Sharp MD-MT90H Manual de usuario

Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

Quick Guide

PORTABLE MINIDISC RECORDER

MODEL

MD-MT90H

Quick Setup Guide

Follow the setup procedure (1-3)

before you use this unit.

Quick Operation Guide

Explainsbasicrecordingandplayback

procedures.

Refer to the operation manual for details.

If you require any advice or assistance regarding

your Sharp product, please visit our web-site

www.sharp.co.uk/support.

Customerswithoutinternetaccessmaytelephone

08705274277duringofficehours(or(01)6760648

if telephoning from Ireland).

A0101.TO

TINSE0367AWZZ

Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

Inserting a MiniDisc

1Slide the OPEN lever to re-

lease the compartment door.

2Lift it up.

3Insert a MiniDisc as shown.

4Close the compartment door.

222 441

Insert according to

the direction arrow.

When you record on a MiniDisc,

check that the erase prevention tab

is set to the “recordable” position.

Recordable Recording

prevented

Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

Connect the AC adaptor

To the DC IN 5V socket.

AC 230-240V,

50/60 Hz

Insert securely, all the way in.

To the wall socket.

1Plug the AC adaptor into the

wall socket. 2Insert the plug on the other

end into the DC IN 5V socket.

Before using the unit with a rechargeable battery, the battery has to be charged.

Refer to “Battery Power”, page 28 - 29 (operation manual) for details.

Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

LINE OUT

LEFTRIGHT

OPTICAL/

LINE IN

Connections

To a stereo system with “LINE OUT” or “AUDIO

OUT” sockets.

Note:

If the audio system has only one pair of sockets they

are usually for input only and recording via this connec-

tion is not possible.

NOTE:

Refer to page 11 (operation manual) for connecting the unit to a stereo system

with “DIGITAL OUT” or “OPTICAL OUT” socket.

Red: To Right

White: To Left

Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

Preparation for use

The unit does not work

if the unit is in the hold mode.

Hold

Release

CAUTION:

It is not recommendable to put the

MiniDisc into a rear pocket, as this

maydamagetheproductwhensitting.

Press the HOLD button for 2 seconds or more.

Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

Recording

Check that the unit is connected to the stereo system.

Continued to the next page

1Press the REC button.

Record pause mode is entered.

2Begin playback on the stereo system connected to this por-

table MD.

To enable the record level to be set.

3Press the 55

5or 44

4button

to adjust the recording level.

Adjust the recording level so that the maximum sound volume from the

source makes the reading swing somewhere between –4 dB and 0 dB.

0dB

4dB

This unit can adjust the digital recording level just the same as the ana-

logue recording.

Level meter indicator

Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

Recording: continued

To stop recording

Press the ■ / :OFF button.

●When recording stops, “TOC” ap-

pears. Whilst “TOC” appears the

MiniDisc recorded contents have

not yet been updated.

●To prevent the new recording from

being lost it is not possible to re-

move the MiniDisc whilst “TOC” is

displayed.

4Press the PAUSE button on the stereo system to enter the play-

back pause mode.

Here you can search for the track to record.

5Press the PLAY/PAUSE button to start the MiniDisc unit re-

cording.

Beginplayback onthestereo system,theoutput willberecorded.

About the TOC

After any recording or editing function

“TOC”(TableOfContents)isdisplayed.

To finalisetherecordingorediting func-

tion, press the

■ / :OFF button. During

thisprocess“TOC” will flash and “TOC

EDIT!” will be displayed.

During any recording or editing func-

tion the MiniDisc unit lid is locked, the

MiniDisc can not be removed until the

process is finalised.

Warning:

If the power is removed (Battery/AC

adaptor) whilst “TOC” is displayed the

MiniDiscunit lid willremainlocked until

thebattery/main power is restored and

the unit is turned on. Your new record-

ings or edited changes will be lost and

your MiniDisc may become unusable.

To update the recorded contents

of the MiniDisc

Press the ■ / :OFF button whilst in

the stop mode.

●The power turns off after recorded

contentshavebeenupdated onthe

MiniDisc.

TOC display

Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

Playback

1Insert the earphones plug firmly into the earphones socket on

the remote control unit.

2Plug the remote control into the REMOTE socket on the unit.

3Insert a MiniDisc.

4Press the PLAY/PAUSE

button.

Playback starts automatically with a playback only MiniDisc or a MiniDisc

which is protected against accidental erasure (Auto-play function).

To stop playback

Press the ■ / :OFF button.

If the unit is not operated for at least 2

minutes whilst in the stop mode, the

power will shut off automatically.
