Sony PCG-ABA1 Series Manual de usuario

4-675-348-11(1)

2003 Sony Corporation

Bluetooth™

USB Adapter

PCGA-BA1 Series

Read This First

Bitte zuerst lesen!

Lisez-moi en premier

•VAIO and are registered trademarks of Sony Corporation.

•Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States

and/or other countries.

•BLUETOOTH and its logo are trademarks owned by Bluetooth SIG, Inc., U.S.A and licenced to

Sony Corporation.

•All other names of systems, products and services are trademarks of their respective owners. In

the manual, the ™ or ® marks are not specified.

In this manual, Microsoft®Windows®XP Home Edition and Microsoft®Windows®XP Professional are

referred to as Windows XP.

Contents

Supplied Accessories ..............................................................................3

Precautions..............................................................................................3

Setup process ..........................................................................................4

Installing the driver and software ...........................................................5

For customers in Europe ............................................................. 5

For customers in the U.S.A., Canada and other regions............. 6

Ways to Connect with a Bluetooth Device .............................................8

Supplied Accessories

Unpack the unit and make sure the following parts are included. If anything

is missing, contact the Sony dealer where you purchased this product or a

Sony service representative serving your area.

• Bluetooth USB Adapter (1) • Software CD-ROM (1)

•Carrying case (1)

•Read This First (this document) (1) • Operating Instructions (1)

•Warranty Card (1) • Safety Regulations

(Europe only) (1)

zHint

The software CD-ROM includes a copy of this document and the separate Operating

Instructions as PDF files in the “manual” folder.

Precautions

Before using the Bluetooth USB Adapter, observe the following

precautions.

• This product can be used with Sony VAIO notebooks running

Windows XP operating system. It cannot be used with models that have

integrated Bluetooth functions.

•Within an aircraft and in other locations where radio emissions may be a

problem, remove the Bluetooth USB Adapter from the computer. Simply

shutting down the software is not enough to stop the emission of

radiowaves from the unit.

• You can use only one Bluetooth USB Adapter per computer.

•Do not install the Bluetooth USB Adapter in an external USB

connection. Otherwise, software and radio functions may not perform

correctly.

Setup process

Before the Bluetooth USB Adapter can be used for communication with a

Bluetooth enabled device, you need to take the following steps.

Install Windows XP Service Pack 1 (if your computer already

has Windows XP Service Pack 1 or later installed, this

operation is not necessary).

Windows XP Service Pack 1 is not included in the software on the supplied

CD-ROM. If it is not already installed, please download it from Microsoft's website

(http://www.microsoft.com/WindowsXP/pro/downloads/servicepacks/sp1/

default.asp).

To determine whether Windows XP Service Pack 1 is installed on your computer,

click the Windows “Start” button and select “Control Panel”. Click “Performance

and Maintenance” and then “System” in the Control Panel, if “Service Pack 1”

appears on the “General” tab in the “System Properties” dialog box. Windows XP

Service Pack 1 is installed.

Install the Bluetooth driver and software

Install the Bluetooth device driver and the BlueSpace NE software by carrying out

the steps listed below.

Install software on target device as required

Depending on the target device, you may need to install software to enable

communication with the Bluetooth USB Adapter. For details, refer to the

documentation of the target device.

Note

Depending on your computer model, after installing Windows XP Service Pack 1, the

following message may appear: “A device or application is disabled. ‘YAMAHA AC-XG

WDM Audio Device’ may cause Windows system to become unstable. This driver was

not loaded. Please click here for details.” In this case, see the “Troubleshooting” section

of the Operating Instructions.

Continued on next page

Installing the driver and software

Install the driver and software required to use this device.

Note

Before starting the procedure below, the computer must be set up to read CD-ROM discs.

Do not remove the CD-ROM until all steps have been completed. For details on

CD-ROM use, refer to the manuals provided with your computer and CD-ROM drive.

For customers in Europe

Installing the Bluetooth Driver and Software

1Turn on the computer and insert the supplied CD-ROM into

the CD-ROM drive.

The installer program starts automatically.

zHint

If the installer program does not start automatically, click “Start”, and select “My

Computer”. Double-click the drive letter (for example, drive E) corresponding to the

CD-ROM drive, the double-click “Setup.exe”.

* The drive name may be vary, depending on the computer.

2Select your language.

