SmartDisk FireLite Manual de usuario

™

Simplifying The Digital Lifestyle™

FWFL UserGuide_Eng REV 1/19/04 12:04 PM Page 1

Preparing your FireLite: Mac OS or Windows? . . . . . . . . . . . . . . . . . . . .1

Using FireLite with Mac OS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installing Mac OS software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Connecting FireLite to a Macintosh Computer . . . . . . . . . . . . . . . . . . . . . .1

Storing and Transferring Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Disconnecting FireLite from a Macintosh Computer . . . . . . . . . . . . . . . . .2

Using FireLite with Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Connecting FireLite to a Windows Computer . . . . . . . . . . . . . . . . . . . . . .3

Storing and Transferring Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Disconnecting FireLite from a Windows Computer . . . . . . . . . . . . . . . . . .3

Formatting FireLite for Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Formatting FireLite under Windows XP or Windows 2000 . . . . . . . . . . . .4

Formatting FireLite under Windows ME or Windows 98 SE . . . . . . . . . .6

Formatting for Windows under Mac OS . . . . . . . . . . . . . . . . . . . . . . . . . . .7

For Mac OS 8.6 - 9.x Users Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

For Mac OS X Users Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

FAT32 OR NTFS? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

FAT32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 .

NTFS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Registering your SmartDisk product . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Warranty Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

FCC Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Guide de l'utilisateur sur CD

Guida per l'utente su CD

Benutzerhandbuch auf CD

Manual del usuario en CD

Handleiding op cd

FWFL UserGuide_Eng REV 1/19/04 12:04 PM Page 3

Preparing Your FireLite: Mac OS or

Windows?

Your FireLite comes pre-formatted for immediate use with Apple

Macintosh computers running Mac OS. (It is formatted as HFS+.) If

you plan to use your FireLite only with computers running Mac OS,

you can leave it formatted as it comes from the factory, and follow the

simple steps in Using FireLite with Mac OS to connect and use your

FireLite.

If you plan to use your FireLite with computers running Windows, or

with both Mac OS and Windows computers, you should reformat your

FireLite so it can be recognized by Windows before saving data to it.

(Mac OS can recognize hard drives formatted for Windows.) If this is

your situation, proceed first to Using FireLite with Windows to prepare

your FireLite. Then you can follow the guidelines in Using FireLite

with Mac OS if you also wish to use your FireLite with a computer

running Mac OS.

Using FireLite with Mac OS

Installing Mac OS Software

If you are using Mac OS X, there is no additional software to install.

Proceed to Connecting FireLite.

If you are using Mac OS 8.6 to 9.2.x, you should install the FireLite

software with the following steps. This will install SmartDisk Tools, a

utility program for Mac OS 8.6 to 9.x users that provides features such

as formatting, partitioning and encryption support. The installation

will also add an extension allowing your computer to detect and use

your SmartDisk hard drive. (Since these features and capabilities are

built into Mac OS X extensions and the Mac OS Disk Utility,

SmartDisk Tools is not applicable if you are running only Mac OS X.)

1. Insert the FireLite Installation CD into your CD-ROM drive.

2. Double-click the Install SmartDisk Tools icon.

3. Follow the on-screen instructions.

Connecting FireLite to a Macintosh Computer

Connect one end of the FireWire cable to an open FireWire port on

your Macintosh, and connect the other end of the cable to either one

of the FireWire ports on your SmartDisk hard drive. Your hard drive

will appear on the desktop as a new disk.

FWFL UserGuide_Eng REV 1/19/04 12:04 PM Page 4

Storing and Transferring Data

Once your SmartDisk hard drive is connected to a computer, it can be

accessed and used like any other removable disk. You can drag files

to your SmartDisk hard drive’s icon to copy them, navigate to your

hard drive in Open or Save dialog boxes, or delete files stored on your

SmartDisk hard drive. For information on copying, opening, or deleting

files, consult your computer’s documentation.

Disconnecting FireLite from a Macintosh Computer

Your SmartDisk hard drive is hot-pluggable; it can be connected and

disconnected without restarting your computer. To disconnect your

SmartDisk hard drive at any time, simply perform the following steps.

1. If you have files located on your SmartDisk hard drive open in

any application, close them.

2. Locate the icon for your SmartDisk hard drive on the desktop,

and drag it to the trash.

3. After the drive icon disappears from the desktop, you can safely

unplug the drive.

You may also simply shut down your computer with your SmartDisk

hard drive connected, and then disconnect it.

