Sony CFD-121 Manual de usuario

CFD-121.E.G_3-858-850-1X.CED.CEK.CEH.EE1.E12.E23.EA

3-858-850-11(1)

CD Radio

Cassette-Corder

1996 by Sony Corporation

Operating Instructions page 2EN

Bedienungsanleitung Seite 2DD

CFD-121

Introduction2EN

CFD-121.E.G_3-858-850-1X.CED.CEK.CEH.EE1.E12.E23.EA

Warning

To prevent fire or shock hazard, do

not expose the player to rain or

moisture.

To avoid electrical shock, do not open

the cabinet. Refer servicing to

qualified personnel only.

Information

For customers in Europe and Saudi Arabia

This Compact Disc player is classified as a

CLASS 1 LASER product.

The CLASS 1 LASER PRODUCT label is

located on the side.

Notice for customers in the United

Kingdom

A moulded plug complying with BS 1363 is

fitted to this equipment for your safety and

convenience.

Should the fuse in the plug supplied need to

be replaced, same rating fuse approved by

ASTA or BSI to BS 1362, (i.e. marked with

or mark) must be used.

If the plug supplied with this equipment has

a detachable fuse cover, be sure to attach the

fuse cover after you change the fuse. Never

use the plug without the fuse cover. If you

should lose the fuse cover, please contact

your nearest Sony service station.

3EN

Introduction

Basic Operations

CFD-121.E.G_3-858-850-1X.CED.CEK.CEH.EE1.E12.E23.EA

Table of contents

Basic Operations

4Playing a CD

6Listening to the radio

8Playing a tape

10 Recording on a tape

The CD Player

12 Using the display

13 Locating a specific point in a

track

14 Playing tracks repeatedly

(Repeat Play)

15 Creating your own program

(Program Play)

Setting Up

16 Choosing the power sources

17 Adjusting the sound emphasis

(TONE/MEGA BASS)

Additional Information

18 Precautions

20 Troubleshooting

22 Maintenance

23 Specifications

24 Index

Basic Operations4EN

CFD-121.E.G_3-858-850-1X.CED.CEK.CEH.EE1.E12.E23.EA

Playing a CD

Basic Operations

Connect the supplied AC power cord (see page 16).

1Set FUNCTION to CD.

2Press OPEN/CLOSE down to

open the CD compartment and

place a CD on the CD

compartment.

3Close the CD compartment.

2,3

With the label side up

Basic Operations

5EN

CFD-121.E.G_3-858-850-1X.CED.CEK.CEH.EE1.E12.E23.EA

Display

Use these buttons for additional operations

To Do this

Adjust the volume Turn VOLUME.

Stop playback Press p.

Pause playback Press ^.

Press again to resume play

after pause.

Go to the next track Press +.

Go back to the previous track Press =.

Remove the CD Press OPEN/CLOSE.

Turn off the player Set FUNCTION to TAPE

(CD/RADIO OFF).

Playing time

Track number

4Press ^.

The player plays all the tracks

once.

OPEN/CLOSEFUNCTION

+/=

VOLUME

Basic Operations6EN

CFD-121.E.G_3-858-850-1X.CED.CEK.CEH.EE1.E12.E23.EA

Listening to the radio

Connect the supplied AC power cord (see page 16).

1Set FUNCTION to RADIO FM or

AM.

2Turn TUNING to tune in a radio

station.

If the received FM stereo is too

weak, the reception becomes

monaural.

1 2

Basic Operations

7EN

CFD-121.E.G_3-858-850-1X.CED.CEK.CEH.EE1.E12.E23.EA

Use these buttons for additional operations

To Do this

Adjust the volume Turn VOLUME.

Turn off the radio Set FUNCTION to TAPE

(CD/RADIO OFF).

To improve broadcast reception

Reorient the antenna for FM. Reorient the player itself

for AM.

Tip

To receive an FM stereo

program (for models for

Europe, UK and Italy)

Set the MONO/

STEREO selector to

STEREO. If the FM

broadcast is noisy, set

the selector to MONO

and the radio will play

in monaural.

MONO/STEREOFUNCTIONVOLUME

For FM For AM

Basic Operations8EN

CFD-121.E.G_3-858-850-1X.CED.CEK.CEH.EE1.E12.E23.EA

Playing a tape

Connect the supplied AC power cord (see page 16).

1Set FUNCTION to TAPE(CD/

RADIO OFF).

2Press p6 to open the tape

compartment and insert a

recorded tape. Use TYPE I

(normal) tape only. Close the

compartment.

3Press 9.

With the side you want

to play facing forward

123

Basic Operations

9EN

CFD-121.E.G_3-858-850-1X.CED.CEK.CEH.EE1.E12.E23.EA

Use these buttons for additional operations

To Do this

Adjust the volume Turn VOLUME.

Stop playback Press p6

Fast-forward or rewind the tape* Press 0or )

Pause playback Press P.

Press the button again to

resume play after pause.

Eject the cassette Press p6.

*For the side facing forward

VOLUME P p6 0/)

Basic Operations10EN

CFD-121.E.G_3-858-850-1X.CED.CEK.CEH.EE1.E12.E23.EA

Connect the supplied AC power cord (see page 16).

1Press p6 to open the tape

compartment and insert a blank

tape. Use TYPE I (normal) tape

only.

2Select the program source you

want to record.

To record from the CD player, set

FUNCTION to CD and insert a

CD (see page 4).

To record from the radio, set

FUNCTION to RADIO FM or AM

and tune in the station you want

(see page 6).

3Press rto start recording. (9is

depressed automatically).

Recording on a tape

Display

With the side you want to

record on facing forward
