Siemens ACC AP Manual de usuario

Access Control

SiPass integrated

ACC AP Technical Manual

MP 2.80

A6V11367717

Smart Infrastructure

07.09.2020

2 | 16

A6V11367717

Technical specifications and availability subject to change without notice.

We reserve all rights in this document and in the subject thereof. By acceptance of

the document the recipient acknowledges these rights and undertakes not to

publish the document nor the subject thereof in full or in part, nor to make them

available to any third party without our prior express written authorization, nor to

use it for any purpose other than for which it was delivered to him.

Edition: 07.09.2020

Document ID: A6V11367717

A6V11367717

3 | 16

Table of Contents

1 About this Document .................................................................................. 5

2 Details for Ordering..................................................................................... 6

3 Safety Regulations...................................................................................... 7

4 Standards and Guidelines........................................................................... 8

5 Technical Specifications ............................................................................. 9

5.1 Battery ...........................................................................................................10

5.2 ACC-AP Controller Diagram .........................................................................10

5.2.1 Description of Numbered Items in the Diagram.............................11

6 Installation ................................................................................................ 12

6.1 OSDP Reader Connections ..........................................................................12

6.2 Wiegand Reader Connections ......................................................................12

6.3 Mounting........................................................................................................14

6.4 Tamper Function ...........................................................................................15

6.5 Configuration .................................................................................................15

About this Document

A6V11367717

5 | 16

1About this Document

This document contains information on the mounting and installation of the

product.

The ACC-AP, SiPass Firmware and Aperio Wireless Locks (which can be

configured only on ACC-AP) work in relation to each other. Hence, it is

recommended that the following documents (from SiPass integrated Software

bundle) are read in conjunction:

●ACC-AP Technical Manual (this document)

●SiPass integrated Firmware Configuration Guide

●SiPass integrated Configuration Client User Guide

●Aperio Wireless Lock Support Guide

Details for Ordering

6 | 16

A6V11367717

2Details for Ordering

The ACC-AP IP Door Controller can be ordered as a

Standalone

unit or as

ACC-

APM PSU

unit in 12V/24V voltage options.

Part Number

Type

Description

S54502-C150-A100

ACC-AP

ACC-AP SiPass integrated IP Door Controller

S54502-C152-A100

ACC-APM-1220

ACC-APM-1220 SiPass IP Controller

12V 2A PSU

S54502-C153-A100

ACC-APM-2420

ACC-APM-2420 SiPass IP Controller

24V 2A PSU

Safety Regulations

A6V11367717

7 | 16

3Safety Regulations

General

●Follow all warnings and instructions marked on the device.

●Keep this document for reference purposes.

●Please take into account any additional country-specific local laws, safety

standards or regulations concerning installation, operation and disposal of the

product.

●Refer to a qualified electrician for installation.

Liability claim

●Do not make any changes or modifications to the device.

●Use only spare parts and accessories that have been approved by the

manufacturer.

Standards and Guidelines

8 | 16

A6V11367717

4Standards and Guidelines

Siemens Switzerland Ltd. hereby declares that this product is in compliance with

the essential requirements and other relevant provisions of:

●Directive 2011/65/EU (Restriction of the use of certain hazardous substances

directive)

●Directive 2014/30/EU (Electromagnetic Compatibility directive)

●Directive 2014/35/EU (Low Voltage directive)

The EC Declaration of Conformity is available from your local Siemens sales office

or from the address below:

Siemens Switzerland Ltd

Building Technologies Division

Theilerstrasse 1a, CH-6300 Zug

+41 58 724 2424

Technical Specifications

Battery

A6V11367717

9 | 16

5Technical Specifications

The technical data for the ACC-AP is as below:

Default IP Address

192.168.251.1

Subnet mask:

255.255.255.0

Supply voltage (nom.*)

12-24 Vnom +/- 10% 1Vpp ripple

Absolute voltage ratings**

9.5V DC –29.5V DC

The AP power supply input must be

protected by a fuse (2A).

Current consumption

Without reader

Idle

12V DC: 200mA

24V DC: 140 mA

Full on***

12V DC: 600mA

24V DC: 400 mA

Battery Type

CR2032

Reader Interface

An electronic fuse blows when the total

current to both the reader interfaces

exceeds 700mA.

Two OSDP Readers plus Power out.

Two Wiegand Readers plus Power out.

Max 700mA (jumper in Vin position)

Max 200mA (jumper in 12V position)

Inputs

Four general inputs

Outputs

Two relay outputs. Max 30V DC, 2A. One

bistable, one monostable.

Four Open-collector outputs, max load 0.5A.

One power supply output with Vin, max load

2A.

Resistor Value for Monitored Inputs

22k (alarm)

11k normal

Temperature Range

-40 to +55 0C

Humidity

250C @80% -> 550C @93%

(III, IEC 60839-11-1)

Environmental Class

II, IEC 60839-11-1

Dimensions (H x W x D)

156 x 201 x 53 mm

* Nominal voltage has margins for transformer tolerances, mains supply variations and

interruptions

** Absolute voltage has no margins and should be used for guidance only

*** Full on represents:

●500 mA (5V) load on high-speed USB connector

●100 mA (5V) load on full-speed USB connector

●No readers connected

●Relays activated

●RJ485 communication on all ports with EOL resistors

●Micro-SD memory card installed

Technical Specifications

Battery

10 | 16

A6V11367717

5.1 Battery

The “CR2032” battery type is supplied and should be mounted in the battery socket

(see item 13 in the

AP Controller Diagram

) with the plus (+) mounted downwards.

The battery keeps the Audit Trail data intact for about 30 days during any power

fail.

5.2 ACC-AP Controller Diagram

See section Description of Numbered Items in the Diagram [➙ 10] for detailed

information.