3Click “Install BlueSpace NE version 3.1” button.

4Follow the instructions on the screen, clicking “Next” and

“Finish”.

Installing Network Smart Capture

1Turn on the computer and insert the supplied CD-ROM into

the CD-ROM drive.

The installer program starts automatically.

zHint

If the installer program does not start automatically, click the “Start” button, and

select “My Computer”. Double-click the drive letter (for example, drive E)

corresponding to the CD-ROM drive, then double-click “Disk1”, and “Setup.exe” in

sequence.

*The drive name may vary, depending on the computer.

2Select your language.

3Click the “Installer Network Smart Capture version 1.2”

button.

4Follow the instructions on the screen by clicking “Next”.

Note

If Network Smart Capture has been previously installed, uninstall it first.

To access Network Smart Capture Help

Click “Start” in the Windows taskbar, point to “programs”, point to

“Network Smart Capture”, and click “Help”.

To read Operating Manual

Click the “View Manual” button.

For customers in the U.S.A., Canada and other regions

Installing the Bluetooth Driver and Software

Required software:

•Bluetooth device driver

•BlueSpace NE software

1Turn on the computer and insert the supplied CD-ROM into

the CD-ROM drive.

The installer program starts automatically.

zHint

If the installer program does not start automatically, click “Start”, and select “My

Computer”. Double-click the drive letter (for example, drive E) corresponding to the

CD-ROM drive, the double-click “Setup.exe”.

* The drive name may be vary, depending on the computer.

2Click “Install Driver and Application”.

3Follow the instructions on the screen, clicking “Next”,

“Continue” and “Finish”.

During installation, when prompted to reboot and install the Bluetooth

USB adapter, click “OK”.

zHint

Refer to the Operating Instructions for how to install the Bluetooth USB adapter.

Installing Network Smart Capture

Required Software:

Network Smart Capture Library 1.3

Network Smart Capture Application 1.2

1Click “Install Network Smart Capture”.

“Region selection” window appears.

2Select your region and click “OK”.

3Select the region from the list and click “OK”.

4Follow the instructions and click “Finish” to complete the

installation.

Note

For more information about Network Smart Capture software, refer to its Help file.

To access Network Smart Capture Help

Click “Start” in the Windows taskbar, point to “programs”, point to

“Network Smart Capture”, and click “Help”.

You can also go to: http://www.ita.sel.sony.com/support/bluetooth

To read Operating Manual

Click the “View Manual” button.

Ways to Connect with a Bluetooth

Device

When connecting to a Bluetooth technology-enabled device, use one of the

following (depending on the function of the device).

•BlueSpace NE software

•Windows XP functions (Wireless Link in Control Panel)

Things you can do using the BlueSpace NE software

•Exchange files and images between computers

•Synchronize data and exchanging files and images with a PDA

•Use a camcorder or a digital still camera as a remote camera, to exchange

images

•Send images to camera or any Bluetooth device that support BIP (Basic

Image Profile)

•Bluetooth Modem Station setup (Europe only)

•Exchange addresses with cellular phones

Things you can do with the Windows XP operating system

•Connect to the Internet with a Bluetooth Modem Station (Europe only)

•Connect to the Internet with a cellular phone

•Use a mouse or keyboard

•Print on a Bluetooth printer

The connection procedure depends on the software used. Each operating

procedure is shown in the following section.

Continued on next page

When using BlueSpace NE software

Turn the computer on and insert the Bluetooth USB Adapter

into the USB port.

Double-click in the taskbar to launch BlueSpace NE.

Perform a device discovery to set up a connection with the

other Bluetooth device.

Perform a service search for the target Bluetooth device, to

check which services are available.

If required, enter the passkey information for verification.

Select the required service.

When using Windows XP Functions

Turn the computer on and insert the Bluetooth USB Adapter

into the USB port.

Click the “Start” button and select “Control Panel”.

The Control Panel appears.

Click “Printers and Other Hardware”, and click “Wireless Link”.

The Bluetooth Connection Wizard appears.

For communications with a device not appearing in the list in

the “Bluetooth” tab, click the “Add” button.

If the device is already present, it is ready for communications.

Follow the Wizard instructions to make the connection.

Proceed as needed for the specific device.

The connection process is now complete. Some Bluetooth devices may

require special software applications. For details, see the manuals provided

with the target Bluetooth device.
