Sony XLR-K3M Guía de referencia

Help Guide

XLR Adaptor Kit

XLR-K3M

Use this Help Guide when you have issues or questions on how to use your XLR adaptor kit.

Supported camera models

Identifying the parts

Preparations

Unpacking

Attaching/removing the XLR adaptor to/from the camera

Attaching/removing the supplied microphone

Recording

Selecting the digital or analog input type

Using the supplied microphone

Using a device, such as an external audio device

Minimizing noise with the LOW CUT function

Adjusting the recording volume level

Selecting the audio input for recording audio to the channels on the camera

About this unit

Notes on use

Specifications

Trademarks

Help Guide

XLR Adaptor Kit

XLR-K3M

Supported camera models

This unit is a kit that includes an XLR adaptor for cameras with the Multi Interface Shoe in addition to a microphone.

For camera models compatible with this unit, visit the website at:

https://www.sony.net/dics/k3m/

Help Guide

XLR Adaptor Kit

XLR-K3M

Identifying the parts

Body parts

Switches and dials

Wind screen1.

Microphone holder2.

Microphone3.

Lock dial4.

Multi Interface foot

Note

Do not touch the connector of the Multi Interface foot with bare hands.

Connector protect cap6.

ATT (INPUT1) switch

Select the standard input level of the INPUT1 jack. This switch setting is active when the INPUT1

(LINE/MIC/MIC+48V) switch is set to “MIC” or “MIC+48V.”

INPUT1 (LINE/MIC/MIC+48V) switch

Select the option suitable for the device connected to the INPUT1 jack.

ATT (INPUT2) switch

Select the standard input level of the INPUT2 jack. This switch setting is active when the INPUT2

(LINE/MIC/MIC+48V) switch is set to “MIC” or “MIC+48V.”

INPUT2 (LINE/MIC/MIC+48V) switch

Select the option suitable for the device connected to the INPUT2 jack.

LOW CUT (INPUT1) switch

Use this switch to minimize unwanted noises by attenuating low-frequency components of the input audio from the

INPUT1 jack.

AUTO/MAN (INPUT3) switch

Select the method (Auto/Manual) to adjust the volume level of the input audio from the INPUT3 jack.

AUTO/MAN (INPUT1) switch

Select the method (Auto/Manual) to adjust the volume level of the input audio from the INPUT1 jack.

AUDIO LEVEL (INPUT1) dial

Adjust the recording volume level of the input audio from the INPUT1 jack.

AUTO/MAN/LINK (INPUT2) switch

Select the method (Auto/Manual/Link to INPUT1) to adjust the volume level of the input audio from the INPUT2 jack.

AUDIO LEVEL (INPUT2) dial

Adjust the recording volume level of the input audio from the INPUT2 jack.

10.

LOW CUT (INPUT2) switch

Use this switch to minimize unwanted noises by attenuating low-frequency components of the input audio from the

INPUT2 jack.

11.

AUDIO LEVEL (INPUT3) dial

Adjust the recording volume level of the input audio from the INPUT3 jack.

12.

DIGITAL/ANALOG switch

Select the digital or analog input type.

13.

Ports and jacks

Related Topic

Supported camera models

Attaching/removing the XLR adaptor to/from the camera

Attaching/removing the supplied microphone

Selecting the digital or analog input type

Using the supplied microphone

Using a device, such as an external audio device

Minimizing noise with the LOW CUT function

Adjusting the recording volume level

Selecting the audio input for recording audio to the channels on the camera

If your camera is compatible with the digital audio interface of the Multi Interface Shoe, set the switch to “DIGITAL.”

This allows the unit and the attached camera to communicate with each other with digital signals and provide audio

recording with minimum noise insertion.

INPUT SELECT switch

Select the audio input for recording audio to the channels on the attached camera.

14.

Release lever1.

Micro USB port2.

Cable holder3.

INPUT3 jack (Stereo mini-jack, plug-in-power compatible)4.

INPUT2 jack (3-pin XLR/TRS, female type, phantom-power compatible)5.

INPUT1 jack (3-pin XLR/TRS, female type, phantom-power compatible)6.

Help Guide

XLR Adaptor Kit

XLR-K3M

Unpacking

If you find anything missing, please contact your dealer.

The number in the parentheses indicates the quantity.

XLR Adaptor (XLR-A3M) (1)

Microphone (ECM-XM1) (1)

Wind screen (1)

Connector protect cap (attached) (2)

Extension Cable for Audio (1)

Case (1)

Set of printed documentation

Help Guide

XLR Adaptor Kit

XLR-K3M

Attaching/removing the XLR adaptor to/from the camera

Attach the XLR adaptor to a camera.

Note

Before attaching/removing the adaptor to/from a camera, turn off the power to the camera.

To remove the XLR adaptor

Turn off the power to the camera, rotate the lock dial counterclockwise until it stops, and then slide out the Multi Interface

foot from the shoe.

To use the Extension Cable for Audio for attachment

Remove the connector protect cap from the XLR adaptor.

Slide the Multi Interface foot of the XLR adaptor into the shoe on the camera ( ), and then rotate the lock

dial in the “LOCK” direction ( ) to firmly secure the adaptor.

When it is difficult to insert the Multi Interface foot into the shoe, rotate the lock dial counterclockwise until it stops,

and then try again.

Alternatively, you can use the supplied Extension Cable for Audio to attach the XLR adaptor to the camera.

Use of this cable for attachment comes in handy when you stand away from the camera and use the microphone

attached to the XLR adaptor for recording.

Note

Using the supplied Extension Cable for Audio with products other than XLR-K3M may affect its performance, leading to accidents

or malfunction.

Remove the connector protect caps from the XLR adaptor and the Extension Cable for Audio.1.

Slide the Multi Interface foot of the XLR adaptor into the shoe of the Extension Cable for Audio ( ), and then rotate

the lock dial in the “LOCK” direction ( ) to firmly secure the adaptor.

Slide the Multi Interface foot of the Extension Cable for Audio in to the shoe on the camera ( ), and then rotate the

lock dial in the “LOCK” direction ( ) to firmly secure the cable.

Help Guide

XLR Adaptor Kit

XLR-K3M

Attaching/removing the supplied microphone

Attach the supplied microphone (ECM-XM1) to the XLR adaptor.

Note

Before attaching/removing the microphone to the adaptor, be sure to set the INPUT1 (LINE/MIC/MIC+48V) switch to the position

other than “MIC+48V.” While the switch is set to “MIC+48V,” plugging/unplugging the cable from the microphone may cause a

loud noise or a malfunction of the microphone.

Fit the supplied wind screen over the microphone.

Unlock the microphone holder and open the lid of the holder.

Place the microphone on the microphone holder so that the model name (ECM-XM1) inscribed on the

microphone faces upward, close the lid of the holder, and then lock the holder.

Connect the cable from the microphone to the INPUT1 jack on the XLR adaptor.
