Siemens LITHOSTAR Multiline Guía de configuración

LITHOSTAR Multiline

Print No.: RXL2-120.091.08.04.02 Doc. Gen. Date: 10.00

Replaces: RXL2-120.091.08.03.02

The reproduction, transmission or

use of this document or its contents

is not permitted without express

written authority. Offenders will be

liable for damages. All rights,

including rights created by patent

grant or registration of a utility

model _or_design,_are_reserved.

System Manual

Replacement of Operating PC

Repair Instructions

LITHOSTAR Multiline Register 5 RXL2-120.091.08 Page 2 of 4 Siemens AG

System Manual Rev. 04 10.00 TD PS 24 Medical Engineering

0 - 2 Revision

Chapter Page Revision

0all04

1all04

2all04

3all04

4all04

5all04

Contents 0 - 3

Siemens AG Register 5 RXL2-120.091.08 Page 3 of 4 LITHOSTAR Multiline

Medical Engineering Rev. 04 10.00 TD PS 24 System Manual

1 _______Software generation ____________________________________________1 - 1

Rear view of the operating PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1

2 _______Operating PC SCENIC Pro C5/ Pro C6______________________________2 - 1

Mechanical changes in the control console . . . . . . . . . . . . . . . . . . . . . . .2 - 1

Opening the operating PC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2

Installing board D51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 - 3

Closing the operating PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 4

3 _______Operating PC LM Control Unit ____________________________________3 - 1

Open operating PC and install board D51. . . . . . . . . . . . . . . . . . . . . . . . 3 - 3

Close the operating PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 3

4 _______Changes to previous version_____________________________________4 - 1

Page

0 - 4 Contents

LITHOSTAR Multiline Register 5 RXL2-120.091.08 Page 4 of 4 Siemens AG

System Manual Rev. 04 10.00 TD PS 24 Medical Engineering

This page intentionally left blank.

Page

1 - 1

Siemens AG Register 5 RXL2-120.091.08 Page 1 of 4 LITHOSTAR Multiline

Medical Engineering Rev. 04 10.00 TD PS 24 System Manual

Rear view of the operating PC 1

1 Keyboard port 5 Parallel interface X50 Respirator-ECG signal interface

2 Moouse port 6 Monitor port X51 DUEP port

3 Serial interface COM 1 7 Power line connector

4 Monitor power line connector

SCENIC Pro C6

Position D51

X50 X51

2356

4Position D51

LM - Control Unit

X50 X51

SCENIC Pro C5 7

X51

X50

Software generation 1

LITHOSTAR Multiline Register 5 RXL2-120.091.08 Page 2 of 4 Siemens AG

System Manual Rev. 04 10.00 TD PS 24 Medical Engineering

1 - 2 Software generation

•SwitchthesystemOFF.

•Placethenew operatingPCinthedrawerof thesystemcontrolconsole.

•Connectthe followingcablestotheoperatingPC:

- linevoltagecableforoperatingPC

- linevoltagecableformonitor

- signalcableformonitor

- signalcableformouse

- signalcableforkeyboard

•SwitchthesystemON.

The greenLED onthe operatingPC mustlightup.

•On the operatingPC.

•SwitchthesystemOFF.

•InsertthebootdiskindriveA of theoperatingPC.

•SwitchthesystemON.

•Ifthekeyboardisreplaced,theUserTerminalsoftwaremustbe reinstalled.

Answeraccordingly.

SCENIC Pro C5 / C6

Ïthe following message appears:

"MS-DOS 6.2 Startup Menü"

•usethedown arrowkey"↓" to select

"2.PCneu startenodermanuell

ausschalten"

German texts will appear during the installation of the software

→This is due to the German operating system.

NOTICE

User-Terminal-Software Installation?

No: Press [ Ctrl ]+ [ C ]

YES: Press any key, to continue

Eine beliebige Taste drücken, um fortzusetzen.

Software generation 1 - 3

Siemens AG Register 5 RXL2-120.091.08 Page 3 of 4 LITHOSTAR Multiline

Medical Engineering Rev. 04 10.00 TD PS 24 System Manual

•Afterafew moments,thefollowingcommandappears:

•Pressthe"J" key and then"Enter/Entrée".

•Thecommand to enterthe type of keyboardappears:

•Selecteither"E"or"F",dependingon the type ofkeyboard,andpress"ENTER"/Entrée".

•Afterafew moments,thefollowingcommandappears:

•Removethe boot disk from driveA.

•Insertthebackupdisk01 in drive A.

•Pressanykey.

•When the system finishesloadingbackupdisk01,the followingcommand appears:

•Remove backup disk 01from drive A.

•Insertbackupdisk02 in driveA.

•Repeatthesame procedurefortheremainingbackupdisks.

•Onceallthe backup diskshavebeen loaded,the followingmessageappears:

•Remove backup disk 05from drive A.

•InserttheUserInterfaceSWdisk in drive A.

Hard-Disk will be formatted!

Please wait 5 sec. for next message and press "J" and [ENTER ] !

