Shuttle AB49 Manual de usuario

AB49 & AB49N

Intel Pentium 4/Celeron

478-pinProcessor

with 400/533 MHz FSB

Based DDR MAINBOARD

User's Manual

M784

Shuttle®AB49 & AB49N

Intel Pentium 4/Celeron

478-pin Processor

with 400/533 MHz FSB

Based DDR Mainboard

Manual Version 1.0

This publication, including all photos, illustrations, and software, is protected under interna-

herein is prohibited without the consent of the publisher.

Disclaimer

Shuttle®Inc. shall not be liable for any incidental or consequential damages resulting from the

performance or use of this product.

This company makes no representations or warranties regarding the contents of this manual.

Information in this manual has been carefully checked for reliability; however, no guarantee is

given as to the correctness of the contents. In the interest of continued product improvement,

this company reserves the right to revise the manual or include changes in the specifications

of the product described within it at any time without notice and without obligation to notify any

person of such revision or changes. The information contained in this manual is provided for

general use by the customers.

Trademarks

Shuttle is a registered trademark of Shuttle Inc.

Intel, Pentium, and Celeron are registered trademarks of Intel Corporation.

PS/2 is a registered trademark of IBM Corporation.

AWARD is a registered trademark of Award Software Inc.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

General Notice: Other product names used in this manual are ascribed to their respective

owners and acknowledged.

Statement of Shuttle Mainboard via the EMI Test

Shuttle mainboards have been via the EMI test in terms of series of regulations: EN55022/

CISPR22/AS/NZS3548ClassB,EN55024(1998/AS/NZS),EN4252.1(1994),EN61000,ANSI

C63.4 (1992), CFR47 Part 15 Subpart B, and CNS13438 (1997). The items tested are illus-

trated as follows:

(A)Voltage:AC110V/60HZ &AC230V/50HZ

(B) Tested Product Information:

Product Name: PC Mainboard

Status: Sample

ModelName:AB49N/AB49

S/N:N/A

CPU:

External Frequency: 100 MHz

IntelPentiumIV1.6/1.8/2.0/2.2/2.4GHz

External Frequency: 133 MHz

IntelPentiumIV2.26/2.40/2.53/2.66/2.80/3.06GHz

Mouse Port: one port with 6 pins

Keyboard Port: one port with 6 pins

Parallel Port: one port with 25 pins

Serial Port: one port with 9 pins

USB Port: four ports with 4 pins respectively

LANPort: one port with 8 pins (10Mbps/100Mbps)(AB49N Only)

Line-In & Line-Out & Mic-In Ports: one port for each

DDR Memory: 256 MB*2

All CPUs have completely been tested, and values offered by the worst EMI combination of

CPU external frequency are listed as follows:

Remedy:N/A

EMIInterference:

Crystal:25.00MHz(X1)/24.576MHz(X2)/32.768KHz(X3)/14.318MHz(X4)

Clock Generator: CLK1

(D) Difference betweenAB49NandAB49:

To discriminate AB49N from AB49 lies in the extent that chips inAB49N support LAN, and the

combination for testing is based onAB49N.

Test Mode

External Frequency

133 MHz

100 MHz

CPU

P4 3.06 GHz

P4 2.4 GHz

Case Open/Closed

Closed

Open

Closed

Open

Power Supply

ENP-0730(ATX12V)

(E) Supported Host Peripherals:

(F) Notices for Assembling Computers:

1. Cases should be made of iron or other metal that has good electric conductivity.

2. Cylinders in a case should be made of metal, and as having a mainboard mounted

in a case, make sure screws are all utilized and fastened on a mainboard.

3. An I/O shielding should be contacted with I/O metallic parts of a mainboard.

4. Cables should appropriately be arranged and fixed in a case. Follow instructions:

Ø Leave IDE cables not crossed upon CPU and SDRAM;

Ø Leave power cables minimum in length, and not crossed upon a mainboard;

Ø Leave CPU fan cables minimum in length, and not near CPU;

Ø Leave cables on panels and other spare cables tied in a computer case.