Using FireLite with Windows

Your SmartDisk hard drive comes pre-formatted as HFS+, the preferred

format when used exclusively with Apple Macintosh computers running

Mac OS. To use the hard drive on a Windows system you will need to

reformat your hard drive once so it can be recognized by Windows computers.

(It will still be recognized by Apple Macintosh computers, too.)

Follow the steps in the separate section Formatting FireLite for

Windows if you ever intend to use your SmartDisk hard drive with a

Windows computer. If you primarily use a Mac OS computer and wish

to share it with a Windows computer, you may find the steps outlined

in Formatting for Windows Under Mac OS a more convenient

procedure for preparing your SmartDisk hard drive for Windows use.

Note: Please be careful to follow the correct procedure when

disconnecting your SmartDisk hard drive. Simply unplugging the

hard drive without first following the instructions below may result

in damage to your hard drive and/or loss of data.

FWFL UserGuide_Eng REV 1/19/04 12:04 PM Page 5

Before proceeding, be sure that your Windows computer has a 6-pin

FireWire (1394a) port available. For convenience, your SmartDisk

hard drive draws its power from this cable. Some computers provide

4-pin FireWire ports only. Since 4-pin ports do not supply power, you

will need to obtain a 6-4 pin FireWire cable and separate A/C adapter

(SmartDisk model ACFWS) to use your SmartDisk hard drive with

this computer.

Connecting FireLite to a Windows Computer

Connect your SmartDisk hard drive to a Windows computer by plug-

ging one end of the FireWire cable to an open FireWire port on your

PC, and the other end of the cable to either one of the FireWire ports

on your hard drive. (If you are using an A/C adapter, plug it in as well.)

Your hard drive will appear on the desktop as a new disk.

Storing and Transferring Data

Once your properly formatted SmartDisk hard drive is connected to a

Windows computer, it can be accessed and used like any other removable

disk. You can drag files to your FireLite’s icon to copy them, navigate

to your FireLite in Open or Save dialog boxes, or delete files stored on

your SmartDisk hard drive. For information on copying, opening, or

deleting files, consult your computer’s documentation.

Disconnecting FireLite from a Windows Computer

Your SmartDisk hard drive is hot-pluggable; it can be connected and

disconnected without restarting your computer. To disconnect your

SmartDisk hard drive at any time, perform the following steps. You

can also disconnect your hard drive at any time while your computer

is powered off.

If you are using Windows 98 SE, and your computer prompts you

to insert the Windows 98 SE Installation CD after connecting your

hard drive, it means you need to install additional FireWire (1394)

support software from Microsoft. You should disconnect your hard

drive, then locate, download, and install the latest FireWire (1394)

drivers for Windows 98 SE from the Microsoft website

http://windowsupdate.microsoft.com.

FWFL UserGuide_Eng REV 1/19/04 12:04 PM Page 6

1. If you have files located on your SmartDisk hard drive open in

any application, close them.

2. Click the Unplug or Eject Hardware button in the System Tray.

3. Select your SmartDisk hard drive from the menu that appears.

4. After a moment, Windows will display a message indicating that

your hardware can be safely removed.

You may also simply shut down your computer with SmartDisk hard

drive connected, and then disconnect it.

Formatting FireLite for Windows

Follow the instructions below to format your SmartDisk hard drive for

use with Windows, or with both Windows and Mac OS. You will only

have to perform this procedure once. The required steps differ

depending on which version of Windows you are using while performing

the format. Follow the instructions for your version of Windows.

Formatting FireLite Under Windows XP or Windows

2000

Follow these steps if you are using Windows XP or Windows 2000

while formatting your SmartDisk hard drive for Windows.

1. Follow the instructions in Connecting FireLite to a Windows

Computer located earlier in this document.

2. Open the Disk Management utility as follows:

Formatting deletes all information on the drive. Double check each

step before execution to ensure that you are formatting the correct

drive. Information that is lost may be irretrievable.

Note: Please be careful to follow the correct procedure when

disconnecting your SmartDisk hard drive. Simply unplugging the

hard drive without first following the instructions below may result

in damage to your hard drive and/or loss of data.

FWFL UserGuide_Eng REV 1/19/04 12:04 PM Page 7

a. Click on the Start menu, then click Settings, and then click

Control Panel.

b.Double-click on Administrative Tools, and then double-click

on Computer Management.

c. In the Storage sub-directory, click on Disk Management.

