SilverStone EC04 Manual de usuario
EC04
PCI express card with two USB 3.0 external ports
and internal 19P dual port connector
MANUAL
EC04
PCI express card with two USB 3.0 external ports
and internal 19P dual port connector
Introduction
Features
Specifications
Model No.
Form factor
USB 3.0 controller
Power Requirement
USB Ports
Transfer speed
Port Interface
USB bus power output
OS Support
SST-EC04
Low profile single lane (X1) PCI Express 2.0
TI TUSB7340
5Vdc via peripheral 4pin power connector
Two external ports and one internal dual port
USB 3.0(5Gbit/s), USB 2.0(480Mbit/s), USB 1.1(12Mbit/s)
USB 3.0 (Max. 5Gbit/s) backwards compatible with USB 2.0
5Vdc with unlimited power current
Windows XP, Vista, 7(32bit/64bit)
1
SilverStone created an excellent expansion card product, the EC04, which connects to the
motherboard via single lane PCI Express 2.0 to support two external and a dual port USB 3.0
connector for maximum compatibility and flexibility. This card is a great add-on for systems
that require connections to multiple USB 3.0 devices such as SilverStone’s own USB 3.0
enclosures RVS02 and TS07.
USB 3.0 with two external standard Type-A ports and one dual port internal connector
PCI Express 2.0 with single lane (x1) throughput 5Gbit/s
Supports simultaneous operation of multiple USB 3.0/2.0/1.1 devices
Adds four total USB 3.0 ports to your system
Built-in power connector to receiving extra power from system power supply
INSTALLATION
1
Install EC04 onto PCIe slot of Motherboard.
(refer to PIC1) Установите плату EC04 вгнездо PCIe
материнской платы. (см. рисунок 1)
Installieren Sie die EC04 im PCIe-Steckplatz
des Motherboards. (vgl. Abb. 1)
將EC04 安裝於主機板上的PCI-E插槽。
（請參考圖一）
Installez le EC04 dans un emplacement PCIe
de la carte mère. (voir image 1)
将EC04 安装于主机板上的PCI-E插槽。
（请参考图一）
Instale el EC04 en el zócalo PCIe de la placa
base. (consulte la IMAGEN1) EC04 をマザーボードのPCIeスロットにインスト
ールします
。
(図1.参照)
Inserisci EC04 nello slot PCIe della scheda
madre. (fare riferimento alla PIC1) EC04 을 메인보드의 PCIe 슬롯에 장착합니다.
(PIC 1 참조)
2
EC04
PCI express card with two USB 3.0 external ports
and internal 19P dual port connector
INSTALLATION 2
Plug Molex 4P power connecter.
(refer to PIC1) Подсоедините 4-контактный разъем питания
Molex. (см. рисунок 1)
Schließen Sie den 4-poligen Molex-Netzstecker
an. (vgl. Abb. 1)
將4pin電源線接上EC04 。（請參考圖一））
Branchez le cordon d'alimentation Molex 4P.
(voir image 1)
将4pin电源线接上EC04 。（请参考图一）
Conecte el Mólex 4P en el conector depotencia.
(consulte la IMAGEN1) Plug Molex 4P電源コネクタを接続します。
(図1.参照)
Connett il molex 4P alla presa d’alimentazione.
(fare riferimento alla PIC1) Molex 4P 파워 커넥터를 연결합니다. (PIC 1
참조)
3
EC04
PCI express card with two USB 3.0 external ports
and internal 19P dual port connector
INSTALLATION 3
Plug internal 20P dual port USB 3.0 connector.
(refer PIC1)
Подсоедините внутренний 20-контактный
разъем для двух портов USB 3.0.
(см. рисунок 1)
Schließen Sie den 20-poligen internen
Dual-Port- USB 3.0-Stecker an. (vgl. Abb. 1)
連接EC04與20pin USB 3.0訊號線。
（請參考圖一）
Branchez le connecteur USB 3.0 à double port
interne 20P. (voir image 1)
连接EC04与20pin USB 3.0讯号线。
（请参考图一）
Conecte el puerto dual 20P al conector USB 3.0.
(consulte la IMAGEN1)
内蔵20PデュアルポートUSB 3.0コネクタを接
続します。(図1.参照)
Connetti la doppia porta interna 20P USB 3.0.
