Simrad PX MultiSensor Manual de usuario

368306/C/14.01.2013

Aboutthebatteryandthecharger

Note

TheSimradPXMultiSensorwillnottakechargeat

temperaturesbelow0°C(32°F).Recommendedcharging

temperatureisbetween+5and+45°C(+41to+113°F).

Inordertoprovidealonglifetime,thebatteryusedinthe

SimradPXMultiSensorisaLi–Ionbattery.

TheSimradPXMultiSensorChargerisdesigned

especiallyforchargingthisbattery.Itmustonlybeused

tochargetheSimradPXMultiSensor.

Important

TheSimradPXMultiSensorChargermustonlybeused

tochargetheSimradPXMultiSensor.

CleaningthechargersocketsonthePX

MultiSensor

ThesocketsonthePXMultiSensorwillbelledwith

seawaterwhenthesensorisused.Thiswatermustbe

removedbeforethechargerplugisinserted.Allthe

socketsonthePXMultiSensormustbedriedandcleaned

beforechargingcantakeplace.

Important

ThePXMultiSensormustneverbechargedwhenitis

mountedinthedooradapteroronthetrawl.

1Usehighpressureair,anddirectthenozzleintoeach

ofthesockets.Blowoutwaterandmoisture.

2Useasmallbrushoracottonswab,andcleaneach

socketthoroughly.

3Wipeoffthesensorwithadrylintfreecloth.Pay

specialattentiontotheareaclosetothesensorsockets.

Charginginstructions

ObservethisproceduretochargethebatteryintheSimrad

PXMultiSensor.

1Makesurethattheambienttemperatureisbetween0

and+45°C(+32to+113°F).

Tip

Ifyoutrytochargethesensorinambienttemperatures

below0°C(32°F),aninternalsafetymechanismwill

preventthecharging.

2Verifythatthesensorsocketsarecleananddry,and

thatsaltresiduesandmoisturehavebeenremoved.

Important

Thisisimportant.Saltandmoistureinthesensor

socketswillincreasethetransitionresistance,andit

willcausethechargerplugstocorrode.

SimradPXMultiSensor

Chargingthesensorbattery

3Connectthe3–pinchargerplugtothesocketsatthe

endofthesensorbody.

4Connectthechargertoamainspoweroutlet(100to

230V ac).

5Observethatasmalllampclosetothesocketson

thesensorbodyislittoindicatethatthechargeris

correctlyconnected.

Verifythatthelampashesonceeveryfourseconds

toindicatethatthechargingisinprogress.

6Observethattheindicatorlamponthechargerislit

withanOrangecolour.

Thismeansthatfastchargingisinprogress.

Tip

Ifyouconnectthechargertoafullychargedsensor

theindicatorlamponthechargerwillbeOrangefor

ashortperiod,andthenchangetoGreen.Charging

isthennotrequired.

7Aftersometime,observethattheindicatorlampon

thechargerforashortperiodchangescolourtoYellow.

Thismeansthatthebatteryhasreachedalmostfull

charge.

8Observethattheindicatorlamponthecharger

changescolourtoGreen.

Thesensorbatteryisnowcharged,andtrickle

charginghasstarted.

Normalchargingtimeforafullydepletedsensoris

approximatelythreehours.

9UnplugthechargerfromtheACmains,then

disconnectthechargerplugfromthesensorbody.

Tip

Thebatterywillnotbedamagedevenifyouleavethe

chargerconnectedforalongperiodoftime.

10Observethesmallinstructionalbookletprovidedby

thechargermanufacturerformoreinformation.

Changingasingleplugonthecharger

connector

Observethisprocedureto

changeasingleplugon

theSimradPXMultiSensor

batterychargerconnector.

Threeextraplugsare

providedwiththeSimrad

PXMultiSensorCharger.If

additionalplugsarerequired,youcanorderthesefrom

Simrad.

1Makesurethatthechargerisdisconnectedfromthe

ACmainspower.

2Useaspanner,andunscrewtheplugfromthe

connector.

3Retrieveanewplug,andscrewitintothesocket.

Important

Donotuseexcessiveforce,maximumtorqueis

1.5Nm.Werecommendthatyoutighteneachplugby

handstoavoiddamage.

368306/C/14.01.2013
