Sony Ericsson K330 Manual de usuario

K330

User guide

This is the Internet version of the User guide. © Print only for private use.

Thank you for purchasing the Sony Ericsson K330. For

additional phone content, go to www.sonyericsson.com/fun.

www.sonyericsson.com/myphone. For product support, go to

www.sonyericsson.com/support.

Prior to use, please see important warranty information and

terms for safe and efficient use separately provided.

Instruction symbols

The following instruction symbols appear in this User guide:

> Use the navigation key to scroll and select.

Press the navigation key up.

Press the navigation key down.

Press the navigation key to the left.

Press the navigation key to the right.

Note

Tip

Warning

Indicates that a service or function is network- or

subscription-dependent. All menus or functions may

not be available in your phone. Consult your network

operator for more information.

This is the Internet version of the User guide. © Print only for private use.

Prepare the phone

To insert the SIM card

1Remove the battery cover.

2Slide the SIM card into its holder with the contacts facing

down.

To insert the battery

1Remove the battery cover.

2Insert the battery with the label side up and the connectors

facing each other.

Do not force the battery cover into place. Slide the battery

cover carefully onto the phone and close it.

This is the Internet version of the User guide. © Print only for private use.

To charge the battery

1The phone battery is partly charged when you buy it. Connect

the charger to the phone. It takes approximately 2.5 hours

to fully charge the battery.

2To remove the charger, tilt the plug upwards.

You can use the phone during charging. You can charge

the battery for more or less than 2.5 hours. Interrupted

charging will not damage the battery.

This is the Internet version of the User guide. © Print only for private use.

To turn on the phone

1Press and hold down .

2Enter your PIN if requested. To correct mistakes, select

Delete.

3Select OK.

4Select a language.

5Enter the time and date and select

Save.

To turn off the phone

•Press and hold down .

Standby

After you have turned on the phone and entered your PIN, the

name of your operator appears on the screen. This is called

standby. You can now make and receive calls.

This is the Internet version of the User guide. © Print only for private use.

SIM and PIN

SIM card

The SIM (Subscriber Identity Module) card, which you

get from your network operator, contains information

about your subscription. Always turn off your phone

and detach the charger before you insert or remove

the SIM card.

PIN code

You may need a PIN (Personal Identification Number) to activate

the services in your phone. Your PIN is supplied by your network

operator. Each PIN digit appears as *, unless it starts with

emergency number digits, for example, 112 or 911. You can call

an emergency number without entering a PIN.

You can save contacts on the SIM card before removing

it from your phone. Contacts may also be saved in the

phone memory. See Contacts on page 18.

If you enter the wrong PIN three times in a row, PIN

blocked. Enter PUK provided by your operator.

appears. To unblock it, you need to enter your PUK

(Personal Unblocking Key).

This is the Internet version of the User guide. © Print only for private use.

Menu overview

Extras Calendar, Timer, Stopwatch, Calculator,

Games & apps, My files, Torch

Internet Homepage, Bookmarks, Go to URL,

View, Advanced

FM Radio

Camera Take pic., Record video, Camera pics,

Videos, Slide show, Settings

Messaging Write new, Inbox, Call voicemail, Drafts,

Sent messages, Saved msgs, Templates,

Delete messages, Settings, Memory

status

Alarms

Calls Call list, Time and cost, Call settings

Contacts View contacts, Find contact, Add

contact, My number, Voicemail, Delete

contacts, Speed dial, Copy contacts,

Send contacts, Settings

Settings Sound & alerts, Wallpaper, Theme, Time

and date, Language, Bluetooth, Select

network, Internet settings, Advanced,

Phone status

Some menus and icons in this document may vary depending

on operator, network or subscription.

This is the Internet version of the User guide. © Print only for private use.

Phone overview

Stereo handsfree

and battery

charger

connector

FM radio keys

Ear speaker

Call key

Keylock

End key,

On/off key

Screen

Silent key

Soft keys

Torch key

This is the Internet version of the User guide. © Print only for private use.

Network coverage

The network bars show the strength of the GSM network in

your area. Try moving to another location if you have trouble

calling and network coverage is poor. No network means you

are not in range of a network.

Battery status

= Good network coverage

= Average network coverage

= The phone battery is fully charged

= The phone battery is empty

Battery

status

Network

coverage

This is the Internet version of the User guide. © Print only for private use.

Screen icons

These icons may appear on the screen.

Icon Description

Battery icon. A completely green icon means the battery

is fully charged

You have missed a call

Divert calls is activated

The phone is set to silent

The keypad is locked

You have received a text message

You have received a picture message

An alarm is activated

Ongoing call

The loudspeaker is on

The FM radio is playing

The Bluetooth function is activated

This is the Internet version of the User guide. © Print only for private use.
