Sony CDP-CE335 - Compact Disc Changer Manual de usuario

3-865-901-11 (1)

1999 by Sony Corporation

Operating Instructions

CDP-CE335

CDP-CE235

CDP-C591

Compact Disc

Player

WARNING

To prevent fire or shock

hazard, do not expose

the unit to rain or

moisture.

To avoid electrical shock,

do not open the cabinet.

Refer servicing to

qualified personnel only.

For the customers in the United States

INFORMATION

This equipment has been tested and

found to comply with the limits for a

Class B digital device, pursuant to Part

15 of the FCC Rules. These limits are

designed to provide reasonable

protection against harmful interference

in a residential installation. This

equipment generates, uses, and can

radiate radio frequency energy and, if

not installed and used in accordance

with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that

interference will not occur in a particular

installation. If this equipment does cause

harmful interference to radio or

television reception, which can be

determined by turning the equipment off

and on, the user is encouraged to try to

correct the interference by one or more of

the following measures:

– Reorient or relocate the receiving

antenna.

– Increase the separation between the

equipment and receiver.

– Connect the equipment into an outlet

on a circuit different from that to

which the receiver is connected.

– Consult the dealer or an experienced

radio/TV technician for help.

CAUTION

You are cautioned that any changes or

modification not expressly approved in

this manual could void your authority to

operate this equipment.

Owner’s Record

The model and serial numbers are

located at the rear of the unit.

Record the serial number in the space

provided below. Refer to them whenever

you call upon your Sony dealer

regarding this product.

Model No. _________________________

Serial No. _________________________

This symbol is intended to alert

the user to the presence of

uninsulated “dangerous voltage”

within the product’s enclosure

that may be of sufficient

magnitude to constitute a risk of

electric shock to persons.

This symbol is intended to alert

the user to the presence of

important operating and

maintenance (servicing)

instructions in the literature

accompanying the appliance.

Getting Started

TABLE OF CONTENTS

Welcome!

Thank you for purchasing the Sony

Compact Disc Player. Before operating

the unit, please read this manual

thoroughly and retain it for future

reference.

About This Manual

The instructions in this manual are for

models CDP-CE335, CDP-CE235 and

CDP-C591. The CDP-CE335 is the model

used for illustration purposes, unless

otherwise mentioned. Any difference in

operation is clearly indicated in the text,

for example, “CDP-CE335 only.”

Conventions

• Instructions in this manual describe

the controls on the player.

You can also use the controls on the

remote if they have the same or

similar names as those on the player.

• The following icons are used in this

manual:

Indicates that you can do the

task using the remote.

(Note that the CDP-CE235 and

CDP-C591 cannot do the tasks

marked with this icon.)

Indicates hints and tips for

making the task easier.

Getting Started

Unpacking........................................................................................................ 4

Hooking Up the System................................................................................. 4

Playing a CD........................................................................................................ 6

Playing CDs

Using the Display ........................................................................................... 8

Replacing Discs While Playing a Disc ......................................................... 9

Locating a Specific Disc ................................................................................. 9

Locating a Specific Track or a Particular Point in a Track ......................10

Playing Repeatedly.......................................................................................11

Playing in Random Order (Shuffle Play) ..................................................11

Creating Your Own Program (Program Play)..........................................12

Recording From CDs

Recording Your Own Program...................................................................14

Recording a CD by Specifying Tape Length (Time Edit)........................14

Fading In or Out............................................................................................15

Adjusting the Recording Level (Peak Search) ..........................................16

Additional Information

Precautions ....................................................................................................17

Notes on CDs.................................................................................................17

Troubleshooting ............................................................................................18

Specifications .................................................................................................18

Index

Index ...............................................................................................................19

Getting Started

Unpacking

Check that you received the following items:

• Audio connecting cord (1)

• Remote commander (remote) (1) (CDP-CE335 only)

• R6 (size AA) batteries (2) (CDP-CE335 only)

Inserting batteries into the remote (CDP-

CE335 only)

You can control the player using the supplied remote.

Insert two R6 (size AA) batteries by matching the +

and – on the batteries. When using the remote, point it

at the remote sensor gon the player.

Hooking Up the System

Overview

This section describes how to hook up the CD player to

an amplifier. Be sure to turn off the power of each

component before making the connections.

CD player

Amplifier

: Signal flow

White

(L)

Red

(R)

White

(L)

Red

(R)

What cords will I need?

Audio cord (supplied) (1)

Line output

(L)

Line output

(R)

Audio input

(L) Audio input

(R)

To an AC outlet

When to replace batteries

With normal use, the batteries should last for about six

months. When the remote no longer operates the player,

replace all the batteries with new ones.

