Shuttle MS11 Manual de usuario
MS11
PPGA Celeron/Coppermine processor
Based AGPsetMAINBOARD
User's Manual
M325
Shuttle MS11
PPGA Celeron/Coppermine processor based AGPset Mainboard
Manual Version 1.0
Copyright
Copyright©2000 by Shuttle Inc. All Rights Reserved.
No part of this publication may be reproduced, transcribed, stored in a retrieval system,
translated into any language, or transmitted in any form or by any means, electronic,
mechanical,magnetic,optical,chemical,photocopying,manual,orotherwise,without
prior written permission from Shuttle Inc.
Disclaimer
Shuttle Inc. shall not be liable for any incidental or consequential damages resulting from the
performance or use of this product.
This company makes no representations or warranties regarding the contents of this manual.
Information in this manual has been carefully checked for reliability; however, no guarantee
is given as to the correctness of the contents. In the interest of continued product improve-
ment, this company reserves the right to revise the manual or include changes in the specifi-
cations of the product described within it at any time without notice and without obligation to
notify any persion of such revision or changes. The information contained in this manual is
provided for general use by the customers.
Trademarks
Spacewalker is a registered trademark of Shuttle Inc.
Intel, Pentium is a registered trademarks of Intel Corporation.
SiS is a registered trademarks of SIS Corporation.
PS/2 is a registered trademark of IBM Corporation.
AWARD is a registered trademark of Award Software Inc.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
General Notice: Other brand and product names used herein are for identification
purposes only and may be trademarks of their respective owners.
- 1 -
WHAT’SINTHEMANUAL ............................................................... 5
Quick Reference ....................................................................................... 5
AboutThisManual ................................................................................... 5
1INTRODUCTION ........................................................................... 6
1.1TODIFFERENTUSERS ....................................................................... 6
FIRST-TIMEDIYSYSTEM BUILDER ........................................................ 6
EXPERIENCEDDIY USER....................................................................... 6
SYSTEMINTEGRATOR ............................................................................ 6
1.2ITEM CHECKLIST:............................................................................... 7
2FEATURES................................................................................... 8
2.1MAINBOARD SPECIFICATIONS .......................................................... 8
3HARDWAREINSTALLATION...................................................... 11
3.1STEP BY STEP INSTALLATION ......................................................... 11
MS11Mainboard with3 PCI slots ........................................................ 11
STEP 1 Install the CPU........................................................................ 12
STEP2 SetJumpers............................................................................ 13
STEP3 InstallSDRAM System Memory.............................................. 13
STEP4 InstallPeripherals in System Case ......................................... 14
STEP 5 Mount the Mainboard on the Computer Chassis ..................... 15
STEP6 ConnectFront Panel Switches/LEDs/Speaker........................ 16
STEP7 ConnectIDE & Floppy Disk Drives.......................................... 18
STEP8 ConnectOtherInternal Peripherals......................................... 19
STEP 9 Connect the Power Supply ..................................................... 19
STEP 10 Install Add-on Cards in Expansion Slots ............................... 20
STEP 11 Connect External Peripherals to Back Panel ....................... 21
STEP12 FirstTime System Boot Up ................................................... 23
TABLEOFCONTENTS
- 2 -
STEP13 InstallDrivers & Software Components................................. 24
3.2JUMPER SETTINGS .......................................................................... 25
JUMPERS&CONNECTORS GUIDE .................................................. 26
CPUHost FrequencySetting (JP3)..................................................... 29
FactoryReserved(JP14) ..................................................................... 30
SetKeyboard &PS/2 Mouse Power-On(JP19) ................................... 30
Clearthe CMOS(JP13) ....................................................................... 31
FlashEEPROMProtection(JP12) ....................................................... 31
FactoryReserved (JP5) ....................................................................... 32
PS/2 Keyboard&PS/2 MouseConnectors .......................................... 32
USB1/USB2Port Connectors............................................................... 32
COM1Connectors ............................................................................... 32
VGAConnectors .................................................................................. 33
ParallelPort Connector ........................................................................ 33
Line-Out ............................................................................................... 33
Line-In.................................................................................................. 33
Mic-In ................................................................................................... 33
GAME/MIDIPort .................................................................................. 34
ATXPower On/OffSwitch Connector (PW_ON) .................................. 34
