SilverStar YX-2007 Manual de usuario

YX-2007

Show-Pro (RGB) Laser

www.yagang.com 2006.4.24

USER MANUAL

Version 1.2

Please read over this manual before operation the light

1) • • • • • • • • • • • • • • • • • • • • Page 1

2) • • • • • • • • • • • • • • • • • • • • • • • • • • • • Page 1

• • • • • • • • • • • • • • • • • • • • • • • • • • • • • Pa ge 2

4) • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Page 2

5) • • • • • • • • • • • • • • • • • • • • • • Pag e 3

6) • • • • • • • • • • • • • • • • • • • • Page 4

7)Control PCB Replacement• • • • • • • • • • • • • • • • • • • • Page 5

8) Sc an m ot or R ep la ce me nt • • • • • • • • • • • • • • • • • • • • Page 6

9)Adjustable mirror holder • • • • • • • • • • • • • • • • • • • • • Page 7

10)Laser diode replacement• • • • • • • • • • • • • • • • • • • • • Page 8

11)Electrical diagram of laser • • • • • • • • • • • • • • • • • • • • Page 9

12)DMX512 Operate • • • • • • • • • • • • • • • • • • • • • • • • Page 10

13) • • • • • • • • • • • • • • • • • • • • • • • • • • • P ag e 11

14) • • • • • • • • • • • • • • • • • • • • • • • • • • • • • Page 11

15)Electrical diagram • • • • • • • • • • • • • • • • • • • • • • • • Page 12

16)Tr ou bl e sh oo ti ng • • • • • • • • • • • • • • • • • • • • • • • • • Pa ge 13

Open the box for checking

Installation

Attention

Warning

Structure of the fixture

Control board instruction

Specification

Maintain

1. Open the box for checking

In order to use this product safety and reasonable for the users, please read over

this manual carefully before use and the operation must strictly according to this

manual to avoid any damage to the product and personal safety.

Once after received this products please take and put carefully. And check

carefully that whether the product was damaged or not during the transportation and

please check the following things were enclosed:

Laser light 1PCS Graphics USB card 1PCS

9 pin signal line 1PCS USB connection cable 1pcs

3 pin signal line 1pcs User manual 1pcs

Power cable 1PCS Install CD-ROM 1PCS

2. Installation

1. Please check the voltage whether is the same with the one showed on the

equipment or not.

2. It must ask for the technical person and set the light safety when installation. And

let the light beam at the suitable angle.

3. When install this equipment please make sure there's no flammable surfaces

(decorated things, etc) within at least 1.5M and maintain minimum distance of

0.5M from the equipment to the walls.

4. Please make sure that there's no other equipment or decorating materials

obstructed the exhaust fan and the vent-pipe.

5. Products should be install immobility.

6. In case of safety, it's very important that to connect the earth with line.

3. Attention

1. Must operate according to the user manual. Don't separate the light personally.

Call the technician when the machine breaks down.

2. Please do not see the laser beam directly to avoid any damage.

3. Before connect or disconnect the power, please adjust the luminance of the laser

diode to the least to avoid any damage to the laser diode.

4. This unit should be keep dry, do not use in the rain or dank and dusty

environment. It can be use in the outdoor with the water-proof cover protector.

5. Set the light immobility and try to avoid strong shake or hit.

6. Prevent dust into the equipment to avoid problems.

7. Please keep that there's no other equipment or decorating materials obstructed

the exhaust fan and the vent-pipe when the equipment was working.

8. Before connect power, check the plug is immobility or not, power line should be

connect well.

9. Please do not open or close the equipment frequently that's to avoid any affect to

the life span of the laser diode, and try the best to avoid the long time working.

10. Due to the characteristic of the laser diode, after three hours working, it should

be close at least 25 minutes until the laser diode cooling then work again.

11. Don't touch the light or draw the power line when your hand was wet. And do

not pull the electronic power line.

12. Maintain the distance at least 10M above from the equipment to the object.

13. This equipment does not have any parts can repair for the users, please do not

open the equipment.

14. When the laser diode became dim or damaged please contact the dealer timely.

15. To use the original package when transport again and to avoid shake.

4. Warning

Don't look the light directly to prevent make some destroy with eyes..

2. Keep the space between light equipments and the lighted things more than 10 M.

No.

Description.

Reflect bowl

Dustproof glass

Lens cover

Red laser diode

Blue laser diode

X scan motor

Y scanmotor

Scan motor holder

Adjustable reflect mirrorholder

Power supply 2 of blue laser diode

Power supply 2 of green laser diode

Power supply 2 of red laser diode

AC 220V fan

Qty

No.