Notes

• Do not leave the remote near an extremely hot or humid

place.

• Do not drop any foreign object into the remote casing,

particularly when replacing the batteries.

• Do not expose the remote sensor to direct sunlight or

lighting apparatuses. Doing so may cause a malfunction.

• If you don’t use the remote for an extended period of time,

remove the batteries to avoid possible damage from battery

leakage and corrosion.

Getting Started

Hookups

When connecting an audio cord, be sure to match the

color-coded cord to the appropriate jacks on the

components: Red (right) to Red and White (left) to

White. Be sure to make connections firmly to avoid

hum and noise.

Amplifier

CD player

You can adjust the output level to the amplifier (CDP-

CE335 only)

Press LINE OUT LEVEL +/– on the remote. You can

reduce the output level up to –20 dB.

When you reduce the output level, “ATT.” appears in the

display.

When you turn off the player, the output level

automatically returns to the maximum level.

Note

If you press the LINE OUT LEVEL +/– buttons on the

remote while recording, the recording level will change

even when it is preset on the tape deck, etc.

• If you have a digital component such as a digital

amplifier, D/A converter, DAT or MD

Connect the component via the DIGITAL OUT (OPTICAL)

connector using the optical cable (not supplied). Take off

the cap and plug in the optical cable.

Note that you cannot use fading in or out (page 15) and

Time Fade (page 15) functions when making this

connection.

Connecting the AC power cord

Connect the AC power cord to a wall outlet.

Transporting the player

Before transporting the player, follow the procedure

below to return the internal mechanisms back to their

original position.

1 Remove all the discs from the disc tray.

2 Press §OPEN/CLOSE to close the disc tray.

“no dISC” appears in the display.

3 Wait for 10 seconds, then press 1/u (Power) to

turn off the player.

POC-15

Optical cable (not supplied)

Note

When you connect via the DIGITAL OUT (OPTICAL)

connector, noise may occur when you play CD software other

than music, such as a CD-ROM.

Digital component

INPUT

LINE

OUT

DIGITAL

OUT

OPTICAL

DIGITAL

INPUT

OPTICAL

CD player

Setting the voltage selector (voltage

selector equipped models only)

Check that the voltage selector on the rear panel of the

player is set to the local power line voltage. If not, set

the selector to the correct position using a screwdriver

before connecting the AC power cord to a wall outlet.

220 - 240 V 110 - 120 V

Basic Operations

Playing a CD

With the label side up Disc number

•See pages 4 – 5 for the hookup

information.

The player plays

All discs in the player consecutively in the order of

disc number

Only the disc you’ve selected

3465

Turn on the amplifier and select the CD player position so that

you can listen to the sound from this player.

Press 1/u (Power) to turn on the player.

Press §OPEN/CLOSE, and place a disc on the disc tray.

To place other discs, press DISC SKIP and place the discs in the

order you want to play.

Each time you press the button, the disc tray turns and you can

place the discs in the empty disc compartments. The player

plays the disc in front of you first.

Press CONTINUE to select ALL DISCS or 1 DISC Continuous

Play mode.

Each time you press the CONTINUE button, “ALL DISCS” or

“1 DISC” appears in the display.

When you select

ALL DISCS

1 DISC

REPEAT

DISC 1 DISC 2 DISC 3 DISC 4 DISC 5

OPEN/CLOSE

DISC

SKIP

CHANGE

AMS

TIME

FADER

MUSIC SCAN

CLEARCHECK

DISC CHECK

PUSH ENTER

CONTINUE SHUFFLE PROGRAM

TIME FADE

EDIT/ SEARCH

PEAK

Basic Operations

6Press ·.

The disc tray closes and the player plays all the tracks once

(Continuous Play). Adjust the volume on the amplifier.

You can select the disc you

want to start playing first

Press one of the DISC 1 – 5

buttons.

You can adjust the output

level to the amplifier (CDP-

CE335 only)

Press LINE OUT LEVEL +/–

on the remote. You can

reduce the output level up to

–20 dB.

When you reduce the output

level, “ATT.” appears in the

display.

When you turn off the

player, the output level

automatically returns to the

maximum level.

Note

If you press the LINE OUT

LEVEL +/– buttons on the

remote while recording, the

recording level will change

even when it is preset on the

tape deck, etc.

To stop playback

Press p.