(refer PIC1)
내부 20P 듀얼 포트 USB 3.0 커넥터를
연결합니다. (PIC 1 참조)
PIC1
4
4P power connecter
USB 3.0 connector
EC04
PCI express card with two USB 3.0 external ports
and internal 19P dual port connector
USB 3.0 Port
USB 3.0 Port
INSTALLATION 4
Install Texas Instruments USB 3.0
host controller driver. Установите драйвер хост-контроллера
Texas Instruments USB 3.0.
Installieren Sie den USB 3.0-Host-Controller-
Treiber von Texas Instruments.
安裝Texas Instruments USB 3.0 host controller
驅動程式。
Installez le pilote du contrôleur hôte
Texas Instruments USB 3.0.
安装Texas Instruments USB 3.0 host controller
驱动程序。
Instale el controlador Texas Instruments
USB 3.0. USB 3.0ホストコントローラドライバをインストール
します。
Installa il driver Texas Instruments
USB 3.0 host controller. Texas Instruments USB 3.0 호스트 컨트롤러
드라이버를 설치합니다.
5
EC04
PCI express card with two USB 3.0 external ports
and internal 19P dual port connector
INSTALLATION 5
After above installation, you will find the
Texas Instruments USB 3.0 host controller
in the device manager. (refer to PIC2)
После установки указанного выше драйвера
хост-контроллер Texas Instruments USB 3.0
отобразится
вдиспетчере устройств.
(см. рисунок 2)
Nach der obigen Installation finden Sie den
USB 3.0-Host-Controller von Texas Instruments
im Geräte-Manager. (vgl.Abb.2)
安裝完成後，在硬體管理員列表中可看見
Texas Instruments USB 3.0 host controller。
（請參考圖二）
Après l'installation ci-dessus, vous trouverez
le contrôleur hôte Texas Instruments USB 3.0
dans le gestionnaire de périphériques.
(voir image 2)
安装完成后，在硬件管理员列表中可看见
Texas Instruments USB 3.0 host controller。
（请参考图二）
Tras la instalación anterior, encontrará el
controlador Texas Instruments USB 3.0 en el
administrador de dispositivos.
上記インストール後、デバイスマネージャには
Texas Instruments USB 3.0
ホストコントローラが表示されます。(図2.参照)
Dopo l’installazione del driver, troverai
Texas Instruments USB 3.0 host controller
in gestione periferiche.
(fare riferimento alla PIC2)
위의 설치 후, 장치관리자에서
Texas Instruments USB 3.0
호스트 컨트롤러를 확인할 수 있습니다.
(PIC 2 참조)
6
EC04
PCI express card with two USB 3.0 external ports
and internal 19P dual port connector
PLEASE SEE EXAMPLE BELOW
PIC2
7
EC04
PCI express card with two USB 3.0 external ports
and internal 19P dual port connector
INSTALLATION 6
Plug your USB 3.0 device and enjoy the
5Gbit/s USB 3.0 super speed transfer speed.
Подключите устройство синтерфейсом USB
3.0 ипередавайте данные на высокой
скорости до 5 Гбит/счерез разъем USB 3.0.
Schließen Sie Ihr USB 3.0-Gerät an und
genießen die USB 3.0-Super-Speed-
Übertragungsgeschwindigkeit von 5 Gbit/s.
連接USB 3.0裝置並開始享受高速傳輸速度。
Branchez vos appareils USB 3.0 et profitez
de la super vitesse de transfert de 5Gbit/s.
连接USB 3.0装置并开始享受高速传输速度。
Conecte el dispositivo USB 3.0 y disfrutede
la transferencia de alta velocidad USB 3.0 de
5Gbit/s.
お持ちのUSB 3.0装置を接続して、5Gbit/sという
USB 3.0の超高速データ転送速度が実感できます。
Connetti pure la tua periferica USB 3.0 ed
apprezza la super velocità di trasferimento dati
di ben 5Gbit/s.
USB 3.0 장비를 연결한 후 5Gbit/s USB 3.0
초고속 전송 속도를 즐기십시요.
8
EC04
PCI express card with two USB 3.0 external ports
and internal 19P dual port connector
December, 2011
