SINTERIT SANDBLASTER SLS Instrucciones de operación

Sinterit SANDBLASTER SLS

ORIGINAL MANUAL

Please read the instruction manual before using the device.

Version 7/2021

2 | Sinterit SANDBLASTER SLS User Manual

Table of contents

1. Marking text conventions used in a document .......................................................................................................3

2. Safety Information..................................................................................................................................................4

2.1 Environment and place of installation ......................................................................................................................... 4

2.2 General safety rules....................................................................................................................................................... 4

2.3 Personal protection....................................................................................................................................................... 4

2.4 Power supply ................................................................................................................................................................. 5

2.5 Safety during sandblasting, repair and maintenance.................................................................................................. 5

2.6 Scrapping ....................................................................................................................................................................... 5

3. Contents of the Sinterit SANDBLASTER SLS pack...................................................................................................6

3.1 Accessories box ............................................................................................................................................................ 6

3.2 Others accessories ....................................................................................................................................................... 6

4. Sinterit SANDBLASTER SLS....................................................................................................................................7

4.1 Description..................................................................................................................................................................... 7

4.2 Specication .................................................................................................................................................................. 8

4.3 Safety plate.................................................................................................................................................................... 9

5. Initial startup of the Sinterit SANDBLASTER SLS after delivery .................................................................................

6. Sandblasting the printouts....................................................................................................................................12

7. Maintenance of the Sinterit SANDBLASTER SLS ..................................................................................................14

7.1 Replacement of the Abrasive material....................................................................................................................... 14

7.1.1 Exchange of Abrasive material with Sinterit ATEX Vacuum Cleaner............................................................. 15

7.1.2 Standard exchange of Abrasive Material......................................................................................................... 15

7.2 Replacement of the ceramic nozzle from the inner air blow gun............................................................................. 16

7.3 Replacement of protective rubber gloves.................................................................................................................. 16

7.4 Maintenance of the Viewing window ......................................................................................................................... 16

9. General legal information .....................................................................................................................................18

10. Disclaimer ..........................................................................................................................................................18

11. Trademarks ........................................................................................................................................................18

12. Terms of warranty...............................................................................................................................................19

13. Technical support ...............................................................................................................................................19

The SANDBLASTER SLS is designed for cleaning, polishing and nishing of printouts, using dry abrasive material only.

IMPORTANT!

Sandblaster does not include an air compressor.

Sinterit SANDBLASTER SLS User Manual | 3

1. Marking text conventions used in a document

Listed below are descriptions of symbols used on the device. They constitute a warning or convey the information to

protect the user, other individuals or surrounding objects and ensure the correct and safe use of the device.

WARNING!

An inevitably dangerous situation which can result in serious injury or even death. Initiation

or omission of a specic procedure or inattention can cause severe physical injury to the

user.

ATTENTION!

Initiation or omission of a specic procedure can cause physical damage to the equipment

or the user.

ATTENTION!

Risk of electric shock which can be fatal or cause severe burns. An inevitably dangerous

situation which can result in serious injury or even death, if not mitigated. Before working

with any equipment, you should be aware of the dangers associated with the ow of

electric current, and become familiar with the standard procedures to prevent accidents.

CAUTION!

Beware of moving parts which can crush hands.

WARNING!

Risk of re and explosion!

Avoid re! Powder dust is ammable.

STOP!

Action prohibited.

ATTENTION!

It is necessary to wear protective gloves and a face mask. Mandatory action when working

with powder.

ATTENTION!

It is necessary to wash hands after each use of the SANDBLASTER SLS.

IMPORTANT!

Information essential to correctly perform a specic task.

IMPORTANT!

You must read the instructions before taking action.

4 | Sinterit SANDBLASTER SLS User Manual

2. Safety Information

The Sinterit SANDBLASTER SLS may create a powerful stream of abrasive particles. To avoid injuries and/or property

damage, carefully read the instruction manual before assembling, operating or performing maintenance of the sandblaster.

While operating the machine, please exercise your common sense at all times.

2.1 Environment and place of installation

WARNING!

• The sandblaster must be positioned protected against atmospheric agents (rain, hail, snow,

fog, dust in suspension, etc.) with an environmental running temperature between 5°C and

45°C and relative humidity not above 70%.

• The work environment must be clean, well-enough lit and devoid of an explosive atmosphere.

• Debris and bad lighting are factors that can cause dangerous situations.

• Never operate this machine in a dangerous working environment. The use of power

equipment in moist environments or rain can cause electrocution.

• Place the unit on a solid and level surface.

2.2 General safety rules

WARNING!

• Only adults should use the sandblaster.

• When using the machine, mind other people, especially children. Keep kids and visitors at a

safe distance.

WARNING!

• Fire and explosion hazard! The sandblaster must not be operated in a

corrosive or explosive environment.

• Avoid prolonged contact with solvents and inhaling their vapours.

• Avoid using the device near open ames.

• Never use this machine near ammable liquids and/or gases.

2.3 Personal protection

WARNING!

• The operator must always wear antistatic clothes and shoes.

• Workplace ooring must be anti-static.

WARNING!

