Silvercrest NM1005 Hoja de instrucciones

MINI-WIRELESS

MOUSE

WIRELESS OPTICAL

MINI-MOUSE WITH RADIO

USB RECEIVER

User manual and service

information

VEZETÉK NÉLKÜLI MINI OPTIKAI

EGÉR USB VEVŐVEL

Felhasználói kézikönyv és szerviz

tájékoztatás

BEZPRZEWODOWA

MINIMYSZ OPTYCZNA Z

ODBIORNIKIEM USB

Instrukcja obsługi oraz

informacje o serwisie

Silvercrest NM1005

hbc_4a_nm1005_0711.qxd 19.12.2007 12:04 Uhr Seite 1

Notebook Mini-Mouse SilverCrest NM 1005

English - 1

Table

1 Left mouse button

2 Back (if software is installed)

Forward (if software is not installed)

3 Forward (if software is installed)

Back (if software is not installed)

4 Control lamp for the condition of the battery power

5 4-way scrolling wheel

6 Right mouse button

7 Switch-over from 500 to 1,000 cpi

8 Radio USB receiver

9 Plug-in module for the radio USB receiver

(lower side of the unit)

Notebook Mini-Mouse SilverCrest NM 1005

2 - English

Contents

Table ................................................................................................1

Important Safety Information............................................................3

Operating Environment.................................................................3

Maintenance and Care .................................................................4

Children ........................................................................................4

Compliant Use..............................................................................4

Batteries........................................................................................5

R/F Interface.................................................................................5

Compliance...................................................................................6

Appliance Disposal.......................................................................6

Scope of delivery..............................................................................7

Equipment required..........................................................................8

Introduction.......................................................................................8

Installing Hardware ..........................................................................9

Inserting the Battery......................................................................9

The USB-Reveiver......................................................................10

Connect the USB Receiver.........................................................11

Software Installation.......................................................................12

Operation........................................................................................14

Toggling between Operating Modes...........................................14

Configuration ..............................................................................14

Attachment.....................................................................................16

Troubleshooting..........................................................................16

Technical Data............................................................................16

Warranty Information......................................................................17

Notebook Mini-Mouse SilverCrest NM 1005

English - 3

Important Safety Information

Before putting the appliance into operation for the first time, please

thoroughly read the following instructions and heed all safety

warnings, even if you are quite used to handling electronic devices.

Keep this manual in a safe place for future reference. If you sell or

pass on the appliance, you should absolutely ensure to hand over

these instructions as well.

Operating Environment

Position the device on a firm, even surface and do not place any

objects on top of it. The appliance is not designed for operation in

spaces subject to high humidity or temperatures (e.g. bathrooms) or

in excessively dusty locations. Operating temperature and air

humidity: 5°C to 45°C, max. relative air humidity 90%.

Please ensure that:

-the appliance is not exposed to direct sources of heat (e.g.

heating elements);

-the appliance is not exposed to direct sunlight or artificial light;

-any contact with splashes and/or drips of water and other

liquids is avoided and the device is not operated near water; in

particular, the appliance may never be submerged (do not place

water-filled objects such as vases or open drinks containers on

top of or near the appliance);

-the appliance is not placed in the direct vicinity of magnetic

fields (e.g. loudspeakers);

-no sources of open flame (e. g. lighted candles) are placed on

top of or near the appliance;

-the appliance is not penetrated by foreign objects;

-the appliance is not exposed to strong temperature fluctuations;

-the appliance is not subjected to excessive shaking or vibration;

Notebook Mini-Mouse SilverCrest NM 1005

4 - English

Maintenance and Care

Maintenance activities are required if the appliance has been

damaged, liquids or objects have penetrated the casing, the

appliance has been exposed to rain or moisture, the appliance is

not working properly or if it has been dropped. If you notice any

smoke developing, unusual noises or smells, please switch off the

appliance immediately. In such cases the appliance may not be

operated until a professional specialist has checked it. Any repairs

are only to be performed by qualified professional technicians.

Never open the casing of the appliance or of any accessories. Only

clean the appliance with a clean and dry cloth, never using any

aggressive liquids.

