Sony Model CDX-L280 Manual de usuario

3-227-649-51 (1)

2002 Sony Corporation

FM/AM

Compact Disc Player

Operating Instructions

Bedienungsanleitung

Mode d’emploi

Istruzioni per l’uso

Gebruiksaanwijzing

Wichtig!

Bitte nehmen Sie sich etwas Zeit, um den Geräte-Pass

vollständig auszufüllen. Dieser befindet sich auf der

hinteren Umschlagseite dieser Bedienungsanleitung.

Si dichiara che l’apparecchio è stato fabbricato in conformità all’art. 2, Comma 1 del

D.M. 28.08.1995 n. 548.

For installation and connections, see the supplied installation/connections

manual.

Zur Installation und zum Anschluss siehe die mitgelieferte Installations-/

Anschlussanleitung.

En ce qui concerne l’installation et les connexions, consulter le manuel

d’installation/connexions fourni.

Per l’installazione e i collegamenti, fare riferimento al manuale di istruzioni di

installazione/collegamenti in dotazione.

Zie voor het monteren en aansluiten van het apparaat de bijgeleverde handleiding

“Installatie en aansluitingen”.

CDX-L280

Welcome !

Thank you for purchasing this Sony Compact

Disc Player. You can enjoy its various features

even more with:

Optional controller accessory

Card remote commander RM-X114

This label is located on the bottom of the

chassis.

CAUTION INVISIBLE

DO NOT STARE INTO BEAM OR

VIEW DIRECTLY WITH OPTICAL INSTRUMENTS

LASER RADIATION WHEN OPEN

This label is located on the drive unit’s internal

chassis.

Table of Contents

Location of controls ............................................. 4

Precautions ............................................................ 6

Notes on discs ....................................................... 6

Getting Started

Resetting the unit ................................................. 7

Detaching the front panel ................................... 8

Setting the clock ................................................... 9

CD Player

Playing a disc ........................................................ 9

Display items ...................................................... 10

Playing tracks repeatedly

— Repeat Play ............................................... 10

Playing tracks in random order

— Shuffle Play ............................................... 10

Radio

Storing stations automatically

— Best Tuning Memory (BTM) ................... 11

Storing only the desired stations ..................... 11

Receiving the stored stations ............................ 12

Other Functions

Adjusting the sound characteristics ................ 13

Quickly attenuating the sound ........................ 13

Cancelling the beep sound ............................... 13

Selecting the sound position

— My Best sound Position (MBP) .............. 14

Boosting the bass sound

— D-bass ........................................................ 14

Additional Information

Maintenance ........................................................ 15

Removing the unit ............................................. 16

Specifications ...................................................... 17

Troubleshooting.................................................. 18

Error displays/Messages .................................. 19

qf Number buttons 13

(3) REP 10

(4) SHUF 10

11, 12

qg BTM (Best Tuning Memory) button 11

qh DSPL (display mode change) button

9, 10

qj OFF button*8, 9

qk SEEK/AMS +/– button

11, 12

*Warning when installing in a car

without an ACC (accessory) position

on the ignition key switch

Be sure to press (OFF) on the unit for

2 seconds to turn off the clock display

after turning off the engine.

Otherwise, the clock display does not turn

off and this causes battery drain.

Location of controls

1Volume +/– button 9, 13

2Receptor for the card remote

commander

3MODE button

11, 12

4SRC (SOURCE) (TUNER/CD) button

9, 11, 12

5SEL (select) button 9, 13, 14

6Display window

MBP (My Best sound Position) button

8D (D-BASS) button 14

9Z(eject) button 9

q; RELEASE (front panel release) button 8

qa RESET button (located on the front side of

the unit, behind the front panel) 7

qs ATT (attenuate) button 13

qd SENS button 12

CDX-L280

SEL

MODE

SRC SOURCE

RELEASE

1ATT

SENS

OFF

D-BASS

MBP

65432

BTM DSPL

REP SHUF

SEEK

AMS

Refer to the pages listed for details.

: During playback : During radio reception

CD RADIO

RADIO RADIO

RADIO

DISC

–

ATTOFF

DSPL MODE

SOURCE

DISC

VOL

–

PRESET

SEEK

–

PRESET –

SOUND

ENTER

LIST

The corresponding buttons of the card

remote commander control the same

functions as those on this unit.

