Singer QUANTUM L-500 Manual de usuario

Feature Benefit

401 Built-in Stitch

Patterns

Fulfill your creative dreams with a large selection stitches including basic,

decorative and stretch stitches for clothing construction, quilting, home décor,

and crafting.

Large Back-Lit LCD

Screen with Brightness

Control

Provides clear and easy viewing of stitch functions including stitch width and

length, tension settings, and the recommended presser foot.

Four Memory Modules Four Memory Modules each hold up to 20 entries. Place names, simple

phrases and decorative stitch sequences in each of these four modules, then

retrieve them anytime you want to personalize your projects.

Mirror Imaging and

Elongation Function

With just a touch of a button selected stitches can be mirrored imaged, add-

ing even more stitch variety. Want to make a stitch longer yet keep the stitch

intact? Select the Elongation button and select stitches can be made 1, 2, 3,

4, or 5 times longer.

Start/Stop Button Unplug the foot control, press the Start button and the machine sews. You

are still in complete control over the speed - just slide the Speed Limiting

Lever to the desired speed.

Automatic Thread Cutter Press the thread cutter button and the machine automatically trims threads

when you are done sewing.

Automatic Needle

Threader Makes threading the needle quick and painless.

Heavy Duty Metal Frame The internal skeleton of the sewing machine is constructed of heavy duty

metal. This rigid support holds all the mechanisms in perfect alignment for

skip-free sewing and overall durability.

Dual Feed System Feeds the top and bottom simultaneously ensuring that the fabric layers feed

evenly.

Long Arm Design The extended sewing bed makes quilting and big projects easier to handle.

Quantum L-500

Feature Benefit

2 Built-In Alphabets

Personalize projects by adding a monogram, name or phrase with the

built-in block or script style alphabets, both available in upper and lower

case.

Horizontal Threading

Quality stitches begin with proper thread delivery. Placing the thread

spool in the horizontal position allows for the thread to feed more

evenly, reducing poor stitch formation and thread breakage.

Key Lock Function Lock in a function and stitch selection to prevent stitch settings from

accidentally being changed.

Pattern Balance Adjustment This function allows you to manually even out decorative stitches.

Programmable Needle

Up/Down

The needle can be programmed to stop in the highest up position when

your foot is lifted from the controller, making it easier for removing the

fabric from the machine Or program the needle to stop in the down posi-

tion, which is ideal for pivoting, appliquéing or quilting.

10 Fully Automatic

1-Step Buttonholes

Buttonhole sewing is a one-step simple process, providing reliable re-

sults every time.

Built-In Stretch Stitches

Specially designed stitches that add strength and flexibility to seams,

especially useful when sewing on knitwear and super-stretch fabrics.

Adjustable Stitch Length

Automatic settings for length can be overridden to personalize length

choice.

Adjustable Stitch Width

Automatic settings for width can be overridden to personalize width

choice.

Quantum L-500

Feature Benefit

Center Zigzag Taper

When tapering with the zigzag stitch, the stitch tapers to the center,

not the left or right. This feature is especially valuable when appliqué-

ing, because it provides a more attractive look when tapering into or

out from a point.

Automatic Locking

Stitch Function

Tie-off decorative and utility stitches with just a push of a button. With

3 tiny tacking stitches, patterns and stitches are reinforced. This

ensures quality stitching and prevents unraveling.

Automatic Reverse

Push the conveniently located Automatic Reverse Button to sew in

reverse and reinforce the stitch.

9mm Stitch Width Most stitches can be set for a maximum width of 7mm creating

more pronounced satin and decorative stitches.

Electronic Twin

Needle Control Stitches are automatically adjusted for twin needle sewing with just the

touch of a button.

90 Needle Positions

Needle position can be changed for individual projects like inserting

zippers or cording and topstitching.

Editing Capabilities When placing letters or stitches in the Memory Modules, it is easy to

make changes or replace your selections.

Error Warning

An audible warning alerts the sewer if something is incorrect. The

audible warning can be deactivated, if desired.

Pattern Override Memory Select a pattern, override the width and/or length, place the stitch in a

Memory Module, and the machine will remember those changes for

future use.

Increased Sewing Speed

With a maximum sewing speed of 1,000 stitches-per-minute, projects

can be sewn quickly.

Independent Bobbin

Winder Motor Allows you to wind a bobbin during sewing.

Quantum L-500

Feature Benefit

Automatic Tension This system ensures stable stitch quality, whatever type of fabric is be-

ing sewn. The tension can be adjusted using the tension adjustment

buttons.

Extra-High Presser Foot Lifter The Presser Foot Lifter has two heights. The second offers more

clearance, which is needed when placing multiple layers of bulky fabric

under the presser foot.

Free Arm

Provides professional results and easy access to cuffs, collars, pant

hems and other difficult-to-reach areas.

Presser Foot

Pressure Adjustment Manually control the amount of pressure placed on the fabric by the

presser foot.

Presser Foot Knee Lifter Control the presser foot lift with the handy knee attachment allowing

more hands-on fabric control.

Drop Feed

A conveniently located lever, when easily and effortlessly moved, will

lower the feed dogs for free-motion embroidery, monograms and for

sewing buttons.

Warning Animation A picture appears on the LCD screen illustrating the probable error.

On Board Storage The accessories are conveniently stored in the removable sewing table,

providing easy access to accessories.

Snap-On Presser Feet Easily change snap-on presser feet without use of a screwdriver.

Optimum Power Control

A control system that senses when additional power is required to

maintain speed through thick or changing fabric conditions. This fea-

ture is most useful when sewing through multiple (6-8) layers of fabric.

Quantum L-500

Feature Benefit

DC Motor Provides instant start up and stop with no coasting, for accurate and

precise stitch placement.

Electronic Foot Pedal Guarantees consistent sewing speed with no jump starts.

Accessories

All Purpose Foot

Zipper Foot

Button Sewing Foot

Satin Stitch Foot

Buttonhole Foot

Open Toe Foot

Blind Hem Foot

Cone Holder (2)

Net

Spool Caps (4)

Bobbins (3)

Pack of Needles

Edge/Quilting Guide

Screwdrivers (large & small)

Seam Ripper/ Brush

Knee Lifter

Dust Cover

Portable

Machine has a built-in carry handle, making it easy to transport the

machine.

Warranty The SINGER Quantum L-500 has a limited 25-year warranty, including

5-year on electronic components and 1-year on adjustments.

7 StayBright™ LED Lights Illuminates the work space.

Industrial Style Thread Holder Keeps thread untangled and moving smoothly.

Front Load Bobbin Jam resistant and easy to load.

Quantum L-500

PATTERN CHART

Patterns

Group 1-A Patterns ( -10Direct Patterns)

Group 2-B Patterns-93

Group 3-C Patterns-25

SEWING BASICS

On the chart below, the portion marked in gray shows a single unit of each pattern.

Group 4-D Patterns-79

A phabets

SEWING BASICS

PATTERN CHART