Pause

Resume play after pause

Go to the next track

Go back to the preceding track

Go to the next disc

Select a disc directly

Stop play and remove the CD

You need to

Press P

Press Por ·

Turn ≠AMS ±clockwise

Turn ≠AMS ±counterclockwise

Press DISC SKIP

Press DISC 1 – 5

Press §OPEN/CLOSE

DISC 1 – 5 ·PpDISC SKIP

§OPEN/CLOSE

≠AMS ±

CONTINUE SHUFFLE PROGRAM REPEAT

DISC 1 DISC 2 DISC 3 DISC 4 DISC 5

OPEN/CLOSE

DISC

SKIP

CHANGE

AMS

TIME

FADER

MUSIC SCAN

CLEARCHECK

DISC CHECK

PUSH ENTER

TIME FADE

EDIT/ SEARCH

PEAK

Playing CDs

Using the Display

You can check information about the disc using the

display.

Playing CDs

Display information while playing a disc

While playing a disc, the display shows the current

disc number, track number, playing time of the track

and the music calendar.

Current disc number

Music calendar

Current track number

Playing time

The track numbers in the music calendar disappear

after they are played.

Checking the remaining time

Each time you press the TIME button while playing a

disc, the display changes as shown in the chart below.

12345

678910

1 2 3 4 5

DISCSALL

DISC

TRACK

MIN

SEC

1 1

156

Playing time and

number of the

current track

Press TIME.

Remaining time

on the current

track

If the track number exceeds 24,

“––.––”appears instead of the

remaining time.

Press TIME.

Remaining time

on the disc

This information is available only in

Continuous Play mode.

Press TIME.

TIME

Checking the total number and playing

time of the tracks

Press TIME before you start playing.

The display shows the current disc number, the total

number of tracks, total playing time and music

calendar.

The information also appears when you press the

§OPEN/CLOSE button to close the disc tray.

The tracks numbered over 20 cannot be displayed in

the music calendar.

Notes on the disc number indications

• The red circle around a disc number indicates the disc is

ready to be played.

• When all the tracks on a disc have been played, the semi-

circle around the disc number disappears.

• When a disc compartment is recognized as empty, the semi-

circled disc number disappears.

12345

678910

1 2 3 4 5

DISCSALL

DISC

TRACK

MIN

SEC

1 10

45 28

Total number of tracks Music calendar

Total playing timeCurrent disc number

12345

678910

1 2 3 4 5

DISCSALL

DISC

TRACK

MIN

SEC

1 1 156

12345

678910

1 2 3 4 5

DISCSALL

DISC

TRACK

MIN

SEC

1 1 157-

12345

678910

1 2 3 4 5

DISCSALL

DISC

TRACK

MIN

SEC

1 43 32-

Playing CDsPlaying CDs

DISC SKIP

1Press EX-CHANGE.

The disc tray opens and two disc compartments

appear. Even if the player is playing a disc, it

doesn’t stop playing.

2Replace discs in the compartments with new ones.

The player plays the disc on the left side

compartment after the current disc, and then the

one on the right side compartment.

3Press DISC SKIP.

The disc tray turns and other two disc

compartments appear.

4Replace discs in the compartments with new ones.

5Press EX-CHANGE.

The disc tray closes.

While the disc tray is open by pressing the EX-CHANGE

button

• If the playback of the current disc ends, the player stops

playing. If the disc is played in 1 DISC Repeat Play mode

(see page 11), the current disc starts playing again.

• In ALL DISCS Shuffle Play mode (see page 11), tracks are

reshuffled on the current disc.

• In Program Play mode (see page 12), only the tracks on the

current disc are played.

• Do not push the disc tray to close it in Step 5, as you may

damage the player.

Replacing Discs While Playing

a Disc

You can open the disc tray while playing a disc so that

you can check what discs are to be played next and

replace discs without interrupting playback of the

current disc.

To locate

The next disc

A specific disc directly

A disc while checking the

labels

A disc by scanning the first

track of each disc for 10

seconds

You can extend the playing time during scanning the

discs

Press DISC CHECK repeatedly until the playing time

you want (10, 20 or 30) appears in the display. Each time

you press the button, the playing time changes cyclically.

Notes

• When you press the DISC CHECK button, the play mode

automatically changes to ALL DISCS Continuous Play

mode.

• When you’ve opened the disc tray by pressing the

EX-CHANGE button, you cannot use the DISC CHECK

function.

• Even if you press the DISC CHECK button while

“REPEAT” appears in the display (see page 11), the player

stops after scanning all the discs once.

Press

DISC SKIP while playing a disc

DISC 1 – 5

DISC CHECK while the disc

tray is open. The disc tray turns

to show you each disc label.

When the disc you want comes

in front of you, press ·to

start playing.

DISC CHECK before you start

playing while the disc tray is

closed. When you find the disc

you want, press ·to start

playing.

