Singer CONFIDENCE 7470 Manual de usuario

225 Stitch Patterns A large variety of stitches including basic, decorative, stretch and

alphanumeric.

6 Fully Automatic

1-step Buttonholes

Buttonhole sewing is a 1-step simple process, providing reliable results.

Each side is sewn in the same direction, creating beautifully balanced

buttonholes.

Drop & Sew™

Bobbin System

Simply place the wound bobbin into the bobbin case, then run the bob-

bin thread through its guide. The machine will automatically draw up the

bobbin thread for you!

LCD Screen The LCD provides clear and easy viewing of stitch patterns, including

stitch width and length.

Built-In Alphabet

Personalize projects by adding a monogram, name or phrase with the

built-in block style alphabet.

Push-Button Stitch Selection With just a simple push of a button you have selected the stitch as well

as the optimum settings for length and width.

Automatic Needle Threader

After effortlessly threading the machine this feature automatically

threads the eye of the needle.

Adjustable Stitch Length

Optimal settings for length are automatically adjusted when choosing a

stitch. They can be overridden to personalize length choice.

Adjustable Stitch Width

Optimal settings for width are automatically adjusted when choosing a

stitch. They can be overridden to personalize width choice.

Center Zigzag Taper

When tapering with the zigzag stitch, the stitch tapers to the center, not

the left or right. This provides a more attractive look when tapering into

or out of a point.

Feature Benefit

Model 7470

Automatic Tacking

Stitch Function

Tie-off decorative stitches with just a push of a button. With 4 tiny

tacking stitches, the start and end of the pattern is reinforced ensuring

quality stitching and preventing unraveling.

Automatic Tie-off

Function

The Automatic Tie-off Function reinforces the start and end of seams

(straight stitches) for stronger stitching.

Exclusive Buttonhole

Underplate

This is a SINGER® developed system that sandwiches fabric between a

lower plate and the foot, to ensure perfect buttonholes on multiple layers

of fabric as well as delicate and stretch fabrics.

7mm Stitch Width When sewing select stitches, the wide stitches are bolder and more

pronounced.

Programmable Needle

Up and Down

Select whether the needle is up or down when the machine stops. It is

beneficial to have the needle stop in the down position when

appliquéing, quilting or pivoting fabric.

20 Character Memory

A memory bank holds full names and simple phrases

3-Step Infinite Length

Bar-Tack Buttonhole Create buttonholes with endlessly long sides. This is ideal when sewing

non-traditional sized buttonholes.

Electronic Twin

Needle Control

With just the touch of a button create two parallel rows adding a

decorative touch

13 Needle Positions

Needle position can be adjusted for techniques, such as inserting

zippers, cording and topstitching.

Automatic Tension

This system ensures stable stitch quality when straight stitching no

matter what type of fabric is being used

Feature Benefit

Model 7470

Editing Capabilities

Editing is simple. A cursor button can be moved through the 20-space

memory. If a stitch or letter needs to be removed, use the editing but-

ton.

Mirror Image

Select stitches can be mirror imaged for decorative stitching

Continuous Pattern

Select stitches can be sewn either as a single pattern or continuously

Automatic Presser Foot

Pressure Control

The amount of pressure exerted on the fabric by the presser foot

against the feed dogs is automatic. Sew from the lightest weight tricots

to the heaviest denim without making adjustments.

Jam-proof Bobbin System

The bobbin case floats above the hook, precluding thread jams. The

machine will not jam, even when sewing on sheer fabric or no fabric at

all.

2 StayBright™ LED Lights

The long-lasting bulbs (100,000 hours) stay cool, regardless how long

the machine is operated.

Extra-High Presser Foot Lifter When the Presser Foot Lifter is held in the extra-high position it offers

more clearance, which is needed when placing multiple layers of bulky

fabric under the presser foot.

Drop Feed Dogs

A conveniently located lever will lower the feed dogs for free-motion

embroidery, monograms, and for attaching buttons.

Heavy Duty Metal Frame This rigid support holds all the mechanisms in perfect alignment for

perfect, skip-free sewing.

Automatic Bobbin Winding Clutch

Needle bar automatically disengages when winding the bobbin, making

bobbin winding more convenient.

Electronic Stitch Formation

Digital electronic control of the stepper motors that control the

pattern formation allows for perfectly formed patterns every time.

Feature Benefit

Model 7470

Pattern Override Memory

The machine remembers, so you don’t have to! Select a pattern,

override the width and/or length, and the machine will remember those

changes. Select a different pattern and then return to the overridden

pattern —the override settings will still be in place as long as the ma-

chine is not turned off.

Box Feed

This is a feed dog motion that moves the feed dogs in a box motion,

rather than the historic arc motion. Box motion assures perfect feeding

because the feed dogs are always in perfect and equal contact with the

fabric and presser foot.

Optimum Power Control A control system that senses when additional power is required to main-

tain speed through thick or changing fabric conditions. This feature is

most useful when sewing through multiple (6-8) layers of fabric.

Accessories

Auxiliary Spool Pin

Spool Pin Felt Discs (2)

Small, Medium and Large Thread Spool Caps (3)

General Purpose Foot

Satin Special Purpose Foot

Zipper Foot

Blind Hem Foot

Buttonhole Foot

4 Standard 15J Bobbins

Needle Package

Screwdriver

Lint Brush/Seam Ripper

Dust Cover

Snap-On Presser Feet Change from one to another effortlessly with a simple push

of the foot release button.

On Board Storage Accessories are always within reach

Warranty 25-year limited warranty including 5 year electronic and 1 year labor

Feature Benefit

Model 7470

7470 Stitch Chart

Decorative

Basic Buttonhole

Stretch

Alpha-Numeric

A B C D E F G H I J K L M N O P Q R S T U

V W X Y Z À È Ì Ò Ù Ä Ë Ï Ö Ü Ñ Î Û É Â

_ . , ’ ? ! & / 0 1 2 3 4 5 6 7 8 9