3. The Write Signature and Upgrade Disk Wizard will start.

a. Click Next to continue the Wizard.

b. Select the SmartDisk hard drive from the list using the checkbox.

c. Click Next to continue.

d.Click Finish to write the signature to the hard drive.

4. The hard drive will be listed without a drive letter, and show as

"unallocated."

5. To create a partition, right click once on the unallocated area of

the hard drive box, and click on Create Partition.

6. The Create Partition Wizard will start.

a. Click Next to continue the Wizard.

b. Choose Primary or Extended Partition (Primary is recommended),

then click Next.

c. Enter the amount of disk space to be allocated (the partition

size). The default is the maximum available disk space

(recommended). Click Next..

d.Assign a drive letter or path (the default letter is recommended),

then click Next.

e. Select a file system to format the disk (FAT32 or NTFS), verify

the settings, and then click Next. Refer to the section FAT32

or NTFS? later in this document if you are not sure which to

choose.

f. Verify the settings, and then click Finish to begin formatting

the hard drive.

7. When formatting has finished, the hard drive will display the

volume name, the drive letter, the size of the partition (in GB),

It is recommended that you select the Perform Quick Format

checkbox. A standard format could take several hours.

Caution: Selecting the wrong drive at this point may

cause you to lose valuable data.

FWFL UserGuide_Eng REV 1/19/04 12:04 PM Page 8

the file system used (FAT32 or NTFS), and a healthy status.

The hard drive is now available to use.

Formatting FireLite Under Windows Me or Windows 98 SE

Follow these steps if you are using Windows Me or Windows 98 SE

while formatting your SmartDisk hard drive for Windows.

1. Follow the instructions in Connecting FireLite to a Windows

Computer located earlier in this document.

2. From the Start menu, click on Run, type command and press

Enter. You should see a small black MS DOS window with a

prompt such as c:\Windows.

3. Type fdisk and press Enter. Type Y(or just hit the Enter key) in

the window that asks if you wish to enable large disk support.

4. You will be presented with a menu of five items. You should

type 5to select the "Change current fixed disk drive" option

then hit the Enter key.

5. You will see a list of hard drives. Your main internal hard drive

will be Disk 1. Any other hard drives will be listed as 2, 3, etc.

If you have only one hard drive in your computer, drive 2 will

be the SmartDisk hard drive. You can also verify which drive on

the list is the SmartDisk hard drive by the size under Mbytes.

The number should be a little less than the size marked on the

product label of your SmartDisk hard drive. Type the number

that represents the SmartDisk hard drive and press Enter.

6. You now are presented with same menu of five items from step

4. This time, you must type 1(Create DOS partition or Logical

DOS drive) and hit Enter.

Caution: Selecting the wrong drive at this point may

cause you to lose valuable data.

Formatting deletes all information on the drive. Double check each

step before execution to ensure that you are formatting the correct

drive. Information that is lost may be irretrievable.

FWFL UserGuide_Eng REV 1/19/04 12:04 PM Page 9

7. At the next menu of three items, verify that you are partitioning

the correct disk number before proceeding. Type 1to select

Create Primary DOS Partition and press Enter. The resulting

process may take about a minute.

8. At the prompt Do you wish to use the maximum available size

for the Primary DOS partition? respond with yes (the default) or

just hit the Enter key. The resulting process may take about a

minute.

9. When the partitioning is complete hit the Esc key twice. You

will see a message that you must restart your PC. You can ignore

this message. Hit the Esc key once more to exit the fdisk program.

Type exit and press Enter to close the MS DOS Prompt window.

10. Double click the "My Computer" icon to open the window.

Unplug the SmartDisk hard drive and then reconnect it to your

PC. An icon with a drive letter should show up in the "My

Computer" window. You will also get a dialog box stating that

the drive is not accessible. Remember the drive letter as you will

need it in the next step. Click on Cancel.

11. You now need to format your SmartDisk hard drive. In the "My

Computer" window, point to the icon that represents the

SmartDisk hard drive and click the right mouse button. From the

menu select Format. At the format window select Full under

Format Type and type any label (10 characters or fewer) if you

choose. Click the Start button. You will see a warning that all

files will be destroyed. Click OK to proceed. This process will

take several minutes. Once complete, click the Close buttons and

you are done.

You may be prompted to run Scandisk to check your disk, but this is

not required. If you choose to do this, you should select Thorough

under Type of Test since there are no files or folders on the disk yet.

Be prepared to wait a long time to complete this test.

