LC-32SH7E(B)

SERVICE MANUAL

No.

LCD COLOUR TELEVISION

MODELS LC-32SH7E(B)

This model is based on the LC-32SH7E and is changed some parts. This Service Manual covers the modifications alone, For the other points,

refer to the LC-32SH7E Service Manual.

Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the

safety and performance of the set.

This document has been published to be used for

after sales service only.

The contents are subject to change without notice.

DIFFERENCES FROM BASE MODEL

LIST OF CHANGED PARTS........................................2

SAFETY PRECAUTION

IMPORTANT SERVICE SAFETY PRECAUTION........3

PRECAUTIONS A PRENDRE LORS DE

LA REPRATION .........................................................4

PRECAUTIONS FOR USING LEAD-FREE

SOLDER ....................................................................5

PRECAUTIONS IN SERVICING THE HDCP-KEY

ROM...........................................................................6

Parts Guide

CONTENTS

In the interests of user-safety (Required by safety regulations in some countries) the set should

be restored to its orig-inal condition and only parts identical to those specified should be used.

OUTLINE

LC-32SH7E(B)

DIFFERENCES FROM BASE MODEL

LIST OF CHANGED PARTS

LC-32SH7E LC-32SH7E(B)

Ref.No. Description Code number Sharp C/N Code number Sharp C/N Note

PWB ASSEMBLES

MAIN Unit CBPF92MBP4 9JR9900000039 CBPF92MBZ5 9JR9900000048 -

POWER Unit ADTV92415PA1 9JR9900000038 ADTV92415PA1 9JR9900000038 -

KEY Unit KEPF9PA9 9JR9900000040 KEPF9PA9 9JR9900000040 -

IR Unit IRPF9PB3 9JR9900000035 IRPF9PB3 9JR9900000035 -

CABINET AND MECHANICAL PARTS

Please refer to a Parts list.

PACKING PARTS AND ACCESSORIES

Please refer to a Parts list.

2008-03-14

LC-32SH7E(B)

PARTS GUIDE

Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the

safety and performance of the set.

This document has been published to be used for

after sales service only.

The contents are subject to change without notice.

Note:

The reference numbers on the PWB

Are arranged in alphabetical order. MODEL: LC-32SH7E(B)

[1] CABINET AND MECHANICAL PARTS

[2] SUPPLIED ACCESSORIES

[3] PACKING PARTS(NOT

PEPLACEMENT ITEM)

[4] SERVICE JIGS(USE FOR SERVICING)

CONTENTS

LC-32SH7E(B)

[1] CABINET AND MECHANICAL PARTS

2008-03-14

LC-32SH7E(B)

NO. PARTS CODE Sharp Code DESCRIPTION

CABINET PARTS(LC-32SH7E-BK)

1 705TZ934240 9JR7050000126 BEZEL ASSY

2 705GZ934236 9JR7050000118 KEY PAD ASSY

3 078G0050 1 M 9JR7800000009 SPEAKER 8 OHM 5W 850/400mm 135X41mm

4 750TVM315B5213N000 9JR7500000024 PANEL V315B5-L02 NH CMO

5 IRPF9PB3 9JR9900000035 IR PCB ASSY

6 CBPF92MBZ5 9JR9900000048 MAIN PCB ASSY

7 ADTV92415PA1 9JR9900000038 POWER PCB ASSY

8 KEPF9PA9 9JR9900000040 KEY PCB ASSY

9 705GZ934144 9JR7050000069 STAND ASSY

10 P34T0385PAA 1T0100 9JR3400000009 NECK

11 705GZ934195 9JR7050000097 REAR COVER ASSY

LC-32SH7E(B)

[2] SUPPLIED ACCESSORIES

LC-32SH7E(B)

DIFFERENCES FROM BASE MODEL

LIST OF CHANGED PARTS

LC-32SH7E LC-32SH7E(B)

Ref.No. Description Code Number Sharp C/N Description Code Number Sharp C/N Note

PRINTED WIRING BOARD ASSEMBLIES

BEZEL ASSY 705GZ934194 9JR7050000096 BEZEL ASSY 705TZ934240 9JR7050000126

Part changed

RATING LABEL P40G 320843 4A 9JR4000000054 RATING LABEL Z40G 32084301A 9JR4000000081 Part changed

CARTON LABEL P40G000184323A 9JR4000000056 CARTON LABEL Z40G000184301A 9JR4000000082

Part changed

PANEL 750TVA315Z9411N0SP 9JR7500000019 PANEL 750TVM315B5213N000 9JR7500000024 Part changed

MAIN Unit CBPF92MBP4 9JR9900000039 MAIN Unit CBPF92MBZ5 9JR9900000048

Some parts changed

POWER Unit ADTV92415PA1 9JR9900000038 POWER Unit ADTV92415PA1 9JR9900000038

No parts changed

KEY Unit KEPF9PA9 9JR9900000040 KEY Unit KEPF9PA9 9JR9900000040

No parts changed

IR Unit IRPF9PB3 9JR9900000035 IR Unit IRPF9PB3 9JR9900000035

No parts changed

HARNESS 30P-20*2P 260mm 75409 095G8018 30981 FP 9JR9500000064 HARNESS 30P-40P 350mm 83009 095G801840FA19 9JR9500000077

Part changed

LCD PANEL

1050 PANEL LK315T3LZ94 JP SHARP 750TVA315Z9411N0SP 9JR7500000019 PANEL V315B5-L02 NH CMO 750TVM315B5213N000 9JR7500000024 Part changed

MAIN Unit

CABINET AND MECHANICAL PARTS

Please refer to a Parts list

PACKING PARTS, ACCESSORIES AND SERVICE JIGS

Please refer to a Parts list

LC-32SH7E(B)

c2009 BY SHARP CORPORATION

SHARP CORPORATION

SHARP ELECTRONICS(Europe) GmbH

Sonnistraße 3, D-20097 Hamburg

No Part of this publication may be reproduced,

stored in a retrieval system, or transmitted in

any from or by any means, electronic, mechanical,

photocopying, recording, or otherwise, without

prior written permission of the publisher.