Children

Electrical appliances are unsuitable as children’s toys. Never permit

children the unsupervised use of any electrical appliances. Children

are not always able to fully appreciate the potential dangers. If

swallowed, batteries and small parts can potentially be life-

threatening. Keep batteries out of reach of small children. If a

battery has been swallowed, medical help needs to be consulted

immediately. Please also keep the plastic packaging away from

children to avoid suffocation risks.

This device does not belong in the hands of children! Spring parts

may jump out if misused and cause them harm (e.g. to their eyes).

Compliant Use

This wireless mouse consists of an optical mouse and a radio

receiver and is an information technology appliance. The appliance

may not be used outside of closed rooms or in regions with a

tropical climate. Only use connecting cables and/or peripheral

devices whose technical safety, electromagnetic compatibility and

shielding properties correspond to the appliance in question. This

appliance meets all the relevant norms and standards in connection

with CE-conformity. Compliance with these standards is no longer

guaranteed if the appliance is modified without the manufacturer’s

authorization. Only use the accessories specified by the

manufacturer.

Notebook Mini-Mouse SilverCrest NM 1005

English - 5

If you are not using the appliance within the Federal Republic of

Germany you are bound by the state regulations and/or legislation

applicable in the country of operation.

Batteries

Please always insert the batteries with the poles pointing in the

proper direction. Never attempt to recharge the batteries and under

no circumstances try to incinerate them. Do not use different

batteries (e.g. old and new, alkaline and carbon, etc.)

simultaneously. Remove batteries if appliance is not being used for

any longer periods of time. Inappropriate battery use may result in

explosion and leakage risks. Never replace batteries in a potentially

explosive environment because impact might cause sparks when

inserting or removing batteries that could cause an explosion.

Never throw batteries into the fire because they could explode.

Please take care to protect the environment. Used batteries do not

belong in the domestic waste and need to be handed in at a

collection point for used batteries instead.

R/F Interface

Please switch off the appliance in airplanes, hospitals, operating

theatres and in the vicinity of medical electronic system. The radio

waves transmitted could impair the functionality of sensitive

appliances.

Observe a minimum distance of 20 cm between the appliance and

any pacemaker as the radio waves could impair the function of the

pacemaker.

The transmitted radio waves may create interference noises in

hearing aids.

Do not allow the appliance to be introduced in the vicinity of

inflammable gases or environments subject to a risk of explosion

(e.g. paint shops) as long as the radio component is switched on,

as the transmitted radio waves could trigger an explosion or fire.

The coverage/range of the radio waves varies depending on the

surrounding and environmental conditions.

In any data exchange via wireless connections, unauthorized third

parties are also able to receive the data. Targa GmbH is not liable

Notebook Mini-Mouse SilverCrest NM 1005

6 - English

for any radio or television interference caused by unauthorized

modifications of this appliance. Targa furthermore accepts no

liability for the replacement or exchange of connection cables and

appliances not specified by Targa GmbH. The user is solely

responsible for the elimination of interferences caused by such

unauthorized modifications, as well as for the replacement or

exchange of the appliances concerned.

Compliance This wireless mouse has been tested and approved

for compliance with the essential requirements and

other relevant regulations contained in the EU EMC

directive 2004/108/EC as well as the directive for low-

voltage appliances 2006/95/EC and the R&TTE

directive 99/5/EC.

Appliance Disposal

All appliances labelled with this symbol are subject to

the European directive 2002/96/EC. All electrical and

electronic appliances need to be disposed off

separately via the facilities provided for this purpose

by the authorities and may not be included in the

domestic waste. The proper disposal of old appliances

helps protect the environment and prevent risks to

your personal health. Further information on the

proper disposal of this appliance, once it is no longer

needed, is available from your municipal authority, the

waste disposal services, or the shop where you

bought the product.

