Introdu tion

This document describes the fixes incorporated in V2.0/7 software, and details the software installation procedure required

to update your system to this latest release of C100 HDS software.

Please note that this release is only applicable to those systems that have previously been installed with V1.1/15 or greater

software. If you have any questions about this release, please contact your local SSL office or distributor.

Do not apply power to – or re-start – the Blackrock processor with the C100 HDS Software Disk in the processor’s DVD

drive; doing so will force a complete system re-install!

Assumptions

The following points are assumed in these installation instructions:

A1. This installation procedure details installation of new software on a running system, not a fresh installation.

A2. During commissioning/installation of the C100 HDS system, at least one networked computer within the studio

facility – ideally located in the same room as the console – will have been configured to communicate with the system.

Access to one of these computers will be required to run the software installation process. This will be referred to

in the following text as the ‘networked omputer’.

A3. The network IP Address that has been assigned to the C100 HDS system will be required. If you do not know either

of these details, please contact your IT or Studio Maintenance Department.

A4. The networked omputer used for this installation should have an SSH client installed (‘

PuTTY

’, for example).

This program will be used to communicate with the C100 HDS system – login as ‘

sbc

’ using ‘

server

’ as the password.

If you are unsure how to run this program, or the default password has been changed, please contact your IT or Studio

Maintenance Department. This computer must also be fitted with a DVD ROM drive.

A5. Backing up of the current system and installation of the new software will require that the networked omputer

has access to the folders exported by the C100 HDS system. This can be achieved as follows:

a. Click on ‘Run’ in the Windows Start menu.

b. In the ‘Run’ box, type ‘

\\<IP_Address> <CR>

’

Where: ‘

’ indicates that we wish to mount a file share,

‘

<IP_Address>

’ is the IP Address of the C100 HDS system,

‘

<CR>

’ indicates the ‘Return’ key on the computer keyboard.

c. At the resulting login prompt, enter the username (‘

sbc

’) and password (the default for this login being ‘

sbc123

’).

This will result in a view of the shared folders on the C100 HDS system, similar to that shown below:

V2.0/7 Software Update

Page 1

C100 HDS Software Update

Page 2

Software Installation on a Single Bla kro k System

This installation procedure applies to single Blackrock systems only – the process for redundant systems is slightly different

and so is detailed separately on page 4.

1. Check the contents of the Software Upgrade it against the packing list; if there are any omissions, please contact your

local SSL office before proceeding further.

Ar hiving the System Disk

2. As with all software installations, we strongly advise you to generate a ‘mirror’ copy of the C100 HDS System Disk

before proceeding. Open the SSH client on the networked omputer and login to the C100 HDS system

(ref. Assumption A4.). Once you are logged in (as user ‘

sbc

’), type:

backup_syste _disk <CR>

This will create a time and date stamped backup file in the

‘

syste _backup

’ folder.

The ackup process copies the entire C100 HDS System Disk and so will take a considera le time (≈15min) to complete.

It is of course also recommended that any ackups created are stored off-line elsewhere.

3. To ensure that sufficient space is still available to contain the upgrade, type:

df -h /ho e <CR>

Check that the percentage used is less than about 90%. If it

is higher, consider removing any old backups from the

‘

syste _backup

’ folder.

Installing the Support Software

4. Place the C100 HDS Software Disk in the DVD drive in the networked omputer and open a window that displays

the contents of the DVD – do not place the software disk in the DVD drive on the Blackrock processor!

5. Locate the ‘

updates

’ folder within the folders exported by the C100 HDS system (ref. Assumption A5.).

6. On the DVD, open the ‘

C100_V2_0_7 Updates

’ folder and drag the following three

.rp

files from the CD into the

‘

updates

’ folder:

•

kernel

SBC kernel and associated modules

•

ssl_console_files

Blackrock system software and files

•

ssl_host_tools

SBC support files and applications

7. Once the

.rp

files have been copied, return to the SSH client and type:

install_updates <CR>

. This will unwrap and install each of the

.rp

archives. Follow

the on-screen instructions to install them. Ignore any error

messages printed to the terminal during this time.

V2.0/7 Software Update

Page 3

Installing the C100 HDS System Software

9. Once the files are installed the system

code will need to be copied to the flash

memory on the Blackrock processor’s

PCIe card. At the terminal prompt typing

load_console_code <CR>

will result in a

list of software versions similar to that

shown here.

Select the version of code you wish to

install by entering the number next to

the software version, eg.

1 <CR>

in the

illustration opposite. The system code

will now be copied to the flash device on

the PCIe card. A percentage indicator on

the terminal will provide an indication as

to how far through the process the

system is. On completion a prompt will request a key on the keyboard be pressed to shutdown ‘p’ or reboot ‘r’ the

Blackrock processor – it is recommended that at this point the Blackrock processor be shutdown and re-powered if

possible.

