37GQ-20FP

SHARP CORPORATION

CONTENTS

PAL / SECAM SYSTEM COLOUR TELEVISION

SEJ37GQ20FP02

SQUAD CHASSIS

SERVICE MANUAL

In the interests of user safety (required by safety

regulations in some countries) the set should restored

to its original condition and only parts identical to

those specified should be used.

MODEL 37GQ-20FP

Issued: 9th June ‘00

This document has been published to

be used for after sales service only.

ELECTRICAL SPECIFICATION.......................2

IMPORTANT SERVICE NOTES.......................3

SERVICE ADJUSTEMENTS.............................4

PRINTED WIRING BOARDS...........................11

SCHEMATIC DIAGRAM, WAVE FORMS..... .13

PART LIST.......................................................18

TROUBLESHOOTING TABLES.....................22

37GQ-20FP

ELECTRICAL SPECIFICATIONS

•Power Input .......................220V-240 Volts AC 50Hz

•Power Consumption

•Audio Power Output Rating .....................2W (MPO)

Speaker............................32Ω2W, 8cm Round, 1pc

Normal Operating....................................30W

Stand-by Operating................................7.5W

(Method IEC60107)

•White Level

Set brightness control to get total picture tube cathode current of 600 milliamperes under no signal condition.

Maximum necessary correction of each picture tube cathode current to get 8950 degree K-20 MPCD screen

temperature should not exceed 15% of its original value.

X=0.290 Y=0.284

WARNING

The chassis in this receiver is partially live. Alwais use an isolation transformer when

servicing this chassis.

To prevent electric shock, do not remove cover. No user-serviceable parts inside. Refer

servicing to qualified service personnel.

Convergence.........................Self Converging System

Focus....................................Bi-Potencial Electrostatic

Sweep Deflection...........................................Magnetic

Specifictions are subject to change without prior notice.

•Sound Carrier Trap

L’..........................................................40.4MHz

L...........................................................32.4MHz

B/G.......................................................33.4MHz

•Picture Intermediate Frecuencies

L’.........................................................33.9MHz

L, B/G..................................................38.9MHz

•Adjacent Sound Carrier Trap

L’..........................................................32.4MHz

L, B/G...................................................40.4MHz

•Adjacent Picture Carrier Trap

L’..........................................................41.9MHz

L...........................................................30.9MHz

B/G.......................................................30.9MHz

•Aerial Input Impedance

VHF/UHF...........................75 ohm Unbalanced

•Tuning Ranges

CATV Special Channels

L/L’..........................55.75MHz thru 855.25 MHz

B/G.........................48.25MHz thru 855.25 MHz

37GQ-20FP

SERVICING OF HIGH VOLTAGE SYSTEM AND PICTURE TUBE

Maintenanceandrepairofthisreceivershouldbedonebyqualifiedservicepersonnelonly.

Whenservicingthehighvoltagesystem,removestaticchargefromitbyconnectinga10Kohmresistorin

serieswithaninsulated wire (suchastest probe) betweenpicturetube ground tag andhigh voltage lead.

(AClinecordshould be disconnectedfromAC outlet).

1.The Picture tube in thisreceiveremploysIntegralImplosionprotection.

2.Replacewithtube of the same typenumber for continued safety.

3.Do not liftpicture tubeby the neck.

4.Handle the picturetubeonlywhenwearingshatterproofgogglesand after discharging thehigh

voltagecompletely.

X-RAY

ThisreceiverisdesignedsothatanyX-Rayradiationiskepttoanabsoluteminimum.Sincecertainmalfunctions

andservicingmayproducepotentiallyhazardousradiationwithprolongedexposureatcloserange,thefollowing

precautionsshouldbeobserved:

1.When repairing the circuit,be sure notto increasethe highvoltage tomore than 25.5KV, (at beam

1000µΑ)for the set.

