................................. 8

Getting started

Locating the controls ................................... 9

Checking the supplied accessories ............ 10

Playing an audio CD or

ATRAC3plus/ATRAC3/MP3 files

1.Connect your CD player........................ 11

2.Insert a CD. ........................................... 11

3.Play a CD. ............................................. 11

Playback options

Playing tracks in random order

(Shuffle play)......................................... 17

Playing all files in a selected group in

random order (Group shuffle play)

(ATRAC/MP3 CD only)........................ 17

Playing your favorite tracks by adding

Bookmarks (Bookmark track play) ....... 18

Playing your favorite play lists

(m3u play list play)

(MP3 CD only)...................................... 19

Searching for your favorite tracks/files/

groups quickly using the JOG DIAL .... 20

Available features

The G-PROTECTION function................. 21

Checking the time remaining on the CD and

the number of tracks left (audio CD) .... 21

Checking information on a CD with

ATRAC3plus/ATRAC3/MP3 files ........ 22

Emphasizing the bass sound (SOUND) .... 22

Protecting your hearing (AVLS)................ 23

Locking the controls (HOLD) ................... 23

Turning off the operation beep sound........ 23

Connecting your CD player

Connecting a stereo system ....................... 24

Connecting to a power source

Using the dry batteries............................... 25

Notes on the power source ........................ 26

Additional information

Precautions ................................................ 27

Maintenance .............................................. 27

Troubleshooting......................................... 28

Specifications ............................................ 30

Optional accessories .................................. 31

4-GB

Enjoy your ATRAC CD Walkman!

Thank you for purchasing the D-NE511. This CD Walkman is called an “ATRAC CD Walkman,”

because you can enjoy “ATRAC CDs” on it.

Create original ATRAC CDs!

You can make your own ATRAC CD.

The procedure is very simple. Just perform Steps 1, 2 and 3.

How to use the SonicStage Simple Burner

Refer to the supplied booklet “SonicStage Simple Burner.”

Audio CDs MP3 files

Audio data is converted to the ATRAC3plus/

ATRAC3 format by the SonicStage Simple

Burner.

Step 1

Install

Install the supplied

“SonicStage Simple Burner”

software.

Step 2

Burn

Create a disc image and burn it on

a CD-R/RW using your PC.

5-GB

Enjoy your ATRAC CD Walkman!

What is an ATRAC CD?

An ATRAC CD is a CD-R/RW on which audio data compressed in theATRAC3plus/ATRAC3

format has been recorded. About 30 audio CDs can be recorded on a CD-R/RW.*You can also

record MP3 files by converting the files to theATRAC3plus/ATRAC3 format.

*When total playing time of one CD (album) is estimated at 60 minutes and you are recording on a 700 MB

CD-R/RW at 48 kbps in ATRAC3plus format.

What is the ATRAC3plus/ATRAC3

format?

Refer to pages 6 - 8 of this manual.

ATRAC CD

You can also enjoy audio CDs on

your CDWalkman.

Step 3

Listen

You can enjoy listening to your

own ATRAC CDs on your ATRAC

CDWalkman.

6-GB

Music sources playable on this CD player

You can play the following 3 music sources on this CD player:

•Audio CDs

•ATRAC3plus/ATRAC3 format files

•MP3 files

Usable disc formats

You can use ISO 9660 Level 1/2 and Joliet extension format discs only.

ATRAC3plus and ATRAC3

“ATRAC3plus,” which stands for “Adaptive TransformAcoustic Coding3plus” is audio

compression technology, developed from theATRAC3 format. Though theATRAC3plus format

can compress music content to about 1/20 of its original size, you can still enjoy high quality

sound. The available transfer bit rates are 64 kbps and 48 kbps.

“ATRAC3,” which stands for “Adaptive Transform Acoustic Coding3” is audio compression

technology that satisfies the demand for high sound quality and high compression rates. The

ATRAC3 format can compress music content to about 1/10 of their original size, which

contributes to reduction of the media volume. The available transfer bit rates are 132 kbps,

105 kbps and 66 kbps.

The usable number of groups and files

•Maximum number of groups: 255

•Maximum number of files: 999

For details, refer to the supplied booklet “SonicStage Simple Burner.”

Note on saving files on the media

Do not save files in other formats or unnecessary groups on a disc that hasATRAC3plus/

ATRAC3 files.

MP3 files

MP3, which stands for MPEG-1 Audio Layer3, a standard for audio files compression supported

by the Motion Picture Experts Group, an ISO (International Organization for Standardization)

working group, enables compression of audio files to about 1/10 of the data size of a standard

7-GB

compact disc. Since the MP3 encoding algorithm is public, there are various encoders/decoders

that are compliant with this standard, including freeware that is available for no charge. Thus, the

MP3 standard is widely used in the computer field.

The major specifications of the acceptable disc format are:

•Maximum directory levels: 8

•Acceptable characters for a file/folder name:

A - Z, a - z, 0 - 9, _ (underscore)

Notes

• When naming files, be sure to add the file extension “mp3” to the file name.

•If you add the extension “mp3” to a file other than an MP3 file, the player will not be able to recognize the

file properly.

•The file name does not correspond to the ID3 tag.

The usable number of groups and files

•Maximum number of groups: 100

•Maximum number of files: 400

Settings for compression and writing software

•This CD player supports MP3 files with the following specifications: transfer bit rate:

16 - 320 kbps and sampling frequencies: 32/44.1/ 48 kHz. Variable Bit Rate (VBR) is also

supported.

To compress a source for an MP3 file, we recommend setting the transfer bit rate of the

compression software to “44.1 kHz,” “128 kbps,” and “Constant Bit Rate.”

•To record up to the maximum capacity, set to “halting of writing.”

