Skytech 5301 Instrucciones de funcionamiento e instalación

5301 Operation description

Date: 2007-11-14

Author: Javy Huang

zLCD Diagram

zLCD Indicator:

1. ON / THERMO / OFF: Indicates operation MODE of system.

zON indicates the system is on, either manually or thermostatically.

zOFF indicates the entire system is turned off.

zTHERMO indicates the system will automatically cycle on/off,

depending on programmed.

2. System ON flame: Indicates whether system ON or not.

3. Clock: Indicates the current time in AM/PM.

4. Low Battery: Battery power is low. Replace batteries within two weeks.

5. Reserve Flame Icon : Reserved for providing multiple flame modulation

levels by providing a variable current output to specific modulation device.

6. ROOM °F OR °C: Indicates current room temperature.

7. Child Proof: Lock-out operation of the appliance.

8. SET °F OR °C: Appears the desired temperature to indicate setting room

temperature during the time of setting in the thermo operation.

9. Timer: Indicates time remaining before system shuts off, when

timer-programmed; 9-hour maximum setting.

10. Timer ON/OFF: Indicates whether timer activate or not.

11. Reserve Fan Icon : Reserved for providing multiple fan modulation levels

by providing a variable current output to specific modulation device.

1. Button Description:

1) Mode/Set or (Touch Panel Region): To operate

the system in the manual mode, ON/ ON THERMO/ THERMO OFF/ OFF.

2) Mode/Set: The Set is activate in Initial Setting mode or Timer Countdown

mode that is accept the setting.

3) UP/DOWN:

¾To adjust the values, Clock/ Timer/ Set Temperature/ Set Swing.

¾Setting °F / °C scale: Press and hold the UP button and the DOWN

button on the transmitter at the same time. Follow this same procedure

to change from °C back to °F . When changing between the °F and °C

scales, the temperature in the SET frame defaults to the lowest

temperature (45°F, or 6°C ). The highest SET temperature is

99°Fahrenheit (32°Celsius).

4) (Touch Panel Region):

¾To enable/ disable timer in TIMER Countdown mode activate.

¾Press and hold it for more than two seconds to enter the clock setting

and accept the clock setting to quit the clock setting mode.

5) Child Proof Lockout: To activate/disengage the child-proof lockout feature,

press and hold and “UP” buttons for 5 seconds, “ ” will

briefly appear/disappear on screen.

6) Swing Setting: Press the and “DOWN” buttons simultaneously

to enter Swing Setting mode.

zOperation Description:

1. Mode:

zON OPERATION: Press the “MODE” key into the ON mode. The

appliance flame will come on. During this time the screen will show

ON and System ON flame. The TIMER function will be activated.

zTHERMO OPERATION: Press the “MODE” key into the THERMO

mode. The transmitter will check the ROOM temperature and SET

temperature to decide the situation ON THERMO or THERMO OFF.

After 2 seconds the LCD screen will display the situation by

temperature detected that is comparing with the SWING temperature

scale.

zOFF OPERATION: Press the “MODE” key into the OFF mode. The

appliance flame will shut off. During this time the screen will show

OFF. The TIMER function will be shut down.

2. THERMOSTAT FUNCTION:

zSETTING DESIRED ROOM TEMPERATURE: This remote control

system can be thermostatically controlled when the transmitter is in the

THERMO mode. To set the THERMO MODE and DESIRED room

temperature, During the THERMO mode, Press “Up” / “DOWN” key

the LCD screen set numbers will increase / decrease between 45° and

99° Fahrenheit.

zTHERMO ON situation: During this mode the screen will display the

set flame/valve at the same time enable the TIMER function setting.

zTHERMO OFF situation: During the situation the TIMER function

will be shut down.

3. Setting Swing:

zTo change the temperature “SWING” setting (1-3), press the

TIMER/TIME and DOWN buttons simultaneously to display the

current “SWING” setting in the SET TEMP frame. The letter “S” will

display in the ROOM TEMP frame on the LCD screen.

zPress the UP or DOWN button to change the temperature differential

or “SWING” (1-3). See above for 1-3 “SWING” temperature valves.

zTo store the “swing number press the SET button or allow 15 seconds

to lapse, and the new “swing number” will be automatically

programmed.

4. Child Proof “Lock-out”:

zTo activate the “LOCK-OUT” feature, press and hold the UP and

TIMER/TIME buttons, together, for 5 seconds. The will appear

on the LCD screen.

zTo disengage the “LOCK-OUT”, press and hold the UP and TIMER

buttons, together for 5 seconds or more, and the will disappear

from the LCD screen and the transmitter will return to its normal

operating condition.

5. Low Battery ( ) will appear when battery power has dropped

significantly.

6. The System Icon ( ) will be showed if the system is ON.

7. The room temperature always shows on screen, which

range between 32 and 99 Fahrenheit.

8. The Child Proof ( ) will appear on screen if the “Lock-out” Feature is

activation.

9. The Flame icon ( ) , the main flame indicates burner/valve in

operation and additional flame is reserved for specific modulation device.

10. The Fan icon ( ) is reserved for specific modulation device.

zFurther Description

1) Radio Frequency range: 303.8MHZ

2) The remote receiver is SR 1001.

3) The remote controller effective distance is above 40 feet.

FCC Compliance Statement:

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and (2)

This device must accept any interference received, including interference that may

cause undesired operation.

Note: The manufacturer is not responsible for any radio or TV interference caused by

unauthorized modifications to this equipment. Such modifications could void the

user’s authority to operate the equipment.