Notebook Mini-Mouse SilverCrest NM 1005

English - 7

Scope of delivery

Please use this list to check the completeness of the content of the

package:

-Wireless optical mouse

-Radio USB receiver

-1 AA battery, 1,5V (Mignon)

-CD with unit software (no figure)

-User manual (no figure)

Notebook Mini-Mouse SilverCrest NM 1005

8 - English

Equipment required

-at least 1 unoccupied USB 2.0 connection (this radio mouse is

not suited to operating on a USB1.1 connection)

-Microsoft Windows Vista™ or Microsoft Windows®2000/XP

-CD Rom drive or DVD drive for installing software

Introduction

Thank you for purchasing a SilverCrest NM 1005. This optical radio

mouse is equipped with two special buttons along with the 3

standard buttons for access to frequently repeated functions. The

scrolling wheel is a 4-way scrolling wheel for vertical and horizontal

scrolling. You can use the CPI (7) special button to change optical

resolution back and forth between 500 cpi and 1,000 cpi.

Notebook Mini-Mouse SilverCrest NM 1005

English - 9

Installing Hardware

Inserting the Battery

Open the battery compartment cover on the lower side of the

mouse and insert the included AA battery in the battery

compartment with the proper poles (refer to the figure below).

10 Optical sensor

11 Battery compartment

12 Eject button for the radio USB receiver

13 Inserted radio USB receiver

The battery is used up when the control lamp (4) on the upper side

of the radio mouse flashes red. Then replace it with a new AA

battery, 1.5 V (Mignon).

Note: The pole direction of the battery to be inserted is sketched in

the battery compartment.

Otros manuales para NM1005

Tabla de contenidos

Idiomas:

Otros manuales de Ratón de Silvercrest

Silvercrest

Silvercrest GML807 Hoja de instrucciones

Silvercrest

Silvercrest OM1007 Manual de usuario

Silvercrest

Silvercrest SFM 4 A1 Manual de usuario

Silvercrest

Silvercrest OML807 Hoja de instrucciones

Silvercrest

Silvercrest OMC807 Manual de usuario

Silvercrest

Silvercrest SFM 4 A1 Manual de usuario

Silvercrest

Silvercrest SGM 4000 A1 Manual de usuario

Silvercrest

Silvercrest SFM 4 C3 Manual de usuario

Silvercrest

Silvercrest Wireless Optical PC Mouse Manual de usuario

Silvercrest

Silvercrest OMC807 Manual de usuario

Silvercrest

Silvercrest SFM 4 A1 Manual de usuario

Silvercrest

Silvercrest SGM 6200 A2 Manual de usuario

Silvercrest

Silvercrest SFM 4 A1 Manual de usuario

Silvercrest

Silvercrest OM 809 Manual de usuario

Silvercrest

Silvercrest SPC M1600 A1 Manual de usuario

Silvercrest

Silvercrest OM1008-SL Manual de usuario

Silvercrest

Silvercrest NM1005 Hoja de instrucciones

Silvercrest

Silvercrest 114047 Manual de usuario

Silvercrest

Silvercrest OM1008-SL Manual de usuario

Silvercrest

Silvercrest OML807 Hoja de instrucciones

Silvercrest

Silvercrest OM1008 Hoja de instrucciones

Silvercrest

Silvercrest 373971 2104 Manual de usuario

Silvercrest

Silvercrest SGM 4000 A1 Manual de usuario

Silvercrest

Silvercrest SFMT 2.4 A1 Hoja de información del producto

Manuales populares de Ratón de otras marcas

Sven

Sven RX-G720 Manual de usuario

3DConnexion

3DConnexion CadMouse Pro Manual de usuario

Canyon

Canyon Puncher GM-20 Manual de usuario

Sharkoon

Sharkoon Light2 180 Manual de usuario

Cherry

Cherry MW 8C ERGO Manual de usuario

NGS

NGS HIT RB Manual de usuario

Sharkoon

Sharkoon FireGlider Manual de usuario

Lenovo

Lenovo Wireless Mouse N3902 Manual de usuario

BASETech

BASETech BN-S11 Manual de usuario

Dell

Dell WM326 Manual de usuario

Areson

Areson B213 Manual de usuario

HP M17587-371 Manual de usuario

Chatpen

Chatpen CHA-30 Manual de usuario

GAMDIAS

GAMDIAS DEMETER GMS5000 Manual de usuario

HP KJ453AA - Wireless Laser Mouse Manual de usuario

Trust

Trust GRAPHIN GXT 960 Manual de usuario

Lenovo

Lenovo SD-9082 Manual de usuario

Alienware

Alienware AW320M Manual de usuario
