Shure PG Wireless Manual de usuario

27A15712 (Rev. 1)

PG Wireless

PG ワイヤレス

PG 무선

PG 无线系统

Nirkabel PG

Printed in U.S.A.

9V battery

audio ready channel

DiversityAntenna System

PG4

Busy Indicator?

set transmitter to same channel as receiver

channelready

audio

Internal Antenna Diversity

channel

mute

PG Wireless

Performance Gear

Congratulations on purchasing your Shure Performance Gear Wireless system. Shure

professional audio products deliver legendary sound quality, stage-proven durability and

hassle-free setup for worry-free performance. Performance Gear Wireless systems are

available in a variety of configurations for handheld, guitar, headset, and presentation

applications.

audio ready channel

Diversity Antenna System

PG4

audio ready channel

System Components

PS21 Power Supply

PG88 Dual Wireless Receiver

PG4 Wireless Receiver

PG1 Bodypack

Transmitter

PG2 Handheld

Transmitter

PG185 Lavalier Mic

PG30

Headworn

Mic

Startup

Follow these simple steps to check for interference and to set your receiver and trans-

mitter to the same channel.

mute

channel

ready

audio

Internal Diver

audio ready channel

DiversityAntenna System

PG4

channel

select

3 s

channel

mute

channelready

audio

Internal Antenna Diversity

channel

mute

channelready

2. Plug in the power supply.

The channel display should illuminate.

There is no power switch.

3. Press and hold down the channel button

until the display begins flashing.

If you see the Busy Indicator (a flashing

dash) change the channel.

4. Wait for the channel display to stop

flashing.

5. If you haven’t installed the battery, do it now

and leave the cover off.

6. Turn ON the handheld or bodypack transmitter

by pressing the power button.

The channel display should illuminate.

It turns off after ten seconds to conserve

battery.

7. Check to see that the transmitter and the receiver dis-

play the same channel.

The ready LED on the receiver should be illuminated.

8. Replace battery cover.

1. Turn OFF the microphone or bodypack.

If left on, it will create a false busy indicator.

Busy Indicator

When selecting channels, a flashing dash indi-

cates interference from television broadcasts,

electronic devices or other wireless systems.

If this occurs, change the channel.

Changing Channels

Press and hold the channel button

until the display starts flashing.

While the display is flashing, press

the channel button.

The channel is active once the display

stops flashing. Receiver and transmitter

channels should match.

Testing Audio

Talk or sing into the microphone or play instrument.

The audio LED on the receiver should flicker green or

amber, if red, adjust the Gain Switch.

Locking and Unlocking Transmitter Controls

Lock system controls to prevent accidental muting.

To lock controls: Turn transmitter off. Remove battery cover. Press and hold Channel

button. Press and release Power/Mute button. Power/Mute LED will flash red and

green.

To unlock controls: Press and hold Power/Mute button down until Power/Mute LED

flashes red and green.

Accessing Gain Switch

Adjust gain setting as needed:

0dB For instrument or quiet

to normal vocal perfor-

mance (default)

–10dB If audio is distorted due

to high vocal or instru-

ment levels

mic For headworn or lavalier

microphones (PG1 only)

channel

ready

audio

Internal Diver

channel

select

3 s

channelready

audio

Internal Antenna Diversity

channel

mute

channel -10dB 0 mic

LED Status

TRANSMITTER

LED COLOR STATUS

Green Ready

Amber Mute on

Red Battery low

Flashing Red on startup Battery is dead

Flashing Green and Red Controls locked

Flashing Amber and Red Mute on, battery low

RECEIVER

AUDIO LED COLOR INDICATES

Green Normal signal strength

Amber Strong signal

Red Peak signal

Green System is ready

Changing Battery

Expected life for a 9 volt alkaline battery is up to 8 hours. Total battery life will vary de-

pending upon battery type and manufacturer.

Red LED signifies “low battery” with typically less than 60 minutes of remaining battery

life.

Note: Remaining battery life will vary depending upon battery type and manufacturer.

Wearing the Bodypack Transmitter

Clip the transmitter to belt or guitar strap as shown.

Make sure the antenna is unobstructed.

