Silver King SKNES2B Guía de inicio rápido

Technical Manual

and

Replacement Parts List

Cream Dispenser

Specifications Subject to Change Without Notice.

1600 Xenium Lane North, Minneapolis, MN 55441-3787

Phone (763) 923-2441

MODEL SKNES2B/3B

FORM NO. 36600 REV A

TECHNICAL MANUAL

MODEL SKNES2B CREAM DISPENSER

INSTALLATION, OPERATION AND MAINTENANCE

Thank you for purchasing Silver King food service equipment. Our goal is to provide our customers with the most reliable

equipment in the industry today. Please read this manual and the accompanying warranty information before operating your new

Silver King unit. Be sure to complete and mail the warranty card within 10 days of purchase to validate your warranty.

Upon delivery of your new Silver King unit, inspect the carton and unit for shipping damages. Report any damage immediately to

the transportation carrier and file a written freight damage claim to protect your investment. If a claim is to be filed, save all

packaging materials.

INSTALLATION

The stainless steel exterior of the cabinet has been protected by a plastic covering during manufacturing and shipping. This

covering can be readily peeled before installation. After removing this covering, wash the interior and exterior surfaces using a

warm mild soapy water solution and a sponge or cloth, rinse with clean water and wipe dry.

Drip Tray:

The Drip Tray and Drip Tray Cover are shipped inside the unit. Install them as shown on the replacement parts diagram found later

in this document.

Location:

When locating your cream dispenser, convenience and accessibility are important considerations, but the following factors must be

observed:

•When placing the unit on a counter, the counter must be able to support a minimum of 100 pounds.

•When placed on a counter, the unit must be on the feet supplied. If the feet are removed the unit will not operate properly

and the warranty will be void.

•There must be at least two inches of clear space above, on the sides and behind the unit and open in front.

•Correct serving height is important so that those using the dispenser can operate the dispenser properly.

•The unit must be level. The feet are adjustable to aid in leveling the unit.

•Avoid placing the unit next to an oven, heating element or hot air source which would affect the performance of the unit.

Electrical Connections:

Be sure to check the data plate, located on the liner of the cabinet, for required voltage prior to connecting the unit to power. The

specifications on the data plate supersede any future discussion.

The standard dispenser is equipped with an seven (7) foot power cord that requires a 115 Volt, 60 Cycle, 1 Phase properly

grounded electrical receptacle. The power cord comes with a 3 prong plug for grounding purposes. Any attempt to cut off the

grounding spike or to connect to an ungrounded adapter plug will void the warranty, terminate the manufacturers responsibility and

could result in serious injury.

The circuit must be protected with a 15 or 20 ampere fuse or breaker.

OPERATION

Initial startup:

After satisfying the installation requirements, the cream dispenser is ready to start. The unit will start when the power cord is

connected to a live electrical receptacle. If the compressor is not running when the unit is initially plugged in, check to make sure

that the Electronic Temperature Control is set to the on position. If the contol is flashing “OF”, press and hold the power button for 3

seconds. Allow the unit to run a minimum of two hours before loading it with product.

Preparation For Use:

Once the unit has achieved proper operating temperature, observe the procedures noted in the label on the door liner for loading

cream into the cream dispenser. When removing an empty Cream Container, be sure to push the Valve Slide in fully before pulling

the Dispensing Tube out of the valve. It may be easier to remove or install the Dispensing Tube in the valve by removing the Valve

Insert first then removing or installing the Cream Container and Dispensing Tube. The end of the tube may need to be cleaned

daily with a clean cloth to prevent buildup which could affect the dispensing of product.

Temperature Control:

The Temperature Control is located on the right side wall of the cabinet and is factory set to maintain an average cabinet

temperature of approximately 35 degrees Fahrenheit. To obtain colder temperatures, press and hold the set button until the set

point value flashes. Use the up or down arrow buttons to change the value and then press the set button again. Allow the unit a

minimum of one hour to respond to a control setting adjustment.

Defrost

The Silver King cream dispenser is an automatic defrost unit. Defrosting is accomplished on a timed basis that is set within the

electronic controller. Defrost water collects in the bottom of the cabinet where it can be wiped out with a cloth.

MAINTENANCE

Preventative maintenance is minimal although these few steps are very important to continued operation and maximizing the life of

the appliance.

Cabinet Surfaces:

The cabinet interior and exterior are stainless steel and should be cleaned periodically with a solution of warm water and a mild

soap, rinsed and wiped dry with a clean soft cloth. A stainless steel cleaner can also be used. Should a surface become stained or

discolored, do not attempt to clean with an abrasive cleaner or scouring pad. Use a soft cleaner and rub with the grain of the metal

to avoid scratching the surface. Do not use chlorinated cleaners.

Valve Assembly:

To dis-assemble the valve for cleaning, with the door open, pull the release latch on the top of the Valve Assembly. The Valve

Assembly will then swivel forward and then slide up and out at an angle. Clean the Valve Assembly with a solution of mild soap and

warm water or in a dishwasher. Rinse, dry and re-assemble. The Valve Body must be cleaned in place as it is not removable.