• During operation, do not expose your skin or hands directly to the line of

operation of the Sinterit SANDBLASTER SLS Static nozzle 20 and Air blow

guns L, 22 .

• Wear a protective mask when working with the sandblaster.

• Breathing in particulate matter causes serious lung problems.

• Wear Protective Glasses when opening the door after using the machine.

ATTENTION!

After each use of the Sinterit SANDBLASTER SLS, wash your hands.

Sinterit SANDBLASTER SLS User Manual | 5

2.4 Power supply

WARNING!

• Before plugging in, make sure the power voltage and frequency match those

shown on the machine safety plate.

• Make sure the machine is properly grounded. In case you are using an

extension, check if it is grounded and if the capacity is sucient.

• During use, mind the power supply cables and avoid crushing or pulling them.

• Periodically check the mains power cable to ensure it is not damaged.

• In the event of the cable, plugs or couplings being replaced, make sure these

are protected against water spray and check mechanical strength.

STOP!

• Never touch electric cables, switches, buttons, etc. with wet hands.

• In the event of the cable being damaged, the machine must not be used.

• Never pull the on the power cable to move the machine around.

2.5 Safety during sandblasting, repair and maintenance

ATTENTION!

• Check the quality of all hoses and pneumatic tubing before each use. Check that all

connections are secured.

• Check the machine previous to each use for damaged and/or defect parts. Pay special

attention if all seals are still good and check all tubings for leakages.

• Check that all components of the Sinterit SANDBLASTER SLS are properly sealed.

• Check the machine for defects previous to each use, in case of a defect, or when the machine

does not function properly, rst have it repaired by a specialized person/company.

• Failure to heed these instructions may cause damage to materials and/or injures!

ATTENTION!

• Do not direct the Air Blow Guns L, 22 at people or objects.

• Do not exceed the maximum operating pressure of the Sinterit SANDBLASTER SLS.

2.6 Scrapping

IMPORTANT!

In case of scrapping, all the component parts of the sandblaster will have to be

disposed of through adequate disposal channels in accordance with applicable

legislation. Before scrapping, all plastic and rubber parts will have to be separated

from the electrical material. Parts made of plastic, aluminium and steel only may

be recycled if collected by special centres.

6 | Sinterit SANDBLASTER SLS User Manual

3. Contents of the Sinterit SANDBLASTER SLS pack

ABRASIVE

MATERIAL

8 kg

ACCESSORIES

Sinterit SANDBLASTER SLS

ORIGINAL MANUAL

Readthe instruction manual before using the device.

Version 7/2021

3.1 Accessories box

APower supply (US or EU version with proper plug) / BWrench 10mm / CWrench 14mm /

DReplaceable ceramic nozzle for Inner air blow gun (3 pcs.) / ERubber grommet / F Air lter / GAllen wrench /

HFilter screw / IAir blow gun pneumatic tubing / JCompressor pneumatic tubing /

KAdjustable mounting feet (4 pcs.) / LAir blow gun / MSpare protective rubber gloves /

NT-type push-in pneumatic tting / OPVC foam tape / PPVC protective tape / RPipe end cap

3.2 Others accessories

SControl pedal’s pneumatic tubings / TControl pedal /

UReplaceable PE protective foil for SANDBLASTER SLS viewing window (5 pcs.)

Sinterit SANDBLASTER SLS User Manual | 7

4. Sinterit SANDBLASTER SLS

4.1 Description

Front and left side view

1Power switch

2Pneumatic pressure regulator

3Viewing window

4Protective rubber gloves

5Pressure gauge

6Door locks

Front and right side view

7Door gasket

8Door

9Sandblaster chamber

10 Gutter

13 Rear and left side view

11 Air lter

12 Pneumatic nipple

13 Antistatic hose socket

14 Antistatic hose

15 Control pedal jack port

16 Power socket

17 Adjustable mounting feet (4 pcs.)

Chamber view

18 LED light

19 PE protective foils for the viewing

window (5 pcs.)

20 Static nozzle

21 Static nozzle pneumatic tubings

22 Inner air blow gun

23 Inner air blow gun pneumatic tubings

24 Inner chamber grid

25 Inner T-type push-in pneumatic tting

(for Inner air blow gun)

19 18

8 | Sinterit SANDBLASTER SLS User Manual

4.2 Specification

GENERAL

Category Cabinet Sandblaster

Type Stationary, operated via a foot pedal

Warranty One-year limited warranty

Dimensions 700 x 550 x 720 [mm] (27.6 x 21.7 x 28.3 [in])

Size of internal mesh 6 x 6 [mm] (0.2 x 0.2 [in])

Weight 30.5 [kg] (67.1 [lbs])

TECHNICAL DATA

Working Area 675 x 450 x 415 [mm] (26.6 x 17.7 x 16.3 [in])

Capacity of Abrasive material 10 [kg] (22 [lbs])

Operating Voltage 110 / 230 [V] AC, 50/60 [Hz]

Maximum power consumption 8 [W]

Working pressure 5.0 – 8.6 [bar] / 72.5 – 125.0 [psi]

Min. ow 290 [l/min]

Filter type HEPA

SAFETY

Certicates CE

PACKAGING

Size 790 x 545 x 765 [mm] (31.1 x 21.5 x 30.1 [in])

Weight 45 [kg] (99.0 [lbs])

Package contains Sandblaster, 8 [kg] (17.6 [lbs]) of abrasive material, manual and accessories

Sinterit SANDBLASTER SLS User Manual | 9

4.3 Safety plate

DO NOT REMOVE THIS LABEL!