Multiple System Setup

To set up multiple systems, repeat the previous steps for each transmitter and receiver

pair. Once transmitters have been set, leave them on. Be sure to set each transmitter

and receiver pair to a different channel. For information about frequencies and compat-

ibility, refer to channel guide.

Troubleshooting

Issue LED Status Solution

No sound or faint sound Transmitter Power/

Mute LED on, receiver

LEDs on

• Perform transmitter

setup.

• Verify all sound

system connections.

• Adjust transmitter

gain.

Receiver Channel

Display off

• Make sure AC

adapter is securely

plugged into electrical

outlet and into

POWER connector

on rear panel of

receiver.

• Make sure AC

electrical outlet works

and is supplying

proper voltage.

Transmitter LED glowing

or flashing red

• Replace transmitter

battery.

Transmitter LED off • Turn transmitter on.

• Make sure the +/-

indicators on battery

match transmitter

terminals.

• Insert fresh battery.

Distortion or unwanted noise bursts • Remove nearby

sources of RF

interference (CD

players, computers,

cell phones, digital

effects, in-ear monitor

systems, etc.)

• Select a new channel

for both receiver and

transmitter.

• Reduce transmitter

gain.

• Replace transmitter

battery.

• If using multiple

systems, change the

channel of one of the

active systems.

Sound level different from cabled guitar or micro-

phone, or when using different guitars

• Adjust transmitter

gain as necessary.

Cannot turn transmit-

ter on

Transmitter LED flash-

ing red

• Replace transmitter

battery.

System Components

All Systems

PG4 or PG88 Receiver Internal Diversity Antenna System

One 9 volt battery AC Power supply User guide

Vocalist System

Microphone Head PG2 handheld

transmitter

Microphone clip

Instrument System

PG1 bodypack

transmitter

4-pin mini connector

(TA4F) to 1/4” connector

cable

Lavalier and Headworn System

PG1 bodypack

transmitter

Microphone (choice of

PG185, PG30)

Replacement Parts

System-Specific Microphone Stand

Adapter (PGX2)

WA371

Belt Clip 44A8035

PG58 Head with Grille RPW108

4-pin mini connector

(TA4F) to 1/4” connec-

tor cable

WA302

Country-Specific AC Adapter (120 VAC,

60 Hz)

PS21

AC Adapter (220 VAC,

50 Hz), Argentina

PS21AR

AC Adapter (230 VAC,

50/60 Hz, Europlug)

PS21E

AC Adapter (230 VAC,

50/60 Hz, UK)

PS21UK

AC Adapter (100 VAC,

50/60 Hz)

PS21J

AC Adapter (220 VAC,

50 Hz, China)

PS21CHN

AC Adapter (230 VAC,

50 Hz,, Australia)

PS21AZ

AC Adapter (220 VAC,

60 Hz, Korea)

PS21K

Optional Accessories

Universal Rack Tray URT

Working Range

Line of Sight

75 m (250 ft)

Note: Actual range depends on RF

signal absorption, reflection and

interference.

Audio Frequency Response 45–15000 Hz

Note: Dependent on microphone type

Total Harmonic Distortion

Ref. ±33 kHz deviation, 1 kHz tone 0.5%, typical

Dynamic Range >100 dB, A-weighted

Operating Temperature Range -18°C (0°F)– +50°C (122°F)

Note: Battery characteristics may limit

this range.

Transmitter Audio Polarity Positive pressure on microphone

diaphragm (or positive voltage applied

to tip of WA302 phone plug) produces

positive voltage on pin 2 (with respect

to pin 3 of low-impedance output) and

the tip of the high impedance 1/4-inch

output.

PG1

Audio Input Level gain position

mic: −10dBVmaximum

0dB: +10 dBV maximum

–10dB: +20 dBV maximum

Gain Adjustment Range 30 dB

Input Impedance 1MΩ

RF Output Power 10–30 mW

varies by region

Dimensions 110 mm x 64 mm x 21 mm (H x W x D)

Weight 75 g (2.6 oz.), without batteries

Housing Molded ABS

Power Requirements battery, 9V, alkaline

Battery Life up to 8 hours (alkaline)
