Show Tec Marquees Uplighter RGB LED Manual de usuario

Marquees Uplighter RGB LED

ORDERCODE 42501

Congratulations!

You have bought a great, innovative product from Showtec.

The Showtec Marquees Uplighter RGB LED brings excitement to any venue. Whether you want simple

plug-&-play action or a sophisticated DMX show, this product provides the effect you need.

You can rely on Showtec, for more excellent lighting products.

We design and manufacture professional light equipment for the entertainment industry.

New products are being launched regularly. We work hard to keep you, our customer, satisfied.

For more information: iwant@showtec.info

You can get some of the best quality, best priced products on the market from Showtec.

So next time, turn to Showtec for more great lighting equipment.

Always get the best -- with Showtec !

Thank you!

Showtec

Showtec Marquees Uplighter RGB LED™Product Guide

Warning.................................................................................…...……………..…………………………….………..…..

Safety-instructions…………………………………………………………………………………………………………

Operating Determinations.………………………………………………………………………………………………

Rigging.………………………………………………………………………………………………………………………

Description...............................................................................…...………………………………………….………..….

Features and Overview ………………………………...….……………….………….……….……….………………

Set Up and Operation.....................................................................……..…………………………………….…………

Control Modes……………………………………………………………………………………………………………...

DMX Channels.........................................................................…………………………………………………..……

Maintenance...................................................................................………..………….…….………………………......

Troubleshooting............................................................................………………….………………….…………….......

No Light..…………………………………..........................................………………….…………………………….....

Product Specifications.................................................................……………….…….………………………………...

WARNING

FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY

BEFORE YOUR INITIAL START-UP!

SAFETY INSTRUCTIONS

Every person involved with the installation, operation and maintenance of this device has to:

-be qualified

-follow the instructions of this manual

Before your initial start-up, please make sure that there is no damage caused by transportation. Should

there be any, consult your dealer and do not use the device.

To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to

follow the safety instructions and warning notes written in this manual.

Please consider that damages caused by manual modifications to the device are not subject to

warranty.

This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

IMPORTANT:

The manufacturer will not accept liability for any resulting damages caused by the non-

observance of this manual or any unauthorized modification to the device.

Never let the power-cord come into contact with other cables! Handle the power-cord and all

connections with the mains with particular caution!

Never remove warning or informative labels from the unit.

Do not open the device and do not modify the device.

Never use anything to cover the ground contact.

Never look directly into the light source.

Never leave any cables lying around.

Never use the device during thunderstorms, unplug the device immediately.

Do not insert objects into air vents.

Do not connect this device to a dimmerpack.

Do not switch the device on and off in short intervals, as this would reduce the lamp’s life.

Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).

Do not shake the device. Avoid brute force when installing or operating the device.

Only use device indoor, avoid contact with water or other liquids.

Only operate the fixture after having checked that the housing is firmly closed and all screws are

tightly fastened.

Only operate the device after having familiarized with its functions.

Avoid flames and do not put close to flammable liquids or gases.

Always replace the lamp, when it is damaged or deformed due to the heat.

Always keep case closed while operating.

Always allow free air space of at least 50 cm around the unit for ventilation.

CAUTION!

Keep this device away from rain and moisture!

Unplug mains lead before opening the housing!

CAUTION! Be careful with your operations.

With a dangerous voltage you can suffer

a dangerous electric shock when touching the wires!

Always disconnect power from the mains, when device is not used, before cleaning or when

replacing lamp! Only handle the power-cord by the plug. Never pull out the plug by tugging the

power-cord.

Make sure that the device is not exposed to extreme heat, moisture or dust.

Make sure that the available voltage is not higher than stated on the rear panel.

Make sure that the power-cord is never crimped or damaged. Check the device and the power-

cord from time to time.

Make sure that no side forces can impact on the truss system.

The cable insert or the female part in the device must never be strained. There must always be

sufficient cable to the device. Otherwise, the cable may be damaged which may lead to deadly

electrical shocks.

If device is dropped or struck, disconnect mains power supply immediately. Have a qualified

engineer inspect for safety before operating.

If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do

not switch it on immediately. The arising condensation water might damage your device. Leave

the device switched off until it has reached room temperature.

If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely

(preferably in the original packing material), and return it to your Showtec dealer for service.

For adult use only. Light effect must be installed out of the reach of children. Never leave the unit

running unattended.

For replacement use fuses of same type and rating only.

This device can be installed on a flat surface.

The user is responsible for correct positioning and operating of the Marquees Uplighter RGB LED.

The manufacturer will not accept liability for damages caused by the misuse or incorrect

installation of this device.

This device falls under protection class I. Therefore it is essential to connect the yellow/green

conductor to earth.

During the initial start-up some smoke or smell may arise. This is a normal process and does not

necessarily mean that the device is defective.

Repairs, servicing and electric connection must be carried out by a qualified technician.