Manufacturer:

Sinterit sp. z o.o. ul. Nad Drwiną 10 bud. B3, 30-741 Kraków,

Poland

www.sinterit.com [email protected]

Name: Sinterit SANDBLASTER SLS

Serial number:

Manufactured: Made in: EU, POLAND

Class 2

IP60

Machine type: ABRASIVE PRESSURE BLAST CABINET 110 [L]

Dimensions: 700 x 550 x 720 [mm] 27.6 x 21.7 x 28.3 [in]

Total weight: 30.5 [kg] 67.1 [lb]

Rated voltage: 230 [V] AC, 50 [Hz] 120 [V] AC, 60 [Hz]

Power consumption: 8 [W]

Ceramic nozzle diameter: 4, 5, 6, 7 [mm] 0.15, 0.19, 0.23, 0.27 [in]

Abrasive material loading capacity: 10 [kg] 22 [lb]

Max. ow rate: 420 [l/min]

Working pressure: 5.0 – 8.6 [bar] 72.5 – 125.0 [psi]

Working area: 675 x 450 x 415 [mm] 26.6 x 17.7 x 16.3 [in]

WARNING! Read and understand operator’s manual and all other safety instructions before using this

machine. Failure to follow operating instructions could result in serious injury.

5. Initial startup of the Sinterit SANDBLASTER SLS after delivery

1. Remove the protective packaging.

2. Gently pull out the contents of the packaging.

3. Remove the bubble wrap and place the machine on a stable surface.

4. Screw the Adjustable mounting feet K, 17 onto the sandblaster.

5. Take out accessories from the box.

6. Unlock both door locks 6and open the door 8.

Remove from inside:

• Transport protection

• Contol pedal’s pneumatic tubings J

• Control pedal K

• Replaceable PE protective foils N

• Accessories box

Check the tting and tightness of:

• Protective Rubber Gloves 6

• Inner Pneumatic tubings 21 , 23

• Static Nozzle 19

• Door gasket 11

7. Screw on the Air lter Fusing the

Filter screw H. Use the allen wrench G

included in the accessories box.

H E F

8. You can use Sandblaster SLS with or without Sinterit ATEX Vacuum Cleaner.

10 | Sinterit SANDBLASTER SLS User Manual

• Sandblasting with Sinterit ATEX Vacuum

Cleaner

Insert Antistatic hose 14 into the Vacuum

Cleaners Suction hose connector.

R• Sandblasting without Sinterit ATEX Vacuum

Cleaner

Detach the Antistatic hose 14 from the

Sandblaster SLS using a 10 mm Wrench B.

Insert the Pipe end cap Rinto the Antistatic

hose socket 13 .

IMPORTANT!

Sandblasting with ATEX Vacuum Cleaner to provide a dustless environment around and inside

the Sandblaster. Please check our website or contact our distributors for more information.

9. Plug the Power supply Ainto the Power socket 16 .

10. Remove the transport protection (plastic cable ties) from the Inner Air blow gun 22 .

11. Connect the compressor and external Air blow gun (Image 5):

a. Connect the T-type push-in pneumatic tting Nto the Pneumatic nipple 12 , and then, on both sides, the

Pneumatic tubings I,J.

b. Plug the Air blow gun Linto the left tubing and the compressor into the right tubing.

COMPRESSOR

N14

Image 5. Correct connection of the compressor and external Air blow gun.

Tabla de contenidos

Otros manuales de Equipos industriales de SINTERIT

SINTERIT

SINTERIT POWDER HANDLING STATION Manual de usuario

SINTERIT

SINTERIT POWDER SIEVE Manual de usuario

Manuales populares de Equipos industriales de otras marcas

ABB

ABB Unifix AD Manual

Mark 7

Mark 7 Evolution Manual de usuario

Husky

Husky HyPET Manual de usuario

bora

bora PM-1800 Manual de usuario

Grizzly

Grizzly T32428 Manual de usuario

Siemens

Siemens 8MF1 Series Manual de usuario

ABB

ABB HT610965 Manual de usuario

ABB

ABB SafeLink Manual de usuario

Phoenix

Phoenix PHX-150 Manual de usuario

ABB

ABB A165-L32 Manual de usuario

ABB

ABB HT842936 Manual de usuario

Rioned

Rioned UrbanJet Manual de usuario

Hermetica

Hermetica 10 Series Manual de usuario

HORNER

HORNER OEE Solution Manual de usuario

Hammerhead

Hammerhead HG375 Manual de usuario

SCHUNK

SCHUNK VERO-S NSE-A3 138 Instrucciones de uso

ABB

ABB HT566657 Manual de usuario

Webasto

Webasto GSE CAN Manual de usuario