WARNUNG! Alle Daten auf der Festplatte in Laufwerk C:

werden gelöscht!

Formatieren durchführen (J/N)?

Enter keyboard type:

E: englisch (international) keyboard

F: french keyboard

Press "E" or "F" according to keyboard type and press [ENTER ]:

Please insert "Backup-Disk 01... 05" (Sicherungdiskette 01... 05)!

Press any key, to continue!

Sicherungsdiskette 01 in Laufwerk A: einlegen

Eine beliebige Taste drücken, um fortzusetzen

Sicherungsdiskette 02 in Laufwerk A: einlegen

Eine beliebige Taste drücken, um fortzusetzen

Please insert disk: "User-Interface-SW"!

Press any key, to continue!

Eine beliebige Taste drücken, um fortzusetzen

LITHOSTAR Multiline Register 5 RXL2-120.091.08 Page 4 of 4 Siemens AG

System Manual Rev. 04 10.00 TD PS 24 Medical Engineering

1 - 4 Software generation

•Afterafew moments,thefollowingcommandappears:

•Remove the User Interface SW disk from drive A.

•InserttheStatusdiskindriveA.

•Afterafew moments,thefollowingcommandappears:

•Removethe Status disk from drive A.

•InsertthebootdiskindriveA.

•Afterafew moments,thefollowingcommandappears:

•SwitchthesystemOFF.

•Removethe boot disk fromdriveA.

•Fortheadditionalstepsrequired,refertothechapterwhichcorrespondsto theoperating

PC being used.

Do not activate the write protection on the diskette, since data

must be written onto it.

Please insert "Status-Disk"!

Press any key, to continue!

Eine beliebige Taste drücken, um fortzusetzen

CAUTION

Please insert "BOOT-Disk" again!

Press any key, to continue!

Eine beliebige Taste drücken, um fortzusetzen

*******A T T E N T I O N: I M P O R T A N T N O T E! *********

Modify CMOS-SETUP according to service-manual!

- CMOS-Setup-Lock by Password

- Disable Disk-Controller

See instructions!

Please remove disk!

Now, switch off the PC and turn it on again for CMOS-Setup-Modify!

Thank you!

2 - 1

Siemens AG Register 5 RXL2-120.091.08 Page 1 of 4 LITHOSTAR Multiline

Medical Engineering Rev. 04 10.00 TD PS 24 System Manual

Mechanical changes in the control console 2

•Especially in thecase oftheSCENIC ProC5: operating PC

- Replacetheexistingground conductorin the controlconsolebythelongerone from

theconversionkit4783 416.

- Connectthecablefor the DUEP connectionX51and fastenfirmlyon thetopof the

connectorbracketusingtheclipfrom the conversion kit.

- Placethewoodenconsolefrom the conversionkit4783 416 onthe drawer.

- PlacetheoperatingPCon thewooden console.

•When the message "PressF2to enterSETUP" appears,pressthe"F2"key.

TheCMOS setupmenu appears.

•Selectthe"Main"menu usingthe← →cursorkeys.

•Inthe "Main" menu, use the ↑ ↓ cursorkeystoselectthe submenu "Boot Option".

•Pressthe "ENTER"key; use "Entrée"onthe French keyboard.

•Setthe"Post Errors"menu to "No Halt on Any Errors"usingthe +/- keys

(numerickeypad).

•Selectthe"FastBoot"menu using the↑ ↓cursorkeys.

•Setthe"Fast Boot" menu to"Enabled"usingthe +/- keys (numeric keypad).

•Selectthe"QuietBoot"menu usingthe↑ ↓cursor keys.

•Setthe"Quiet Boot" menu to"Enabled"usingthe+/-keys(numerickeypad).

•Selectthe"BootSequence:1."menu using the ↑ ↓cursorkeys.

•Setthe"Boot Sequence: 1." menu tothe harddiskusingthe "-" key (numeric keypad.

(theharddiskis1; the disketteis2).

•Pressthe "Esc" key; use the "Echap"keyon the Frenchkeyboard.

•Selectthe"Advanced"menu using the ← → cursorkeys.

•Inthe"Advanced"menu, use the↑ ↓ cursorkeys toselectthesubmenu"Peripheral

Configuration".

•Pressthe "ENTER"key; use "Entrée"onthe French keyboard.

•Selectthe"DisketteController" menu using the ↑ ↓cursorkeys.

•Setthe"DisketteController"menuto"Disabled"usingthe+/-keys(numerickeypad)

•Pressthe"Esc" key; use "Echap" on theFrenchkeyboard.

•Selectthe"Security"menuusingthe← → cursor keys.

•Inthe"Security"menu, use the ↑ ↓ cursorkeystoselect"SetSetup Password".

•Pressthe "ENTER"key; use "Entrée"onthe French keyboard.

•Enterthepassword"TDRX".

•Pressthe "ENTER" key twice;use"Entrée"onthe French keyboard.

•Enterthe password"TDRX" again.

