Signode TABLE-TYER Manual de instrucciones

12/14/10

CONTENTS

Page

Safety Information

Specifications

Major Components

Disconnect & Lockout

Electrical Schematic

Operation

Parts List & Views

Spare Parts

CONGRATULATIONS

12/14/10

Thank you for purchasing your Table-Tyer Strapping Machine. The Table-Tyer has

been designed to be a reliable, maintenance free strapping machine. The

innovative design of this machine allows for every maintenance part to be

replaced easily and quickly with very little or no instruction.

Considerableeffort has been made to ensure that this product conforms to our

high quality standards. However, should you experience any difficulties, please

contact your Signode Representative with your machine model and serial number.

Thank you for your help.

TABLE-TYER

STRAPPING MACHINE

PART NO.

500998

All conditions and options have

been

detailed

in this manual to guide and alert

operating and service personnel with respect

to safety, operation and maintenance

procedures. A complete parts listing, with

exploded views, has been included in this

manual in the event replacement parts must

be ordered. Please review each section of

this manual before operating your machine.

PLEASE NOTE: Most of the fasteners in this machine are metric. Before removing and replacing any

part, refer to the parts listing to determine the proper tools to use and

the correct size hardware that may have to be replaced.

12/14/10

WARNING - READ AND FOLLOW THESE INSTRUCTIONS - FAILURE TO

THIS COULD RESULT IN SEVERE PERSONAL

INJURY.

OPERATING INSTRUCTIONS

1. Only people trained in the use of strapping machines are to operate or service this machine.

2. Read all signs on machine. Do not remove, modify or deface any sign. Replace all damaged

signs.

3. Inspect the machine for unsafe conditions - DAILY - and replace all worn or broken parts.

4. Keep work area uncluttered and well lit.

5. If you require safety instructions in another language, contact your local Signode

representative.

MAINTENANCE

1. Establish a preventive maintenance program for your machine by following the preventive

maintenance program in this manual.

2. To ensure proper machine operation, use the specified power sources listed in this manual.

3. Do not overload the machine by exceeding the package size specification.

4. Remove all packages from the machine before performing service.

5. Unless otherwise noted in this manual, disconnect and lockout all power before servicing your

machine.

6. Follow all maintenance and service instructions in this manual.

MOVING MACHINE PARTS

1. Disconnect and lock out all power to Signode's machines before entering the strap chute area.

2. Never put any part of your body into the strap chute area or machine enclosure with machine

power on.

3. Never stand on the machine table-top.

MACHINE INSTALLATION

1. All customer interlocks must be connected as shown in this manual's electrical drawings.

Failure to properly connect interlocks can result in improper machine operation and/or

personal injury.

2. Be familiar with the locations of safety interlocks/guards and Emergency Stop Devices - refer

to machine manual topic "Disconnect & Lockout Procedures".

3. Do not defeat any safety interlock or safety device. Do not operate machine with any safety

devices/guards removed.

4. Before operating the machine, ensure that all safety interlocks and Emergency Stop buttons

are operating properly.

5. Unauthorized modifications can present a safety hazard to machine personnel and will void the

machine warranty.

6. Secure the machine in place using the locking casters.

12/14/10

PERSONAL PROTECTION

1. To prevent back or other body injuries, your employer must provide proper lifting and/or

handling instructions. Your employer may also contact the National Safety Council, Itasca, IL

60143-0558 for information on lifting techniques.

2. When removing tensioned strap from a package, proceed as follows:

a. Wear eye, face and hand protection

b. Before cutting strap, make sure all personnel are at a safe distance.

c. Hold the strap against the load above the cutter as shown.

d. Using the proper Signode strap cutter, cut strap as pictured.

e. Stand clear of unheld strap end which will spring out if under

pressure.

3. Always wear steel reinforced safety shoes.

4. Always wear safety glasses with side shields which conform to ANSI

Standard Z-87.1 or EN 166

5. Wear protective gloves when handling strap.

ENVIRONMENTAL INFORMATION

The emissions produced during the heat sealing process may be an irritant to some people. Use

this machine in areas that are externally ventilated. Should you be affected by these fumes, move

away from machine to fresh air.

LOCKOUT/TAGOUT

1. Follow OSHA 1910.147 (Lockout/Tagout Regulation) for machine lockout procedures and other

important lockout/tagout guidelines.

2. Be familiar with all lockout sources on this machine, refer to the "Lockout & Tagout" section of

this manual.

3. Even after a machine has been locked out, there may be stored energy in the system. To

ensure that all stored energy is relieved, wait at least one minute before servicing electrical

capacitors and wait 5 minutes for hot knife to cool.

4. Before performing service in the strap chute area, disconnect and lockout machine power.

MOVING THE MACHINE

Wheel kits are standard for Signode general purpose machines. A forklift may be used to transport

the machine from one location to another. Consult your employer for proper lifting and handling

methods.

12/14/10

TABLE-TYER,

MACHINE SPECIFICATIONS

STRAP SIZES: Signode Empax 1/4" (6mm), 3/8" (9mm), 1/2" (12mm)

PACKAGE SIZE (Minimum): 3 1/2" W x 1-1/2" H

VOLTAGE SPECIFICATIONS:

Rated current:

Rated voltage:

110V

Rated frequency:

6OHz

Type of current:

FAULT PROTECTION: Fused

SYSTEM DISCONNECT: HP Rated switch

OPERATING HEIGHT: Minimum 30-3/4", Maximum 37-1/2"

WEIGHT: 168 lbs.

NOISE EMISSIONS: 55dB

MACHINE DIMENSIONS:

12/14/10

MAJOR COMPONENTS - EXTERNAL

1. Main switch

2. Heater lamp, lamp will light on when proper sealing temperature is reached

3. Potentiometer, strap feed length

4. Button, strap feed and reset

5. Potentiometer, strap tension adjustment

6. Table top, hinge

7. Strap reel

8. Caster (2 locking)

9. Adjustable legs (Table-Tyer)

10. Frame

11. Access Door

12/14/10

MACHINEDISCONNECT AND LOCK-OUT PROCEDURES

This machine is equipped with shut off devices which satisfy OSHA Regulation 1910.147 (control

of hazardous energy sources - lock out/tag out).

Become familiar with the location, and operation of each shutoff device.

Disconnect/Lock-Outall power sources before servicing machine.

Never use machine operating controls as a means for locking out power.

ELECTRICAL

The machine is ready to operate when connected to the main power supply and the main switch

QS I is switched to ON position. It takes approximately I minute for the heating element to reach

its operating temperature.

The machine is switched on and off with the main switch QS 1 located on the machine front

operating panel.

P Turn the main disconnect switch to the OFF position.

P Locate the appropriate locking hole on the switch, and apply a locking device.

NOTE: Some electrical components in the machine may be electrically charged after the power is

shut off. Wait no less than one minute after the power has been disconnected before servicing the

panel.

12/14/10

ELECTRICAL SCHEMATIC, TABLE TYER
