Sony XDP-PK1000 Manual de usuario

4-291-715-12(1)

XDP-PK1000

Digital Link

Sound System

Owner’s Record

The model and serial numbers are located on the bottoms of the DSP

master unit and amplifier.

Record these numbers in the spaces provided below.

Refer to these numbers whenever you call upon your Sony dealer

regarding this product.

Model No.

Serial No.

Operating Instructions US

Manual de instrucciones ES

Warning

This equipment has been tested and found

to comply with the limits for a Class B

digital device, pursuant to Part 15 of the

FCC Rules.

These limits are designed to provide

reasonable protection against harmful

interference in a residential installation.

This equipment generates, uses, and can

radiate radio frequency energy and, if not

installed and used in accordance with the

instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that

interference will not occur in a particular

installation. If this equipment does cause

harmful interference to radio or television

reception, which can be determined by

turning the equipment off and on, the user

is encouraged to try to correct the

interference by one or more of the

following measures:

– Reorient or relocate the receiving

antenna.

– Increase the separation between the

equipment and receiver.

– Connect the equipment into an outlet on

a circuit different from that to which the

receiver is connected.

– Consult the dealer or an experienced

radio/TV technician for help.

You are cautioned that any changes or

modifications not expressly approved in

this manual could void your authority to

operate this equipment.

For the State of California, USA only

Perchlorate Material – special handling

may apply, See

www.dtsc.ca.gov/hazardouswaste/perchlorate

Perchlorate Material: Lithium battery

contains perchlorate

iPhone®, iPod®, iPod classic®,

iPod nano®, and iPod touch®are

trademarks of Apple Inc., registered in the

U.S. and other countries.

Warning if your car’s ignition has no

ACC position

To prevent battery drain, turn off the

system after use by pressing and holding

the SOURCE/OFF button on the remote

commander/cradle more than two

seconds. The LED indicators on the DSP

master unit and cradle turn off when the

system is off.

Note on the lithium battery

Do not expose the battery to excessive heat

such as direct sunlight, fire or the like.

Table of contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Resetting the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

The System Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

DSP master unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

RM-X251 Card remote commander . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Subwoofer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Sound Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Optimized sound setting based on your vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Setting the sound balance based on your listening preference . . . . . . . . . . . . . . . . . .11

Setting up the Cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Before Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Arranging the cradle cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Attaching an iPod/iPhone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Setting up the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Enjoying an iPod/iPhone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Playing from a car audio unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Introduction

Thank you for purchasing the Digital Link Sound System (XDP-PK1000).

This system allows you to digitally integrate an iPod/iPhone into your existing car audio unit.

You can enjoy exciting sound from your car audio unit and iPod/iPhone via this system, which

features sound settings optimized for your vehicle type by using Sony’s original digital sound

technology, and powerful bass delivered by the supplied subwoofer and amplifier.

The DSP master unit makes a natural “front sound field” possible, so that you can feel bass as

though it comes from directly in front of the driver’s seat even though the subwoofer is located

at the rear of your car, e.g., in a cargo area.

There is also a digital connection for an iPod/iPhone so that you can enjoy high quality sound

in your car without noise/distortion.

Enjoy the new sound experience with this Digital Link Sound System.

Getting Started

Resetting the unit

Before operating the system for the first time, or after replacing the car battery or changing

connections, you should reset the system (page 5).

Press the RESET button of the DSP master unit.

The System Components

This section contains explanations on the location of controls and their basic operations.

DSP master unit

Sound setting switches page 10

Set each switch according to your car

type/interior.

SOURCE indicator

You can check the status of the DSP

master unit.

INPUT SELECT switch

Select either 2-channel or 4-channel

sound from the car audio unit. Select

“2ch” if you connect only the front car

speakers to the DSP master unit, with

High Level Input connection.

RESET

Press to reset the DSP master unit

settings.

Note

• Avoid touching the top of the DSP master unit

during use, as it becomes hot over time.