The hard drive is now available to use.

Formatting for Windows Under Mac OS

It is possible to format your SmartDisk hard drive in FAT32 format

while connected to an Apple Macintosh computer running Mac OS.

This may be a convenient method if you primarily use your SmartDisk

hard drive on a Mac OS computer, but want to later connect it to a

Windows computer as well. 7

FWFL UserGuide_Eng REV 1/19/04 12:04 PM Page 10

For Mac OS 8.6 - 9.x Users Only

Open SmartDisk Tools, and click on the Format tab. Within the

Format tab, click on Custom setup. Change the Partition Scheme to

DOS (this will change the format field to DOS), and click Initialize.

Wait for the initialization to complete. Your drive is now ready to be

connected to a Windows operating system.

For Mac OS X Users Only

Your SmartDisk hard drive can be formatted and partitioned using

Apple’s Disk Utility, located in your Utilities folder. Under Disk and

Volumes Selected, select the appropriate drive, and click on the

Partition tab. Under Volume Information, expand the Format field and

choose Free Space. Click on the Erase tab, expand the Volume Format

field, and click MS-DOS File System. Click Erase and wait for the

Erase to complete. Your drive is now ready to be connected to a

Windows operating system.

FAT32 or NTFS?

When formatting your SmartDisk hard drive while running Windows

XP or Windows 2000, you will have the choice between FAT32 and

NTFS formats. Following are some considerations for making your

choice.

FAT32

FAT32 is compatible with the following Windows operating systems:

Windows 98, Windows 98 SE, Windows Me, Windows 2000,

Windows XP. FAT32 can also be read by Apple Macintosh

computers running Mac OS.

Limitations: Under Windows 2000 and Windows XP users will not

be able to create partition sizes larger than 32GB (though they can

access these larger partitions). (This limitation does not apply to

other supported operating systems.)

In general, FAT32 is a good choice if you’ll be using your

SmartDisk hard drive with computers running Windows 98,

Windows 98 SE, or Windows Me, or if you’ll be using it with both

Windows and Mac OS computers.

NTFS

NTFS is compatible with the following Windows operating systems:

Windows NT, Windows 2000, and Windows XP. NTFS usually

results in higher performance than FAT32, and will permit users to

create partition sizes larger than 32GB under supported operating

systems. 8

FWFL UserGuide_Eng REV 1/19/04 12:04 PM Page 11

Otros manuales para FireLite

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Almacenamiento de SmartDisk

SmartDisk

SmartDisk FireFly USBFF05P Manual de usuario

SmartDisk

SmartDisk NetDisk Manual de usuario

SmartDisk

SmartDisk Rover none Manual de usuario

SmartDisk

SmartDisk FireLite FireWire 800 Manual de usuario

SmartDisk

SmartDisk FireLite USBFL Series Manual de usuario

SmartDisk

SmartDisk FotoChute Portable Hard Drive Manual de usuario

SmartDisk

SmartDisk FireLite XPress Manual de usuario

SmartDisk

SmartDisk FireFly Computer Hard Drive Manual de usuario

SmartDisk

SmartDisk FireLite Manual de usuario

SmartDisk

SmartDisk FireLite Manual de usuario

SmartDisk

SmartDisk FireLite Manual de usuario

Manuales populares de Almacenamiento de otras marcas

QNAP

QNAP TS 32PXU Series Manual de usuario

LaCie

LaCie RUGGED RAID Manual de usuario

Freecom

Freecom CLS DOCK Manual de usuario

PNY

PNY Attache P-FD64MBATT3 Manual de usuario

HP StorageWorks MSL2024 Manual de usuario

OLT

OLT 6x6 Maximizer Manual de usuario

Transcend

Transcend JetFlash 160 Manual de usuario

LaCie

LaCie RUGGED MINI Manual de usuario

Thunderbolt

Thunderbolt 600 Manual de usuario

Panasonic

Panasonic LB-DH8 series Manual

Intel

Intel RAID High Availability Manual de usuario

LaCie

LaCie 12big Thunderbolt 3 Manual de usuario

Spectra Logic

Spectra Logic T-Series Spectra T50e Manual de usuario

Panasonic

Panasonic LKM-F931-1 Manual de usuario

Tabernus

Tabernus Enterprise Erase E2400 Manual de usuario

Rocstor

Rocstor COMMANDER 3F series Manual de usuario

HP P9000 Manual de usuario

Western Digital

Western Digital Ultrastar Data60 Manual de usuario