5. Make sure an EMI shielding attached to a case has properly been installed.

6. Make sure a 5.25" or 3.5" FDD and screws are fastened to an EMI shielding.

7. Make sure a case is closely in contact with EMI connected points.

8. Make sure there is no cleft in a case which is not deformed.

9. Make sure a PCI orAGP door is bound to a case.

10. Make sure cables of other devices (fans or some others) are fixed in a case.

Host Peripheral Product Name Model Name S/N FCC ID

#1 Case KF45A N/A

#2 Power Supply (300W) ENP-0730 (ATX12V) 1000002885

#3 IBM HDD (30.7GB) 91024UB YKFY7981 3892I168

#4 MITSUMI FDD D353M

#5 SONY VCD Player CDU4811 3892A291

#6 AGP Card Winfast Geforce 2 MX 3892C520

#7 Power Cable Detachable and Shielded

- 1 -

WHAT'S IN THE MANUAL.................................................................... 5

Quick Reference............................................................................................... 5

About This Manual ........................................................................................... 5

1 INTRODUCTION................................................................................ 6

1.1 TO DIFFERENT USERS ............................................................................. 6

FIRST-TIMEDIYSYSTEMBUILDER............................................................ 6

EXPERIENCEDDIYUSER ......................................................................... 6

SYSTEMINTEGRATOR............................................................................... 6

1.2 ITEM CHECKLIST....................................................................................... 7

2 FEATURES ........................................................................................ 8

2.1 SPECIFICATIONS ....................................................................................... 8

3 HARDWARE INSTALLATION.......................................................... 11

3.1 STEP BY STEP INSTALLATION................................................................11

STEP1 Installthe CPU.......................................................................... 12

STEP 2 Set Jumpers............................................................................. 13

STEP3 InstallDDR SDRAMSystem Memory........................................ 13

STEP 4InstallInternal PeripheralsinSystem Case ................................ 14

STEP5 Mountthe Mainboardon theComputer Chassis........................ 15

STEP6 ConnectFront PanelLEDs/Switches/USB................................ 16

STEP 7 Connect IDE and Floppy Disk Drives........................................ 17

STEP8Connect OtherInternalPeripherals............................................ 18

STEP9 Connectthe PowerSupplies .................................................... 19

STEP10 InstallAdd-on Cards inExpansion Slots .................................. 19

STEP11 ConnectExternalPeripherals toBack-Panel........................... 20

STEP12 InstallDrivers &SoftwareComponents ................................... 21

TABLE OF CONTENTS

- 2 -

3.2 JUMPER SETTINGS ................................................................................. 22

JUMPERS& CONNECTORSGUIDE.................................................... 23

Jumpers

Clear CMOS Setting (JP1) ................................................................... 25

BIOSFlash ProtectionSetting (JP2) ...................................................... 25

Back-Panel Connectors

PS/2Mouse &PS/2 KeyboardConnectors............................................ 26

ParallelPortConnector.......................................................................... 26

COM1Port Connector ........................................................................... 26

USB1/2/3/4PortConnectors ................................................................. 26

LANPort Connector(AB49N Only) ........................................................ 27

Line-In(6-ChannelRear-Out)Port Connector ......................................... 27

Line-Out(6-ChannelFront-Out)Port Connector...................................... 27

Mic-In(6-ChannelCenter/Bass-Out)Port Connector .............................. 27

Front-Panel Connectors

HDD LED Connector (HDLED) ............................................................. 28

HardwareResetConnector (HWRST).................................................... 28

GreenLED Connector (GRNLED) ......................................................... 29

ATXPowerOn/Off SwitchConnector(PWRSW).................................... 29

ExtendedUSB Header (USB3).............................................................. 30

FrontPanelMicrophone andLine-OutHeader(AUDIO1) ....................... 30

Internal Peripheral Connectors

Enhanced IDEand FloppyConnectors (IDE1/IDE2& FDD1) ................. 31

Other Connectors

ATXPower SupplyConnectors (ATX1/ATX12V).................................... 32

CPU,Power, andChassis FanConnectors (CPUFAN1/PWRFAN1/

CASFAN1)............................................................................................ 33

- 3 -

AudioCD_INConnectors (CDIN1/CDIN2) ............................................. 33

IRHeader(IR1)...................................................................................... 34

3.3 SYSTEM MEMORY CONFIGURATION ..................................................... 35

1.INSTALLMEMORY ............................................................................ 35

2.UPGRADEMEMORY ........................................................................ 35

4 SOFTWARE UTILITY ......................................................................36

4.1 Mainboard CD Overview ......................................................................... 36

4.2 Install Mainboard Software ..................................................................... 37

4.2.A Install Intel Chipset Driver .................................................................... 38

4.2.B Install Intel Ultra ATADriver ................................................................. 39

4.2.C Install USB 2.0 Driver ........................................................................... 40

4.2.D Install Audio Driver ............................................................................... 41

4.2.E Install LAN Driver (AB49N Only) .......................................................... 42

