Silvercrest 88711 Manual de usuario

IAN 88711

STEAM IRON DB 1400 A1 BL

STEAM IRON

Operating instructions

ПАРНА ЮТИЯ

Ръководство за експлоатация

FIER DE CĂLCAT CU ABURI

Instrucţiuni de utilizare

ΑΤΜΟΣΙΔΕΡΟ

Οδηүίες χρήσης

GLAČALO NA PARU

Upute za upotrebu

DAMPFBÜGELEISEN

Bedienungsanleitung

GB/CY Operating instructions Page 1

HR Upute za upotrebu Stranica 9

RO Instrucţiuni de utilizare Pagina 17

BG Ръководство за експлоатация Cтраница 25

GR/CY Οδηүίες χρήσης Σελίδα 33

DE/AT/CH Bedienungsanleitung Seite 41

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of

the device.

Prije nego što pročitate tekst, otvorite stranicu sa slikama i upoznajte se na osnovu toga sa svim funkcijama

uređaja.

Înainte de a citi instrucţiunile, priviţi imaginile şi familiarizaţi-vă cu toate funcţiile aparatului.

Преди да прочетете отворете страницата с фигурите и след това се запознайте с всички функции

на уреда.

Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες

της συσκευής.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen

Funktionen des Gerätes vertraut.

- 1 -

Content Page

Introduction 2

Intended use 2

Scope of delivery 2

Operating elements 2

Technical data 2

Safety instructions 3

Before initial use 5

Filling the water tank 5

Plugging in and ironing 6

Steam ironing 6

Ironing with steam blast 6

Temporarily setting the steam iron aside 6

Turning off the steam iron 6

Cleaning 7

Storage 7

Troubleshooting 7

Disposal 7

Warranty and service 8

Importer 8

Read the operating instructions carefully before using the device for the first time and keep this booklet for

later reference. Pass this manual on to whoever might acquire the device at a future date.

- 2 -

STEAM IRON

Introduction

Congratulations on the purchase of your new appli-

ance.

You have clearly decided in favour of a quality pro-

duct. These operating instructions are a constituent

of this product. They contain important information

with regard to safety, use and disposal. Before using

the product, familiarise yourself with all of these ope-

rating and safety instructions. Use the product only

as described and only for the specified areas of appli-

cation. Please also pass these documents on to any

future owner, together with the product.

Intended use

The steam iron is exclusively intended for ironing

textiles. The iron may only be used indoors and in

private households. Any other use is deemed

improper. The apparatus is not intended for com-

mercial use!

Scope of delivery

Steam Iron

Measuring beaker

Operating instructions

Operating elements

1Water jet

2Filler opening for the water tank

3Steam regulator

4Button for steam blast

5Button

for fine water spray

6Thermostat

7Temperature control lamp

8Power cable with anti-kink protection

9Appliance base

0Ironing sole

Technical data

Power supply voltage: 220 - 240 V ~ / 50 Hz

max. power consumption: 1400 W

- 3 -

Safety instructions

Risk of Burns!

• Always hold the steam iron by the handle when it is hot.

• Children should be supervised to ensure that they do not play with the appliance.

• Never hold your hand over the steam spray or touch hot metal parts.

• The filler opening of the water reservoir must not be opened while the iron is in

use. First allow the steam iron to cool down and remove the plug from the po-

wer socket.

• The iron and its connecting cable must be kept out of the reach of children

younger than 8 years old when it is switched on or cooling down.

Risk of Injury! Risk of fire!

• Never leave a steam iron that is hot, switched on or connected to the mains

power supply unattended.

• Do not put the steam iron into storage until it has cooled down completely.

• This steam iron must be used and placed on a stable surface.

• When ironing, only use the temperatures detailed in the garment care instructions,

or those suitable for the material. Otherwise, you could damage the textiles.

Should care instructions not be given or known, start with the lowest temperatu-

re setting.

• NEVER allow children to use the steam iron.

• Always put the iron on a level, heat-resistant surface. The iron must be in a

stable position.

• Should you wish to put the steam iron down, always put it on the appliance base.

Risk of electric shock!

• The rating of the local power supply must correspond with the details given on

the rating plate of the appliance.

• To avoid potential risks, arrange for defective appliances to be checked and

possibly repaired by a qualified specialist workshop, or contact our Customer

Service Department.

• Arrange for defective power plugs and/or cables to be replaced immediately

by qualified technicians or our Customer Service Department.

- 4 -

• To disconnect from the power source, only pull the plug itself, not the cable.

• Never bend (kink) or crush the power cable. Arrange it in such a way that it

cannot come into contact with hot surfaces and so that no-one can step on it or

trip over it.

