Sony CDX-G1200U Manual de usuario

CDX-G1200U

4-595-966-71(1)

FM/AM

Compact Disc Player

Owner’s Record

The model and serial numbers are located on the

bottom of the unit.

Record the serial number in the space provided below.

Refer to these numbers whenever you call upon your

Sony dealer regarding this product.

Model No. CDX-G1200U

Serial No.

Operating Instructions GB

Mode d’emploi FR

Manual de instrucciones ES

To cancel the demonstration (DEMO) display, see

page 11.

For the connection/installation, see page 21.

Pour annuler l’affichage de démonstration (DEMO),

reportez-vous à la page 10.

Pour le raccordement/l’installation, reportez-vous à

la page 21.

Para cancelar la pantalla de demostración (DEMO),

consulte la página 10.

Para la conexión/instalación, consulte la página 21.

2GB

The nameplate indicating operating voltage,

etc., is located on the bottom of the chassis.

Warning

For safety, be sure to install this unit in the

dashboard of the car as the rear side of

the unit becomes hot during use.

For details, see “Connection/Installation”

(page 21).

FOR THE CUSTOMERS IN THE USA.

NOT APPLICABLE IN CANADA,

INCLUDING IN THE PROVINCE OF

QUEBEC.

POUR LES CLIENTS AUX ÉTATS-UNIS.

NON APPLICABLE AU CANADA, Y

COMPRIS LA PROVINCE DE QUÉBEC.

This equipment has been tested and

found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the

FCC Rules.

These limits are designed to provide

reasonable protection against harmful

interference in a residential installation.

This equipment generates, uses, and can

radiate radio frequency energy and, if not

installed and used in accordance with the

instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that

interference will not occur in a particular

installation. If this equipment does cause

harmful interference to radio or television

reception, which can be determined by

turning the equipment off and on, the

user is encouraged to try to correct the

interference by one or more of the

following measures:

– Reorient or relocate the receiving

antenna.

– Increase the separation between the

equipment and receiver.

– Connect the equipment into an outlet

on a circuit different from that to which

the receiver is connected.

– Consult the dealer or an experienced

radio/TV technician for help.

You are cautioned that any changes or

modifications not expressly approved in

this manual could void your authority to

operate this equipment.

3GB

CAUTION

The use of optical instruments with this

product will increase eye hazard.

For the State of California, USA only

Perchlorate Material – special handling may

apply, See

www.dtsc.ca.gov/hazardouswaste/

perchlorate

WARNING: Do not ingest

battery, Chemical Burn Hazard.

The remote commander contains a

coin/button cell battery. If the coin/button

cell battery is swallowed, it can cause severe

internal burns in just 2 hours and can lead to

death.

Keep new and used batteries away from

children. If the battery compartment does

not close securely, stop using the product

and keep it away from children.

If you think batteries might have been

swallowed or placed inside any part of the

body, seek immediate medical attention.

Note on the lithium battery

Do not expose the battery to excessive heat

such as direct sunlight, fire or the like.

Disclaimer regarding services offered

by third parties

Services offered by third parties may be

changed, suspended, or terminated without

prior notice. Sony does not bear any

responsibility in these sorts of situations.

Warning if your car’s ignition has no

ACC position

Be sure to set the AUTO OFF function

(page 11). The unit will shut off completely

and automatically in the set time after the

unit is turned off, which prevents battery

drain. If you do not set the AUTO OFF

function, press and hold OFF until the

display disappears each time you turn the

ignition off.

4GB

Table of Contents

Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Guide to Parts and Controls. . . . . . . . . . . . . 5

Getting Started

Detaching the Front Panel . . . . . . . . . . . . . . 7

Resetting the Unit. . . . . . . . . . . . . . . . . . . . . 7

Setting the Clock. . . . . . . . . . . . . . . . . . . . . . 7

Connecting a USB Device. . . . . . . . . . . . . . . 8

Connecting Other Portable Audio

Device . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Listening to the Radio

