Parts Manual fo

22" VARIABLE SPEED 3N1

WALK BEHIND MOWERS

Revision: B 5/13/2011

Briggs & Stratton Yard Power Products Group

Manual No. 7104293

535 Macon Road

McDonough, GA, 30253 U.S.A.

800-935-2967

Descri

tionModel No.

780075

NSXPV2270

780075

NSXPV2270E

780070

SPXV2270

780070

SXPV2270E

Not for

Reproduction

Not for

Reproduction

Table Of Content

TP 400-5481-B-WB-N

22" VARIABLE SPEED 3N1

Manual No. 7104293

PAGE GROUP

4Handle & Controls Group (Manual Start)

6Drive Control Assembly (Manual Start)

8Handle & Controls Group (Electric Start)

10 Drive Control Assembly (Electric Start)

12 Mower Deck Group

14 Engine, Blade & Grass Bag Group

16 Transmission & Wheels Group

18 Decals Group

Not for

Reproduction

Manual No. 7104293 22" VARIABLE SPEED 3N1

Handle & Controls Group (Manual Start)

Not for

Reproduction

Footnotes:

Manual No. 710429322" VARIABLE SPEED 3N1

Handle & Controls Group (Manual Start)

Part No Descri

tionItem Qty

1 7090015 1 BOLT, 1/4-20 x 1-3/4” Round Head Square Neck, GR 2, YZ

2 7090391 4 WASHER, 5/16” Internal Tooth Lock

3 7090951 2 NUT, 5/16-18 Large Flange Center Lock

4 7091189 2 BOLT, 5/16-18 x 2” Curved Head Square Neck, GR 2

5 723873 2 BOLT, 5/16-18 x 3/4” Square Neck Carriage, GR 5

6 1931338 2 BOLT, 5/16-18 x 1-3/4” Round Head Square Neck Carriage

7 2860694 2 NUT, 1/4-20 Hex Flange (Esna), YZ

8 7024649 2 WIRE TIE, 11 Inch Standard Black Nylon

9 7101410 1 ROPE GUIDE, (1/4-20 thread)

10 7102990 4 KNOB, Handle, (5/16-18 internal threads) 5-Prong

11 7103774 1 METER, Service Indicator

12 7300649BH 2 HANDLE, Connecting, 21” / 22” WBM

13 7301189BH 1 HANDLE, Lower

14 7501967 1 ASSEMBLY, Drive Control, MY2010 Walk

7800707, 7800756 & 7800774

Not for

Reproduction

Manual No. 7104293 22" VARIABLE SPEED 3N1

Drive Control Assembly (Manual Start)

Not for

Reproduction

Footnotes:

Manual No. 710429322" VARIABLE SPEED 3N1

Drive Control Assembly (Manual Start)

Part No Descri

tionItem Qty

1 7091075 1 SCREW, #10-24 x 5/8” Hex Washer Self-Tap, GR 5 BZ

2 7091195 4 SCREW, #10-16 x 3/4” Pan Head Self-Tap Combo, BZ

3 1960593 1 NUT, #10-24 Speed Retainer w/extrusion

4 7102803 2 LEVER, Drive Control

5 7102804 2 LEVER, OPC, Control

6 7102805 1 CAM, Drive, LH

7 7102806 1 CAM, Drive, RH

8 7103325 1 CONTROL PANEL, Bottom, MY Mower

9 7103326 1 PANEL, Bottom Control, WBM, RH

10 7103327 1 PANEL, Bottom Control, WBM, LH

11 7103456 1 PANEL, Access, Maintenance Reminder

12 7104294 1 PANEL, Top Control

13 7104689 1 SPRING, Tension, Drive Control

14 7104752 1 CABLE, OPC, 2010 NXT

15 7105092 1 CABLE, Control, 2010 NXT (Was 7103770)

16 7900081 4 SCREW, #10-16 x 2” Hi-Lo Cross Pan Head

Model pt. #'s: 7800707, 7800756 & 7800774

Not for

Reproduction

Manual No. 7104293 22" VARIABLE SPEED 3N1

Handle & Controls Group (Electric Start)

Not for

Reproduction

Footnotes:

Manual No. 710429322" VARIABLE SPEED 3N1

Handle & Controls Group (Electric Start)

Part No Descri

tionItem Qty

1 7028765 1 SWITCH, ES, Start/Run

2 7102990 4 KNOB, Handle, (5/16-18 internal threads) 5-Prong

3 7090015 1 BOLT, 1/4-20 x 1-3/4” Round Head Square Neck, GR 2, YZ

4 7090391 4 WASHER, 5/16” Internal Tooth Lock

5 7090951 2 NUT, 5/16-18 Large Flange Center Lock

6 7091189 2 BOLT, 5/16-18 x 2” Curved Head Square Neck, GR 2

7 1931333 2 BOLT, 5/16-18 x 3/4” Round Head Short Square Neck Carriage, GR 5

8 2860694 2 NUT, 1/4-20 Hex Flange (Esna), YZ

9 7023506 1 BEZEL, Black

10 7024649 4 WIRE TIE, 11 Inch Standard Black Nylon

11 7101410 1 ROPE GUIDE, (1/4-20 thread)

12 7102931 1 BATTERY, 12V DC, 1.3A / HR

13 7103774 1 METER, Service Indicator

14 7104149 1 NUT, Plastic, 5/8-32

15 7300649BH 2 HANDLE, Connecting, 21” / 22” WBM

16 7301189BH 1 HANDLE, Lower

17 7502046 1 ASSEMBLY, Drive Control, Snapper Electric Start

18 1931338 2 BOLT, 5/16-18 x 1-3/4” Short Square Neck Carriage, GR 5

19 7011138 1 KEY, Ignition, Pair

20 7103988 1 CHARGER, Battery, 14V 260MA, 120V AC

Model pt. #'s: 7800708, 7800757 & 7800775

Not for

Reproduction

Manual No. 7104293 22" VARIABLE SPEED 3N1

Drive Control Assembly (Electric Start)
