Smeg LBE16 Manual de usuario

19 590 1488 00 1

Index Pag.

1. Instructions for unpack and transport 2

2. Plinth dismount 3

3. Rubber strap dismount 4

4. Rubber strap use 5

5. Door dismount 6

6. Cleaning 7

19 590 1488 00 2

1. Instruction for unpack and transport

NO NO

NO NO

YES YES

19 590 1488 00 3

2. Plinth dismount

1) With a screwdriver, makes lever on the points

…. 2) … indicated, with a movement from the bottom

to the upper …

3) in order to permit the plastic tooth, on the

plinth, to come out from the site 4) After the described operation on both sides,

proceed with the plinth dismount following the

order in picture.

5) For the assemblage of the plinth, follow the

order on the picture. 6) Finish the operation with a light pressare on

the points in picture. The “click” sound will

indicate that the plinth is assembled.

2

1

2

3

1

2

1

A

19 590 1488 00 4

3. Rubber strap dismount

1) For remove the rubber straps on the door 2) rotates the plastic terminal for 180° ….

3) … with a light pressure… 4) and the extract them.

19 590 1488 00 5

4. Rubber strap use

In picture, the possibility to insert some products in the vain can be appreciated …

ATTENTION:

Weight Max 4,0kg

… these products are of daily use, e.g. detergents, softener etc.

ATTENTION

This appliance is intended for use by adults.

Do not allow children to tamper with the controls or play with the washing machine.

Do not allow children to approach the appliance.

Keep children away from the appliance.

19 590 1488 00 6

5. Door dismount

1) For remove the door, unscrew the indicated

screw 2) on both the hinges (cross screwdriver)

SI

NO

3) support the door and extract … 4) .. the hinges from their sites.

19 590 1488 00 7

6. Instruction for cleaning

Instructions for the cleaning of the product:

The surfaces have to be cleaned with water and soft clothes (e.g. micro fiber)

Do not use never chemical products or aggressives (e.g. abrasives clothes, etc.)

YES NO

YES NO