2. To keep theset ina normaloperation, besure tomake itfunction on22.4KV±1.5KV (at beam

800µΑ) in thecase of theset. The sethas been factory-adjusted tothe abovementioned high

voltage.Alwayscheckthehighvoltageifthereis any possibility that it might have changed as a

resultof therepair.

3.Donotsubstitute a picture tubewithunauthorized types and/or brandswhich may cause excess

X-Ray radiation.

BEFORE RETURNING THE RECEIVER

Inadditiontotheabovechecks,thefollowingsafetychecksshouldalsobecarriedoutbefore returningthe

unittotheuser.

1.Inspect all leadsanddress to makecertainthat theleads arenot pinchedor thathardwareis not

loggedbetween thechassis andother metalparts.

2.Inspectallprotectivedevices such as non-metallic control knobs, insulating fish papers, cabinet

backs, adjustment andcompartment covers or shields,insolation resistor-capacity networks,

mechanicalinsulatorsetc.

IMPORTANT SERVICE NOTES

37GQ-20FP

SERVICE ADJUSTMENT

•SERVICE MODE FUNCTION

This mode funtion is provided to assist with the settings of those adjustments that may vary from one

Picture Tube to another, or between models.

In order to use the Service Mode

1. Press main switch to OFF.

2. Connect Test Pattern signal to antenna terminal.

3. Press ∨, CH ∨and main switch to ON simultaneosly or

press ∧, CH ∧ and main switch to ON simultaneosly.

4. -SERVICE- will appear on screen. Service mode is now entered.

5. Select adjustment using buttons ∧ CH ∧.

To exit Service Mode, press main switch to OFF or press MENU button on R/C.

SERVICE

NVM

AGC GAIN

AGC STR

PLL

PAL

AUTO

B-GAIN

G-GAIN

G-DC

R-GAIN

R-DC

HOR POS

VERT POS

VERT AM

Displayed

on screen Hexadecimal /

Decim. Range Function

00∼03H

00∼63H

S, L, VL, N

4-43, 3-58,

SECAM, NTSC

4-43,NTSC 3-58,

AUTO PNS,

AUTO PN

AUTO, 50HZ,

60HZ

0∼63d

0∼15d

Indicates operative Service Mode.

Access to NVM memory

Auto Gain Control

Auto Gain Starting Point

Line PLL time constant

Colour system.

FieldFrequency

Blue Gain

Green Gain

Green Cut

Red Gain

Red Cut

Horizontal Position shift

Vertical Position shift

Vertical Amplitude shift

6. For « a » Selection:

NVM storage location settings variants.

BANK POS VALUE

X XXH XXH Assigned value

Storage location

Memory Bank

In order to have access to NVM «MENU» button should be pressed. To obtain a higher or lower Memory

Bank, buttons ∨∧ should be pressed respectively. To have access to the desired Storage Location,

buttons ∨CH ∧ should be pressed, as required to obtain a higher or lower location, respectively.

37GQ-20FP

Bear in mind that, for storage location indication a hexadecimal numerical system is used, instead of a

decimal system.

0, 1, 2, 3, 4, 5, 6, 7, 8, 9, A, B, C, D, E, F, 10, 11, ......19, 1A, 1B, 1C, 1D, 1E, 1F, 20, 21, ....., 99, 9A, 9B,

9C, 9D, 9E, 9F, A0, A1, ....., B0, ....., C0, ....., D0, .....E0, ....., F0, F1, F2, F3, F4, F5, F6, F7, F8, F9, FA,

FB, FC, FD, FE, FF.

From the last location FF to the first 00 can be reached by increasing and from first to last by decreasing.

Once the storage location to be varied has been selected, its value can be modified by the bits that form

part of the storage location numerical buttons, numbers «0» to «7», respectively. This swithches the binary

number from and between 0 and 1 each time one of the buttons is pressed.

«0»:20=1, «1»: 21=2, «2»: 22=4, ...

7. For «b,c» and «g» thru «n» selections:

Adjustment to a selection can be made by pressing buttons ∨∧.

