SERVICE MANUAL

This document has been published to be used for

after sales service only.

The contents are subject to change without notice.

Refrigerator-freezer

MODEL

SJ-XF50X-T

No.S0311SJF50XTFT

DESTINATION F

CONTENTS

Refer to "REFRIGERATING-CYCLE REPAIR MANUAL" for handling this refrigerant.

Refrigerant; R600a

[1] PRODUCT SPECIFICATIONS

1. SPECIFICATIONS ………………………… 2

2. ACCESSORIES …………………………… 2

3. AUTOMATIC ICE MAKING ……………… 3

[2] DESIGNATION OF VARIOUS PARTS

1. PART NAMES ……………………………… 4

2. INTERNAL STRUCTURE ………………… 5

3. FLOW OF COOL AIR ……………………… 6

4. TEMPERATURE DISTRIBUTION………… 7

[3] DIMENSIONS

OUTER DIMENSIONS AND CLEARANCE

…8

2. INNER DIMENSIONS ……………………… 9

[4] ELECTRICAL CIRCUIT DIAGRAMS…………10

1. WIRING DIAGRAM …………………………10

2. ELECTRIC ACCESSORIES LAYOUT …… 11

PRECAUTIONS FOR USING LEAD-FREE SOLDER

……12

[5] ELECTRICAL SYSTEM SPECIFICATIONS…13

1. FUNCTIONAL PART SPECIFICATIONS…13

2. MODE FOR DISPLAY………………………14

[6]

REFRIGERATION CYCLE SYSTEM SPECIFICATIONS

1. R600A PRECAUTIONS ……………………15

TABLE OF R600A CHARACTERISTICS

…15

3. REFRIGERATION CYCLE DIAGRAM……15

[7] TROUBLESHOOTING

1. SELF-DIAGNOSIS MODE …………………18

FORCED STOPPING OF DOOR ALARM BUZZER

…22

THERMISTOR CIRCUIT CHECK METHOD

…22

INSPECTION FLOWCHART AND REPAIR ITEMS

…23

PLASMACLUSTER OK/NG JUDGMENT

…25

[8] DISASSEMBLY/ASSEMBLY

GENERAL DISASSEMBLY SEQUENCE

…26

REFRIGERATOR COMPARTMENT DISASSEMBLY

…27

3. FREEZER COMPARTMENT/ICE

COMPARTMENT DISASSEMBLY ………29

VEGETABLE COMPARTMENT DISASSEMBLY

…31

5. HOW TO REMOVE OP. PWB ASS'Y ……32

6. HOW TO REMOVE TERMINAL BOX ……33

7. HOW TO INSTALL R-SUB PACKING ……33

HOW TO INSTALL DUCT RT ASS'Y COVER

…34

ADJUSTMENT OF R-DOOR (DOUBLE DOOR)

…35

.MAIN PARTS ASSEMBLY…………………36

Parts Guide

SJXF50XT

[1] PRODUCT SPECIFICATIONS

SPECIFICATIONS1.

Item SJ-XF50X-T

Rated voltage/Rated frequency 110V~60Hz

Rated current (W) 118

Rated power input of heating systems (W) 171

Defrosting input (W) 130

Defrosting heater input (W) 130

O u t e r d i m e n s i o n s

Width×Depth×Height (mm) 685 x 699 x 1820

Rated total storage volume 501L (17.7 cu.ft.)

Refrigerator compartment 268L (9.47 cu.ft.)

Freezer compartment (upper) 28L (0.99 cu.ft.)

Freezer compartment (lower) 96L (3.39 cu.ft.)

Ice compartment 19L (0.67 cu.ft.)

Vegetable compartment 90L (3.18 cu.ft.)

Weight (kg) 89

Refrigerant (Charging quantity) [Flammable] R600a (68g)

Insulation blowing gas [Flammable] Cyclo pentane (HC)

Cabinet

Inner box material ABS plastic

Outer shell material PET steel

(Hot dipped zinc plated steel sheet with baked polyester resin coating)

Door Door shell material Steel

Door inner material ABS plastic

Temperature control Automatic(adjustable)

Defrosting system Heater system

(automatic start, automatic ﬁnish)

Refrigerator lamp LED (8 pcs)

Adjustable legs 2

Casters 4

Climate class ST

PLUG TYPE

Plug cord 2pin

Plug type A-1

Destination mark F

COLOR

Items -T

Outside color Brown

Inside color White

ACCESSORIES2.

Refrigerator Compartment

R shelf 2

Free set shelf (front/back) 1 each

Chilled case 1

Chilled case tray 1

Case 1

Door pocket (left) 2

Door pocket (right) 2

Egg case 1

Egg tray 1

Bottle pocket (left/right) 1each

Water tank (Tank cap, Lock lever, Slide

cap, Filter case, Water tank, Water ﬁlter) 1

SJXF50XT

Freezer compartment (Upper)

Freezer case (Upper) 1

Stainless tray 1

Freezer compartment (Lower)

Freezer case (top) 1

Freezer case (bottom) 1

Ice compartment

Ice storage box 1

Noise-proof sheet 1

Ice scoop 1

Vegetable compartment

Vegetable case 1

Fruit case 1

Pet case 1

Stainless tray 1

Other Accessories and Printed Materials

Foot grille 1

Operation manual 1

Warranty card 1

AUTOMATIC ICE MAKING3.