Listening to the Radio . . . . . . . . . . . . . . . . . 8

Using Radio Data System (RDS). . . . . . . . . . 9

Playback

Playing a Disc . . . . . . . . . . . . . . . . . . . . . . . . 9

Playing a USB Device . . . . . . . . . . . . . . . . . . 9

Searching and Playing Tracks . . . . . . . . . . 10

Settings

Canceling the DEMO Mode . . . . . . . . . . . . . 11

Basic Setting Operation . . . . . . . . . . . . . . . . 11

General Setup (GENERAL) . . . . . . . . . . . . . . 11

Sound Setup (SOUND) . . . . . . . . . . . . . . . . 12

Display Setup (DISPLAY). . . . . . . . . . . . . . . 13

Additional Information

Updating the Firmware . . . . . . . . . . . . . . . 14

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . 14

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . 15

Specifications . . . . . . . . . . . . . . . . . . . . . . . 15

Troubleshooting . . . . . . . . . . . . . . . . . . . . . 17

Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Connection/Installation

Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Parts List for Installation . . . . . . . . . . . . . . . 21

Connection . . . . . . . . . . . . . . . . . . . . . . . . . 22

Installation . . . . . . . . . . . . . . . . . . . . . . . . . 24

5GB

Guide to Parts and Controls

Front panel release button

SRC (source)

Turn on the power.

Change the source.

OFF

Press and hold for 1 second to turn the

source off and display the clock.

Press and hold for more than 2 seconds

to turn off the power and the display.

If the unit is turned off and the display

disappears, operation by the remote

commander is not available.

Control dial

Rotate to adjust the volume.

PUSH ENTER

Enter the selected item.

Open the setup menu.

Disc slot

Display window

/ (SEEK–/+)

Tune in radio stations automatically.

Press and hold to tune manually.

/(prev/next)

/(fast-reverse/fast-forward)

(disc eject)

PTY (program type)

Select PTY in RDS.

(browse) (page 10)

Enter the browse mode during playback.

(Not available when a USB device in

Android™ mode is connected.)

EQ (equalizer)

Select an equalizer curve.

(back)

Return to the previous display.

MODE (page 8)

Receptor for the remote commander

Number buttons (1 to 6)

Receive stored radio stations. Press and

hold to store stations.

ALBUM /

Skip an album for audio device. Press and

hold to skip albums continuously.

(Not available when a USB device in

Android mode is connected.)

(repeat)

(Not available when a USB device in

Android mode is connected.)

(shuffle)

(Not available when a USB device in

Android mode is connected.)

(play/pause)

Main unit

6GB

EXTRA BASS

Reinforces bass sound in synchronization

with the volume level. Press to change

the EXTRA BASS setting: [1], [2], [OFF].

AUX input jack

DSPL (display)

Change display items.

SCRL (scroll)

Press and hold to scroll a display item.

USB port

The VOL (volume) + button has a tactile dot.

ATT (attenuate)

Attenuate the sound. Press again to

cancel the attenuation.

SOUND

Open the SOUND menu directly.

Press and hold to open the setup menu.

///

Select a setup item, etc.

ENTER

Enter the selected item.

/(prev/next)

+/– (album +/–)

VOL (volume) +/–

Remove the insulation film before use.

RM-X211 Remote commander

7GB

Detaching the Front Panel

You can detach the front panel of this unit to

prevent theft.

1Press and hold OFF until the unit

turns off, press the front panel

release button , then pull the panel

towards you to remove.

Caution alarm

If you turn the ignition switch to the OFF

position without detaching the front panel,

the caution alarm will sound for a few

seconds. The alarm will only sound if the

built-in amplifier is used.

Resetting the Unit

Before operating the unit for the first time,

or after replacing the car battery or

changing connections, you must reset the

unit.

1Press DSPL and (back)/MODE for

more than 2 seconds.

Note

Resetting the unit will erase the clock setting and

some stored contents.

Setting the Clock

1Press MENU, rotate the control dial to

select [GENERAL], then press it.

2Rotate the control dial to select [SET

CLOCK-ADJ], then press it.

The hour indication flashes.

3Rotate the control dial to set the hour

and minute.

To move the digital indication, press SEEK

+/–.

4After setting the minute, press MENU.

The setup is complete and the clock

starts.

To display the clock

Press DSPL.

Getting Started

Attaching the front panel

8GB

Connecting a USB Device

1Turn down the volume on the unit.

