EN Operating instructions

ER326AB92X

to be used with Town Gas

Table of contents

Safety precautions....................................................5

Your new appliance..................................................8

The gas burner.........................................................9

Switching on

automatically

...................................................

Safety

system

.....................................................................

Switching off the

burner......................................................

Power levels

.......................................................................

Warnings

............................................................................

Suitable

pans

......................................................................

Accessories........................................................................

Cooking

recommendations.................................................

Precautions for use.................................................13

Cleaning and maintenance.....................................14

Cleaning

.............................................................................

Unsuitable

products............................................................

Maintenance

.......................................................................

Faults......................................................................15

Technical Assistance Service.................................16

Warranty

conditions............................................................

Used appliances and packaging.............................16

Dear customer,

Congratulations on your choice and thank you for purchasing one of our

appliances. This practical, modern and functional appliance is manufactured using

materials of the highest quality which are subject to strict Quality Control checks

throughout the entire manufacturing process. The appliance is meticulously tested

to ensure that it meets your demands and produces perfect cooking results.

Do not remove the appliance from its protective packaging until it is installed in the

unit.

Please read these instructions carefully before proceeding to install and use the

appliance. The information contained in these instructions is essential for the

correct operation of the appliance and, more importantly, for your safety.

The packaging of your appliance has been manufactured using only the materials

which are strictly necessary to guarantee efficient protection during transport.

These materials are 100% recyclable, thus reducing the environmental impact. You

can also contribute to caring for the environment, by following the advice below:

- dispose of the packaging in the appropriate recycling bin.

- before you get rid of an old appliance, make sure you disable it. Contact your local

authority to find out the address of your nearest recycling centre to dispose of your

appliance.

- do not pour used oil down the sink. Collect it in a sealed container and take it to

an appropriate collection point or, failing that, place it in the rubbish bin (it will end

up in a controlled dump; this is probably not the best option, but it will avoid

contaminating ground water).

IMPORTANT:

In the unlikely event that the appliance should be damaged or not meet your

expectations in terms of quality, please inform us as soon as possible. For the

warranty to be valid, the appliance must not have been tampered with, or used

inappropriately.

Safety precautions

Read these instructions carefully. Reading these

instructions will enable you to use your appliance

safely and effectively.

Use approved gas tubing bearing EMSD approval

marking (example: 機電工程署批准 EMSD

APPROVAL GTXXXX) for connection to appliances,

or other appropriate methods accepted by EMSD.

HK Town Gas connection

External Gas Governor Beckley 2300 or Elitre EL-

130 should be installed, the operating pressure is

12.5mbar.

Attention! According to the Gas Safety

Ordinance of Hong Kong, any gas installation

works including the installation of appliances

and connection tubing, must be undertaken by

registered gas installers who are registered for

that appropriate classes and be employed by

registered gas contractors.

When installing built-in gas hob on top of stove

cabinet, please check that there is provision for

ventilation at the cabinet to ensure proper

operation of the gas hob.

Do not store any flammable materials, sprays or

pressurized containers inside the stove cabinet.

The panel of this built-in hob is made of ceramic

glass which is safer than normal glass for this

application. However, the following safety

precautions for using gas hob with glass top

panel should also be noted in order to prevent

the glass top panel from breaking：

1. Clean the burner assembly frequently to

maintain a clear gas passage on the flame

distributor. Clean and tidy up the flame

distributor after spillage of food and liquid once

the burner assembly cooled down.

2. Turn off the gas appliance immediately if

abnormal noise propagates from the gas

appliance and contact a gas supply company or

gas hob importer for inspection.

3. Do not use oversized utensils for cooking.

4. Do not impact the glass surface with hard

objects or place heavy objects on the glass

surface.

Please do not use additional fitting, such as

aluminum cover.

All operations relating to installation and regulation

must be carried out by an authorised installation

engineer, respecting applicable regulations,

standards and the specifications of the local gas

and electricity providers.

Before installing your new hob, ensure that it is

being installed according to the assembly

instructions.

This appliance can only be installed in a well

ventilated place in accordance with existing

regulations and ventilation specifications. The

appliance must not be connected to a combustion

product removal device.

This appliance has been designed for home use

only, not for commercial or professional use. This

appliance cannot be installed on yachts or in

caravans. The warranty will only be valid if the

appliance is used for the purpose for which it was

designed.

The place in which the appliance is installed must

have fully- functioning ventilation, in accordance with

the regulations.

Do not subject the appliance to draughts. These

might blow out the burner.

This appliance leaves the factory set to the type of

gas that is indicated on the specifications plate. It

must not be changed to another type of gas.

Do not tamper with the appliance’s interior. If

necessary, call our Technical Assistance Service.

These operating and installation instructions should

be retained, and passed onto the buyer if the

appliance is sold.

Do not switch on the appliance if it is damaged in

any way. Contact our Technical Assistance Service.

The surface of cooking appliances heat up during

use. Care must be taken when using these

appliances. Keep children well away from the

appliance.

This appliance is only intended for cooking

purposes, not as a heating system.

Fat or oil which is overheated can catch fire easily.

Do not leave oil or fats to heat up unattended. If oil

or fats do catch fire, never use water to put the fire

out. Risk of burns! Put the fire out by covering the

pan with a lid and switch off the hotplate.

In the event of a malfunction, turn off the

appliance’s gas and electricity supply. For repairs,

call our Technical Assistance Service.

If one of the controls will not turn, do not force it.

Call the Technical Assistance Service immediately,

so that they can repair or replace it.

Never place unstable pans on the hob or the

burners, as they may accidentally tip over.

Do not clean the hob using a steam cleaner. Risk of

electrocution!

This appliance is class 3 type, according to EN 30-1-

1 standard for gas appliances: built-in appliance.

Do not store or use corrosive chemicals, steamers,

flammable materials or non-food products below or

near this domestic appliance.

This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.

Never let children play with the appliance.

Never leave the appliance unattended during

operation.

The graphics in this instruction manual are

given as a guide only.

The manufacturer is exempt from all

responsibility

the requirements of this manual

are not complied with.

Your new appliance

Product description: Double-flame burner town gas hob with flame sensor safety

device.

Heat input: 6.0 kW (with Hong Kong town gas at 12.5 mbar)

Product dimension: 520 x 302 x 87 mm (D x W x H)

Net weight: 8,0 kg

Operating gas pressure/

outlet pressure of

governor:

12.5 mbar (Hong Kong town gas)

Dual double-flame

burner

Pan support

Control knob

This individual appliance can be combined and/or with conventional hobs of the same

make, using the joint accessory. See the catalogue for details.

The gas burner

OperationIt is essential to ensure that all the burner parts and the pan

supports are correctly installed for the appliance to work

correctly. Fig. 1 + 2.

1 burner cover

2 burner cap

3 outer burner spreader

4 intermediary ring

5flame diffuser

Fig. 1

Fig. 2

Switching on

automatically 1. Press the burner control and turn it anticlockwise to the

ignition position .

While the control is still pressed down, sparks are produced

on the burner. The flame ignites (it is no longer necessary to

press down the control).

2. Turn the control to the required setting.

If it does not come on, turn the control to the off setting Úand

repeat the steps above. This time, press and hold the control

for longer (up to 10 seconds).

Warning! If after 15 seconds have elapsed, the flame does not

ignite, switch off the burner and open a nearby window or

door. Wait at least one minute before trying to switch the

burner back on.

Safety system Your hob has a safety system (thermocouple) that prevents

the flow of gas if the burner accidentally switches off. To

ensure that this device is active, switch on the burner as usual

and, without releasing the control, press and hold it down

firmly for 4 seconds after lighting the flame.

Switching off the

burner Turn the control clockwise to the off setting Ú.

Power levels The progressive controls can be used to control the power

needed, from minimum to maximum power.

For dual double flame burners, the inner and outer flames can

be controlled separately.

The available power levels are as follows:

Inner and outer flame on full power.

Outer flame on minimum, inner flame on full power.

Inner flame on full power.

Inner flame on minimum power.

Warnings It is normal to hear a slight whistling noise while the burner is

operating.

When it is first used, it is normal for the burner to give off

odours; this does not pose any risk and does not indicate a

malfunction; they will disappear in time.

A few seconds after the burner is switched off, a sound (thud)

will be produced. This is not a fault – this means that the

safety device is no longer operating.

Otros manuales para ER326AB92X

Tabla de contenidos

Otros manuales de Quemador de Siemens

Siemens

Siemens iQ700 ER9A6SB70 Series Hoja de especificaciones

Siemens

Siemens ET975MD11Q Manual de usuario

Siemens

Siemens EC645HB90E Manual de usuario

Siemens

Siemens EH6 QA1 Series Manual de usuario

Siemens

Siemens EH Series Manual de usuario

Siemens

Siemens EH8..ML2 series Manual de usuario

Siemens

Siemens EX8 LV Series Manual de usuario

Siemens

Siemens EH675TK11E Guía de configuración

Siemens

Siemens Gas hob Manual de usuario

Siemens

Siemens iQ500 EP6A C 20 Series Hoja de especificaciones

Siemens

Siemens ER726RB90E Manual de usuario

Siemens

Siemens EC675PB21 Manual de usuario

Siemens

Siemens EX875KYW1E Manual de usuario

Siemens

Siemens ET6 CEA1 Series Manual de usuario

Siemens

Siemens EH9 LV Series Manual de usuario

Siemens

Siemens ET6..HF17. Manual de usuario

Siemens

Siemens ET8 Series Manual de usuario

Siemens

Siemens EC6A H 90I Series Hoja de especificaciones

Siemens

Siemens ET645FEP1E Manual de usuario

Siemens

Siemens EF 781 Series Manual de usuario

Siemens

Siemens EH875FFB1E Manual de usuario

Siemens

Siemens ET515502 Manual de usuario

Siemens

Siemens EH8 HVB Series Hoja de especificaciones

Siemens

Siemens EP6A C 20 Series Manual de usuario

Manuales populares de Quemador de otras marcas

AEG

AEG CERAMIC HOB 6010 K Manual de usuario

VALERA

VALERA CT 70A Manual de usuario

Zanussi

Zanussi ZGF 6420 Manual de usuario

Gaggenau

Gaggenau CI 273 Manual de usuario

G3 Ferrari

G3 Ferrari Energy Manual de usuario

Pkm

Pkm IN4B Manual de usuario

Award

Award H903BG Manual de usuario

Zanussi

Zanussi VCH 5005 RZ Manual de usuario

Miele

Miele KM 523 Manual de usuario

Hotpoint

Hotpoint IS67V8CCXT/E Manual de usuario

AEG

AEG HK854870XB Manual de usuario

Cookology

Cookology SEP600BK Manual de usuario

Bauknecht

Bauknecht Hob Manual de usuario

Zanussi

Zanussi ZGM 782 Manual de usuario

dipo INDUCTION

dipo INDUCTION DIBK218S Manual de usuario

Miele

Miele KM 5987 Manual de usuario

Miele

Miele KM 360 G Manual de usuario

Blomberg

Blomberg MKN 24201 W Manual de usuario
