Sim-Lab GRID DDU5 Manual de usuario

GRID DDU5

VERSION 1.1

Last updated: 28-11-2022

INSTRUCTION MANUAL

2|2 20

BEFORE YOU START:

Thank you for your purchase. In this manual we will provide you with

the means to get started using your new dash!

GRID DDU5

Features:

5” 854x480 VOCORE LCD

20 full RGB leds

Up to 30 FPS

24 bit Colors

USB Powered

Multiple software options

Drivers included

Mounting the dash is very easy thanks to the included mounting

brackets. We offer a wide range of support for most popular

hardware. In this manual we only display the two mounting brackets

included with the dash. Please review our website to determine

which mounting bracket ﬁts your hardware.

| |320 20

Mounting the dash

To be able to mount the dash on the hardware of your choice, we provide several

mounting brackets. Which ones you have received may depend on your purchase

and may be different from the following ones we show. However, mounting is all

more of the same. With the instructions for the two included brackets, you should be

able to mount any speciﬁc ones for your hardware.

4|4 20

OSW/SC1/VRS

Remove the existing upper bolts which hold the motor in place. Re-use these bolts

and washers to ﬁx the mounting bracket to the front mount.

| |520 20

Fanatec DD1/DD2

Locate the accessory mounting holes on your Fanatec hardware and use the two

bolts (A4) and washers (A6) from our supplied hardware kit.

6|6 20

Installing drivers

To make the display part of the dash functional, speciﬁc drivers are needed. Drivers

can be downloaded from the product page.

Vocore drivers download:

Installation

To install the display drivers, run the downloaded package and specify the location

where to install the drivers:

Press ‘Next’.

| |720 20

Specify the name of the start menu folder:

Press ‘Next’.

Review the settings before installation:

Press ‘Install’.

8|8 20

The drivers will install now. Sometimes this can take longer than expected. This

usually means a system restore point is being made and should not hinder

installation.

If it does, unplug the USB cable to the Dash in case it is connected and try again.

Make sure you have administrator rights on your system.

Press ‘Finish’.

| |920 20

SimHub installation

To control the LEDs of the dash, SimHub can be used.

Download the lastest version of SimHub from https://simhubdash.com

Installation

Unzip the downloaded ﬁle and run the setup ﬁle:

Press ‘Next’.

10 |10 20

Specify the location where to install the software:

Press ‘Next’.

Make sure all options are checked:

Press ‘Next’.