8. For «d» thru «f» selections:

Adjustment to a selection can be made by pressing button ∧.

NVM LIST DESCRIPTION

BANK ADDRESS DESCRIPTION VALUE

00H 00H ZONE FOR TUNNING INFORMATION (BEGIN) CAH

3BH ZONE FOR TUNNING INFORMATION (END) 10H

3CH STAND BY: 44H -> ON

40H -> OFF 44H

3DH OPTION BYTE:

10XXXXXX -> HOTEL MODE 1 (START IN

PRG1. NO TUNNING OPTION.

VOLUME LIMITATION).

11XXXXXX -> HOTEL MODE 2 (START IN

PRG 1. NO TUNING OPTION.

VOLUME LIMITATION.

START IN SCART MODE.

OUT FROM STDBY WITH SSW.

XXDDDDDD -> VOLUME ATTENUATION:

0AH -> 100%, 00H -> 0%

0AH

3EH DIODE_NVM:

XXXXXXX0 -> SYMBOLIC OSD.

XXXXXXX1 -> CHARACTER OSD

XXXXX1XX -> ENGLISH LANGUAGE.

04H

3FH DIODE2_NVM:

XXXXXXX1 -> FRENCH STANDARD

XXXXX01X -> BG STANDARD

XXXXX10X -> L/L’ STANDARD

XX1XXXXX -> AUDIO FOR UK

X1XXXXXX -> AUTOINSTALLATION ON

1XXXXXXX -> ONLY UHF BAND.

05H

01H 00H ZONE FOR TUNNING INFORMATION (BEGIN) 10H

3BH ZONE FOR TUNNING INFORMATION (END) 10H

3DH UHFLOW: LOW WINDOW LIMIT FOR UHF BAND 00H

3EH VHF3LOW: LOW WINDOW LIMIT FOR VHF3 BAND 00H

3FH VHF1LOW: LOW WINDOW LIMIT FOR VHF1 BAND 00H

02H 00H RESERVED ZONE FOR PROGRAMME NAMES (BEGIN) 24H

3FH RESERVED ZONE FOR PROGRAMME NAMES (END) 24H

37GQ-20FP

03H 00H ONE CHIP REGISTER 00: 80H

01H ONE CHIP REGISTER 01: 30H

02H ONE CHIP REGISTER 02: 9FH

03H ONE CHIP REGISTER 03: 2DH

04H ONE CHIP REGISTER 04: 00H

05H ONE CHIP REGISTER 05: B6H

06H ONE CHIP REGISTER 06: 00H

07H ONE CHIP REGISTER 07: 32H

08H ONE CHIP REGISTER 08: 19H

09H ONE CHIP REGISTER 09: 99H

0AH ONE CHIP REGISTER 0A: 3CH

0BH ONE CHIP REGISTER 0B: B2H

0CH ONE CHIP REGISTER 0C: 2EH

0DH ONE CHIP REGISTER 0D: 24H

0EH ONE CHIP REGISTER 0E: 22H

0FH ONE CHIP REGISTER 0F: 18H

10H ONE CHIP REGISTER 10: 1FH

11H ONE CHIP REGISTER 11: 00H

12H ONE CHIP REGISTER 12: 00H

13H ONE CHIP REGISTER 13: 38H

14H ONE CHIP REGISTER 14: 20H

15H ONE CHIP REGISTER 15: 00H

16H ONE CHIP REGISTER 16: 1DH

17H ONE CHIP REGISTER 17: 0FH

18H ONE CHIP REGISTER 18: 2FH

19H ONE CHIP REGISTER 19: 00H

1AH ONE CHIP REGISTER 1A: 90H

1BH ONE CHIP REGISTER 1B: 90H

1CH ONE CHIP REGISTER 1C: 90H

1DH ONE CHIP REGISTER 1D: 00H

1EH ONE CHIP REGISTER 1E: 00H

1FH ONE CHIP REGISTER 1F: 00H

20H VPOS_50 (VERTICAL POSITION) 4/3 50 Hz. 12H

21H VAMP_50 (VERTICAL AMPLITUDE) 4/3 50 Hz 0FH

22H VPOS_60 (VERTICAL POSITION) 4/3 60 Hz 0FH

23H VAMP_60 (VERTICAL AMPLITUDE) 4/3 60 Hz 0FH

24H HSHIFT_60 (HORIZONTAL SHIFT) 60Hz 1DH

25H HSHIFT_50 (HORIZONTAL SHIFT) 50Hz 22H

26H FINVFH: STEP FOR FINE TUNING IN VHF BAND 00H

27H VHF1_STEP: THICK TUNING STEP FOR VHF1 BAND F3H

28H VHF3_STEP: THICK TUNING STEP FOR VHF3 BAND 64H

29H UHF_STEP: THICK TUNING STEP FOR UHF BAND 64H

2AH LP_COARSE: THICK TUNING ADJUSTMENT FOR L’ 02H

2BH BG_COARSE: THICK TUNING ADJUSTMENT FOR L AND BG 0AH

2CH BG_FINE: FINE TUNING ADJUSTMENT FOR L AND BG 00H

2DH LP_FINE: FINE TUNING ADJUSTMENT FOR L’ 00H

2EH DELAY SEARCH:

XXXXXXX0 -> SHOWS ‘PROGRAMME –‘

DURING AUTOSEARCH.

XXXXXXX1 -> DHOWS ‘AUTO SEARCH’

DURING AUTOSEARCH

00H

2FH VHF1_SP: STEP FOR AUTO SEARCH IN VHF1 BAND 17H

30H VHF3_SP: STEP FOR AUTO SEARCH IN VHF3 BAND 0AH

31H UHF_SP: STEP FOR AUTO SEARCH IN UHF BAND 06H

32H OLD_PROGRAM: FOR FLASHBACK RETURN 0AH

33H UHFHIGH: UPPER WINDOW LIMIT FOR UHF 01H

34H VHF3HIGH: UPPER WINDOW LIMIT FOR VHF3 01H

37GQ-20FP

35H VHF1HIGH: UPPER WINDOW LIMIT FOR VHF1 01H

36H PRG_NUMBER: CURRENT PROGRAMME NUMBER 08H

37H WAITSUP: UPPER LIMIT DELAY TIME FOR AUTOSEARCH. 0FH

38H WAITINF: LOWER LIMIT DELAY TIME FOR AUTOSEARCH 03H

3BH SCART BLOKING:

-00H = NO SCARTBLOCKING

-01H = SCART BLOCKING WHEN ANY PR. IS IN CHILD

LOCK MODE.

00H

Do not use.

Just for

UK models

3CH RET_COL: DELAY IN COLOUR IDENTIFICATION IN AUTO

MODE. 40H

3FH CHECKSUM 35H

04H 00H ONE CHIP REGISTER 00: 80H

01H ONE CHIP REGISTER 01: 30H

02H ONE CHIP REGISTER 02: 9FH

03H ONE CHIP REGISTER 03: 2DH

04H ONE CHIP REGISTER 04: 00H

05H ONE CHIP REGISTER 05: B6H

06H ONE CHIP REGISTER 06: 00H

07H ONE CHIP REGISTER 07: 32H

08H ONE CHIP REGISTER 08: 19H

09H ONE CHIP REGISTER 09: 99H

0AH ONE CHIP REGISTER 0A: 3CH

0BH ONE CHIP REGISTER 0B: B2H

0CH ONE CHIP REGISTER 0C: 2EH

0DH ONE CHIP REGISTER 0D: 24H

0EH ONE CHIP REGISTER 0E: 22H

0FH ONE CHIP REGISTER 0F: 18H

10H ONE CHIP REGISTER 10: 1FH

11H ONE CHIP REGISTER 11: 00H

12H ONE CHIP REGISTER 12: 00H

13H ONE CHIP REGISTER 13: 38H

14H ONE CHIP REGISTER 14: 20H

15H ONE CHIP REGISTER 15: 00H

16H ONE CHIP REGISTER 16: 1DH

17H ONE CHIP REGISTER 17: 0FH

18H ONE CHIP REGISTER 18: 2FH

19H ONE CHIP REGISTER 19: 00H

1AH ONE CHIP REGISTER 1A: 90H

1BH ONE CHIP REGISTER 1B: 90H

1CH ONE CHIP REGISTER 1C: 90H

1DH ONE CHIP REGISTER 1D: 00H

1EH ONE CHIP REGISTER 1E: 00H

1FH ONE CHIP REGISTER 1F: 00H

20H VPOS_50 (VERTICAL POSITION) 4/3 50 Hz. 12H

21H VAMP_50 (VERTICAL AMPLITUDE) 4/3 50 Hz 0FH

22H VPOS_60 (VERTICAL POSITION) 4/3 60 Hz 0FH

23H VAMP_60 (VERTICAL AMPLITUDE) 4/3 60 Hz 0FH

24H HSHIFT_60 (HORIZONTAL SHIFT) 60Hz 1DH

25H HSHIFT_50 (HORIZONTAL SHIFT) 50Hz 22H

26H FINVFH: STEP FOR FINE TUNING IN VHF BAND 00H

27H VHF1_STEP: THICK TUNING STEP FOR VHF1 BAND F3H

28H VHF3_STEP: THICK TUNING STEP FOR VHF3 BAND 64H

29H UHF_STEP: THICK TUNING STEP FOR UHF BAND 64H

2AH LP_COARSE: THICK TUNING ADJUSTMENT FOR L’ 02H

2BH BG_COARSE: THICK TUNING ADJUSTMENT FOR L AND BG 0AH

2CH BG_FINE: FINE TUNING ADJUSTMENT FOR L AND BG 00H

2DH LP_FINE: FINE TUNING ADJUSTMENT FOR L’ 00H

2EH DELAY SEARCH:

XXXXXXX0 -> SHOWS ‘PROGRAMME –‘

DURING AUTOSEARCH.

XXXXXXX1 -> DHOWS ‘AUTO SEARCH’

DURING AUTOSEARCH

00H

37GQ-20FP

2FH VHF1_SP: STEP FOR AUTO SEARCH IN VHF1 BAND 17H

30H VHF3_SP: STEP FOR AUTO SEARCH IN VHF3 BAND 0AH

31H UHF_SP: STEP FOR AUTO SEARCH IN VHF BAND 06H

32H OLD_PROGRAM: FOR FLASHBACK RETURN 0AH

33H UHFHIGH: UPPER WINDOW LIMIT FOR UHF 01H

34H VHF3HIGH: UPPER WINDOW LIMIT FOR VHF3 01H

35H VHF1HIGH: UPPER WINDOW LIMIT FOR VHF1 01H

36H PRG_NUMBER: CURRENT PROGRAMME NUMBER 08H

37H WAITSUP: UPPER LIMIT DELAY TIME FOR AUTOSEARCH. 0FH

38H WAITINF: LOWER LIMIT DELAY TIME FOR AUTOSEARCH 03H

3BH SCART BLOKING:

-00H = NO SCARTBLOCKING

-01H = SCART BLOCKING WHEN ANY PR. IS IN CHILD

LOCK MODE.

00H

Do not use.

Just for

UK models

3CH RET_COL: DELAY IN COLOUR IDENTIFICATION IN AUTO

MODE. 40H

3FH CHECKSUM 35H

05H 00H ONE CHIP REGISTER 00: 80H

01H ONE CHIP REGISTER 01: 30H

02H ONE CHIP REGISTER 02: 9FH

03H ONE CHIP REGISTER 03: 2DH

04H ONE CHIP REGISTER 04: 00H

05H ONE CHIP REGISTER 05: B6H

06H ONE CHIP REGISTER 06: 00H

07H ONE CHIP REGISTER 07: 32H

08H ONE CHIP REGISTER 08: 19H

09H ONE CHIP REGISTER 09: 99H

0AH ONE CHIP REGISTER 0A: 3CH

0BH ONE CHIP REGISTER 0B: B2H

0CH ONE CHIP REGISTER 0C: 2EH

0DH ONE CHIP REGISTER 0D: 24H

0EH ONE CHIP REGISTER 0E: 22H

0FH ONE CHIP REGISTER 0F: 18H

10H ONE CHIP REGISTER 10: 1FH

11H ONE CHIP REGISTER 11: 00H

12H ONE CHIP REGISTER 12: 00H

13H ONE CHIP REGISTER 13: 38H

14H ONE CHIP REGISTER 14: 20H

15H ONE CHIP REGISTER 15: 00H

16H ONE CHIP REGISTER 16: 1DH

17H ONE CHIP REGISTER 17: 0FH

18H ONE CHIP REGISTER 18: 2FH

19H ONE CHIP REGISTER 19: 00H

1AH ONE CHIP REGISTER 1A: 90H

1BH ONE CHIP REGISTER 1B: 90H

1CH ONE CHIP REGISTER 1C: 90H

1DH ONE CHIP REGISTER 1D: 00H

1EH ONE CHIP REGISTER 1E: 00H

1FH ONE CHIP REGISTER 1F: 00H

20H VPOS_50 (VERTICAL POSITION) 4/3 50 Hz. 12H

21H VAMP_50 (VERTICAL AMPLITUDE) 4/3 50 Hz 0FH

22H VPOS_60 (VERTICAL POSITION) 4/3 60 Hz 0FH

23H VAMP_60 (VERTICAL AMPLITUDE) 4/3 60 Hz 0FH

24H HSHIFT_60 (HORIZONTAL SHIFT) 60Hz 1DH

25H HSHIFT_50 (HORIZONTAL SHIFT) 50Hz 22H

26H FINVFH: STEP FOR FINE TUNING IN VHF BAND 00H

27H VHF1_STEP: THICK TUNING STEP FOR VHF1 BAND F3H

28H VHF3_STEP: THICK TUNING STEP FOR VHF3 BAND 64H

29H UHF_STEP: THICK TUNING STEP FOR UHF BAND 64H

2AH LP_COARSE: THICK TUNING ADJUSTMENT FOR L’ 02H

37GQ-20FP

••

•PIF/AGC Adjustement ••

••

•Screen Adjustement

Apply mains voltage of 220V AC/50HZ to TV.1. Receive Philips pattern signal to a level

between 60 and 80 dBµV.

Set contrast to 10/10, brightness to 5/10

and colour 0/10.

Adjust focus potentiometer to obtain

maximum definition.

4. Focus Adjustment

1. B/G AFT Adjustment

Connect the output of SSG (Standard Signal

Generator)tothe tuner IF output terminal.

•SSG output 38.9 MHz (CW)± 5 KHz.

•SSG output level: approx. 90 dBµV.

Enter into Service Mode.

2.Push «2» key on R/C. «FI OK» will appear.

3.Switch set OFF and ON again, setting is now

memorized.

2. L/L’ AFT Adjustment

Connect the output of SSG (Standard Signal

Generator) to the turner IF output terminal.

•SSG output 34.47MHz (CW) ± 5 KHz.

•SSG output level: approx. 90 dBµV.

Enter into Service Mode.

2.Push «3» key on R/C. «FI OK» will appear.

3.Switch set OFF and ON again, setting is now

memorized.

Receive the «COLOUR BAR» signal (Channel E-

12). Signal strength: 57 dBµV.

Enter into Service Mode.

3. RF-AGC STR Adjustment

Push CH until AGC STR appears on screen.

4.Push «7» key of R/C.«AGC OK» will appear.

Switch set OFF and ON again, setting is now

memorized.

5. G2 Adjustment

Apply mains voltage of 220V AC/50HZ to TV.

1.Receive cross hatch pattern signal to a level

between 60 and 80 dBµV.

Apply High Voltage Probe to Pin 8 of CRT socket

4.Adjust G2 potentiometer until obtaining 525V

±10%.

5.Check BKGD. If it is necessary adjust BKGD

according to instructions detailed in the next

page.

2BH BG_COARSE: THICK TUNING ADJUSTMENT FOR L AND BG 05H

2CH BG_FINE: FINE TUNING ADJUSTMENT FOR L AND BG 80H

2DH LP_FINE: FINE TUNING ADJUSTMENT FOR L’ 80H

2EH DELAY SEARCH:

XXXXXXX0 -> SHOWS ‘PROGRAMME –‘

DURING AUTOSEARCH.

XXXXXXX1 -> DHOWS ‘AUTO SEARCH’

DURING AUTOSEARCH

00H

2FH VHF1_SP: STEP FOR AUTO SEARCH IN VHF1 BAND 17H

30H VHF3_SP: STEP FOR AUTO SEARCH IN VHF3 BAND 0AH

31H UHF_SP: STEP FOR AUTO SEARCH IN VHF BAND 06H

32H OLD_PROGRAM: FOR FLASHBACK RETURN 0AH

33H UHFHIGH: UPPER WINDOW LIMIT FOR UHF 01H

34H VHF3HIGH: UPPER WINDOW LIMIT FOR VHF3 01H

35H VHF1HIGH: UPPER WINDOW LIMIT FOR VHF1 01H

36H PRG_NUMBER: CURRENT PROGRAMME NUMBER 08H

37H WAITSUP: UPPER LIMIT DELAY TIME FOR AUTOSEARCH. 0FH

38H WAITINF: LOWER LIMIT DELAY TIME FOR AUTOSEARCH 03H

3Bh SCART BLOKING:

-00H = NO SCARTBLOCKING

-01H = SCART BLOCKING WHEN ANY PR. IS IN CHILD

LOCK MODE.

00H

Do not use.

Just for

UK models

3CH RET_COL: DELAY IN COLOUR IDENTIFICATION IN AUTO

MODE. 40H

3FH CHECKSUM 35H

37GQ-20FP

1. HOR POS

a) Receive Philips pattern signal.

b) When ∧button is pressed, picture moves to the left.

c) When ∨button is pressed, picture moves to the right.

d) Adjust the horizontal location to obtain picture centering (Fig.1).

•GEOMETRY ADJUSTMENT PROCEDURE

2. VERT POS

a) Receive Philips pattern signal.

b) When ∧button is pressed, picture moves up.

c) When ∨button is pressed, picture moves down.

d) Adjust the vertical location to obtain picture centering (Fig.2).

3. VERT AM

a) Receive Philips pattern signal.

b) When ∧button is pressed, vertical size of picture increases.

c) When ∨button is pressed, vertical size of picture decreases.

d) Adjust the vertical size to obtain picture overscan (Fig.3).

The following adjustments are requiered when the Picture Tube or IC801 are replaced,

or may be necessary after adjustment of the G2 voltage.

1. «B-GAIN», «G-GAIN»

a) Adjust G2.

b) Tune a grey scale pattern.

c) Adjust colour to minimum.

d) Fix R-GAIN value to 50.

e) Position colourmeter in the the left point of Fig.4.

f) Using brightness and contrast buttons, select a luminance of ≈120 nits.

g) Operate again in Service Mode and select location B-GAIN and

G-GAIN to obtain colour coordinates:

X = 0.290 ±0.015

Y = 0.284 ±0.015

h) Exit Service Mode and check colour coordinates «X» and «Y» at 20 and 120 nits. It may be

necessary to repeat the same procedure or re-adjust the cuts as show the be below one.