• Remove the plug from the power socket after every use, and before cleaning

or filling with tap water.

• Always unwind the power cable fully before switching on, and do not use an

extension cable.

• Never touch the power cable or the plug with wet hands.

• Never use the steam iron near a bath, shower, wash basin or other vessel

containing water. The proximity of moisture presents a danger, even when the

appliance is switched off.

• Under no circumstances should you submerge the steam iron in liquid or permit

liquids to penetrate the casing of the steam iron. Do not expose the appliance

to humidity and do not use outdoors. Should liquids enter the casing, unplug

the appliance from the socket immediately and arrange for it to be repaired by

a qualified technician.

• You may not open the casing of the steam iron. Should repairs be necessary,

only allow authorised technicians to repair a defective appliance.

• Under NO circumstance should you use the appliance if it shows visible signs

of damage, has fallen, or is leaking. Arrange for it to be repaired by qualified

specialists.

• Do not use the appliance if the anti-kink protection on the power cable is da-

maged!

• This appliance may be used by children aged 8 years or over and by individuals

with reduced physical, sensory or mental capabilities, or lack of experience

and/or knowledge if they are supervised or have been instructed in the safe

use of the appliance and have understood the poten-tial risks. Children may

not play with the appliance. Cleaning and user maintenance should not be

carried out by children without supervision.

- 5 -

Filling the water tank

• Put the iron down on its soleplate 0.

• Open the cover of the filler opening for the

water tank 2.

• Using the measuring beaker, fill the water tank to

the "MAX" marking.

• Slide the cover of the filler opening for the water

tank 2back to close it.

Note:

Should the tap water in your area be rated as hard,

it is recommended that you mix tap water with some

distilled water. Otherwise, the jets for the steam

blast function could calcify (become blocked) pre-

maturely.

To extend the optimal steam blast function, mix tap

water with distilled water as follows.

The water hardness level can be queried at your

local water works.

Water hardness

Ratios - distilled

water to

tap water

very soft / soft 0

medium 1 : 1

hard 2 : 1

very hard 3 : 1

Attention!

• Should the clothing care instructions forbid iro-

ning, (symbol ), the clothing item may not be

ironed. If you do so, the clothing item could be

permanently damaged.

• The water tank is to be filled exclusively with tap

water or distilled water. Otherwise, you will da-

mage the steam iron.

• Do not clean the steam iron with solvents, alcohol

or abrasive cleaning agents, since these could

cause damage.

Before initial use

• Remove the steam iron from the packaging.

• Remove all stickers and protective film from the

steam iron and the ironing sole 0.

Risk of asphyxiation!

Plastic bags can be dangerous. To avoid the risk of

asphyxiation, keep plastic bags out of the reach of

toddlers and small children.

• Pour water into the water tank (see chapter

"Filling the water tank").

• Insert the plug into a wall power socket supply-

ing an electrical current as detailed on the rating

plate.

• Move the thermostat 6to the "MAX" position.

• Heat the steam iron up for several minutes at the

highest setting.

• Press the steam blast button 4a few times

until steam exits from the ironing sole 0.

• Then iron a scrap piece of material to remove

possible contamination from the ironing sole 0.

- 6 -

Plugging in and ironing

Dry ironing is possible at all temperatures, steam iro-

ning is possible by adjusting to on the

thermostat 6.

• Insert the plug into a power socket.

Attention!

Should the clothing care instructions forbid ironing,

(symbol ), the clothing item may not be ironed.

If you do so, the clothing item could be permanently

damaged.

• Check the care instructions on the labels in the

garment to see whether it is suitable for being

ironed, and at which temperature setting.

• Select the best suitable temperature setting with

the thermostat 6.

The temperature control lamp 7glows. When the

set temperature has been reached, the temperature

control lamp 7 goes out.

• Wait until the temperature control lamp 7

switches off.

• To moisten the laundry, press the button for fine

water spray 5.

This function is suitable for extremely dry and extremely

crumpled garments.

Symbol thermostat 6Type of material

Acrylic, rayon

Silk, wool, polyester

blended fabrics

Cotton, linen, viscose

Steam ironing

• Set the steam regulator 3to the desired steam

setting.

• The thermostat 6must be moved to at least

adjustment range . Otherwise it cannot pro-

duce any steam.

Ironing with steam blast

The steam blast is especially suitable for smoothing

parts of a garment that are difficult to reach.

• Slightly raise the steam iron.

• For a steam blast, press the steam blast

button 4.

Temporarily setting the steam

iron aside

Risk of fire!

NEVER leave the hot, mains-connected or switched-on

steam iron unattended.

• Set the thermostat 6to the "MIN" position.