23 41

Indicator Status

Turns blue. A car audio unit is selected as

the source.

Turns red. An iPod/iPhone is selected as

the source.

Flashes blue. Diagnostic error. See

“Troubleshooting” (page 22).

Flashes red. Overload error when an

iPod/iPhone is selected as the

source. See

“Troubleshooting” (page 22).

Flashes blue

and red

alternately.

Temperature detection is

working. See

“Troubleshooting” (page 22).

Cradle

Suction cup

SEEK /buttons*1*2

Press to skip tracks.

Remote sensor

Indicator

You can check the status of the DSP

master unit.

VOLUME (VOL) +/–*2

SOURCE/OFF button

Press to turn on the power/change the

source between a car audio unit and an

iPod/iPhone.

Press and hold more than two seconds

to turn off the system. The indicator

() turns off.

Port for the cradle cable

Used for connecting the cradle cable.

Cover for the suction cup

PUSH RELEASE button

Push to stretch the arm.

LOCK/RELEASE lever

Turn to lock/release the suction cup.

PUSH button

Press hard to secure the cradle on the

dashboard.

Tab

Pull up to remove the cradle from the

dashboard.

*1 has a tactile dot.

*2 These buttons work only when an iPod/

iPhone is selected as the source and the music

player on an iPod/iPhone is activated.

Indicator Status

Turns blue. A car audio unit is selected as

the source.

Turns red. An iPod/iPhone is selected as

the source.

Flashes blue. Diagnostic error. See

“Troubleshooting” (page 22).

Flashes red. Overload error when an

iPod/iPhone is selected as the

source. See

“Troubleshooting” (page 22).

Flashes blue

and red

alternately.

Temperature detection is

working. See

“Troubleshooting” (page 22).

RM-X251 Card remote

commander

Remove the insulation film before use.

SOURCE/OFF button

Press to turn off the power/change the

source between a car audio unit and an

iPod/iPhone.

Press and hold more than two seconds

to turn off the system. The indicators on

the DSP master unit and the cradle turn

off.

FAD/BAL (FRONT/CNT/REAR)

buttons page 11

Press to adjust the balance between the

speakers.

VOL +/– buttons*1

LEFT/RIGHT buttons page 11

Press to adjust the speaker balance.

Press and hold the CNT button () to

return to the default setting.

BASS (–/CNT/+) buttons page 11

Press to adjust the bass level.

ALO (Automatic Level Optimizer)

button*1page 11

Adjust the playback volume level of an

iPod/iPhone to the optimum level:

“ON,” “OFF.”

/buttons*1

Press to skip tracks.

TREBLE (–/CNT/+) buttons page 11

Press these buttons to adjust the treble

level.

SUB VOL +/– button*2page 11

Press to adjust the subwoofer volume.

*1 These buttons work only when an iPod/

iPhone is selected as the source and the music

player on an iPod/iPhone is activated.

*2 SUB VOL + has a tactile dot.

Note

• If the system is turned off and the indicators on

the cradle/DSP master unit are off, remote

commander operation is not possible. To

activate the system again, press the SOURCE/

OFF button on the cradle, and make sure that

the indicators on the cradle/DSP master unit

are lit.

Amplifier

POWER/PROTECTOR indicator

Lights up in green during operation.

If the PROTECTOR turns on, the

indicator will change from green to red.

If the PROTECTOR turns on, refer to

“Troubleshooting” (page 22).

Dynamic Distortion Suppressor

Conventional Amplifier

Rated Power

Output Signal

Max. Power

Output Signal

Rated Power

Output Signal

Max. Power

Output Signal

Activated

Distortion

Suppressed!

Now you can enjoy clear bass sound with less distortion.

Subwoofer

Sound Settings

Optimized sound setting

based on your vehicle

This system provides clear treble and

powerful bass optimized for the vehicle type

by setting the DSP master unit. 18 different

settings are available.

Warning

• Avoid touching the top of the DSP master unit

when setting the switches, as it becomes hot

during use.

