Instructions

1 Instructions

1.1 General safety instructions

Risk of personal injury

• During use the appliance and its

accessible parts become very

hot. Never touch the heating

elements during use.

• Protect your hands by wearing

oven gloves when moving food

inside the oven.

• Never try to put out a fire or

flames with water: turn off the

appliance and smother the

flames with a fire blanket or

other appropriate cover.

• This appliance may be used by

children aged at least 8 and by

people of reduced physical,

sensory or mental capacity, or

lacking in experience in the use

of electrical appliances,

provided that they are

supervised or instructed by

adults who are responsible for

their safety.

• Children must not play with the

appliance.

• Keep children under the age of

8 at a safe distance unless they

are constantly supervised.

• Keep children under the age of

8 away from the appliance

when it is in use.

• Cleaning and maintenance

must not be carried out by

unsupervised children.

• Make sure that the flame-

spreader crowns are correctly

positioned in their seats with

their respective burner caps.

• Be aware of how rapidly the

cooking zones heat up. Do not

place empty pans on the heat.

Danger of overheating.

• Cooking process should always

be kept under control. A short

cooking process must be

continuously surveyed.

Instructions

• Fats and oils can catch fire if

they overheat. Do not leave the

appliance unattended while

preparing foods containing oils

or fats. If fats or oils catch fire,

never put water on them. Place

the lid on the pan and turn off

the relevant cooking zone.

• While cooking do not place

metal objects, such as cutlery or

dishes on the hob surface as

they may overheat.

• Do not insert pointed metal

objects (cutlery or utensils) into

the slots in the appliance.

• Do not pour water directly on

very hot trays.

• Keep the oven door closed

during cooking.

• If you need to move food or at

the end of cooking, open the

door 5 cm for a few seconds,

let the steam come out, then

open it fully.

• Do not open the storage

compartment (where present)

when the oven is on and still hot.

• The items inside the storage

compartment could be very hot

after using the oven.

• Switch off the appliance after

use.

• Do not pull the cable to remove

the plug.

• DO NOT USE OR STORE

FLAMMABLE MATERIALS IN

THE STORAGE COMPART-

MENT (IF AVAILABLE) OR

NEAR THE APPLIANCE.

•DONOTUSEAEROSOLSIN

THE VICINITY OF THIS

APPLIANCE WHILST IT IS IN

USE.

• DO NOT MODIFY THIS

APPLIANCE.

• Before any operation on the

appliance (installation,

maintenance, positioning or

movement) always wear PPM.

Instructions

• Before performing any

operation on the appliance,

switch off the power supply.

• Have qualified personnel carry

out installation and assistance

interventions according to the

standards in force.

• Do not try to repair the

appliance yourself or without

the intervention of a qualified

technician.

• If the power supply cable is

damaged, contact technical

support immediately and they

will replace it.

Risk of damaging the appliance

• Do not use abrasive or

corrosive detergents (e.g.

scouring powders, stain

removers and metallic sponges)

on glass parts.

• Use wooden or plastic utensils.

• Do not use steam jets to clean

the appliance.

• Do not obstruct ventilation

openings and heat dispersal

slots.

• Do not sit on the appliance.

• Racks and trays should be

inserted as far as they will go

into the side guides. The

mechanical safety locks that

prevent them from being

removed must face downwards

and towards the back of the

oven.

• Never leave the appliance

unattended during cooking

operations where fats or oils

could overheat and take fire. Be

very careful

• Never leave objects on the

cooking surface.

• Do not spray any spray

products near the oven.

• DO NOT USE THE

APPLIANCE TO HEAT

ROOMS FOR ANY REASON.

•Donotuseplastic cookware or

containers for cooking.

• Do not place sealed tins or

containers in the oven cavity.

• Remove all trays and racks

which are not required during

cooking.

Instructions

• Do not cover the bottom of the

oven cavity with aluminium or tin

foil sheets.

• Do not place pans or trays

directly on the bottom of the

oven cavity.

• If you wish to use greaseproof

paper, place it so that it will not

interfere with the hot air

circulation inside the oven.

