Siemens SIMATIC IPC347G Manual de usuario

2.5mm²

PH2

Risk of electric shock when using a power connection without earth connection.

Using a mains cable without proper earth connection can result in personal injury or even death by

electric shock.

A mains cable is not included with IPC347G.

Make sure the cable you use provides a proper earth connection.

It is highly recommended that you use a mains cable from SIEMENS.

WARNING

CAUTION

The device is intended for operation on grounded power supply systems (TN systems according to IEC

60364-3). It is not designed for opertion on undergrounded or impedance-grounded power networks

(IT networks).

In case of connect the device to ungrounded or impedance-grounded power networks (IT networks),

there is a risk of electric shock, ﬁre and burst.

Ensure the power supply system the device operating on is correctly grounded.

nnecting the power

Mounting on telescopic rails

Mounting on angle brackets Mounting on device bases

The device is too heavy to be mounted exclusively with the 19 inch brackets of the front panel.

The device may fall down, injure people and get damaged.

Secure the device using additional measures. The mounting screws of the telescopic rails may not

protrude more than 5 mm into the device.

CAUTION

Risk of physical injury

With a safety alert symbol, indicates that minor personal injury can result if proper precauions are

not taken.

CAUTION

The manual symbol refers to detailed information in the operating instructions.

IMPORTANT: observe all documents enclosed with the device and the operating instructions manual

before mounting and connecting the device. You can ﬁnd the complete documentation of the device

on the enclosed USB stick and on the internet.

(http://www.siemens.com/simatic-ipc-doku-portal)

40 °C

5 °C

At least 50 mm space has to be left free around the ventilation slot.

Before mounting and commissioning

Installing the device

Valid Mounting positions

Mounting the device Connecting the device

Connecting the power supply

Connecting the function earth

SIMATIC

Industrial PC

SIMATIC IPC347G

Quick Install Guide

Central Technical Support

https://support.industry.siemens.com

Mounting the device

Connecting the device

Commissioning the device

10/2020

A5E50059910-AA

Siemens AG

Division Digital Factory

Postfach 48 48

90026 NÜRNBERG

GERMANY

Disclaimer of Liability

We have reviewed the contents of this publication to ensure consistency with the hardware and

software described. Since variance cannot be precluded entirely, we cannot guarantee full

consistency. However, the information in this publication is reviewed regularly and any necessary

corrections are included in subsequent editions.

This document contains illustrations of the described devices and accessories.

The illustrations may deviate from the particularities of the delivered device and accessories.

Illustrations

Self-Test

Operating system starts automatically after the Self-Test is completed.

Press the on/oﬀbutton to start the computer.

Set the on/oﬀswitch to position “ ”.

PS2

VGADisplayPort

USB

Commissioning the device

Connecting mouse, keyboard, monitor

Switching on the device