Description.

DC 12V fan

Power supply 1 of blue laser diode

Feet of machine

Power supply 1 of red laser diode

Power supply 1 of green laser diode

Green laser diode

X scan

Control board

TTL switchboard

Power supply

Connector

Qty

5. Structure of the fixture

6. Control board instruction

NOTE:

1. When ILDA DB 25F connector s connection port are free, the lamp will drive

by the inside program, temporality it can control by DMX 512 signal.

2. After connect the ILDA DB 25F, The lamp will change to ILDA connected port

drive mode ,this connection port can receive all the signal of laser perform

software that accord with the ILDA standard, such as LD-2000 of Pangolin

Company.

POWER INPUT Input power, with inner fuse.

DMX IN/OUT DMX signal input/output

POWER ON/OFF Power switch

Security key switch Laser diode ON/OFF

Remote Lock In the event of removal, laser will not emit any beam.(E.U. IEC regulation)

th th

ADDRESS: the 10 code is switch code. When the 10 code is OFF, 1~9 are

function codes. When the 10 code is ON,1~9 will be DMX address codes.

The address code of first light usually by 1, the second light is 14 and so on.

ILDA DB 25 F Connector: signal input connection port of the laser perform

software that in accordance with the ILDA standard.

ADDRESS

ILDADB-25F Connector-IN

ILDADB-25F Connector-OUT

OFF

Security

key switch

ON OFF

IN DMX OUT

POWER INPUT

Remote Lock

1235

BINARY

USAGE OF DIP SWITCH

1 2 3 4 5

7 8 9 10

OFF

511

LSB MSB

1 2 3 4 5

7 8 9 10

OFF

1 2 3 4 5

7 8 9 10

OFF

1 2 3 4 5

7 8 9 10

OFF

DMX address code setting:

in the binary, each digit have 0 or 1 just correspond to OFF or ON

switch situation.

Example for DMX address code:

DECIMAL

7. Control PCB Replacement

Steps:

Disassemble defective PCB and then assemble new PCB.Make some marks of

cable connection of refer to electrical diagram so that the connection of cables shonld

be exactly same as original one.

Fig 7-1 Control PCB Assembling Diagram

Signal switch PCB

Y scanPCB

X scan PCB

Control PCB

(2) Optical system:

RGB mix beam be reflected out by X,Y scan mirrors.

8. Scan motor Replacement

(1) Steps:

1. Unscrew UK M6 screw and plug out male signal connector.

2. Disassemble all M4 10 screw for X,Y scanner socket so that scan motors can

be took out,put in or rotate to adjust the scan angle.

3. After adjust ,fix M4 screws,plug in male signal connector and then screw

UK M6 screw.

Y scanmotor

X scan motor

UK M6 screw(with femal screw)

Signal connector(Male)

M4 10 screw

Fig8-1 Scan motor install diagram

White beam

RGB mix beam

Fig8-2 Optical System diagram

9. Adjustable mirror socket

(1) Steps

1. Loose setscrew of X,Y and then adjust mirror socket to suitable position by

X,Y adjustable screws.

2. Adjust Z adjustable screw at same time.

3. Fix X,Y setscrew.

NOTE:Made sure all beams through adjustable mirror socket be one point when you

adjust X,Y,Z line with adjustable screw.

(2) RGB Laser beams mix system:

Mirror socket 1:Transmit green beam,reflect red beam,and then mix out yellow

beam through mirror socket 1.

Mirror socket 2:Transmit yellow beam,reflect blue beam ,and then mix out white

beam through mirror socket 2.

Y setscrew

Y adjustablescrew

X adjustable screw

Z adjustable screw

X setscrew

setscrew

Fig9-1 Adjustable mirror socket structure

Blue beam Red beam

Green beam

Yellowbeam

White beam

Mirror 2 Mirror 1

Fig9-2 RGB laser beams mix system

10. Laser diode replacement

Methods:

Disassemble whole laser system (include power supply1,power supply 2,laser

diode) and then replace new one at original position.

Note:keep laser diode,power supply and cables be ompletly and don`t try to

damage,destroy or cut them so that it can be repaired (crefer fig 1-7).

Fig10-1

Correct Method

3344

power supply 1 of blue laser diode

power supply 2 of blue laser diode

blue laser diode

red laser diode

power supply 2 of red laser diode

power supply 2 of green laser diode

power supply 1 of red laser diode

Green laser diode

power supply 1 of green laser diode

Wong Method

Snip Snip