1DSPL button

2MENU*button

3SOURCE button

4SEEK (</,) buttons

5SOUND button

(used as 5SEL button for this unit)

6OFF button

7VOL (+/–) buttons

MODE button

9LIST*button

q; DISC*/PRESET (M/m) buttons

qa ENTER*button

qs ATT button

*Not available for this model

Note

If the unit is turned off by pressing (OFF) for 2

seconds, it cannot be operated with the card

remote commander unless (SRC) on the unit is

pressed, or a disc is inserted to activate the unit

first.

Tip

Refer to “Replacing the lithium battery” for details

on how to replace the batteries (page 16).

Card remote commander RM-X114

(optional)

Precautions

•If your car was parked in direct sunlight,

allow the unit to cool off before operating it.

•Power aerials will extend automatically

while the unit is operating.

If you have any questions or problems

concerning your unit that are not covered in

this manual, please consult your nearest Sony

dealer.

Moisture condensation

On a rainy day or in a very damp area,

moisture condensation may occur inside the

lenses and display of the unit. Should this

occur, the unit will not operate properly. In

such a case, remove the disc and wait for about

an hour until the moisture has evaporated.

To maintain high sound quality

Be careful not to splash juice or other soft

drinks onto the unit or discs.

Notes on discs

•To keep the disc clean, do not touch the

surface. Handle the disc by its edge.

•Keep your discs in their cases or disc

magazines when not in use. Do not subject

the discs to heat/high temperature. Avoid

leaving them in parked cars or on

dashboards/rear trays.

•Do not attach labels, or use discs with sticky

ink/residue. Such discs may stop spinning

when used, causing a malfunction, or may

ruin the disc.

•Do not use any discs with labels or stickers

attached.

The following malfunctions may result from

using such discs:

—Inability to eject a disc (due to a label or

sticker peeling off and jamming the eject

mechanism).

—Inability to read audio data correctly (e.g.,

playback skipping, or no playback) due to

heat shrinking of a sticker or label causing

a disc to warp.

•Discs with non-standard shapes (e.g., heart,

square, star) cannot be played on this unit.

Attempting to do so may damage the unit.

Do not use such discs.

•You cannot play 8 cm CDs.

•Before playing, clean the discs with a

commercially available cleaning cloth. Wipe

each disc from the centre out. Do not use

solvents such as benzine, thinner,

commercially available cleaners, or antistatic

spray intended for analog discs.

Getting Started

Resetting the unit

Before operating the unit for the first time or

after replacing the car battery, you must reset

the unit.

Remove the front panel and press the RESET

button with a pointed object, such as a

ballpoint pen.

Note

Pressing the RESET button will erase the clock

setting and some stored contents.

RESET button

Notes on CD-R/CD-RW discs

•You can play CD-Rs (recordable CDs)/CD-

RWs (rewritable CDs) designed for audio use

on this unit.

Look for these marks to distinguish CD-Rs/

CD-RWs for audio use.

These marks denote that a disc is not for

audio use.

•Some CD-Rs/CD-RWs (depending on the

equipment used for its recording or the

condition of the disc) may not play on this

unit.

•You cannot play a CD-R/CD-RW that is not

finalized*.

*A process necessary for a recorded CD-R/CD-RW

disc to be played on the audio CD player.

Attaching the front panel

Attach part Aof the front panel to part Bof

the unit as illustrated and push the left side

into position until it clicks.

Note

Do not put anything on the inner surface of the

front panel.

Detaching the front panel

You can detach the front panel of this unit to

protect the unit from being stolen.

Caution alarm

If you turn the ignition switch to the OFF

position without removing the front panel, the

caution alarm will beep for a few seconds.

If you connect an optional amplifier and do not

use the built-in amplifier, the beep sound will

be deactivated.

1Press (OFF)*.

CD playback or radio reception stops (the

key illumination and display remain on).

*If your car has no ACC position on the

ignition switch, be sure to turn the unit off by

pressing (OFF) for 2 seconds to avoid car

battery drain.

2Press (RELEASE), then pull it off towards

you.

Notes

•If you detach the panel while the unit is still

turned on, the power will turn off automatically

to prevent the speakers from being damaged.

•Do not drop or put excessive pressure on the

front panel and its display window.

•Do not subject the front panel to heat/high

temperature or moisture. Avoid leaving it in

parked cars or on dashboards/rear trays.

Tip

When carrying the front panel with you, use the

supplied front panel case.

(OFF)

(RELEASE)

Setting the clock

The clock uses a 12-hour digital indication.

Example: To set the clock to 10:08

1Press (DSPL) for 2 seconds.

