4010 Suppression Release Kits
Installation Instructions
¤
1998 Simplex Time Recorder Co., Gardner, MA 01441-0001 USA
All specifications and other information shown were current as of publication, and are subject to change without notice 574-166
Rev. B
DO NOT INSTALL ANY SIMPLEX PRODUCT THAT APPEARS
DAMAGED. Upon unpacking your Simplex product, inspect the contents of the
carton for shipping damage. If damage is apparent, immediately file a claim
with the carrier and notify Simplex.
ELECTRICAL HAZARD - Disconnect electrical power when making any
internal adjustments or repairs. Servicing should be performed by qualified
Simplex Representatives.
STATIC HAZARD - Static electricity can damage components. Therefore,
handle as follows:
1. Ground yourself before opening or installing components (use the 553-484
Static Control Kit).
2. Keep uninstalled component wrapped in anti-static material at all times.
RADIO FREQUENCY ENERGY - This equipment generates, uses, and can
radiate radio frequency energy and if not installed and used in accordance with
the instruction manual, may cause interference to radio communications. It has
been tested and found to comply with the limits for a Class A computing device
pursuant to Subpart J of Part 15 of FCC Rules, which are designed to provide
reasonable protection against such interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause
interference in which case the user at his own expense will be required to take
whatever measures may be required to correct the interference.
This publication shows how to install the 4010-9814 (120V) and the 4010-9824
(240V) Suppression Release Kits into a 4010 Fire Alarm Control Panel (FACP).
Refer to the 4010 Fire Alarm - Installation Instructions (574-052) for
configuration information. Refer to the 842-058 Field Wiring Diagram for
additional wiring information.
This publication discusses the following topics:
Topic See Page #
Overview 1
4010-9814 and -9824 Suppression Release Kits 2
Installation 3
Wiring 5
Power-Up and Checkout 7
Cautions and Warnings
Overview
In this Publication
Technical Manuals Online! - http://www.tech-man.com
2
When the suppression function is controlled by the 4010 Fire Alarm Control
Panel, a Suppression Release Kit (power supply 565-793) can be added to
supply power for this function. The suppression release kit provides
filtered/regulated 24VDC, 4A power for Notification. When controlling the
suppression release function, a Notification Appliance Circuit is limited to
driving a single valve.
Terminals 1 and 2 are rated at 2A, 24VDC “A Tap” and Terminal 3 and 4 are
rated at 2A, 24VDC “B Tap.” Maximum wire length is 3,270 feet. Be sure to
include Auxiliary 24VDC in battery standby considerations. See Figure 1 for
connector locations.
565-792
OR
565-793 +- +-
Figure 1. 4010 Suppression Release Kit
4010-9814 and -9824 Suppression Release Kits
Overview
P1 Connector (Red)
P2 Connector (White)
TB1 AUX Power Output
(4Amp MAX)
Battery Leads
Technical Manuals Online! - http://www.tech-man.com
3
The 4010-9814 and -9824 Suppression Release Kits install in their own
hardware slot located to the right of the 4010 SFI/O module (see Figure 2). Use
Steps 1 through 3 to mount the suppression release kit.
1. Disconnect battery and then AC power from the FACP.
2. With TB1 of the suppression release kit in the bottom position, slip the top
hole of the suppression release kit’s metal bracket over the flanges located
on the 4010 chassis.
3. Use the supplied slotted TORX screws (Part No. 441-002) and lock washers
to secure the other end of the suppression release kit’s bracket to the chassis.
4010-9813
Expansion Power
Supply (565-792)
or
4010-9814
Supression Power
Supply (565-793)
4010-9809
City Module
4010-9820
Meter Module
or
4010-9825
24V Extender
Terminal Block
4010-9806
Class A
Module
(565-789)
Pot for LCD Adjustment
4010-9806
Class A
Module
(565-789)
WARNING: PTCs MUST NOT TOUCH EACH OTHER OR
ANY OTHER METAL SURFACE!
Figure 2. 4010 Suppression Release Kit
Continued on next page
Installation
Mounting
Expansion Supply
Hardware Slot
P13 (Red) and P14
(White) Expansion
Supply Connectors
Technical Manuals Online! - http://www.tech-man.com
4
When the suppression function is controlled by the 4010 Fire Alarm Control
Panel, the panel must be labeled to indicate this fact. The label lets all persons
servicing the system know that the panel is configured for suppression release
and that they must disable all releasing device circuits before servicing the panel.
