SERVICE MANUAL

S23OJLC50LE44

LCD COLOUR TELEVISION

MODEL LC-50LE440M

W/DIVX Series

In the interests of user-safety (Required by safety regulations in some countries) the set should be restored

to its original condition and only parts identical to those specified should be used.

CONTENTS

Page

• SERVICING NOTICES ON CHECKING …………………………………………………………………………………

…

A1-1

• HOW TO ORDER PARTS …………………………………………………………………………………….……………

…

A1-1

• IMPORTANT ……………………………………………………………………………………………...…………………

…

A1-1

• ABOUT LEAD FREE SOLDER (PbF) ……………………………………………………………..………………………

…

A1-2

• HOTEL MODE FUNCTION ……………………………………………………………..…………………………………

…

A1-3

• GENERAL SPECIFICATIONS ……………………………………………………………………………………………

…

A2-1~A2-6

• DISASSEMBLY INSTRUCTIONS ………………………………………………………………….……………………… B1-1~B2-2

• HOW TO UPGRADE SOFTWARE ………………………………………………………………………………………

…

C-1

• ELECTRICAL ADJUSTMENTS……………………………………………………………………..……………………… D-1, D-2

• TROUBLESHOOTING GUIDE ……………………………………………………………………….……………………

…

E-1, E-2

• BLOCK DIAGRAM …………………………………………………………………………………..………………………

…

F-1, F-2

• PRINTED CIRCUIT BOARDS ……………………………………………………………………….……………………

…

G-1~G-4

• SCHEMATIC DIAGRAMS …………………………………………………………………………..……………………… H-1~H-10

• WAVEFORMS ……………………………………………………………………………………….………………………

…

I-1

• MECHANICAL EXPLODED VIEWS ……………………………………………………………………… ……………… J-1~J-3

• REPLACEMENT PARTS LIST ……………………………………………………………………..……..………………

…

K1-1~K2-5

Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with

specified ones for maintaining the safety and performance of the set.

SHARP CORPORATION

This document has been published to be used for

after sales service only.

The contents are subject to change without notice.

CONTENTS

K1~K6

H1~H17

(A)

1. KEEP THE NOTICES 6. PERFORM A SAFETY CHECK AFTER

SERVICING

As for the places which need special attentions,

they are indicated with the labels or seals on the Confirm that the screws, parts and wiring which

cabinet, chassis and parts. Make sure to keep the were removed in order to service are put in the

indications and notices in the operation manual. original positions, or whether there are the

portions which are deteriorated around the

2. AVOID AN ELECTRIC SHOCK serviced places serviced or not. Check the

insulation between the antenna terminal or

There is a high voltage part inside. Avoid an external metal and the AC cord plug blades.

electric shock while the electric current is And be sure the safety of that.

flowing.

(INSULATION CHECK PROCEDURE)

3. USE THE DESIGNATED PARTS

1. Unplug the plug from the AC outlet.

The parts in this equipment have the specific 2. Remove the antenna terminal on TV and turn

characters of incombustibility and withstand on the TV.

voltage for safety. Therefore, the part which is 3. Insulation resistance between the cord plug

replaced should be used the part which has terminals and the eternal exposure metal

the same character. [Note 2] should be more than 1M ohm by

Especially as to the important parts for safety using the 500V insulation resistance meter

which is indicated in the circuit diagram or the [Note 1].

table of parts as a ! mark, the designated 4. If the insulation resistance is less than 1M

parts must be used. ohm, the inspection repair should be

required.

SERVICING NOTICES ON CHECKING

required.

4. BE CAREFUL WITH THE

LCD PANEL [Note 1]

If you have not the 500V insulation

Avoid a shock to the panel while servicing. resistance meter, use a Tester.

Take enough care to deal with it.

[Note 2]

5. PUT PARTS AND WIRES IN THE External exposure metal: Antenna terminal

ORIGINAL POSITION AFTER Headphone jack

ASSEMBLING OR WIRING

There are parts which use the insulation

material such as a tube or tape for safety, or

which are assembled in the condition that

these do not contact with the printed board.

The inside wiring is designed not to get closer

to the pyrogenic parts and high voltage parts.

Therefore, put these parts in the original

positions.

Please include the following informations when you order parts.

1. MODEL NUMBER

The MODEL NUMBER can be found on the back of each product can be found at the end of the SERIAL NUMBER.

2. PART NO. and DESCRIPTION

You can find it in your SERVICE MANUAL.