• Always put the steam iron on the appliance

base 9.

Turning off the steam iron

• Remove the plug from the wall socket.

• Empty the water tank and clean the ironing

sole 0.

• Put the steam iron on the appliance base 9

after it has cooled down.

- 7 -

Cleaning

Potentially fatal danger!

Disconnect the plug before cleaning. Otherwise

there is a risk of receiving a potentially fatal electric

shock!

Risk of physical injury!

Allow the appliance to cool before cleaning it.

If you do not, there is a risk of receiving burn

injuries!

• Clean the casing with a soft, dry cloth only.

Attention!

Do not use aggressive, abrasive or chemical cleaning

agents. These could attack the surfaces and cause

irreparable damage to the appliance.

• Clean the soleplate 0using a damp cloth and

a mild, non-scouring detergent.

Storage

Store the appliance in a clean, dust-free, and dry

location after it has cooled down.

Troubleshooting

Steam iron producing little or no steam:

The reserves of water in the steam iron are depleted.

Fill the water tank with tap water (See "Filling the

water tank").

The steam iron does not get hot:

• The steam iron is not plugged in or is not switched

on. Insert the plug into a wall power socket and

adjust the thermostat 6to the desired ironing

temperature.

• The steam iron is defective. Arrange for the steam

iron to be repaired by qualified specialists.

Disposal

Do not dispose of the appliance in your

normal domestic waste. This appliance

is subject to the provisions of European

Directive 2002/96/EC.

Dispose of the appliance through an approved dis-

posal centre or at your community waste facility.

Observe the currently applicable regulations.

In case of doubt, please contact your waste disposal

centre.

Dispose of all packaging materials in an

environmentally friendly manner.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Hierro de Silvercrest

Silvercrest

Silvercrest SDBK 2200 A1 Manual de usuario

Silvercrest

Silvercrest SDBS 2400 A1 Manual de usuario

Silvercrest

Silvercrest 412019 2110 Manual de usuario

Silvercrest

Silvercrest SDB 2400 F4 Manual de usuario

Silvercrest

Silvercrest SDBS 2200 A1 Manual de usuario

Silvercrest

Silvercrest SDB 2200 D2 Manual de usuario

Silvercrest

Silvercrest SDBE 2400 A1 Manual de usuario

Silvercrest

Silvercrest DB 1400 A1 Manual de usuario

Silvercrest

Silvercrest SDBK 2200 C3 Manual de usuario

Silvercrest

Silvercrest 93488 Manual de usuario

Silvercrest

Silvercrest SDBS 2400 A1 Manual de usuario

Silvercrest

Silvercrest KH 1281 Manual de usuario

Silvercrest

Silvercrest 331979 1907 Manual de usuario

Silvercrest

Silvercrest SDBS 2400 B2 Manual de usuario

Silvercrest

Silvercrest DB 1400 A1 Manual de usuario

Silvercrest

Silvercrest SDBK 2400 F5 Manual de usuario

Silvercrest

Silvercrest SDB 2200 C1 Manual de usuario

Silvercrest

Silvercrest SDB 2200 A1 Manual de usuario

Silvercrest

Silvercrest SDB 2200 B1 Manual de usuario

Silvercrest

Silvercrest SDB 2400 F4 Manual de usuario

Silvercrest

Silvercrest 387993 2104 Manual de usuario

Silvercrest

Silvercrest SDBS 2400 A1 Manual de usuario

Silvercrest

Silvercrest SDBE 2400 A1 Manual de usuario

Silvercrest

Silvercrest SDBE 2600 A1 Manual de usuario

Manuales populares de Hierro de otras marcas

Clatronic

Clatronic DB 3703 Manual de usuario

TEFAL

TEFAL FV4093Z0 Manual de usuario

Gorenje

Gorenje SIH 2200 BS Manual de usuario

Philips

Philips GC6012 Manual de usuario

Bosch

Bosch 2 Series Manual de usuario

Riffel

Riffel Catena KB-819 Manual de usuario

Texi

Texi Hestia Manual de usuario

Maxwell

Maxwell MW-3010 Manual de usuario

TREVIDEA

TREVIDEA Girmi ST60 Manual de usuario

Philips

Philips HI5914/30 Manual de usuario

Primula

Primula Vapormat Manual de usuario

Magio

Magio MG-541 Manual de usuario

Scarlett

Scarlett SC-1334S Manual de usuario

Bosch

Bosch Sensixx B22L Manual de usuario

Philips

Philips GC651 Manual de usuario

Vitek

Vitek VT-1247 VT Manual de usuario

Cleanmaxx

Cleanmaxx 3397 Manual de usuario

Philips

Philips GC800 Manual de usuario