• Do not use the open door to

place pans or trays on the

internal glazing pane.

• Cooking vessels or griddle

plates should be placed inside

the perimeter of the hob.

• All pans must have smooth, flat

bottoms.

• If any liquid does boil over or

spill, remove the excess from the

hob.

• Take care not to spill acid

substances such as lemon juice

or vinegar on the hob.

• Do not use steam jets to clean

the appliance.

• Do not put empty pans or frying

pans on switched on cooking

zones.

• Do not use rough or abrasive

materials or sharp metal

scrapers.

• Do not use cleaning products

containing chlorine, ammonia

or bleach on parts made of

steel or that have metallic

surface finishes (e.g. anodizing,

nickel- or chromium-plating).

•Donotuseabrasiveor

corrosive detergents (e.g.

scouring powders, stain

removers and metallic sponges)

on glass parts.

• Do not wash the removable

components such as the hob

grids, flame-spreader crowns

and burner caps in a

dishwasher.

• Never use the oven door to

lever the appliance into place

when fitting.

• Avoid exerting too much

pressure on the door when

open.

• Do not use the handle to lift or

move this appliance.

Instructions

Installation

• THIS APPLIANCE MUST NOT

BE INSTALLED IN A BOAT OR

CARAVAN.

• This appliance must not be

installed on a pedestal.

• Position the appliance into the

cabinet cut-out with the help of

a second person.

• To prevent any possible

overheating, the appliance

should not be installed behind

a decoration door or a panel.

• Before installation, make sure

that the local distribution

conditions (nature and pressure

of the gas) and the adjustment

of the appliance are

compatible.

• This appliance is not connected

to an exhaust system for

combustion products. It must be

installed and connected in

compliance with the current

installation regulations. Special

attention should be paid to the

relevant requirements as for

ventilation.

• The adjustment conditions for

this appliance are shown on

the gas setting label.

• Have the gas connection

performed by authorised staff.

• Installation using a hose must

be carried out so that the length

of the hose does not exceed

2 metres when fully extended

for steel hoses and 1.5 metres

for rubber hoses.

• The hoses should not come into

contact with moving parts and

should not be crushed in any

way.

• If required, use a pressure

regulator that complies with

current regulations.

• After carrying out any

operation, check that the

tightening torque of gas

connections is between 10 Nm

and 15 Nm.

• At the end of the installation,

check for any leaks with a

soapy solution, never with a

flame.

Instructions

• Have the electrical connection

performed by authorised

technicians.

• The appliance must be

connected to ground in

compliance with electrical

system safety standards.

• Use cables withstanding a

temperature of at least 90 °C.

• The tightening torque of the

screws of the terminal board

leads must be 1.5 - 2 Nm.

For this appliance

• Ensure that the appliance is

switched off before replacing

the bulb.

• Do not rest any weight or sit on

the open door of the appliance.

• Take care that no objects are

stuck in the doors.

1.2 Manufacturer liability

The manufacturer declines all

liability for damage to persons or

property caused by:

• use of the appliance other than

that specified;

• failure to comply with the

instructions in the user manual;

• tampering with any part of the

appliance;

• use of non-original spare parts.

1.3 Appliance purpose

• This appliance is intended for

cooking food in the home

environment. Every other use is

considered inappropriate.

• The appliance is not designed

to operate with external timers

or with remote-control systems.

Instructions

1.4 Identification plate

The identification plate bears the

technical data, serial number and

brand name of the appliance. Do not

remove the identification plate for

any reason.

1.5 This user manual

This user manual is an integral part of

the appliance and must therefore be

kept in its entirety and within the

user’s reach for the whole working

life of the appliance.

Read this user manual carefully

before using the appliance.

1.6 Disposal

This appliance must be

disposed of separately from

other waste (Directives

2002/95/EC, 2002/96/EC,

2003/108/EC). The appliance

does not contain substances in

quantities sufficient to be considered

hazardous to health and the

environment, in accordance with

current European directives.

To dispose of the appliance:

• Cut the power supply cable and

remove it along with the plug.

Power voltage

Danger of electrocution

• Disconnect the mains power

supply.