WARRANTY: Till one year after date of purchase.

OPERATING DETERMINATIONS

This device is not designed for permanent operation. Consistent operation breaks will ensure that the

device will serve you for a long time without defects.

The minimum distance between light-output and the illuminated surface must be more than 0,5 meters.

The maximum ambient temperature ta= 45°C must never be exceeded.

The relative humidity must not exceed 50 % with an ambient temperature of 45° C.

If this device is operated in any other way, than the one described in this manual, the product may suffer

damages and the warranty becomes void.

Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.

You endanger your own safety and the safety of others!

Improper installation can cause serious damage to people and property !

CAUTION ! EYEDAMAGES !.

Avoid looking directly into the light source.

(meant especially for epileptics) !

Connection with the mains

Connect the device to the mains with the power-plug.

Always pay attention, that the right color cable is connected to the right place.

International

EU Cable

UK Cable

US Cable

BROWN

RED

YELLOW/COPPER

FASE

BLUE

BLACK

SILVER

NUL

YELLOW/GREEN

GREEN

EARTH

Make sure that the device is always connected properly to the earth!

Description of the device

Features

The Showtec Marquees Uplighter RGB LED is a LED effect with high output and great effects.

• Never change lamps again!

• Beam angle 25 º

• DMX-512 controlled

• Signal connector XLR 3-pole und 5-pole Male/ Female

• Master/Music/Manual

• Indoor use only

• 7x 1W RGB LEDs

• 1, 2, 3 or 7 DMX channel Mode

NOTE: Knowledge of DMX is required to fully utilize this unit.

Overview

Fig. 1

1) LCD Display 6) 5-pin XLR DMX signal connector (IN)

2) Menu Buttons (MODE/UP/DOWN) 7) Fuse

3) 3-pin XLR signal connector (OUT) 8) CEE 16A 3-pole male

4) 3-pin XLR DMX signal connector (IN) 9) CEE 16A 3-pole female

5) 5-pin XLR DMX signal connector (OUT)

Installation

Remove all packing materials from the Marquees Uplighter RGB LED. Check that all foam and plastic

padding is removed. Connect all cables.

Always disconnect from electric mains power supply before cleaning or servicing.

Damages caused by non-observance are not subject to warranty.

Set Up and Operation

Follow the directions below, as they pertain to your preferred operation mode.

Before plugging the unit in, always make sure that the power supply matches the product specification

voltage.

Damages caused by non-observance are not subject to warranty.

FUNCTIONS:

There are 2 options for using the LED Marquees Uplighter: Stand-alone

DMX Mode

Stand-alone

In Stand-alone mode, you can use the menu button on the back of the device to scroll through the

options.

DMX Mode

The Marquees Uplighter will automatically detect the presence of a DMX signal.

If a DMX signal is present, the DMX LED will blink.

In order to receive a DMX signal, the controller must be attached to a DMX controller by a 3-pin or 5-pin

DMX cable and the DMX controller must be turned on.

The Marquees Uplighter can operate as a 1, 2, 3 or 7-channel DMX fixture.

Mode Options

Mode 1 (1 DMX Channel) Mode 3 (3 DMX Channels)

Mode 2 (2 DMX Channels) Mode 4 (7 DMX Channels)

Mode 1 - 1 Channels

Channel 1 –Macro Colors

Mode 2 - 2 Channels

Channel 1 –Macro Colors

Channel 2 –Dimmer

Mode 3 - 3 Channels

Channel 1 –Red

Channel 2 –Green

Channel 3 –Blue

Mode 4 - 7 Channels

Channel 1 –Red

Channel 2 –Green

Channel 3 –Blue

Channel 4 –Macro Colors

Channel 5 –Strobe / (Speed only in combination with CH6)

0-255

35 Macro colors

0-255

35 Macro colors

0-255

Dimmer from 0 –100%

0-255

Red from 0 –100%

0-255

Green from 0 –100%

0-255

Blue from 0 –100%

0-255

Red from 0 –100%

0-255

Green from 0 –100%

0-255

Blue from 0 –100%

0-255

35 Macro colors

0-255

Strobe, from slow to fast

Channel 6 –Built-in Programs

0-35

No function

36-71

Slow Fade IN to Full beam then Out

72-107

Full beam to slow Fade Out

108-143

Slow Fade IN to Full Beam to Slow Fade OUT

144-179

Continuous Flow of all colors from slow to fast

180-251

Color Switching

252-255

Sound-controlled

Note : from 36-143 the intensities only work if you also use CH1, CH2, CH3 .

From 36-251 CH5 controls the changing speed of the built-in programs.

Channel 7 –Dimmer

Maintenance

The operator has to make sure that safety-relating and machine-technical installations are to be

inspected by an expert after every four years in the course of an acceptance test.

The operator has to make sure that safety-relating and machine-technical installations are to be

inspected by a skilled person once a year.

