Sony GP-VPT2BT Guía de referencia

Help Guide

Shooting Grip With Wireless Remote Commander

GP-VPT2BT

Use this Help Guide when you have issues or questions on how to use your Shooting Grip With Wireless Remote

Commander.

Supported camera models

Identifying the parts

Preparations

Unpacking

Inserting the battery

Pairing the unit with the mounted camera

Confirming the setting on the camera

Mounting the camera

Adjusting the tilt angle

Preventing unintentional operations

Shooting

About the camera shooting styles

Shooting a still image

Shooting a video

Zooming the camera

Indicator activities

Activating the camera's C1 function

About this unit

Notes on use

Specifications

Trademarks

Troubleshooting

The remote commander function of this unit fails to work.

Help Guide

Shooting Grip With Wireless Remote Commander

GP-VPT2BT

Supported camera models

This unit is Shooting Grip with the Bluetooth compatible wireless remote commander function (hereinafter referred to as

“this unit”).

For camera models compatible with this unit, visit the website at:

https://www.sony.net/dics/vpt2bt/

Help Guide

Shooting Grip With Wireless Remote Commander

GP-VPT2BT

Identifying the parts

About the built-in Bluetooth®antenna

This unit is equipped with a built-in Bluetooth antenna at the section shown in the following illustration. When you

operate this unit, keep your hand away from the section to prevent a possible Bluetooth connection failure.

Camera mounting screw1.

Flip button

Flips around the mounted camera. For details, see “Adjusting the tilt angle.”

Angle adjusting button

Adjusts the angle of the grip. For details, see “Adjusting the tilt angle.”

PHOTO button4.

Indicator5.

MOVIE button6.

LOCK switch

Disables the remote commander function to prevent unintentional camera operations.

Zoom button8.

C1 button

Activates the function assigned to the C1 button on the camera. For details about the camera's settings, refer to the

operating instructions supplied with your camera.

Adjustment wheel

Adjusts feel for changing the angle of the grip.

10.

Camera mounting wheel11.

Battery chamber lid12.

Related Topic

Activating the camera's C1 function

Preventing unintentional operations

Inserting the battery

Supported camera models

Pairing the unit with the mounted camera

Indicator activities

Help Guide

Shooting Grip With Wireless Remote Commander

GP-VPT2BT

Unpacking

If you find anything missing, please contact your dealer.

The number in the parentheses indicates the quantity.

Shooting Grip With Wireless Remote Commander (1)

Lithium coin cell battery (CR2032) (1)

Pouch (1)

Set of printed documentation

Help Guide

Shooting Grip With Wireless Remote Commander

GP-VPT2BT

Inserting the battery

Insert the supplied lithium coin cell battery (CR2032) into the battery chamber of this unit.

Push the tab ( ) on the battery chamber lid to the left and hold the tab, push down the other tab ( ) on

the lid, and then remove the battery chamber lid.

Insert the supplied lithium coin cell battery.

Insert the battery so that the + terminal is facing upward.

(+ on the battery chamber indicates the direction of the battery.)

Replace the battery chamber lid.

Help Guide

Shooting Grip With Wireless Remote Commander

GP-VPT2BT

Pairing the unit with the mounted camera

Establish a Bluetooth connection between this unit and a camera.

Before establishing a Bluetooth connection, you must pair the unit with the camera (device registration).

Note

The following is an example of the mounting procedure for Sony Interchangeable Lens Digital Cameras and Sony digital still

cameras.

Before you start pairing, make sure that the LOCK switch on this unit is NOT in the “LOCK” position.

Note

If pairing fails, the indicator on this unit flashes rapidly. If this happens, repeat the procedure all over again.

A pairing attempt times out when a certain amount of time elapses between the actions in step and step .

In the event of the following, pair this unit with the mounted camera all over again.

On the camera, select MENU → (network) → [Bluetooth Settings] → [Bluetooth Function] → [On].

On the camera, select MENU → (network) → [Bluetooth Rmt Ctrl] → [On].

If the pairing screen appears on the camera's screen, proceed to step .

On the camera, select MENU → (network) → [Bluetooth Settings] → [Pairing].

On this unit, press and hold the PHOTO button ( ) and the T side of the Zoom button ( ) simultaneously

for at least 7 seconds.

When a confirmation message appears on the camera's screen, select [OK].

appears and pairing begins.

When pairing is complete, [Paired.] appears.

You mounted a different camera on this unit for operation. (When you replaced the camera back with the previously mounted

one, you must pair the unit with the mounted camera all over again as well.)

You reset the camera's network settings.

If this unit is kept unused while a Bluetooth connection is established, (no Bluetooth connection) may appear on the camera’s

screen.

Help Guide

Shooting Grip With Wireless Remote Commander

GP-VPT2BT

Confirming the setting on the camera

On the camera, select MENU → (network) → [Bluetooth Rmt Ctrl] and make sure that [On] is selected.

Note

You cannot use the function for linking location information with a smartphone while [Bluetooth Rmt Ctrl] is set to [On].

You cannot use an infrared remote commander while [Bluetooth Rmt Ctrl] is set to [On].

While [Bluetooth Rmt Ctrl] is set to [On], the camera will not switch to the power-saving mode. Change the setting to [Off] when

you are done using the Bluetooth remote commander.