• Unplug the appliance.

Instructions

• Deliver the appliance to the

appropriate recycling centre for

electrical and electronic

equipment waste, or return it to

the retailer when purchasing an

equivalent product, on a one for

one basis.

Our appliances are packaged in

non-polluting and recyclable

materials.

• Deliver the packing materials to

the appropriate recycling centre.

1.7 How to read the user manual

This user manual uses the following reading

conventions:

1. Sequence of instructions for use.

• Standalone instruction.

Plastic packaging

Danger of suffocation

• Do not leave the packaging or

any part of it unattended.

• Do not let children play with the

plastic bags.

Instructions

General information on this user

manual, on safety and final

disposal.

Description

Description of the appliance and its

accessories.

Use

Information on the use of the

appliance and its accessories.

Cleaning and maintenance

Information for proper cleaning and

maintenance of the appliance.

Installation

Information for the qualified

technician: Installation, operation

and inspection.

Safety instructions

Information

Advice

Description

2 Description

2.1 General Description

1 Upstand

2 Cooking hob

3 Control panel

4 Main oven light

5 Main oven seal

6 Main oven door

7 Main oven fan

8 Auxiliary oven light

9 Auxiliary oven seal

10 Auxiliary oven door

11 Storage compartment

Rack/tray support frames

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Estufa de Smeg

Smeg

Smeg SUK61MBL9 Manual de usuario

Smeg

Smeg TR93IX Manual de usuario

Smeg

Smeg Portofino CPF92IMA Manual de usuario

Smeg

Smeg Mista Aesthetic Manual de usuario

Smeg

Smeg SUK92CMX5 Manual de usuario

Smeg

Smeg FS67MFX Manual de usuario

Smeg

Smeg CB661EA Manual de usuario

Smeg

Smeg A42-5 Manual de usuario

Smeg

Smeg Classica CG90IANT9 Manual de usuario

Smeg

Smeg A41C-5 Manual de usuario

Smeg

Smeg C9MAXSSA9 Manual de usuario

Smeg

Smeg S9GMXU Manual de usuario

Smeg

Smeg SY92IPX9 Manual de usuario

Smeg

Smeg CBE66MF Guía de inicio rápido

Smeg

Smeg A2PYID-81 Manual de usuario

Smeg

Smeg Mista Aesthetic B601GMXI9 Manual de usuario

Smeg

Smeg AS5601 Manual de usuario

Smeg

Smeg BG91IX2 Manual de usuario

Smeg

Smeg CX 68 CM8 Manual de usuario

Smeg

Smeg CPF120IGMPX Manual de usuario

Smeg

Smeg Classica Concerto SSA92MAA9 Manual de usuario

Smeg

Smeg Victoria TR4110RW1 Manual de usuario

Smeg

Smeg A1BL-9 Manual de usuario

Smeg

Smeg Victoria TR90GR2 Manual de usuario

Manuales populares de Estufa de otras marcas

Modena

Modena FC 7645 SGM Manual del propietario

Electrolux

Electrolux Insight EKG6049 Manual de usuario

Stanley

Stanley Donard 60 Manual de usuario

Bartscher

Bartscher 201TC Manual de usuario

Parkinson Cowan

Parkinson Cowan 50 GR/BU Manual de usuario

Siemens

Siemens HK9P00020U Manual de usuario

Creda

Creda S150E Guía

Creda

Creda HB48309 Manual de usuario

Bosch

Bosch HCE743220F Manual de usuario

Tricity Bendix

Tricity Bendix SE545P Manual de usuario

NEFF

NEFF E1461A2/01 Manual de usuario

Zanussi

Zanussi ZCM 700 X Manual de usuario

RiverGrille

RiverGrille TF2002501-RG Manual de usuario

Vollrath

Vollrath 69504F Manual de usuario

Tricity Bendix

Tricity Bendix CSIE500 Manual de usuario

AEG

AEG Competence 5731 V Manual de usuario

Euromaid

Euromaid ES60 Manual de usuario

Hotpoint

Hotpoint HUI 62 TP Manual de usuario