When you exchange IC and Transistor with a heat sink, apply silicon grease (YG6260M) on the contact

section of the heat sink. Before applying new silicon grease, remove all the old silicon grease.

(Old grease may cause damage to the IC and Transistor).

HOW TO ORDER PARTS

IMPORTANT

A1-1

ABOUT LEAD FREE SOLDER (PbF)

Distinction of PbF PCB:

PCBs (manufactured) using lead free solder will have a PbF printing on the PCB.

(Please refer to figures.)

Caution:

• Pb free solder has a higher melting point than standard solder;

Typically the melting point is 86

F~104

F(30

C~40

C) higher.

Please use a soldering iron with temperature control and adjust it to 650

F ± 20

F (350

C ± 10

C).

In case of using high temperature soldering iron, please be careful not to heat too long.

•Pb free solder will tend to splash when heated too high (about 1100

F/ 600

C).

•

All products with the printed circuit board with PbF printing must be serviced with lead free solder.

•

All products with the printed circuit board with PbF printing must be serviced with lead free solder.

When soldering or unsoldering, completely remove all of the solder from the pins or solder area,

and be sure to heat the soldering points with the lead free solder until it melts sufficiently.

Recommendations

Recommended lead free solder composition is Sn-3.0Ag-0.5Cu.

A1-2

HOTEL MODE FUNCTION

To set the Hotel mode, please follow the steps below.

1. Press the MENU ---> 1147 button on the remote control.

2. Select the "GENERAL SETTEING" menu, then press ENTER button. Hotel Mode On

3. Select the "Hotel Mode" menu, Select "ON", then press the RETURN button. Source Lock

4. Press the MENU button on the remote control. Default Source Off

5. Press the RIGHT button on the remote control, Select the "OPTION" menu, Default Prog 1

then press ENTER button. Max Volume 100

6. Press the DOWN button on the remote control, Select the "Hotel Mode" menu, Default Volume 20

then press ENTER button. Clear Lock

7. Please input the password "0000". Set Password

8. The Hotel mode menu will appear. Export Settings

9. Select the "Hotel Mode" menu, Select "ON", Import Settings

10. Using the UP/DOWN button on the remote control, select the desired mode.

Then press the ENTER button.

11. Using the LEFT/RIGHT button on the remote control, set the mode to

desired setting.

## The Hotel mode has now been set up.

To reset the Hotel mode, please follow the steps below.

Press the MENU button on the remote control.

2. Press the RIGHT button on the remote control, Select the "OPTION" menu, then press ENTER button.

3. Press the DOWN button on the remote control, Select the "Hotel Mode" menu, then press ENTER button.

4. Please input the password "0000".

5. The Hotel mode menu will appear.

6. Select the "Hotel Mode" menu, Select "ON",

7. Press the DOWN button on the remote control,

8. Select the "Clear Lock" menu, then press ENTER button.

9. The setting items has now been returned to initial value.

1 Setting of the CH if select "Default Source" to TV input.

Setting of the maximum volume value.

20 Setting volume at Power on.

Output the setting of menu and current CH Map to

USB Memory.

Read the setting of menu and current CH Map from

USB Memory.

Setting Input skip, combine with "Default Source".Source Lock

Import Settings

Export Settings

100

Setting of the Hotel Mode return factory setting.

Setting of the Password.

Maximum volume

Default Volume

Set Password

Clear Lock

Setting Input Source, combine with "Source Lock"

If select "Source Lock" for this function disappear.

FUNCTIONSetting item Setting value

TV/AV/COMPONENT

HDMI/PC/MEDIA

OFF/TV/AV/

Default Prog 0~199

0~100

Initial value

OffDefault Source

PC/MEDIA

COMPONENT/HDMI/

A1-3

GENERAL SPECIFICATIONS

G-1 TV LCD LCD Size / Visual Size 49.50 inch / 1257.3mmV

System LCD Type Color TFT LCD

Number of Pixels 1920(H) x 1080(V)

Double Scan No

View Range Left/Right 89/89 degree

Up/Down 89/89 degree

Bright Dot n≦0

Zero Bright Dot Ratio --

Color System PAL / SECAM / NTSC3.58 / NTSC4.43 / PAL60

Speaker 2 Speaker

Position Bottom

Size 1.6 x 4.8 inch

Impedance 8 ohm

Sound Output MAX 9W + 9W

10%(Typical) ---

G-2 Tuning Broadcasting System Analog

PAL(B/G, D/K, I), SECAM(B/G, D/K)NTSC3.58(M)