Enabling the New System

10. When the system has fully booted, a pop-up will appear on screen inviting you to enter a Software Licence string and

so enable the software.

You will not e a le to use the console until the Software Licence has een accepted.

Open the Software Licence envelope containing your Licence string and type this carefully using the on-screen

keyboard. Once the system has verified the validity of the Licence, a Software Licence Agreement will appear on-

screen. Stab on the ‘I Agree’ box at the top of the pop-up to complete the licensing procedure. Reboot the processor

to ensure the licence is correctly read.

11. Remember to store the Software Licence string in a safe place along with the C100 HDS Software Disk.

Once the update is complete and the console has re ooted, any Windows workgroup the Blackrock has een assigned to

may need to e reassigned (updates performed y the SSL Host Tools package may erase various parts of the network

integration settings) – you may need to contact your contact your IT or Studio Maintenance personnel to check this.

Software Installation on a Redundant Bla kro k System

Installation of software and support files on a redundant Blackrock system must e performed on one processor at a time

with the other processor powered down. Do not attempt this process with oth units running!

1. Check the contents of the Software Upgrade it against the packing list; if there are any omissions, please contact your

local SSL office before proceeding further.

Ar hiving the System Disk

2. As with all software installations, we strongly advise you to generate a ‘mirror’ copy of the C100 HDS System Disk

before proceeding. Open the SSH client on the networked omputer and login to the C100 HDS system

(ref. Assumption A4.). Once you are logged in (as user ‘

sbc

’), type:

backup_syste _disk <CR>

This will create a time and date stamped backup file in the

‘

syste _backup

’ folder.

The ackup process copies the entire C100 HDS System Disk and so will take a considera le time (≈15min) to complete.

It is of course also recommended that any ackups created are stored off-line elsewhere. This must e done separately

for oth Blackrock processors – ut this can e done on oth processors simultaneously.

3. To ensure that sufficient space is still available to contain the upgrade, on each system type:

df -h /ho e <CR>

Check that the percentage used is less than about 90%. If it

is higher, consider removing any old backups from the

‘

syste _backup

’ folder.

Installing the Support Software

4. Ensure that the slave Blackrock processor has been powered down. Proceed through the following steps on the master

processor first.

5. Place the C100 HDS Software Disk in the DVD drive in the networked omputer and open a window that displays

the contents of the DVD – do not place the software disk in the DVD drive on the Blackrock processor!

6. Locate the ‘

updates

’ folder within the folders exported by the C100 HDS system (ref. Assumption A5.).

7. On the DVD, open the ‘

C100_V2_0_7 Updates

’ folder and drag the following three

.rp

files from the CD into the

‘

updates

’ folder:

•

kernel

SBC kernel and associated modules

•

ssl_console_files

Blackrock system software and files

•

ssl_host_tools

SBC support files and applications

8. Once the

.rp

files have been copied, return to the SSH client and type:

install_updates <CR>

. This will unwrap and install each of the

.rp

archives. Follow

the on-screen instructions to install them. Ignore any error

messages printed to the terminal during this time.

C100 HDS Software Update

Page 4

V2.0/7 Software Update

Page 5

Installing the C100 HDS System Software

10. Once the files are installed the system

code will need to be copied to the flash

memory on the Blackrock processor’s

PCIe card. At the terminal prompt typing

load_console_code <CR>

will result in a

list of software versions similar to that

shown here.

Select the version of code you wish to

install by entering the number next to

the software version, eg.

1 <CR>

in the

illustration opposite. The system code

will now be copied to the flash device on

the PCIe card. A percentage indicator on

the terminal will provide an indication as

to how far through the process the

system is. On completion a prompt will request a key on the keyboard be pressed to shutdown ‘p’ or reboot ‘r’ the

Blackrock processor – it is recommended that at this point the Blackrock processor be shutdown and re-powered if

possible.

Enabling the New System

11. When the system has fully booted, a pop-up will appear on screen inviting you to enter a Software Licence string and

so enable the software.

You will not e a le to use the console until the Software Licence has een accepted.

Open the Software Licence envelope containing your Licence strings. Each processor will have a different licence;

match the 5 digit PAL id. given with the licence to the Blackrock network ID on the sticker on the front face of the

Blackrock unit and type this in carefully using the on-screen keyboard. Once the system has verified the validity of the

Licence, a Software Licence Agreement will appear on-screen. Stab on the ‘I Agree’ box at the top of the pop-up to

complete the licensing procedure. Reboot the processor to ensure the licence is correctly read.

12. Power down the master Blackrock processor and power up the slave processor, such that only the slave processor

is on and running. Repeat this process from Step 2. for the slave processor.