To apply the label, do the following:
1. Refer to Figure 3 and locate the LCD Display and the Touch Pad keys
below it.
2. Notice the placement of the label below the LCD Display and the Touch
Pad keys in Figure 3.
3. Place the Suppression Release Label on the 4010 Fire Alarm Control Panel
door in the same position as that shown in Figure 3.
Installation,
Continued
Applying the Suppression
Release Label
Suppression
Release Label
Technical Manuals Online! - http://www.tech-man.com
5
Use the following information, the 526-407 and 526-408 labels inside the FACP,
and the 842-058 Field Wiring Diagram to wire the suppression release kit.
CAUTION: Pay careful attention to the routing for Power-Limited
and Non-Power Limited wiring. You must maintain a
1/4-inch separation between these two types of wiring.
Follow Steps 1 through 4 to wire AC power to the 4010-9814 or -9824
suppression release kit.
1. Disconnect battery and then AC power from the FACP.
2. Remove the existing AC harness from the FACP. Remove the Quick-
Disconnect connector from the chassis by firmly gripping the release tabs
and pulling it free. The Quick-Disconnect connector is located directly
below the chassis.
IMPORTANT: The Quick Disconnects on the AC Harnesses are not
rated for Quick Disconnect while power is applied.
Power should be turned OFF at the breaker box
before disconnecting the AC Power Quick
Disconnect connectors.
3. Remove the harness wiring from the AC terminal block located in the lower
right corner of the 4010 back box.
4. Wire the 733-949 (4010-9814-120V supply) or the 733-955 (4010-9824-
240V supply) harness to the back box terminal block. Match incoming
Neutral and Hot wires to their corresponding wires leading from the
terminal block located in the lower right corner of the back box to the
appropriate harness and screw into place.
WARNING: DO NOT APPLY POWER TO THE 4010 AT THIS TIME!
DO NOT connect the quick-disconnect AC connectors
to either the suppression power supply or the main
chassis. Refer to the “Power-Up and Checkout”
section of this publication.
Continued on next page
Wiring
Overview
AC Wiring
Technical Manuals Online! - http://www.tech-man.com
6
The suppression release kit requires power and communications connections to
the 4010 SFI/O board. Use Steps 1 through 3 to connect a power and
communications harness from the suppression release kit to the 4010 FACP.
Both harness connectors are keyed for correct connection.
1. Connect the 733-950 (white) harness from P1 of the suppression release kit
to P14 of the SFI/O board.
2. Connect the 733-951 (red) harness from P2 of the suppression release kit to
P13 of the SFI/O board.
3. Neatly dress the wiring behind the 4010 chassis using the holes provided to
tie-wrap the harnesses.
The suppression release kit requires connection to the battery terminals (TB8) on
the 4010 SFI/O board.
x
Connect the red battery lead from the suppression release kit to the (+)
terminal of TB8 on the SFI/O.
x
Connect the black battery lead from the suppression release kit to the (-)
terminal of TB8 on the SFI/O.
Wiring,
Continued
Communication and Power
Wiring
Battery Wiring
Technical Manuals Online! - http://www.tech-man.com
7
Use the following steps to apply AC and battery power to the 4010 FACP.
1. Connect the appropriate dual AC harness to the bottom of the suppression
release kit first and then to the bottom of the main FACP chassis.
2. Connect the crimped ends of the 733-945 battery harness to the batteries.
Observe polarity (red to +, black to -) when connecting batteries.
WARNING: Battery contains sulfuric acid which can cause severe
burns to the skin and eyes, and can destroy fabrics.
Replace any leaking or damaged battery. If contact is
made with sulfuric acid, immediately flush skin or eyes
with water for 15 minutes and seek immediate medical
attention.
After applying power to the system, use the following list to check the 4010 for
proper operation.
x
Check that the green AC Power LED is ON.
x
Check that all yellow and red LEDs are OFF.
x
Use the Lamp Test procedure in the Operation Chapter of this publication to
verify that all 4010 LEDs and LCD segments work properly.
Power-Up and Checkout
Connect AC and Battery
Power
Technical Manuals Online! - http://www.tech-man.com
574-166
Rev. B