System Tuner and System 1Tuner (Analog)

Receive CH Destination UK, I.R., CCIR Hyper

CH Coverage Analog 44.25MHz~863.25MHz

Intermediate Analog BG / II / DK / M

Frequency Picture(FP) 38.9 / 38.9 / 38.9 / 45.75MHz

Sound(FS) 33.4 / 32.9 / 32.4 / 41.25MHz

FP-FS 5.5 / 6.0 / 6.5 / 4.5MHz

Auto Tuning Method ALL Band (Not C.C.I.R. CH Plan)

Preset CH Analog 199 Carrier

Stereo/Dual TV Sound Nicam / A2 Dual / US Stereo(w/ SAP)

Tuner Sound Muting Yes

G-3 Power Power Source AC 110-240V AC 50/60Hz

DC ---

Power Consumption at AC 125 W at AC 220 V 50 Hz

at DC --

Stand by (at AC) w/ EPG Timer --

w/o EPG Timer 1 W at AC 230 V 50 Hz

Per Year -- kWh/Year

Protector Power Fuse Yes

G-4 Regulation Safety IEC60065:01, SASO

Radiation ---

X-Radiation ---

G-5 Temperature Operation 0oC ~ +40oC

Storage -20oC ~ +60oC

Space Around Unit 100mm (4inch)

G-6 Operating Humidity Less than 80% RH

G-7 OSD Language English, Simplified Chinese, Arabic, Thai, Persian

French, Vietnam, Russian, Malay, Portuguese,

Spanish, Indonesian

G-8 Clock and Sleep Timer Max Time 240 Min

Timer Step 10 / 20 / 30 / 60 / 90 / 120 / 180 / 240 Min

On/Off Timer Program(On Timer / Off Timer) -- Program / -- Program

Timer Back-up (at Power Off Mode) more than -- Min Sec

EPG Timer Events --

G-9 Remote Unit RC-UW

Control Glow in Dark Remocon No

Remocon Format SHARP

Format SHARP

Custom Code 10000 / 10001 / 01111

Power Source Voltage(D.C) 3V

UM size x pcs UM-4 x 2 pcs

Total Keys 43 Keys

Keys Power (Stand By) Yes

Information Yes

Analog Menu No

Digital Menu No

Input Select Yes

TV/DVB-T No

Guide No

Picture Size Yes

1 Yes

2 Yes

3 Yes

4 Yes

5 Yes

6 Yes

7 Yes

8 Yes

9 Yes

0 Yes

Sleep No

Mute Yes

A2-1

GENERAL SPECIFICATIONS

Volume Up / →No

Volume Down / ←No

Volume Up Yes

Volume Down Yes

CH Down No

CH Up No

Menu Yes

↑Yes

↓Yes

←Yes

→Yes

MEDIA Yes

Enter / CH List Yes

Return / Index Yes

Freeze frame No

TV/Radio No

Subtitle No

T'TEXT Keys TV / TEXT / MIX Yes

Reveal / Skip No

Reveal Yes

Display Cancel No

HOLD / Freeze Yes

Red Yes

Green Yes

Yellow Yes

Cyan Yes

Normal No

U.N.L.(Expand) No

F/T/B(Expand) Yes

Quick View No

Sub Page / Quick View Yes

Page Up / CH Up Yes

Page Down / CH Down Yes

Reset No

Audio 1/2 Yes

Reset / Audio 1/2 No

USB MEDIA Keys PLAY / PAUSE Yes

STOP Yes

SEARCH > Yes

SEARCH < Yes

SKIP >> Yes

SKIP << Yes

G-10 Features Power On Memory Yes

Auto Shut Off Yes

Just Clock Function No

Game Position No

DNR Yes

Comb Filter Yes

Auto Set Up (Fast installation) Language Yes

Country No

TV Location No

Auto Power Off Yes

Auto tuning Yes

CH sort No

ATS No

Auto clock (Digital tuner) No

Plug in start Yes

Picture Setting(TV) Picture Mode Yes

Brightness , Contrast , Color Yes

Tint Yes

Sharpness Yes

DNR Yes

Color Temperature Yes

Backlight Control Yes

DBC (Dynamic Backlight Control) No

Motion 100/120Hz No

Film Mode No

Picture Setting(PC) Picture Mode Yes

Brightness , Contrast , Color Yes

Sharpness No

HOR POSITION , VER POSITION Yes

PHASE , CLOCK Yes

AUTO ADJUST Yes

RED , GREEN , BLUE No

DNR No

Color Temperature Yes

A2-2

GENERAL SPECIFICATIONS

Backlight Yes

WXGA INPUT No

WVGA INPUT No

Audio Sound Mode Yes

Tone Control (Bass/Treble/Balance) Yes

Surround Yes

Equalizer No

Speaker No

Auto Volume Yes

BBE No

SRS WOW (SRS 3D/Focus/Tru Bass) No

Variable Audio Out No

Tuning Auto Tuning Yes

Manual Tuning Yes

Update Scan No

CH Skip Yes

CH Move Yes

CH Del Yes

Fine Tuning Yes

Lock Key Lock Yes

Channel Lock No

Parental Lock (Digital) No

Hotel Lock Yes

USB Clone (Hotel Lock) Yes

Screen Saver Inversion No

Full White No

Screen Saver No

Static Image No

T'Text Yes

Text type Fastext / Toptext

Text Language English, German, Swedish, Finnish, Hungarian,

Italian, French, Portuguese, Spanish, Czech,

Slovak, Polish, Estonian, Lettish, Lithuanian,

Slovenian, Rumanian, Russian,

Ukrainian, Turkish, Greek, Hebrew, Farsi

Arabic, Serbian, Croatian, Bulgarian

Text and Picture No

Wide Mode (4:3/16:9/CINEMA/REAL) Yes

CH Label Yes

Reset to Default Yes

HD Zoom No

Picture Scroll (Vertical Position) No

PFC(Power Factor circuit) Yes

Freeze frame Yes (ATV/CVBS in Only)

Plug and Play No

Power Management Yes

Hearing Impaired No

Audio Description No

Power On LED No

HDMI Mode No

Blue Back Yes

Scart Spec Scart1 AV in No

AV out No

S-Video in No

RGB in No

Scart2 AV in No

AV out No

S-Video in No

RGB in No

Digital Text (VBI teletext) No

MHEG-5 No

MHP No

EPG (BBC type 8Days Digital tuner only) No

OAD (Over Air Download) No

Common Interface (Digital tuner only) No

Rec Screen Status No

Ch sorting based on Ch List (Digital/Germany only) No

Rename Carrier (Digital) No

Edit Event Timer No

Software Update via CI Slot No

Preference Language (Audio/Subtitle/Digital Service)(Digital) No

DVB Subtitle (Digital) No

Clock No

DST No

Signal Status No

Digital Out Dolby Digital No

Dolby Digital Plus No

MPEG No

A2-3

GENERAL SPECIFICATIONS

HE AAC No

Decode(Down Mix) Dolby Digital No

Dolby Digital Plus No

MPEG No

HE AAC No

USB Media Player Photo JPEG (.jpg/.jpeg), BMP (.bmp), PNG (.png)

Music MP3 (.mp3), WMA (.wma), AAC (.aac/.m4a)

Video Container AVI (.avi), MKV (.mkv), MP4 (.mp4),

PS (.mpg), TS (.ts/.trp), VOB (.vob),

DIVX(.div/.divx/.avi/.mp4), MOV(.mov)

Video Codec Xvid, MPEG1, MPEG2, MPEG4 SP/ASP,

MJPEG, H.264, DivX

Audio Codec MPEG2, MP3, PCM/ADPCM, WMA, AC-3, AAC

Text Text (.txt)

PC Monitor Input Yes

VGA (640x480) Yes (60Hz)

VGA (720x400) No (Possible to Display)

WVGA (848x480) No

SVGA (800x600) Yes (60Hz)

XGA (1024x768) Yes (60Hz)

WXGA (1280x768) Yes (60Hz)

WXGA (1280x720) Yes (60Hz)

WXGA (1360x768) Yes (60Hz)

SXGA (1280x1024) Yes (60Hz)

WXGA+ (1440x900) Yes (60Hz)

WSXGA+ (1680x1050) No (Possible to Display)

FULL HD (1920x1080) Yes (60Hz)

HDMI Input Yes

VGA (640×480) Yes (60Hz)

VGA (720x400) No (Possible to Display)

WVGA (848x480) No

SVGA (800x600) Yes (60Hz)

XGA (1024x768) Yes (60Hz)

WXGA (1280x768) Yes (60Hz)

WXGA (1280x720) Yes (60Hz)

WXGA (1360x768) Yes (60Hz)

SXGA (1280x1024) Yes (60Hz)

WXGA+ (1440x900) Yes (60Hz)

WSXGA+ (1680x1050) No (Possible to Display)

FULL HD (1920x1080) Yes (60Hz)

720×480i (4:3) Yes (60Hz)

720×480i (16:9) Yes (60Hz)

720×480p (4:3) Yes (60Hz)

720×480p (16:9) Yes (60Hz)

720×576i (4:3) Yes (50Hz)

720×576i (16:9) Yes (50Hz)

720×576p (4:3) Yes (50Hz)

720×576p (16:9) Yes (50Hz)

1280×720p Yes (50/60Hz)

1920×1080i Yes (50/60Hz)

1920×1080p Yes (24/50/60Hz)

CEC(ORION Standard) No

Deep Color No

xvYCC No

Component Input Yes

720×480i (4:3) Yes (60Hz)

720×480i (16:9) Yes (60Hz)

720×480p (4:3) Yes (60Hz)

720×480p (16:9) Yes (60Hz)

720×576i (4:3) Yes (50Hz)

720×576i (16:9) Yes (50Hz)

720×576p (4:3) Yes (50Hz)

720×576p (16:9) Yes (50Hz)

1280×720p Yes (50/60Hz)

1920×1080i Yes (50/60Hz)

1920×1080p No (Possible to Display)

Wall Mount Size W x H(mm) Yes (200 x 400)

Screw Size M6 x 10

Stand Tilt No

Swivel No

A2-4

GENERAL SPECIFICATIONS

G-11 Accessories Owner's Manual Language English/Arabic/French/Russian/Portuguese/Kazak

w/Guarantee Card No

Remote Control Unit Yes

Rod Antenna No

Poles -

Terminal -

Loop Antenna (W/ Antenna Change Plug) No

Terminal -

DVB-T Antenna No

U/V Mixer No

Information Sheet (VESA) No

DC Car Cord (Center+) No

Guarantee Card No

Warning Sheet No

Circuit Diagram No

Antenna Change Plug No

Service Facility List No

Important Safeguard No

Quick Set-up Sheet No

Battery Yes

UM size x pcs UM-4 x 2 pcs

OEM Brand No

AC Adapter No

AC Cord (for AC Adapter) No

AC Cord Yes

AV Cord (2Pin-1Pin) No

HDMI-DVI Cable No

Registration Card No

300 ohm to 75 ohm Antenna Adapter No

Stand Screw Yes (8pcs)

Stand Yes

Frame Stand No

G-12 Interface Switch Side Power (Tact) Yes

System Select No

Main Power SW No

Channel Up/Menu Up Yes

Channel Down/Menu Down Yes

Volume Up/Menu > Yes

Volume Down/Menu < Yes

Input Select/Enter Yes

Menu No ("Vol-"+"Vol+" 1sec)

Indicator Power/Stand-by Yes(Green / Red)

On Timer No

Terminals Side Video Input 1 RCA x 1

Audio Input 1 RCA x 2(L, R)

S- Input 1 No

Video Input 2 No

Audio Input 2 No

S- Input 2 No

Video Output RCA x 1

Audio Output RCA x 2(L, R)

Digital Audio Out (Coaxial) No

Euro Scart (21Pin) No

Component In RCA x 3

Audio Input (Component In use) Audio Input1 Alternative

HDMI Input 1 Yes

Audio Input (HDMI/DVI In use) PC Monitor Audio Input Alternative

HDMI Input 2 No

Audio Input (HDMI/DVI In use) No

USB Yes

Sub Woofer Output No

Diversity No

Ext Speaker No

DC Jack 12V(Center +) No

VHF/UHF Antenna Input DIN Type

Headphone Yes

CI Card Slot No

AC Inlet Yes

A2-5

GENERAL SPECIFICATIONS

Rear Video Input 2 No

Audio Input 2 No

S- Input 2 No

Video Output No

Audio Output No

Component In No

Audio Input (Component In use) No

HDMI Input 1 No

Audio Input (HDMI/DVI In use) No

HDMI Input 2 Yes

Audio Input (HDMI/DVI In use) No

HDMI Input 3 No

Audio Input (HDMI/DVI In use) No

Euro Scart (21Pin) No

USB No

VHF/UHF Antenna Input No

PC Monitor Input (D-Sub) Yes

Audio Input Mini Pin Jack(φ3.5), STEREO

G-13 Set Size Approx. W x D x H (mm) 1,155 x 246 x 726

w/o Stand,Handle Approx. W x D x H (mm) 1,155 x 77.8 x 690.6

G-14 Weight Net Approx. 18.0kg (40.0lbs)

Net w/o Stand,Handle Approx. 16.5kg (36.7lbs)

Gross Approx. 21.0kg (47.7lbs)

Gross w/Master Carton (Approx.) --- kg ( --- lbs)

G-15 Carton Master Carton No

Content ---- Sets

Material -- /--

Dimensions W x D x H(mm) -- x -- x --

Description of Origin No

Gift Box Yes

Material Double/Full Color

W/Color Photo Label No

Dimensions W x D x H(mm) 1,290 x 176 x 838

Design As per Buyer's

Description of Origin Yes

Drop Test 1 Corner / 3 Edges / 6 Surfaces

Height (cm) 46

Container Stuffing 351 Sets/40' hi-cub container

w/Pallet No

w/Wrapping No

G-16 Material Cabinet Cabinet Front PC+ABS 94V0 NON-HALOGEN

Cabinet Rear PS 94V0 NON-DECABROM

Speaker Box ---

Stand PS 94HB (Piano)

PCB Non-Halogen No

Eyelet Yes

G-17 Environment Environmental standard requirement Green procurement of SHARP

Pb- Free Phase3(PHASE3A)

Measures for Whisker Yes

WEEE No

A2-6

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Televisor LCD de Sharp

Sharp

Sharp AQUOS LC-46LE831E Manual de usuario

Sharp

Sharp LC-22DV510K Manual de usuario

Sharp

Sharp LC 13SH4U Manual de usuario

Sharp

Sharp Aquos LC-13E1E Manual de usuario

Sharp

Sharp LC-32LE340E Manual de usuario

Sharp

Sharp AQUOS LC-19A35X-BK Manual de usuario

Sharp

Sharp LC-40LE832U Manual de usuario

Sharp

Sharp LC-15S2US Manual de usuario

Sharp

Sharp Aquos LC-70UH30U Manual de usuario

Sharp

Sharp LC-26SB25E Manual de usuario

Sharp

Sharp LC-40LX710H Manual de usuario

Sharp

Sharp Aquos LC-70LE660U Manual de usuario

Sharp

Sharp LC-32LE530E Manual de usuario

Sharp

Sharp LC-13C3US Manual de usuario

Sharp

Sharp LC-26DA5U, LC-32DA5U Manual de usuario

Sharp

Sharp AQUOS LC-37GE1E Manual de usuario

Sharp

Sharp LC-C3234U - 32" LCD TV Manual de usuario

Sharp

Sharp LC-20SH7U - 20" LCD TV Manual de usuario

Sharp

Sharp LC-30HV2M Manual de usuario

Sharp

Sharp Aquos LC-13B2UB Manual de usuario

Sharp

Sharp AQUOS LC-60LE831E Manual de usuario

Sharp

Sharp LC-13B2U Manual de usuario

Sharp

Sharp Aquos LC-65LE654U Manual de usuario

Sharp

Sharp Aquos LC-20B4M Manual de usuario

Manuales populares de Televisor LCD de otras marcas

LG 32LC4R* Manual de usuario

ViewSonic

ViewSonic N4200w-1 VS10945-1M Manual de usuario

Salora

Salora 22LED1600 Manual de usuario

Samsung

Samsung LA32E420 Guía

Dell

Dell W1900 19 Instrucciones de uso

Samsung

Samsung LN40C670M1F Manual de usuario

Samsung

Samsung Series 4+ Manual de usuario

Samsung

Samsung 5 Series Manual de usuario

Grundig

Grundig 40 VLE 8230 BP Manual de usuario

Philips

Philips 43PFL4901/F7 Manual de usuario

Sony

Sony Bravia XBR-43X830C Manual de usuario

LG 32LS350 Manual de usuario

VIORE

VIORE LED32VF60 Manual de usuario

Toshiba

Toshiba Regza 42HL167 Manual de usuario

JVC

JVC LT-32A220 Manual de usuario

Philips

Philips 20TA1000/93 Manual de usuario

Philips

Philips 32PFL3158T/12 Manual de usuario

Sony

Sony Bravia KDL-V32XBR2 Manual de usuario