13. Once all updates have been performed, re-boot both processors together.

14. Remember to store the Software Licence strings in a safe place along with the C100 HDS Software Disk.

Once the update is complete and the console has re ooted, any Windows workgroup the Blackrock has een assigned to

may need to e reassigned (updates performed y the SSL Host Tools package may erase various parts of the network

integration settings) – you may need to contact your contact your IT or Studio Maintenance personnel to check this.

Page 6

C100 HDS Software Update

New Features

Bla klight (Bulk I/O ard)

Following customer demand for more I/O channels, greater I/O flexibility and more robust RIO redundancy C100 HDS V2

introduces the new Blacklight I/O pipe, a powerful optical audio interconnect that carries four times the capacity of standard

MADI and is designed for secure, fail-safe operation over huge distances.

Each Blacklight mezzanine card holds four Blacklight I/O transceivers providing two permanently configured redundant 256

channel optical I/O channels on four duplex LC connectors. Each Blackrock core can now contain up to two Blacklight

mezzanine cards, two standard 64ch. MADI I/O cards or a combination of the two.

Introduction of the new Blacklight I/O mezzanine card provides the following functionality:

• 256 input channels with full processing from a single, upgraded Blackrock DSP card

• 256ch I/O bandwidth with control and status data between Blackrock and B-RIO, over a single duplex fibre pair

• An automatic ‘split point’ for the division of the maximum Blackrock ‘I/O slot’ limit of 512 bidirectional channels

between the upper and lower mezzanine cards

• An automatic ‘split point’ dividing the I/O slot allocation between the redundant ports on a Blacklight I/O card

according to the I/O cards fitted in each B-RIO

Additionally the V2 Software is compatible with the original C100 HDS 128ch DSP cards, providing various bug fixes and

offering a cost option retrofit for Blacklight I/O cards. A further DSP upgrade is also available as a cost option to allow

access to greater than 128 audio channels.

256 Input Channels from a Single Bla kro k DSP ard

All new C100 HDS consoles shipping from early 2010 will be fitted with the upgraded 256ch DSP card as standard and only

a licence will be required to access the higher channel counts. Full processing is available on all 256chs though Audio delays

remain the same: 64 modules shared between all input channels and ASG buses, each with 5.4s duration.

256 Channels of I/O Bandwidth between Bla kro k and B-RIO

In the current implementation if redundant fibre connections and redundant Blackrock processors are specified the four RIO

MADI ports will all carry the same data (two sets to and from each Blackrock) thus reducing the maximum I/O count to

62chs per RIO. However, with the new Blacklight mezzanine cards fitted in both the Blackrocks and B-RIO the four links

will provide 256chs audio I/O with control and status and full fibre redundancy, so that each Blackrock can have 256ch main

and one 256ch backup I/O link, regardless of the I/O cards fitted in the B-RIO.

Automati I/O Split Point between Mezzanines

The console detects the I/O cards fitted in the B-RIO(s) and allocates enough I/O slots to each mezzanine card, starting with

the lower card and finishing with the upper one.

This applies to B-RIO and MORSE Stage oxes only and not for any other MADI units.

Automati I/O Split Point within Mezzanines

The console detects the I/O cards fitted in the B-RIO(s) and automatically divides the I/O slots allocated to a Blacklight

mezzanine card between the two redundant ports according to the physical I/O cards fitted in the attached B-RIO(s).

This only applies to B-RIO and MORSE Stage oxes. For all other ports the console will assign I/O slots consecutively to the

remaining MADI ports until all availa le slots are used or all MADI ports have een completely included.

Support for several ombinations of MADI and Bla klight I/O ards

Standard 64 channel MADI cards and Blacklight I/O cards can be fitted in the Blackrock core in several combinations. For

example:

* This variant is not possi le due some technical limitations.

Link Setup Page

The Link Setup Page has been updated to

reflect the new 256ch I/O count and will

now display how many channels are fitted in

the B-RIO. In the adjacent picture, links 1

through 4 are Blacklight I/O ports whilst

ports 5 through 8 are MADI ports.

The RIO unit attached to the Blacklight I/O

ports contains 2 x 64ch DIO cards, 1 x 24ch

Analogue I/O card and 1 x 12ch. Mic I/P

card, hence the 164 channel count.

Long Press on Changeover

The Core Swap switch has now been linked

to the ‘Press & Hold Delay’ facility in the

Front Panel,Settings menu. This

security feature has been introduced to

ensure that a momentary and unintentional

press of the Core Swap switch will not

initiate a core changeover. The delay can be

set between 0.1s and 3.0s so that the switch

must be held down for a pre-determined

time before changeover takes place.

System Master GPO fun tion added

To the GPIO.lst file can be added, the option, to trigger a relay when the slave system is active. This can be used to provide

an indication as to which blackrock processor is active. When the Master system is active, any button the GPO is assigned

to, will be lit. If the Slave system is active the button the GPO is assigned to will not be lit.