The hour indication flashes.

1Press either side of the volume +/–

button to set the hour.

2Press (SEL).

The minute indication flashes.

3Press either side of the volume +/–

button to set the minute.

2Press (DSPL).

The clock starts. After the clock setting is

completed, the display returns to normal

play mode.

CD Player

Playing a disc

Insert the disc (labelled side up).

Playback starts automatically.

If a disc is already inserted, press (SRC)

repeatedly until “CD” appears to start

playback.

To Press

Stop playback Zor (OFF)

Eject the disc Z

Skip tracks (SEEK/AMS) (./>)

– Automatic [once for each track]

Music Sensor

Fast-forward/ (SEEK/AMS) (m/M)

reverse [hold to desired point]

– Manual Search

Note

When the last track on the disc is over, playback

restarts from the first track of the disc.

Display items

When the disc/track changes, any prerecorded

title of the new disc/track is automatically

displayed.

To Press

Switch display (DSPL)

item

Source

Displayable items

•Clock

•Elapsed playing time

Track number

Playing tracks repeatedly

— Repeat Play

The current track will repeat itself when it

reaches the end.

During playback, press (3) (REP) until

“REP” indicator appears in the display.

Repeat Play starts.

To return to normal play mode, press (3)

(REP) again.

Playing tracks in random

order — Shuffle Play

You can select to play the tracks on the current

disc in random order.

During playback, press (4) (SHUF) until

“SHUF” indicator appears in the display.

Shuffle Play starts.

To return to normal play mode, press (4)

(SHUF) again.

Otros manuales para Model CDX-L280

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Receptor de coche de Sony

Sony

Sony MDX-C6500X Manual de usuario

Sony

Sony XAV-601BT Manual de usuario

Sony

Sony CDX-656 - Compact Disc Changer System Manual de usuario

Sony

Sony XR-CA300 - Fm-am Cassette Car Stereo Manual de usuario

Sony

Sony XR-3208MK2 Manual de usuario

Sony

Sony CDX GT330 - Radio / CD Manual de usuario

Sony

Sony XR-6859RDS Manual de usuario

Sony

Sony CDX-F7710 Operating Instructions (English Manual de usuario

Sony

Sony XR-CA360X Manual de usuario

Sony

Sony CDX-757MX - Compact Disc Changer System Manual de usuario

Sony

Sony XR-C5300RX Guía del producto

Sony

Sony CDX-C90R Manual de usuario

Sony

Sony CDX GT330 - Radio / CD Manual de usuario

Sony

Sony CDXGT320 - CDX Radio / CD Manual de usuario

Sony

Sony CDX-GT350MP - Fm/am Compact Disc Player Guía del producto

Sony

Sony XR-CA430X Manual de usuario

Sony

Sony XR-C503 Manual de usuario

Sony

Sony XR-CA300 - Fm-am Cassette Car Stereo Manual de usuario

Sony

Sony CDX-GT42IPW - Fm/am Compact Disc Player Manual de usuario

Sony

Sony XR-C8220R Manual de usuario

Sony

Sony CDX-F7500 Manual de usuario

Sony

Sony CDX-GT410U - Fm/am Compact Disk Player Guía del producto

Sony

Sony XR-CA610X Manual de usuario

Sony

Sony MEX-BT3800U - Bluetooth Audio System Guía del producto

Manuales populares de Receptor de coche de otras marcas

Motorola

Motorola VWA63 Manual de usuario

Nextar

Nextar D3201 Manual de usuario

Alpine

Alpine CDE-163BT Manual de usuario

Pioneer

Pioneer DEH-P645R Manual de usuario

Axxera

Axxera XDMA7600 Instrucciones de funcionamiento

XM OnyX Manual de usuario

Sound Storm

Sound Storm STM93R Manual de usuario

Soundstream

Soundstream VIR-5000 Manual de usuario

Avson

Avson MKT Platform Manual de usuario

Pioneer

Pioneer DVH-P500UB Manual de usuario

JVC

JVC KD-AHD69 Manual de usuario

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manual de usuario

XFIRE AUDIO

XFIRE AUDIO BMW42S Manual de usuario

VDO

VDO CD 2253 Manual de usuario

Volvo

Volvo 13 84 580 Manual de usuario

ZENEC

ZENEC ZE-160DVD Manual de usuario

Medion

Medion Car Audio Manual de usuario

Philips

Philips CEM5000 Manual de usuario
