Setting SmartScan50 to VOLUME measurement:
From the main configuration menu set the following parameters:
• T pe of application – Set to Level.
• Units – Set our own units (i.e. meter, inch, feet, etc.).
• Tank height – Set vessel height bottom to sensor.
Do not define the 4-20mA current values et.
From the “additional configuration” menu set the following parameters:
• Pr.0 – Set Ind1 for volume measurement.
• Pr.1 or Pr.2 – Define strapping table.
With SmartScan it is possible to define the strapping table in two methods:
•Manual insertion of strapping table: The user enters both LEVEL and VOLUME values.
•Semi-automatic insertion of strapping table: SmartScan measures LEVEL and the user onl
enters the corresponding VOLUME value.
Loop current values 4-20mA are set after strapping table is configured. SmartScan50 is read for volume
measurement after exiting the configuration menu.
4. MANUA INSERTION OF STRAPPING TAB E
Use “manual insertion of strapping table” when:
•There is a fixed known ratio between LEVEL and VOLUME for our vessel.
•The vessel is of standard shape such as c linder or cone or and it is eas to map LEVEL to VOLUME.
Refer to appendix A for some examples.
•It is not possible to use the semi-automatic mode.
Manual insertion of strapping table is performed with the additional menu configuration - Pr.1.
is recommended to map vessel interferences using Scan
to the User Manual of SmartScan for details.