Add the following line of text to the Fun tions List/GPIO.lst file found in the Root directory on the hard drive:

System Master,0,0,0,System Master,System Master

Reboot, and check for correct operation. If unsure of how to perform the above procedure please contact your local SSL

distributor or the SSL Service Department.

Upper

Mezzanine (spare) MADI (spare) MADI Blacklight Blacklight *

Lower

Mezzanine MADI MADI Blacklight Blacklight Blacklight MADI *

V2.0/7 Software Update

Page 7

C100 HDS Software Update

Page 8

Bug Fixes

The following is a list of the major bugs fixed or resolved in this release:

• PGM bus OLED meters above the faders are now pre-processing

• File synchronization and project integrity have been made more robust

•The HDS logo now appears on boot

• Occassional surface freeze has been fixed

• Morse routing is correctly retained when switching between main and redundant processors

• The mic gain – on a MORSE stagebox connected directly to the processor – displays it’s value correctly

• The channel gate no longer fully attenuates when the gate is switched in

• GPIO naming on systems with 2 RIOs now displays correctly

• Morse static output routes are no longer overwritten when switching between main and redundant processors

• The swap function now includes the channel input in the swap. Previously a copy was actioned

• When pressing attention keys to select ASGs or Auxes in the routing menu the attention keys now light

• The processor will now boot correctly if the the ethernet connection to the DAW is not present

• The change over switch now requires a press and hold to action changeover

• In the event of a main processor crash the changeover to the redundant system is actioned faster

• In the event of a dormant processor crash the changeover button on a console surface does not remain lit

• Fader starts on stereo channels are now saved in Control Linking

• Now responds to Morse router restart messages and re-sends mic gain, pad etc

• Added support for Morse router card changeover when ethernet to the active Morse controller card fails

• Clear warning about Morse router being offline from the status bar when its comes back online

• UOP TFT source names now correct respect whether Main or Alt input route is active

• Project Write Protect menu is now always visible when entering the Status Page

• Channel delays no longer introduce delay when dialled in but switched out

• Changeover switch now more reliable

• Routes which go over the 512 total IO slot limit are now permanently greyed out

• A potential system hang no longer possible when locking a channel to the surface

Otros manuales para C100 HDS

Tabla de contenidos

Otros manuales de Equipo de DJ de Solid State Logic

Solid State Logic

Solid State Logic C200 routing guide Manual de usuario

Solid State Logic

Solid State Logic AWS 900+ SE Manual de usuario

Solid State Logic

Solid State Logic Super-Analogue Outboard XR622 Manual de usuario

Solid State Logic

Solid State Logic C200 routing guide Manual de usuario

Solid State Logic

Solid State Logic C100 HDS Manual técnico

Solid State Logic

Solid State Logic C200 routing guide Manual de usuario

Solid State Logic

Solid State Logic Nucleus Manual de usuario

Solid State Logic

Solid State Logic LIVE Manual de usuario

Solid State Logic

Solid State Logic SSL UF8 Manual de usuario

Solid State Logic

Solid State Logic XLogic Alpha Channel Manual de usuario

Solid State Logic

Solid State Logic XL-Desk Manual de usuario

Solid State Logic

Solid State Logic Nucleus Manual de usuario

Solid State Logic

Solid State Logic AWS V4 Logictivity Manual de usuario

Solid State Logic

Solid State Logic SSL UF1 Manual de usuario

Solid State Logic

Solid State Logic Duality Manual de usuario

Solid State Logic

Solid State Logic AWS 900+ Manual de usuario

Manuales populares de Equipo de DJ de otras marcas

ALPHA LITE

ALPHA LITE ALPHA 1500 Manual del propietario

Chauvet

Chauvet OVATION E-930VW Manual de usuario

Zumtobel

Zumtobel APHRODITE Home Manual de usuario

Snow Masters

Snow Masters Zig Oscillator Manual de usuario

EuroLite

EuroLite 50530554 Manual de usuario

Beamz

Beamz BUV243 Manual de usuario

thomann

thomann Stairville DJ Lase 40-G MK-III Manual de usuario

Eagletone

Eagletone 6 Eyes Flower Manual de usuario

EuroLite

EuroLite FLD-1508 Manual de usuario

Technical Pro

Technical Pro LG8xSEA Manual de usuario

JB Systems

JB Systems Lounge Laser DMX Manual de usuario

Lightmaxx

Lightmaxx Vega Halo 90 Manual de usuario

Elation

Elation FUZE WASH Z350 Manual de usuario

Maverick

Maverick MK3 WASH Manual de usuario

Infinity

Infinity TF-260C7 Fresnel Manual de usuario

Chauvet

Chauvet EVE E-50Z Manual de usuario

Eliminator Lighting

Eliminator Lighting E 138 Manual de usuario

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Manual de usuario