SystemManagementInterfaceConnector (SMI) ................................. 34
HardwareResetConnector(RST) ....................................................... 35
KEYLOCK............................................................................................ 35
SpeakerConnector(SPEAKER) .......................................................... 35
HDDLEDConnector (H_LED) ............................................................. 35
GreenLEDConnector (G_LED)........................................................... 36
PWRLEDConnector (P_LED)............................................................. 36
FrontPanel USBConnectorHeader (J5/JP4)...................................... 36
EnhancedIDE PortsandFloppy Connectors....................................... 37
- 3 -
ATXPowerSupplyConnector (ATP1) ................................................. 37
CoolingFan Connectorsfor CPU (FAN1),
Chassis(FAN2) & AMR(FAN3) ........................................................... 38
COM2Connector(JP7)........................................................................ 38
IRConnector(J7)................................................................................. 38
Wake-onLANConnector (J1) .............................................................. 39
AudioConnector VIDEO_In(JP9)........................................................ 39
AudioConnector CD_In(JP10)............................................................ 39
AudioConnector AUX_In(JP11).......................................................... 39
3.3 SYSTEM MEMORY CONFIGURATION ................................................ 40
1.INSTALL MEMORY: ........................................................................ 40
2.UPGRADE MEMORY: ..................................................................... 40
4 SOFTWARE UTILITY .................................................................. 41
4.1 MS11 Mainboard CD Overview ......................................................... 41
4.2 Install Display Adaptor Driver Software ............................................ 42
4.3 Install Audio Device Software .......................................................... 43
4.4 To View the User's Manual ............................................................... 44
5BIOSSETUP............................................................................... 45
5.1ENTERING BIOS ............................................................................... 45
5.2 THE MAIN MENU ............................................................................... 46
STANDARDCMOS SETUP ..................................................................... 48
ADVANCEDBIOSFEATURES................................................................ 52
ADVANCED CHIPSETFEATURES ......................................................... 56
INTEGRATEDPERIPHERALS ................................................................ 61
POWERMANAGEMENTSETUP ............................................................ 65
PNP/PCICONFIGURATION .................................................................... 69
- 4 -
PCHEALTH STATUS .............................................................................. 71
FREQUENCY/VOLTAGECONTROL....................................................... 73
LOADFAIL-SAFE DEFAULTS................................................................. 74
LOADOPTIMIZEDDEFAULTS ............................................................... 74
SETPASSWORD .................................................................................... 75
SAVE& EXITSETUP .............................................................................. 77
EXITWITHOUT SAVING ......................................................................... 77
- 5 -
Quick Reference
HardwareInstallation>>Step-by-Step ............................................ Page 11
JumperSettings>>A Closer Look ................................................. Page 25
Drivers/SoftwareUtilities>>How to Install ..................................... Page 41
BIOSSetup >> How toConfigure .................................................... Page 45
AboutThisManual
ForFirst-Time DIY System Builder....................................................Page 6
For Experienced DIY User ................................................................ Page 6
For System Integrator....................................................................... Page 6
WHAT’SINTHEMANUAL
- 6 -
1.1ToDifferent Users
First-Time DIY System Builder
Welcome to the DIY world! Building your own computer system is not as
difficult as you may think. To make your first computer DIY experience a
success, right from the start, we have designed the 3.1 Hardware Installation
section in a step-by-step fashion for all the first-time DIY system builders.
Priorto installation,we also suggestyou toread thewhole manual carefullyto
gain a complete understanding of your new Shuttle MS11 mainboard.
Experienced DIY User
Congratulations on your purchase of the Shuttle MS11 mainboard. You will
findthatinstalling your newShuttleMS11mainboard is justthateasy. Bundled
with an array of onboard functions, the highly-integrated MS11 mainboard
providesyou witha totalsolution tobuild themost stableand reliablesystem.
Referto section 3.2 Jumper Settings and Chapter 4 Drivers/Software Utilities
to find out how to get the best out of your new mainboard. Chapter 5 BIOS
Setup also contains relevant information on how to tune up your system to
achievehigher performance.
SystemIntegrator
You have wisely chosen Shuttle MS11 to construct your system. Shuttle
MS11 incorporates all the state-of-the-art technology of the MS11 chipset
from Intel. It integrates the most advanced functions you can find to date in
a compact MicroATX board. Refer to section 3.2 Jumper Settings and
Chapter 4 Drivers/Software Utilities for an in-depth view of system
construction.