Operating PC SCENIC Pro C5/ Pro C6 2

LITHOSTAR Multiline Register 5 RXL2-120.091.08 Page 2 of 4 Siemens AG

System Manual Rev. 04 10.00 TD PS 24 Medical Engineering

2 - 2 Operating PC SCENIC Pro C5/ Pro C6

•Pressthe"ENTER" key; use "Entrée"on the French keyboard.

•Usethe↑ ↓ cursor keys to selectthesubmenu "FlashWrite".

•Setthe"Flash Write"menu to"Disabled"usingthe+/-keys(numerickeypad).

•Pressthe"Esc"key;use "Echap" on theFrenchkeyboard.

•Usethe← → cursorkeystoselectthe"Power"menu.

•Usethe↑ ↓ cursor keys to select the"APM"menu.

•Setthe"APM" menuto "Disabled"usingthe +/- keys (numerickeypad).

•If"PowerManagementMode" is notsetto "Disabled",usethe↑ ↓cursorkeys to select

"PowerManagementMode".

•Pressthe"Esc"key;use "Echap" on theFrenchkeyboard.

•Selectthe"Power"menu using the ← → cursorkeys.

•Inthe "Power" menu, use the↑ ↓ cursorkeys toselectthesubmenu"PowerManage-

mentMode".

•Setthe"Power Management Mode"menu to "Disabled" usingthe +/- keys (numeric

keypad).

•Pressthe"Esc"key;use "Echap" on theFrenchkeyboard.

•Pressthe"ENTER" key twice;use"Entrée"onthe French keyboard.

•Afteramoment, the Multiline operatingsoftwarewilldisplaythe start-upmessage:

"NoHost Communication".

•SwitchthesystemOFF.

Opening the operating PC 2

•Removeallexternalcables.

•Openthe operatingPC (1/Fig.1).

•Slidethedrivecovertothe left (2/Fig.1).

•Forthe upper part of the housing

- slightly lifttherearedge (1/Fig.2).

- slidetowardsthefront(2/Fig.2).

- liftitupwards(3/Fig. 2).

Fig. 1 Fig. 2

Otros manuales para LITHOSTAR Multiline

Tabla de contenidos

Otros manuales de Equipos industriales de Siemens

Siemens

Siemens SINAMICS G120 PM240-2 FSA Guía del administrador

Siemens

Siemens SIRIUS 3RB29 6-2 Series Manual de usuario

Siemens

Siemens SICHARGE UC Guía

Siemens

Siemens SIMATIC NET CP 1542-5 Documento técnico

Siemens

Siemens ST750 Manual de usuario

Siemens

Siemens SINUMERIK ONE NCU 1760 Documento técnico

Siemens

Siemens Desigo PXC4.E16 Manual de usuario

Siemens

Siemens sitrans Manual de usuario

Siemens

Siemens 3RK1405-1SE15-0AA2 Manual de usuario

Siemens

Siemens 3KC8338-0CA22-0GA3 Manual de usuario

Siemens

Siemens SIVACON 8PS LD Series Manual de usuario

Siemens

Siemens 3RV1.6 Manual de usuario

Siemens

Siemens Gigaset S2 Professional Manual de usuario

Siemens

Siemens 3VL9300-8BG00 Manual de usuario

Siemens

Siemens ET 200iSP Manual de usuario

Siemens

Siemens SIVACON Manual de usuario

Siemens

Siemens 3TK2810-1 Manual de usuario

Siemens

Siemens MOBILETT Plus Instrucciones de funcionamiento

Siemens

Siemens SIMATIC S7-1500R/H Documento técnico

Siemens

Siemens BD2 Manual de usuario

Siemens

Siemens SIREMOBIL Compact L Instrucciones de uso

Siemens

Siemens SIMATIC ET 200S Manual de usuario

Siemens

Siemens 3VA9 47 0KT00 Series Manual de usuario

Siemens

Siemens BD 2-AK 1 Series Manual de usuario

Manuales populares de Equipos industriales de otras marcas

ABB

ABB Unifix AD Manual

Mark 7

Mark 7 Evolution Manual de usuario

Husky

Husky HyPET Manual de usuario

bora

bora PM-1800 Manual de usuario

Grizzly

Grizzly T32428 Manual de usuario

ABB

ABB HT610965 Manual de usuario

ABB

ABB SafeLink Manual de usuario

Phoenix

Phoenix PHX-150 Manual de usuario

ABB

ABB A165-L32 Manual de usuario

ABB

ABB HT842936 Manual de usuario

Rioned

Rioned UrbanJet Manual de usuario

Hermetica

Hermetica 10 Series Manual de usuario

HORNER

HORNER OEE Solution Manual de usuario

Hammerhead

Hammerhead HG375 Manual de usuario

SCHUNK

SCHUNK VERO-S NSE-A3 138 Instrucciones de uso

ABB

ABB HT566657 Manual de usuario

Webasto

Webasto GSE CAN Manual de usuario

ABB

ABB HT614003 Manual de usuario