•To record at one time up to the maximum capacity on media that has nothing recorded on it,

set to “Disc at Once.”

Notes on saving files on the media

•Do not save files in other formats or unnecessary folders on a disc that has MP3 files.

• When a disc is inserted, the CD player reads all the information of folders and files on that

disc. If there are many folders on the disc, it may take a long time for play to begin or for the

next file to start playback.

Enjoy your ATRAC CD Walkman!

8-GB

Difference between ATRAC3plus/ATRAC3 and

MP3

Groups and folders

The ATRAC3plus/ATRAC3 format has a very simple structure. It consists of “files” and

“groups.” A “file” is equivalent to a “track” of an audio CD. A “group” is a bundle of files and is

equivalent to an “album.” A “group” has no directory-type structure (a new group cannot be

made within an existing group). This CD player is designed to recognize an MP3 file folder as a

“group” so that it can play CD-Rs/RWs recorded in both the ATRAC3plus/ATRAC3 format and

those recorded in the MP3 format with the same operation.

Displaying the track name, etc.

When playing a CD havingATRAC3plus/ATRAC3 files or MP3 files on this CD player, track

names, artist names and album names are displayed. This CD player conforms to Version 1.1/2.2/

2.3 of the ID3 tag format*.

*ID3 tag is a format for adding certain information (track name, album name, artist name, etc.) to MP3 files.

Notes

• This CD player cannot record music content on recordable media, such as CD-Rs/RWs.

•CD-Rs/RWs recorded in the ATRAC3plus/ATRAC3 format cannot be played on your computer.

•Playback capability may vary depending on the quality of the disc and the condition of the recording device.

9-GB

Getting started

Locating the controls

For details, see pages in parentheses.

CD player (front)

CD player (inside)

1i(headphones)

jack (pages 11,

24)

6DISPLAY button

(pages 21, 22)

qj Battery compartment

(page 25)

7HOLD switch

(page 23)

3OPEN button

(page 11)

8JOG DIAL/

ENTER (pages 16, 20)

qs DC IN 4.5 V

(external power

input) jack

(page 11)

qf u* (play/pause) button

(pages 11, 12, 16, 18, 19)

qd x(stop) button

(pages 12, 23)

qg ./>(AMS/search)

buttons (pages 12, 16, 19)

qh G-PROTECTION

switch (page 21)

4+/–

buttons

(page 12)

2VOL (volume)

+*/– buttons

(page 11)

5P MODE/

(play mode/repeat)

button (pages 16 - 19)

q; SOUND button

(pages 22, 23)

9Display

(pages 13, 16, 19 - 23)

qa Strap holes

*The button has a tactile dot.

Getting started

10-GB

Checking the supplied accessories

AC power adaptor (1) Headphones/earphones (1)

CD-ROM (SonicStage Simple Burner) (1)

User’s guide for SonicStage Simple Burner (1)

Otros manuales para Walkman D-NE511

Tabla de contenidos

Idiomas:

Otros manuales de Reproductor de CD de Sony

Sony

Sony CDX-1300 - Fm/am Compact Disc Player Guía del producto

Sony

Sony CDP-CX235 - Mega Changer Manual de usuario

Sony

Sony Walkman D-FS601 Manual de usuario

Sony

Sony CDX-GT828U Manual de usuario

Sony

Sony CDP-102 - Compact Disc Player Manual de usuario

Sony

Sony CDX-L410 Manual de usuario

Sony

Sony D-NE715 - Portable Cd Player Manual de usuario

Sony

Sony MXD-D4 Manual de usuario

Sony

Sony CDX-848X - Compact Disc Changer System Manual de usuario

Sony

Sony Walkman MZ-NF610 Manual de usuario

Sony

Sony CFD-S35CP Manual de usuario

Sony

Sony DVP-M35 Manual de usuario

Sony

Sony CDX-L350 - Fm/am Compact Disc Player Manual de usuario

Sony

Sony CDP-361 - Single Disc Compact Player Manual de usuario

Sony

Sony CDX-R3300T Guía del producto

Sony

Sony CDX-454XRF Manual de usuario

Sony

Sony CFD-V35 - Cd Radio Cassette-corder Manual de usuario

Sony

Sony DVX-100S Manual de usuario

Sony

Sony CDPCX455 - 400 Disc MegaStorage CD Changer Manual de usuario

Sony

Sony CDP-XE330 Manual de usuario

Sony

Sony CDX-GT500 - Fm/am Compact Disc Player Manual de usuario

Sony

Sony D-EJ001 Manual de usuario

Sony

Sony D-NE720 Manual de usuario

Sony

Sony D-E200 Primary Manual de usuario

Manuales populares de Reproductor de CD de otras marcas

RCA

RCA RP-7923 Manual de usuario

Pioneer

Pioneer DEH-P3550MP XM Manual de usuario

Philips

Philips AZ1207 Manual de usuario

Philips

Philips CD582 Manual de usuario

Philips

Philips AZ 6821 Manual de usuario

Lasonic

Lasonic MSU-2020 Manual de usuario

THOMSON

THOMSON RCD150 Manual de usuario

Denon

Denon DCD-1420 Manual de usuario

Panasonic

Panasonic SJ-MR100 Manual de usuario

Onkyo

Onkyo DX-7210 Manual de usuario

Denon

Denon DVM-4800 Manual de usuario

JBL

JBL MR-32 Manual de usuario

RCA

RCA RCD152 Manual de usuario

Technics

Technics SL-PS770A Manual de usuario

Clarion

Clarion compact disc Manual de usuario

Philips

Philips Expanium AZ 1538 Manual de usuario

Rotel

Rotel RCD 975 Manual de usuario

Pioneer

Pioneer CLD-D790 Manual de usuario
