Sharp LC-40Q3020U Manual de usuario

ES-M1826C1-1

Help SHARP improve the environment by reducing paper waste.

For detailed instructions and feature descriptions, access the full User Manual online.

Quick Start Guide

LC-40Q3000U

LC-40Q3020U

LC-40Q3030U

LC-40Q3040U

LC-40Q3050U

LC-40Q3060U

LC-40Q3070U

LC-40Q3080U

LC-40Q3090U

Table of Contents

Register Your TV! .....................................................................................................................2

Packaged Contents ..................................................................................................................3

Buttons and Ports on the TV ....................................................................................................4

Attach the TV Stand or Wall Mount Bracket .............................................................................5

Connect Devices to your TV.....................................................................................................7

Buttons on your TV Remote .....................................................................................................9

Begin Using your Remote.......................................................................................................10

Power on the TV..................................................................................................................... 11

Complete the Setup Wizard....................................................................................................12

Product Speci ications............................................................................................................13

Quick Problem-Solving Tips ...................................................................................................14

Certification and Compliance..................................................................................................16

PACKAGED CONTENTS

Your package in which you purchased your new TV contains the following items:

● TV ● 2basestands

● 4screws(M4×20) ● RemoteControl

● 2AAAbatteries ● QuickStartGuide(thisdocument)

● ImportantSafetyInformationandWarrantyCard

IMPORTANT:

To prevent accidentally discarding items that came with your TV, be sure to check ALL of the foam in the carton box.

·Please check foam for accessories before discarding.

·Veuillez vérifier la mousse pour qu'il n'y ait pas d'accessoires avant de la jeter.

·Antes de desechar la espuma, asegúrese de retirar todos los accesorios.

Required tools and devices

● Phillipsscrewdriver(notincluded)tosecuretheTVstand

● HDMIandothertypesofcables(notincluded)toconnectexternaldevicestotheTV

● Wallmountbracket(notincluded)ifyouprefertomounttheTVtothewall

BUTTONS AND PORTS ON THE TV

Back View of the TV

TV Side View

TV Bottom View

STEP 1. Attach the TV Stand or Wall Mount Bracket

Attach the TV Stand

Follow the illustrations and instructions below to complete the installation steps:

1. CarefullyplaceyourTVfacedownonasoft,atsurfacetopreventdamagetotheTVorscratchingtothescreen.

2. Remove the 2 stands from the accessory bag and then insert the stands into the bottom slots of the TV.

3. Use the 4 screws in the accessory bag to secure the BASE STAND to the TV.

Screws

M4×20

BASE STAND

Screws

M4×20

BASE STAND

Attach the Wall Mount Bracket (not included)

Before you begin the third-party manufacturer instructions, be

sure to do the following things:

1.Place the TV face down on a clean, safe and cushioned surface.

2.Remove the TV stand if you already attached it.

3.Place the spacers (not included) in the corresponding bracket

holes.

CAUTION:

• Whenyouattachthemount,besuretousethespacers

(providedbythethird-partymanufacturer)betweentheTV

and the bracket.

Screw

(not provided)

Bracket

(not provided)

Spacer

(not provided)

• TopreventinternaldamagetotheTVandensureitis

mountedsecurely,besuretousexingscrews(not

provided)thatare 8-10mminlengthwhenmeasuredfrom

the attaching surface of the mounting hook.

FollowinstructionsprovidedwiththeWallmountbracket.

● Tocompletetheinstallation,pleasecontactthewall-mount

manufacturer or the retailer from which you purchased the TV.

● Theselectedscrewsare8-10mminlengthwhenmeasured

from the attaching surface of the rear cover.

NOTE:Thediameterandlengthofthescrewsdiffer

dependingonthewallmountbracketmodel.

Rear cover of the TV Spacer

Screw

Wall mount bracket

8 - 10 mm

Wall mount hole pattern

VESA (mm) 200 × 200

Wall mount screw size (mm) M6

STEP2.ConnectdevicestoyourTV

Check to ensure that you have selected the right cables for the ports and that they are connected securely. Loose connections can affect

the quality of the picture image and color.

TV label Port Cable External Equipment Brief Description

ANT

CABLE IN

Antenna

VHF/UHF Antenna

ANT OUT

Connect an outdoor VHF/UHF antenna.

HDMI

DVD Player/Recorder

Set-top Box

Satellite Receiver

Satellite

antenna

cable

VCR

Video

Camera

COMPO-

NENT IN

YGreen

Connect a component video cable and left-right

audio cables from an external AV device.

PBBlue

PRRed

LWhite

RRed

AV IN

VIDEO Yellow

Connect a composite video cable and left-right

audio cables from an external AV device.

LWhite

RRed

Connect a High Definition Multimedia Interface

(HDMI) cable from an external device.