Water supply method: Storing water in tank/Direct water supply to ice cube maker•

Water tank volume: Approx. 1.0 L•

Ice making capacity (External air temperature: 30ºC, No door opening/closing, Temperature control: “• 中”, Ice-making mode: “ 通常 ”)

Ice cube size Standard Large

Daily Approx. 1.2 kg Approx. 1.5 kg

Once (8 pieces) Approx. 100 g Approx. 230 g

Ice-making time/once•

Ice cube size Standard Large

Ice making

mode

通常 Approx. 2 hours Approx. 3 hours and 30 minutes

明亮 Approx. 6 hours Approx. 8 hours

急速 Approx. 1 hour and 20 minutes Approx. 2 hours

Others: Water filter is attached.•

Ice scoop is provided.

Enables test operation with the cleaning function.

Heat-resistant temperature of water tank: Approx. 60ºC•

Ice storage quantity•

Ice cube size Standard Large

Normal Approx. 4

0 to 64 pcs. Approx. 24 to 32 pcs.

Maximum (when leveled) Approx. 88 to 104 pcs. Approx. 40 to 48 pcs.

SJXF50XT

[2] DESIGNATION OF VARIOUS PARTS

PART NAMES1.

Parts names in parentheses "[ ]" are denominations used in the Operation manual.

>@

Ice compartment Freezer compartment (upper)

Freezer compartment (lower)

Noise-proof sheet

Ice storage box

Ice scoop F case sus

F case s

F top case

F bottom case Vegetable case

Fruit case

V case sus

Pet case

Vegetable compartment

Free set shelf

Egg case

Egg tray

Water tank

Cool plate

Case

Chilled case

C case tray

LED

[ ]

[ ] [ ]

[ ]

Plasmacluster unit

R shelf

Bottle pocket(left) Bottle pocket(right)

Door pocket(left) Door pocket(right)

[ ]

SJXF50XT

INTERNAL STRUCTURE2.

Catalyzer

Humidity sensor

OP. PWB

Proximity switch

Thermo fuse

Catalyzer

Ice compartment Freezer compartment (upper)

Vegetable compartment

Refrigerator compartment

R-shower duct ass’y

D-fan motor PCI

Damper ass’y

Thermistor

Ice cube heater

Evaporator

V-thermistor (G-thermistor)

V heater

Damper

Terminal box

(Main PWB, EECON-INV PWB, REACTANCE)

Compressor, protector, valve turret

Fan motor g

Condensor unit

Caster

Evaporating pan

Side view

Adjustable leg ass’y

F proximity switch

Ice maker ass’y

R door switch

LED PWB ass’y

Cool plate

LED PWB ass’y

R-thermistor

Gear pump

Water pipe ass’y

Water pipe heater

Tank heater

F-thermistor

Evaporator

Heater

Front view

Temp.control PWB

Fan motor f

DEF thermistor

Duct heater

Freezer

compartment (lower)

SJXF50XT

FLOW OF COOL AIR3.

Flow of Cool air

Ice compartment

Refrigerator compartment

Freezer

compartment (lower)

Freezer

compartment (upper)

Vegetable compartment

Side view

Front view

Freezer

compartment (lower)

Freezer

compartment (upper)

Refrigerator compartment

Ice compartment

When Plasmacluster ion is in operation.

SJXF50XT

TEMPERATURE DISTRIBUTION4.

●The temperatures above are indications under the condition of no

food inside, doors closed and surrounding temperature is 30 after

stabilized the inside temperature. (Temperature adjustment is "中")

Approx.3 ~ 7°C Approx.2 ~ 5°C Approx.3 ~ 7°C

Approx.0 ~ 2°C

Approx.-17 ~ -19°C

Approx.-18 ~ -20°C

Approx.3 ~ 8°C

SJXF50XT

[3] DIMENSIONS

OUTER DIMENSIONS AND CLEARANCE (UNIT:mm)1.

198 281

699

285 396

551

632.5

661.5

608

626.5

685

1820

853.2180.8

335

365

15.5

709

930

1043

705

60 60

Moving wheels

back side

Moving wheels

front side

(Adjustable feet)

More than More than

More than

135°135°

More than More than

SJXF50XT

INNER DIMENSIONS2.

The dimensions between shelves can be changed by setting the shelves on the other rails.•

311

292

311

562

292

282

118

156 118

246

226

355.5

79.5

398.8

392

383

235

139

112

558

543

542

135 269

269

236

268

144

138

123

183

135

163

398.8

98 68

311

811651

292

123 138

116

145

311

106

354

172

206

211

301 213

238

253

310

218

519

532

393

94.5

109.5

137.5

172

SJXF50XT

[4] ELECTRICAL CIRCUIT DIAGRAMS

WIRING DIAGRAM1.

Source cord

Reactance

Main PWB

PWB

EECON-INV

PWB

Protector Compressor

Fan

motor g

Fan

motor f

LED

PWB

(left)

Temp.

control

PWB

Indicator

PWB

Plasmacluster

unit

Motor

D-fan motor PCI

Gear

pump

Damper

thermistor

F thermistor

DEF

thermistor Ice maker unit

Motor

Switch

Thermistor

Proximity

switch

F proximity

switch

Ice cube

heater

R door

heater

V heater

Duct

heater

V thermistor

V damper

Door

switch

(left)

Door

switch

(right)

LED

PWB

(right)

Terminal box

Valve turret

Humidity sensor

Heater

Thermo fuse

Tank heater Water

pipe

heater