Notes

• Set the sound of the car audio unit (BASS/

TREB/Loudness, etc.) to the flat position.

• Set the switches on the front panel of the DSP

master unit with your fingers. Do not use any

tools when setting these switches.

SW LOCATION switch

Select from one of three positions (FAR/

MID/NEAR) based on the distance between

the driver’s seat and where the subwoofer is.

TRUNK switch

Select “Y” (yes) or “N” (no) based on

whether the subwoofer is mounted in the

trunk.

If the subwoofer is mounted in the trunk,

select “Y.”

VEHICLE SIZE switch

Select from one of three sizes (L/M/S) based

on the air volume of your car.

See the following examples.

Compact hatchback

Middle sized sedan

Pickup Truck

Full sized SUV

SW LOCATION: MID

TRUNK: N

VEHICLE SIZE: S

SW LOCATION: MID

TRUNK: Y

VEHICLE SIZE: M

SW LOCATION: NEAR

TRUNK: N

VEHICLE SIZE: S

SW LOCATION: FAR

TRUNK: N

VEHICLE SIZE: L

Otros manuales para XDP-PK1000

Tabla de contenidos

Otros manuales de Receptor de coche de Sony

Sony

Sony XR-C5090/4790 Manual de usuario

Sony

Sony HCD-451 Manual de usuario

Sony

Sony CDX-L510X - Fm/am Compact Disc Player Manual de usuario

Sony

Sony GT120 - CDX Radio / CD Player Manual de usuario

Sony

Sony CDX-C860 - Fm/am Compact Disc Player Manual de usuario

Sony

Sony Sony Car Stereo System XR-M510 Manual de usuario

Sony

Sony XR-C900RDS Manual de usuario

Sony

Sony CDX-GT55IP Manual de usuario

Sony

Sony XR-4900 Manual de usuario

Sony

Sony CDX-L350 - Fm/am Compact Disc Player Manual de usuario

Sony

Sony XR-3750 Manual de usuario

Sony

Sony CDX-GT700HD - Fd 8g Usb 1wire Manual de instalación y operación

Sony

Sony XR-5800R Guía

Sony

Sony XPlod MEX-BT5000 Manual de usuario

Sony

Sony ST-JX44L Manual de usuario

Sony

Sony BluetoothH MEX-BT5100 Manual de usuario

Sony

Sony HCD-ECL5 Manual de usuario

Sony

Sony CDX-F5500 (XT-XM1) Manual de usuario

Sony

Sony XR-4880 Manual de usuario

Sony

Sony CDX-GT440U - Fm/am Compact Disc Player Manual de usuario

Sony

Sony CDX-C460 - Fm/am Compact Disc Player Manual de usuario

Sony

Sony CDX-GT424U Manual de usuario

Sony

Sony CDX-1150 - Compact Disc Player Manual de usuario

Sony

Sony XR-C5100 Guía de inicio rápido

Manuales populares de Receptor de coche de otras marcas

Motorola

Motorola VWA63 Manual de usuario

Nextar

Nextar D3201 Manual de usuario

Alpine

Alpine CDE-163BT Manual de usuario

Pioneer

Pioneer DEH-P645R Manual de usuario

Axxera

Axxera XDMA7600 Instrucciones de funcionamiento

XM OnyX Manual de usuario

Sound Storm

Sound Storm STM93R Manual de usuario

Soundstream

Soundstream VIR-5000 Manual de usuario

Avson

Avson MKT Platform Manual de usuario

Pioneer

Pioneer DVH-P500UB Manual de usuario

JVC

JVC KD-AHD69 Manual de usuario

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manual de usuario

XFIRE AUDIO

XFIRE AUDIO BMW42S Manual de usuario

VDO

VDO CD 2253 Manual de usuario

Volvo

Volvo 13 84 580 Manual de usuario

ZENEC

ZENEC ZE-160DVD Manual de usuario

Medion

Medion Car Audio Manual de usuario

Philips

Philips CEM5000 Manual de usuario