4.3 View the User's Manual........................................................................... 42

5 BIOS SETUP ................................................................................... 43

5.1 ENTER BIOS ............................................................................................. 43

5.2 THE MAIN MENU ...................................................................................... 44

STANDARD CMOS FEATURES ............................................................... 46

ADVANCED BIOS FEATURES................................................................. 48

ADVANCED CHIPSET FEATURES .......................................................... 51

INTEGRATEDPERIPHERALS .................................................................. 53

POWERMANAGEMENT SETUP.............................................................. 56

PNP/PCICONFIGURATIONS .................................................................... 60

PCHEALTH STATUS................................................................................ 61

FREQUENCY/VOLTAGECONTROL......................................................... 62

LOAD FAIL-SAFE DEFAULTS .................................................................. 63

- 4 -

LOADOPTIMIZEDDEFAULTS ................................................................. 63

SETSUPERVISOR/USER PASSWORD................................................... 64

SAVE & EXIT SETUP................................................................................ 65

EXITWITHOUTSAVING ............................................................................ 65

- 5 -

Quick Reference

Hardware Installation >> Step-by-Step ................................................ Page 11

Jumper Settings >> A Closer Look.......................................................Page 22

Drivers/Software Utilities >> How to Install .........................................Page 36

BIOS Setup >> How to Configure.........................................................Page 43

About This Manual

For First-Time DIY System Builder.........................................................Page 6

For Experienced DIY User ......................................................................Page 6

For System Integrator .............................................................................Page 6

WHAT'S IN THE MANUAL

- 6 -

1INTRODUCTION

1.1 To Different Users

First-Time DIY System Builder

Welcome to the DIY world! Building your own computer system is not as diffi-

cult as you may think. To make your first computer DIY experience successful,

right from the start, we have designed the 3.1 Hardware Installation section

in a step-by-step fashion for all the first-time DIY system builders. Prior to instal-

lation, we also suggest you to read the whole manual carefully to gain a com-

plete understanding of your new Shuttle AB49/AB49N mainboard.

Experienced DIY User

Congratulate on your purchase of the Shuttle AB49/AB49N mainboard. You

will find that installing your new Shuttle AB49/AB49N mainboard is just easy.

Bundled with an array of onboard functions, the highly-integrated AB49/AB49N

mainboard provides you with a total solution to build the most stable and reli-

able system. Refer to sections 3.2 Jumper Settings and Chapter 4 Drivers/

Software Utilities to find out how to get the best out of your new mainboard.

Chapter 5 BIOS Setup also contains the relevant information on how to tune

up your system to achieve higher performance.

System Integrator

You have wisely chosen Shuttle AB49/AB49N to construct your system.

Shuttle AB49/AB49N incorporates all the state-of-the-art technology of the

845PE (GMCH) chipset from Intel. It integrates the most advanced functions

you can find to date in a compact ATX board.

This manual is all-purpose for two kinds of mainboards: AB49 and

AB49N. The main difference between them is that AB49N is equipped

with an onboard LAN. In the manual, if there are some standards, charac-

teristics, equipment, or software adopted only by AB49N, it will be high-

lighted in brackets.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Placa madre de Shuttle

Shuttle

Shuttle av61 Manual de usuario

Shuttle

Shuttle FV24 Manual de usuario

Shuttle

Shuttle FB75 Manual de usuario

Shuttle

Shuttle HOT-679V Manual de usuario

Shuttle

Shuttle AK32E Manual de usuario

Shuttle

Shuttle FX43G Manual de usuario

Shuttle

Shuttle HOT-675V Manual de usuario

Shuttle

Shuttle HOT-673 Manual de usuario

Shuttle

Shuttle Spacewalker MV17 Manual de usuario

Shuttle

Shuttle DL30N Series Manual de usuario

Shuttle

Shuttle HOT-675 Manual de usuario

Shuttle

Shuttle HOT-681 Manual de usuario

Shuttle

Shuttle FN45 Manual de usuario

Shuttle

Shuttle AN51R Manual de usuario

Shuttle

Shuttle FN25 Manual de usuario

Shuttle

Shuttle HOT-661Z Manual de usuario

Shuttle

Shuttle FX83 Manual de usuario

Shuttle

Shuttle ME21 Manual de usuario

Shuttle

Shuttle HOT-649A Manual de usuario

Shuttle

Shuttle AN35 Ultra Manual de usuario

Shuttle

Shuttle MK35 Manual de usuario

Shuttle

Shuttle Spacewalke AK21 Manual de usuario

Shuttle

Shuttle Spacewalker MS50 Manual de usuario

Shuttle

Shuttle HOT-641/P Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario
