8M-B32C1 Dismantle Instruction

Dismantle Instruction

LCD MONITOR

MODEL

8M-B32C1

8M-B32C1 Dismantle Instruction

Table of contents

1. Scope.................................................................................................................. 3

2. Tools for dismantling............................................................................................... 3

3. Dismantle Procedure .............................................................................................. 3

4. Stand, Back cover and PWB Plate............................................................................... 4

5. Printed circuit boards ............................................................................................. 8

6. Battery................................................................................................................ 9

7. LCD Module ........................................................................................................ 10

8. Capacitors.......................................................................................................... 11

9. Parts List ........................................................................................................... 12

8M-B32C1 Dismantle Instruction

1. Scope

This document describes dismantling instruction according to Annex VII of Directive 2012/19/EU.

2. Tools for dismantling

Below tools are required to dismantle this product.

- Screw Driver

- Nipper

3. Dismantle Procedure

This product can be dismantled by below steps.

1. Remove Stand, Back cover and PWB Plate (section 4)

2. Remove Printed circuit boards (section 5)

3. Remove Battery (section 6)

4. Dismantle LCD (section 7)

5. Remove Electrolyte Capacitors (section 8)

8M-B32C1 Dismantle Instruction

4. Stand, Back cover and PWB Plate

Stand can be removed with screw driver.

Remove SCREW COVER SEAL on back cover.

Then back cover can be removed with screw driver.

8M-B32C1 Dismantle Instruction

Cut the cable tie on VESA angle with nipper, and peel off ALPET SHEET and ALPET SHEET S.

Then remove VESA angle with screw driver. (right side in back view)

ALPET SHEET S

ALPET SHEET

8M-B32C1 Dismantle Instruction

Detach the cables from DC switch PWB and remove the PWB with screw driver.

Remove WIRING SHEET (Black PC sheet) from PWB Plate.

Release all the cables that runs through the plate aperture. (cables from beneath the plate).

DC switch PWB

8M-B32C1 Dismantle Instruction

Detach Key-FFC from the connector on Main I/F PWB

Release from wire holders and remove the fixing tape on PWB Plate.

Then PWB Plate can be removed with screw driver.

(When the plate is lifted up, cables should go through the aperture of plate)

8M-B32C1 Dismantle Instruction

5. Printed circuit boards

All PWBs can be removed by screw driver.

Power PWB (1pcs)

Main I/F PWB (1pcs)

LED Driver PWB (2pcs) UCCT PWB (1pcs) DC switch PWB (1pcs)

Connector PWB (1pcs) Varistor PWB (1pcs)

T-CON PWB (1pcs) Key PWB (1pcs)

8M-B32C1 Dismantle Instruction

6. Battery

This model uses only CR2032 Lithium Coin battery on Main I/F PWB.

Battery CR2032 can easily be removed from the battery holder.

8M-B32C1 Dismantle Instruction

7. LCD Module

- LCD Dismantle procedure

LCD