EX-CHANGE

DISC 1 – 5 DISC CHECK ·DISC SKIP

Locating a Specific Disc

You can locate any disc before or while playing a disc.

Playing CDs

Locating a Specific Track or a

Particular Point in a Track

You can quickly locate any track while playing a disc

using the AMS (Automatic Music Sensor) control or

number buttons on the remote. You can also locate a

specific point in a track while playing a disc.

When you directly locate a track numbered over 10

(CDP-CE335 only) Z

Press >10 first, then the corresponding number buttons

on the remote. To enter “0,” use button 10/0.

Example: To play track number 30

Press >10 first, then 3 and 10/0.

You can extend the playing time during Music Scan

Press MUSIC SCAN repeatedly until the playing time

you want (10, 20 or 30) appears in the display. Each time

you press the button, the playing time changes cyclically.

Note

If “ ” appears in the display, the disc has reached the end

while you were pressing the )button. Press 0or turn

≠AMS ±counterclockwise to go back.

≠AMS ±

MUSIC SCAN

0/)

(CDP-CE335 only)

=/+

0/)

>10

To locate

The next or

succeeding tracks

The current or

preceding tracks

A specific track

directly (CDP-

CE335 only) Z

A track by scanning

each track for 10

seconds

(Music Scan)

A point while

monitoring the sound

A point quickly by

observing the display

during pause

You need to

Turn ≠AMS ±clockwise until

you find the track. When using the

remote, press +repeatedly until you

find the track.

Turn ≠AMS ±counterclockwise

until you find the track. When using

the remote, press =repeatedly until

you find the track.

Press the number button of the track

on the remote

Press MUSIC SCAN before you start

playing. When you find the track you

want, press ·to start playing.

Press )(forward) or 0(backward)

and hold down until you find the

point

Press )(forward) or 0(backward)

and hold down until you find the

point. You will not hear the sound

during the operation.

Number buttons

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Reproductor de CD de Sony

Sony

Sony CDP-CX681 - 200 Disc Cd Changer Manual de usuario

Sony

Sony CDX-G3150UV Manual de usuario

Sony

Sony CFD-CD777S MK2 Manual de usuario

Sony

Sony CDX91 Manual de usuario

Sony

Sony DVP-CX995V Operating Instructions (DVP-CX995V CD/DVD... Manual de usuario

Sony

Sony CFDF17CP Manual de usuario

Sony

Sony CFD G505 - Xplod Boombox Manual de usuario

Sony

Sony CDX-705 - Compact Disc Changer System Manual de usuario

Sony

Sony CDX-L490EE Manual de usuario

Sony

Sony CDX-626 Manual de usuario

Sony

Sony CDP-CE375 Manual de usuario

Sony

Sony Walkman D-E340 Manual de usuario

Sony

Sony CDX-GT454US Manual de usuario

Sony

Sony D-NE1 - Portable Cd Player Manual de usuario

Sony

Sony CDX-2500R Manual de instrucciones

Sony

Sony CDP-XE270 - Compact Disc Player Manual de usuario

Sony

Sony CDX-M620 - Fm/am Compact Disc Player Manual de usuario

Sony

Sony CFD-503 Manual de usuario

Sony

Sony Walkman D-EJ250 Manual de usuario

Sony

Sony D-E505 Manual de usuario

Sony

Sony D-E330 - Portable Cd Player Manual de usuario

Sony

Sony CDX-M800 Manual de usuario

Sony

Sony CFD-S20CP - Cd Radio Cassette-corder Manual de usuario

Sony

Sony CFD-V17 - Cd Radio Cassette-corder Manual de usuario

Manuales populares de Reproductor de CD de otras marcas

RCA

RCA RP-7923 Manual de usuario

Pioneer

Pioneer DEH-P3550MP XM Manual de usuario

Philips

Philips AZ1207 Manual de usuario

Philips

Philips CD582 Manual de usuario

Philips

Philips AZ 6821 Manual de usuario

Lasonic

Lasonic MSU-2020 Manual de usuario

THOMSON

THOMSON RCD150 Manual de usuario

Denon

Denon DCD-1420 Manual de usuario

Panasonic

Panasonic SJ-MR100 Manual de usuario

Onkyo

Onkyo DX-7210 Manual de usuario

Denon

Denon DVM-4800 Manual de usuario

JBL

JBL MR-32 Manual de usuario

RCA

RCA RCD152 Manual de usuario

Technics

Technics SL-PS770A Manual de usuario

Clarion

Clarion compact disc Manual de usuario

Philips

Philips Expanium AZ 1538 Manual de usuario

Rotel

Rotel RCD 975 Manual de usuario

Pioneer

Pioneer CLD-D790 Manual de usuario