1INTRODUCTION
- 7 -
1.2ItemChecklist:
Check all items you received with your MS11 mainboard to make sure
nothing is missing. The complete package should include:
One Shuttle MS11 Mainboard
(with onboard Socket370, built-in SiS630 and
SiS950 chipset , MicroATX form factor, including
2xUSB, 1xSerial, and 1xParallel ports, plus 1xPS/2
Keyboard, and 1xPS/2 Mouse connectors.)
OneATA 33/66Ribbon Cable
One Floppy Ribbon Cable
One 9-pin COM2 Cable
This MS11 User’s Manual
One Shuttle Spacewalker Bundled CD-ROM containing:
The MS11 user’s manual on file
The SiS630 VGA driver
The audio CODEC driver
The Awdflash Utility
- 8 -
The MS11 mainboard is carefully designed for the demanding PC user who wants high
performance and maximum intelligent features in a compact package.
2.1Specifications
CPU Support
Intel PPGA Celeron processors 300 ~ 600+ MHz.
Intel Coppermine FC-PGA processors 500 ~ 850+/100 MHz FSB.
Chipset
Features 66/100/133 MHz SiS630 system chipset with integrated 128-bit
2D/3D AGP graphics engine and Integrated 3D positional Audio Controll.
Integrated128-bit 2D/3D Graphics Accelerator
Advanced HW Acceleraton for DVD Playback Including MC, IDCT.
Fully DirectX6 Compliant Graphics Engine.
UMA Architecture with 2/4/8/16/32/64 System Memory Sharable as Display
Memory.
Support VESA DDC1, DDC2B & DDC 3.0.
Integrated 3D Positional Audio Controller
64-voice Polyphony Wavetable Synthesizer.
DirectSound 3D Accelerator for IID, IAD and Doppler Effects.
Full-duplex, Independent Sample Rate Converter for Audio Recording and
Playback.
AC'97 V2.1 Interface for External Audio Codec.
SoundBlaster Pro/16 compliant-Driver Support for Windows 95/98, NT 4.0,
Windows2000.
Jumperless CPU Configuration
Auto-detectCPU voltage
Soft-configure CPU Speed (The CPU operating speed is software
configurable in the CMOS Setup menu of the BIOS Setup utility.)
Versatile Memory Support
Equipped with two DIMM sockets for (8, 16, 32, 64, 128 or 256 MB) 168-
pin 66MHz or 100MHz PC SDRAM memory modules up to 512 MB.
2FEATURES
Tabla de contenidos
Otros manuales de Placa madre de Shuttle
Shuttle
Shuttle Spacewalker AV40S Manual de usuario
Shuttle
Shuttle FX43G Manual de usuario
Shuttle
Shuttle Spacewalker AK11 Manual de usuario
Shuttle
Shuttle MS52P Manual de usuario
Shuttle
Shuttle Spacewalker MV25 Manual de usuario
Shuttle
Shuttle FB77 Manual de usuario
Shuttle
Shuttle Spacewalker ME17 Manual de usuario
Shuttle
Shuttle HOT-637 Manual de usuario
Shuttle
Shuttle FS58 Manual de usuario
Shuttle
Shuttle FB75 Manual de usuario
Shuttle
Shuttle HOT-661Z Manual de usuario
Shuttle
Shuttle Spacewalker HOT-685Z Manual de usuario
Shuttle
Shuttle FB62 Manual de usuario
Shuttle
Shuttle AB61 Manual de usuario
Shuttle
Shuttle FB86 Manual de usuario
Shuttle
Shuttle Spacewalker AV30 Manual de usuario
Shuttle
Shuttle AK32A Manual de usuario
Shuttle
Shuttle MB47N Manual de usuario
Shuttle
Shuttle FB51 Manual de usuario
Shuttle
Shuttle HOT-687V Manual de usuario
Manuales populares de Placa madre de otras marcas
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manual de usuario
Gigabyte
Gigabyte GA-9IVDT Manual de usuario
Texas Instruments
Texas Instruments ADS8372EVM Manual de usuario
Commell
Commell MS-C73 Manual de usuario
IBT Technologies
IBT Technologies MB860 Manual de usuario
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manual de usuario
