Singer FEATHERWEIGHT FW-75 Manual de usuario

MAIN PARTS

1.Face Plate

2.Reverse Stitch Button

3.Slow Button

4.Start/Stop Button

5.Speed Control Lever

6.Extension Table (Accessory Case)

7.Bobbin Winder Tension disc

8.Needle Up/Down Button

9.Thread Tension Regulator

10.Spool pin

11.Bobbin winder Shaft

12.Bobbin Winder Stop

13.Hand Wheel

14.Stitch Width Button

15.Stitch Length Button

16.Pattern Selector Button

17.Thread Cutter

78 9 10 11 12 13

-2-

5756

4645

59 60

48 49

1615141312

3534

2423

37 38

26 27

030201 04 05

61 62

50 51

64 65

53 54

20191817

39 40

28 29

42 43

31 32

0806 07 09 10

-3-

18.Carrying Handle

19.Thread guide for upper threading

20.Power switch

21.Air vent

22.Foot control plug

23.Plug socket

24.Power cord

25.Foot control

26.Lower thread guide

27.Needle threader lever

28.Needle threader

29.Buttonhole lever

30.Presser foot thumb screw

31.Needle plate

32.Bobbin cover

34.Presser foot holder

35.Presser foot

36.Needle thread guide

37.Needle clamp screw

38.Presser foot lever

39.Drop feed lever

33.Bobbin cover release lever

40.LED light

ACCESSORIES

-4-

1.Needle set

2.Bobbins

3.Spool pin cap (large)

4.Spool pin cap (small)

5.Straight stitch foot

6.Needle plate screwdriver

7.Screwdriver

8.Buttonhole opener with brush

9.Oiler

10.Buttonhole Foot

11.Overcasting Foot

12.Zipper Foot

123

OPENING THE ACCESSORY CASE

To open the accessory case, lift up on the

top left side of the table and pull toward you.

11 12

Some accessories are provided in the accessory case.

13.Blind hem Foot

14.Satin Foot

15 16 17

15.Rolled hem Foot

16.Gathering Foot

17.Darning & Embroidery Foot

18.General purpose foot(on machine)

19.Extension table

18 19

-5-

a.REMOVING THE EXTENSION TABLE

Hook your finger to the bottom of extension

table and slid to the left. To attach, insert to

the right.

b.OPENING THE ACCESSORY CASE

Hook your finger to the left side of accessory

case and pull toward you.

DUST COVER

Cover the machine with dust cover when it is

not in use.

This manual will be stored on the holder

provided on the side of the cover.

-6-

CHANGING THE PRESSER FOOT

The presser foot must be changed according to the stitch you sew, or work you do.

CAUTION:To prevent accidents.

Turn off the power switch before you change the presser foot.

1.Turn the hand wheel toward you until the

needle is at its highest point.

2.Raise the presser foot lifter.

3.Remove the presser foot by pushing the

presser foot release lever toward you.

4.Place desired foot with its pin directly under

the slot in presser foot holder.

5.Lower the presser foot lifter and the presser

foot will snap into place.

REMOVING THE PRESSER FOOT HOLDER

INSERTING THE NEEDLE

Select a needle of the right type and size for the fabric to be sewn.

CAUTION:To prevent accidents.

Turn off the power before removing the needle.

1.Turn the hand wheel toward you until the

needle is at its highest point.

2.Loosen the needle clamp screw.

3.Remove the needle.

4.Insert new needle into needle clamp with

the flat side to the back and push it up as

far as it will go.

5.Tighten the needle clamp screw.

A.Do not use bent or blunt needles.

Place needle on a flat surface and check

to see if bent.

You may need to remove the presser foot holder to use

some presser feet.

To remove, raise the presser foot lifter and loosen the

presser foot thumb screw (A).

To attach, tighten the screw after raising the presser foot

holder.

-7-

CONNECTING THE MACHINE