2Connect the USB device to the unit.

Connecting Other Portable

Audio Device

1Turn off the portable audio device.

2Turn down the volume on the unit.

3Connect the portable audio device to

the AUX input jack (stereo mini jack)

on the unit with a connecting cord

(not supplied)*.

* Be sure to use a straight type plug.

4Press SRC to select [AUX].

To match the volume level of the

connected device to other sources

Start playback of the portable audio device

at a moderate volume, and set your usual

listening volume on the unit.

Press MENU, then select [SOUND] [SET AUX

VOL] (page 13).

Listening to the Radio

To listen to the radio, press SRC to select

[TUNER].

1Press MODE to change the band (FM1,

FM2, FM3, AM1 or AM2).

2Press MENU, rotate the control dial to

select [GENERAL], then press it.

3Rotate the control dial to select [SET

BTM], then press it.

The unit stores stations in order of

frequency on the number buttons.

1Press MODE to change the band (FM1,

FM2, FM3, AM1 or AM2).

2Perform tuning.

To tune manually

Press and hold SEEK +/– to locate the

approximate frequency, then press SEEK

+/– repeatedly to fine adjust to the

desired frequency.

To tune automatically

Press SEEK +/–.

Scanning stops when the unit receives a

station.

1While receiving the station that you

want to store, press and hold a

number button (1 to 6) until [MEM]

appears.

1Select the band, then press a number

button (1 to 6).

Listening to the Radio

Storing automatically (BTM)

Tuning

Storing manually

Receiving the stored stations

9GB

Using Radio Data System

(RDS)

1Press PTY during FM reception.

2Rotate the control dial until the

desired program type appears, then

press it.

The unit starts to search for a station

broadcasting the selected program type.

Type of programs

The CT data from the RDS transmission sets

the clock.

1Set [SET CT-ON] in [GENERAL]

(page 12).

Playing a Disc

1Insert the disc (label side up).

Playback starts automatically.

Playing a USB Device

AOA (Android Open Accessory) 2.0, MSC

(Mass Storage Class) and MTP (Media

Transfer Protocol) type USB devices*

compliant with the USB standard can be

used. Depending on the USB device, the

Android mode or MSC/MTP mode can be

selected on the unit.

Some digital media players or Android

smartphones may require setting to MTP

mode.

* e.g., a USB flash drive, digital media player,

Android smartphone

Notes

• For details on the compatibility of your USB device,

visit the support site on the back cover.

• Smartphones with Android OS 4.1 or higher

installed support Android Open Accessory 2.0

(AOA 2.0). However, some smartphones may not

fully support AOA 2.0 even if Android OS 4.1 or

higher is installed.

For details on the compatibility of your Android

smartphone, visit the support site on the back

cover.

• Playback of the following files is not supported.

MP3/WMA/FLAC:

– copyright-protected files

– DRM (Digital Rights Management) files

– Multi-channel audio files

MP3/WMA:

– lossless compression files

Selecting program types (PTY)

NEWS (News), INFORM (Information), SPORTS

(Sports), TALK (Talk), ROCK (Rock), CLS ROCK

(Classic Rock), ADLT HIT (Adult Hits), SOFT RCK

(Soft Rock), TOP 40 (Top 40), COUNTRY

(Country), OLDIES (Oldies), SOFT (Soft),

NOSTALGA (Nostalgia), JAZZ (Jazz), CLASSICL

(Classical), R & B (Rhythm and Blues), SOFT R&B

(Soft Rhythm and Blues), LANGUAGE (Foreign

Language), REL MUSC (Religious Music), REL

TALK (Religious Talk), PERSNLTY (Personality),

PUBLIC (Public), COLLEGE (College), HABL ESP

(Spanish Talk), MUSC ESP (Spanish Music), HIP

HOP (Hip-Hop), WEATHER (Weather)

Setting clock time (CT)

Playback

10GB

Before making a connection, select the USB

mode (Android mode or MSC/MTP mode)

depending on the USB device (page 12).

1Connect a USB device to the USB port

(page 8).

Playback starts.

If a device is already connected, to start

playback, press SRC to select [USB].

2Adjust the volume on this unit.