2. «G-DC», «R-DC»

a) Adjust G2, in the case that it has not been made previously.

b) Tune a grey scale pattern.

c) Adjust colour to minimum.

e) Position colourmter in the the right point of Fig.4.

f) Using brightness and contrast buttons, select a luminance of ≈20 nits.

g) Operate again in Service Mode and select location G-DC and R-DC to obtain colour

coordinates: X = 0.290 ±0.015

Y = 0.284 ±0.015

h) Exit Service Mode and check colour coordinates «X» and «Y» at 20 and 120 nits. It may be

necessary to repeat the same procedure or the previous one.

•COLOUR ADJUSTMENT (BKGD) PROCEDURES

NOTE: Locations «R» alter «X» coordinates; «G» alter «Y» coordinates; «B» alter «X» and «Y»

coordinates.

Fig. 2

Fig. 1

Fig. 3

Fig. 4

3 7 4 0

6 5 4 3 2 1 0

(0: Black ... 7: White)

Gain point

DC point

Tabla de contenidos

Otros manuales de TELEVISOR de Sharp

Sharp

Sharp Aquos LC 26D7U Manual de usuario

Sharp

Sharp CX34L3 Manual de usuario

Sharp

Sharp LC-13S1H Manual de usuario

Sharp

Sharp LC-39LE650E Manual de usuario

Sharp

Sharp ROKU LC-43LB371U Manual de usuario

Sharp

Sharp 20F640 XFlat Manual de usuario

Sharp

Sharp 21J-FV1RU Manual de usuario

Sharp

Sharp LC-37D40U Manual de usuario

Sharp

Sharp Aquos LC-32D33X Manual de usuario

Sharp

Sharp CX-34G3 Manual de usuario

Sharp

Sharp 50BJ2K Manual de usuario

Sharp

Sharp Aquos LC-80UH30U Manual de usuario

Sharp

Sharp 21J-FG1RU Manual de usuario

Sharp

Sharp CX48K4 Manual de usuario

Sharp

Sharp LC-20B2UA Manual de usuario

Sharp

Sharp LC-60UI7652K Manual técnico

Sharp

Sharp 32R-S50 Manual de usuario

Sharp

Sharp Aquos LC-46D92U Manual de usuario

Sharp

Sharp 20F540 XFlat Manual de usuario

Sharp

Sharp LC-32CHG6021E Manual de usuario

Sharp

Sharp 54DS05SN Manual de usuario

Sharp

Sharp LC-19SB15U, LC-19SB25U, LC-19SB25U-W Manual de usuario

Sharp

Sharp LC-40FI5242KF Manual técnico

Sharp

Sharp 32LF-94EC Manual de usuario

Manuales populares de TELEVISOR de otras marcas

Philips

Philips Colour Television Manual de usuario

Toshiba

Toshiba 27A10 Manual de usuario

Philips

Philips 42PF9630A/37 Manual de usuario

Hitachi

Hitachi 32FX48B Manual de usuario

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manual de usuario

Changhong Electric

Changhong Electric uhd55b6000is Manual de usuario

Philips

Philips Matchline 21CE7551 Manual de usuario

Panasonic

Panasonic Genus TX-G10 Manual de usuario

Toshiba

Toshiba 19A20 Manual de usuario

Philips

Philips 25PT4523-16 Manual de usuario

Sony

Sony XBR-100Z9D Manual de usuario

Philips

Philips PR0930X3 Manual de usuario

Philips

Philips Brilliance 231P4QPY Manual de usuario

Samsung

Samsung 55S9 B Series Manual de usuario

Philips

Philips 32HF9385D Guía de solución de problemas

Loewe

Loewe Table Stand Reference 55 Manual de usuario

Philips

Philips 32PFH5300 Manual de usuario

Sylvania

Sylvania 6427FB Manual de usuario