The following points have to be considered during the inspection:

1. All screws used for installing the device or parts of the device have to be tightly connected and must

not be corroded.

2. There may not be any deformations on housings, fixations and installation spots.

3. The electric power supply cables must not show any damages or material fatigue.

The Showtec Marquees Uplighter RGB LED requires almost no maintenance. However, you should keep

the unit clean.

Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply, and

then wipe the cover with a damp cloth. Do not immerse in liquid. Wipe lens clean with glass cleaner and

a soft cloth. Do not use alcohol or solvents. Keep connections clean. Disconnect electric power, and

then wipe the DMX and audio connections with a damp cloth. Make sure connections are thoroughly

dry before linking equipment or supplying electric power.

Troubleshooting

This troubleshooting guide is meant to help solve simple problems.

If a problem occurs, carry out the steps below in sequence until a solution is found. Once the unit

operates properly, do not carry out following steps.

1. If the device does not operate properly, unplug the device.

2. Check the power from the wall, all cables etc.

3. If all of the above appears to be O.K., plug the unit in again.

4. If you are unable to determine the cause of the problem, do not open the Marquees Uplighter RGB

LED,

as this may damage the unit and the warranty will become void.

5. Return the device to your Showtec dealer.

No Light

This troubleshooting guide is meant to help solve simple problems. If a problem occurs, carry out the steps

below in sequence until a solution is found. Once the unit operates properly, do not carry out following

steps.

If the light effect does not operate properly, refer servicing to a technician.

Response: Suspect two potential problem areas: the power supply or the LEDs.

1. Power supply. Check that the unit is plugged into an appropriate power supply.

2. The LEDs. Return the Marquees Uplighter RGB LED to your Showtec dealer.

0-255

Dimmer, from closed to open (0-100%)

Tabla de contenidos

Otros manuales de Equipo de DJ de Show Tec

Show Tec

Show Tec ACT Flood 80 RGBW Manual de usuario

Show Tec

Show Tec Derby LED V2 Manual de usuario

Show Tec

Show Tec Data Flash Strobe Manual de usuario

Show Tec

Show Tec 51329 Manual de usuario

Show Tec

Show Tec Shogun Pro-500 Manual de usuario

Show Tec

Show Tec Powerspot 10 SW White Manual de usuario

Show Tec

Show Tec Phantom 280 Hybrid Manual de usuario

Show Tec

Show Tec Eventspot 1900 MKII Manual de usuario

Show Tec

Show Tec Eventlite 177IR Manual de usuario

Show Tec

Show Tec Star Dream 6x4m 192 LED White Manual de usuario

Show Tec

Show Tec Cameleon Flood 6 Q4 Tour Manual de usuario

Show Tec

Show Tec EventMOVE 4/4 Manual de usuario

Show Tec

Show Tec Juno Manual de usuario

Show Tec

Show Tec PIXEL BAR 12 MKII Manual de usuario

Show Tec

Show Tec LED Par 36 DMX Manual de usuario

Show Tec

Show Tec 34014 Manual de usuario

Show Tec

Show Tec Shogun Club G-40 Manual de usuario

Show Tec

Show Tec DB-1-4/RDM Manual de usuario

Show Tec

Show Tec SF-250 Manual de usuario

Show Tec

Show Tec 43552 Manual de usuario

Show Tec

Show Tec 40292 Manual de usuario

Show Tec

Show Tec GALACTIC BEAM G40 V1 Manual de usuario

Show Tec

Show Tec Performer 2000 Fresnel DDT MKII V3 Manual de usuario

Show Tec

Show Tec Spectral PC 600Z V3 Manual de usuario

Manuales populares de Equipo de DJ de otras marcas

ALPHA LITE

ALPHA LITE ALPHA 1500 Manual del propietario

Chauvet

Chauvet OVATION E-930VW Manual de usuario

Zumtobel

Zumtobel APHRODITE Home Manual de usuario

Snow Masters

Snow Masters Zig Oscillator Manual de usuario

EuroLite

EuroLite 50530554 Manual de usuario

Beamz

Beamz BUV243 Manual de usuario

thomann

thomann Stairville DJ Lase 40-G MK-III Manual de usuario

Eagletone

Eagletone 6 Eyes Flower Manual de usuario

EuroLite

EuroLite FLD-1508 Manual de usuario

Technical Pro

Technical Pro LG8xSEA Manual de usuario

JB Systems

JB Systems Lounge Laser DMX Manual de usuario

Lightmaxx

Lightmaxx Vega Halo 90 Manual de usuario

Elation

Elation FUZE WASH Z350 Manual de usuario

Maverick

Maverick MK3 WASH Manual de usuario

Infinity

Infinity TF-260C7 Fresnel Manual de usuario

Chauvet

Chauvet EVE E-50Z Manual de usuario

Eliminator Lighting

Eliminator Lighting E 138 Manual de usuario

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Manual de usuario