To stop playback

Press and hold OFF for 1 second.

To remove the device

Stop playback, then remove the device.

Searching and Playing

Tracks

Not available when a USB device in Android

mode is connected.

1During playback, press (repeat) or

(shuffle) repeatedly to select the

desired play mode.

Playback in the selected play mode may

take time to start.

Available play modes differ depending on

the selected sound source.

Not available when a USB device in Android

mode is connected.

1During CD or USB playback, press

(browse)*to display the list of search

categories.

When the track list appears, press

(back) repeatedly to display the desired

search category.

* During USB playback, press (browse) for

more than 2 seconds to directly return to the

beginning of the category list.

2Rotate the control dial to select the

desired search category, then press it

to confirm.

3Repeat step 2 to search the desired

track.

Playback starts.

To exit the Quick-BrowZer mode

Press (browse).

Not available when a USB device in Android

mode is connected.

1Press (browse).

2Press SEEK +.

3Rotate the control dial to select the

item.

The list is jumped in steps of 10 % of the

total number of items.

4Press ENTER to return to the Quick-

BrowZer mode.

The selected item appears.

5Rotate the control dial to select the

desired item, then press it.

Playback starts.

Repeat play and shuffle play

Searching a track by name (Quick-

BrowZer™)

Searching by skipping items

(Jump mode)

Otros manuales para CDX-G1200U

Tabla de contenidos

Otros manuales de Reproductor de CD de Sony

Sony

Sony WALKMAN MZ-NF520 Manual de usuario

Sony

Sony CFD-S22 - Cd Radio Cassette-corder Manual de usuario

Sony

Sony CDP-C301M Manual de usuario

Sony

Sony CDP-CX230 - Compact Disc Changer Manual de usuario

Sony

Sony CFD-980 Operating Instructions (English,... Manual de usuario

Sony

Sony MXD-D4 Manual de usuario

Sony

Sony CDX-V4800 Manual de usuario

Sony

Sony DVP-CX995V Operating Instructions (DVP-CX995V CD/DVD... Manual de usuario

Sony

Sony CDP-CX230 - Compact Disc Changer Manual de usuario

Sony

Sony CDX-GT615UV Manual de usuario

Sony

Sony CDX-424RF - Compact Disc Changer System Guía del producto

Sony

Sony CFD-E95L Manual de usuario

Sony

Sony MZ-E80 Manual de usuario

Sony

Sony CDX-705 - Compact Disc Changer System Manual de usuario

Sony

Sony CDP-CE375 Manual de usuario

Sony

Sony CDP-C425 Manual de usuario

Sony

Sony SCD-XA1200ES Manual de usuario

Sony

Sony DVP-FX850 Manual de usuario

Sony

Sony D-CS901 - Portable Cd Player Manual de usuario

Sony

Sony MZ-N707 OpenMG Jukebox NOTES on installing &... Manual de usuario

Sony

Sony DVP-FX810 Manual de usuario

Sony

Sony D-835K Manual de usuario

Sony

Sony DVP-NS92V Manual de usuario

Sony

Sony D-V55 Manual de usuario

Manuales populares de Reproductor de CD de otras marcas

RCA

RCA RP-7923 Manual de usuario

Pioneer

Pioneer DEH-P3550MP XM Manual de usuario

Philips

Philips AZ1207 Manual de usuario

Philips

Philips CD582 Manual de usuario

Philips

Philips AZ 6821 Manual de usuario

Lasonic

Lasonic MSU-2020 Manual de usuario

THOMSON

THOMSON RCD150 Manual de usuario

Denon

Denon DCD-1420 Manual de usuario

Panasonic

Panasonic SJ-MR100 Manual de usuario

Onkyo

Onkyo DX-7210 Manual de usuario

Denon

Denon DVM-4800 Manual de usuario

JBL

JBL MR-32 Manual de usuario

RCA

RCA RCD152 Manual de usuario

Technics

Technics SL-PS770A Manual de usuario

Clarion

Clarion compact disc Manual de usuario

Philips

Philips Expanium AZ 1538 Manual de usuario

Rotel

Rotel RCD 975 Manual de usuario

Pioneer

Pioneer CLD-D790 Manual de usuario
