Sony Ericsson W910 Manual de usuario

Installation Instruction, Mechanical

1/00021-1/FEA 209 544/129 A

Company Internal

Sony Ericsson Mobile Communications AB

Installation Instruction, Mechanical

Applicable for W910

Contents

General.............................................................................................................................2

Hardware.........................................................................................................................2

2.1

Test Setup ..........................................................................................................2

2.2

Computer ........................................................................................................... 3

2.3

Sony Ericsson programming interface cable – DCU-60 ...................................3

2.4

Bluetooth Device............................................................................................... 3

2.5

Power Supply (optional).................................................................................... 3

2.6

Battery Eliminator (Dummy Battery)................................................................3

2.7

Label Printer ......................................................................................................3

Software ...........................................................................................................................4

3.1

EMMA III.......................................................................................................... 4

3.2

Labelmake II software.......................................................................................4

Revision History.............................................................................................................. 5

Installation Instruction, Mechanical

1/00021-1/FEA 209 544/129 A

Company Internal

Sony Ericsson Mobile Communications AB

2(5)

1 General

This document describes the installation procedure for the Mechanical repair package.

The Mechanical repair package consists of a Computer and Interface Cables. A service

card is required for security reasons. A label printer can be installed to be able to print

new labels (optional).

2 Hardware

All hardware must be approved by Sony Ericsson and is documented in the Equipment

List.

2.1 Test Setup

The equipment in this picture is specified in the Equipment List.

Installation Instruction, Mechanical

1/00021-1/FEA 209 544/129 A

Company Internal

Sony Ericsson Mobile Communications AB

3(5)

2.2 Computer

IBM compatible computer is required. The computer should include at least two USB-

ports. Refer to Equipment List for minimum requirements.

2.3 Sony Ericsson programming interface cable – DCU-60

The cable is the interface between the computer and the phone. The DCU-60 cable

should be connected to a USB-port on the computer.

2.4 Bluetooth Device

Any Bluetooth device such as a headset, other Bluetooth phone or other Bluetooth

device can be used to verify the Bluetooth function in the phone. Set up the connection

according to the chosen equipment manufacturer instructions.

2.5 Power Supply (optional)

A Power Supply according to the Mechanical Equipment List may be used.

Set the output of the Power Supply as follows

•Voltage: 3.8Vdc

•Current: 2.0Amps

2.6 Battery Eliminator (Dummy Battery)

A Battery Eliminator is to be used together with a power supply to power the phone.

Connect the cables from the battery eliminator to the power supply, red cable to positive

output terminal and black cable to negative output terminal. There is a 3-position switch

on the Battery Eliminator that should be set to position “B”.

2.7 Label Printer

A Zebra printer shall be used. Connect the printer with a Null Modem cable [refer to the

Zebra printer manual] to the serial port on the computer. Read the Zebra installation

manual for more information about the installation.

Installation Instruction, Mechanical

1/00021-1/FEA 209 544/129 A

Company Internal

Sony Ericsson Mobile Communications AB

4(5)

3 Software

3.1 EMMA III

EMMA III contains software upgrades and tools required for servicing this phone. Emma

III is accessible through the CSPN web page. Installation and user manuals are

available at the EMMA III start page.

http://ma3.extranet.sonyericsson.com/ma3/

3.2 Labelmake II software

LabelMake II is an application installed through Java Web Start.

Access the Labelmake II software from the CSPN Web page.

You will find LabelMake II in the dropdown menu on the CSPN web page.

http://cspn.extranet.sonyericsson.com

Press “START LabelMake II “button and you will be directed to the LABELMAKE II client

page.

Product labels are downloaded on-line from a remote server database.

Installation Instruction, Mechanical

1/00021-1/FEA 209 544/129 A

Company Internal

Sony Ericsson Mobile Communications AB

5(5)

4 Revision History

Rev. Date Changes / Comments

A 2007-10-09 Initial Release
