Siemens SION 3AE Manual de usuario

SION®

Vacuum circuit breaker 3AE

Instructions for assembling and disassembling ten-pole

X01 and X02 connectors

OPERATING INSTRUCTIONS

General

These operating instructions describe how to assemble and disassemble the ten-pole X01 and X02 connectors. In

doing so, it is possible to wire the upper parts of the ten-pole X01 and X02 connectors in such a way that the low-

voltage interface is connected to the signaling switch in the plug-in unit.

Fig. 1 Terminal strip with the ten-pole X01 and X02

connectors located behind

Disassembly

Note

For clearer orientation, the terminal strip is no longer

illustrated in Fig. 2 to Fig. 4.

1. Disassemble and remove the shrouding cover and

cover for the low-voltage interface (see vacuum cir-

cuit breaker 3AE 9229 0001 176 operating instructi-

ons, chapter entitled "Disassembling and assemb-

ling covers").

Fig. 2 Position of the ten-pole connectors (illustra-

tion without terminal strip)

Order no.: 9229 0018 176 0-

Ordering location: E D MV C S

AG 01.2011 en

© Siemens AG 2010. All rights reserved.

2. Pull the lower parts of the X01 and X02 connectors

downward.

Fig. 3 Pulling the lower parts of the connectors

downward

Note

Nuts and washers may fall into the drive of the SION®

vacuum circuit breaker.

Secure nuts and washers so that they do not fall down.

3. If necessary, secure nuts (x4) and washers (x8)

using a magnetic socket, to ensure that they do not

fall down and disassemble them.

4. Pull the upper parts of the X01 and X02 connectors

upward.

Fig. 4 Disassembling the upper parts of the con-

nectors

Assembly

Assembly is carried out in reverse order and should be performed using new self-locking nuts (from the accesso-

ries pack).

Tighten the Phillips screws using a tightening torque of 1.4 ±0.1 Nm. Exceeding the tightening torque will result in

damage to the plug flanges.

Published by

Published by

Energy Sector

Power Distribution Division

Medium Voltage Components

Berlin Schaltwerk switchgear factory

D - 13629 Berlin
