PN-V601 Installation Guidelines

CONFIDENTIAL

PN-V601 Installation Guidelines <Rev1.4 > September.30, 2010

CONFIDENTIAL 1

About the handling of this material / Contents

- This document is made to explain the installation

know-how of large size displays for our business partners.

Therefore, please handle this material very carefully.

- This document describes basic notes to install and use the

display for long term reliable service.

Contents

[Warning]

This document is to explain the installation

know-how to our business partners. Please

be careful not to distribute this document or

its contents to other companies, or divert

(use) it towards competitors’ models.

In addition, please be reminded that values

and expressions on this document are

subject to change without notice.

•Procedures of installation

•Overall precautions

•Precautions for temperature and clearance space 1, 2, 3, 4, 5

•Precautions for sunlight exposure

•Precautions against dust

•Position of exhaust fan and intake port

•Precautions for dew condensation, water drops, and salt damage

•Precautions for orientation, power supply and voltage

•Precautions for vibration and residual images

•Operation check before installation

•Precautions for installation space dimensions

•Precautions for space between displays

•Precautions on stand installation

•Precautions of wall mounting

•Precautions in installing and handling 1, 2, 3

•Attachment precaution 1 , 2

•Installation tool 1, 2 , 3, 4, 5, 6

•Precautions on PC installation

•Color Adjustment 1, 2

•Software tool

•Software applications

•Maintenance & check items

•Periodical maintenance

Handling this material

CONFIDENTIAL

PN-V601 Installation Guidelines <Rev1.4 > September.30, 2010

CONFIDENTIAL

Make enough

space before

starting the job.

Check power cable

and/or floor levelness.

Procedures of Installation

(Please thoroughly observe these recommendations)

Check worker’s

clothes and their

belongings.

Wear simple clothes and

do NOT put their mobile

phone and/or pen in a

pocket.

We recommend that the following procedures are entrusted to Sharp sales

subsidiaries or dealers/contractors trained by Sharp.

The person responsible

of installation directly

explains to the workers

how to handle the display

securely and shows them

examples.

Then, start the job.

3Prior

Explanation

How to open the box for display.

How to take the display from the box.

How to hold the display and the holding position(s) for workers [Attachment precaution 2]

How to temporarily store the display after taking it from the box.

We recommend temporarily storing the display on a temporary stand. If you inevitably put

the surface of LCD monitor on the ground when there is no temporary stand, check whether

there is dust and/or projection, and place on a clean board larger than the display.

How to check and/or store the accessories of display.

Installation with stand and

wall-mounting bracket

Unlike Sharp “PN-E” standard models,

the PN-V601 requires close attention to

handling due to its thin bezel.

Even dealers or workers familiar with the

conventional models must confirm

precautions beforehand Please study

the installation guide of the PN-V601 and

recommended stands as much as

possible, and please entrust the

installation work to Sharp sales

subsidiaries or dealers /contractors

trained by Sharp.

Precautions for fan

Precautions for adjacent

positioning

Do Not touch

LCD surface

Attention to

bezel handling

CONFIDENTIAL

PN-V601 Installation Guidelines <Rev1.4 > September.30, 2010

CONFIDENTIAL

1. Check worker’s clothes and their belongings. Wear simple clothes and do NOT put their

mobile phone and/or pen in a pocket.

2. Make enough space before starting the job. Check power cable and/or floor for levelness.

3. The person responsible for the installation directly explains to the workers how to handle the

display securely and shows them examples. Then, start the job.

Setting board larger

than PN-V601

protecting sheet

like blanket

PN-V601

-Do not set the PN-V601 on a setting

board smaller than itself to avoid the

contact with corner of the board.

- Use a protecting sheet like blanket

- Do not add force from the above.

- Do not drag only the PN-V601

How-tos for PN-V601 installation

Please set the PN-V601 in the centre

of the setting board/protecting sheet

and be careful to avoid the contact

with corner of the board.

4. Installation with Wall-mounting Bracket and Stand

- Unlike Sharp “PN-E” standard models, the PN-V601 requires close attention for handling due to its thin bezel.

- Even the dealers or worker familiar with the conventional models must confirm precautions beforehand.

Please study the installation of the Sharp recommended stand as much as possible, and please entrust the

installation work to Sharp sales subsidiaries or dealers /contractors trained by Sharp.

Procedures of Installation

(Please thoroughly observe these recommendations)

How to open the box for display.

How to take the display from the box.

How to hold the display and the holding position(s) for worker [Attachment precaution 2]

How to temporarily store the display after taking it from the box.

We recommend temporarily storing the display on a temporary stand. If you inevitably put

the surface of LCD monitor on the ground when there is no temporary stand, check whether there

is dust and/or projection, and place on a clean board larger than the display.

How to check and/or store the accessories of display.

We recommend that the following procedures are entrusted to Sharp sales

subsidiaries or dealers/contractors trained by Sharp.

CONFIDENTIAL

PN-V601 Installation Guidelines <Rev1.4 > September.30, 2010

CONFIDENTIAL 4

Overall precautions

Precautions for Usage, Installation

- Do not use the information display under following conditions ;

1) Usage beyond its capability, feature/function, accuracy/precision

2) Usage that could develop into injury or life-threatening situation under product breakdown

3) Usage that could lead to major monetary damage

We will not take any responsibility if the product was used under above conditions.

Control of all types of safety related usage of transportation equipment (air plane, train, car, etc.), aerospace

equipment, communication equipment, nuclear control equipment, medical equipment, disaster-prevention/security

equipment, all types of safety equipment, etc.

- We will not take any responsibility for any failure, damage, loss, etc. which arise from particular installation

(high-ceiling mounting etc.) and/or installation by non-Sharp related parties. Prior to the installation, please

examine the potential problems by the installation location and installation method, and only operate within the

appropriate environment.

In case of product failure, regardless of warranty period, removal and installation expenses incurred will be the

customer’s responsibility.

Repairing may take a certain time period. For that reason, arranging of a back-up is recommended.

- Installation environment of the information display differs by individual cases. Please make appropriate installation by

referring to this material. If you have any difficulty in making judgment about installation or have any

comments/questions about the contents of this material, please ask SHARP Business Solution factory via your local

Sharp sales window.

CONFIDENTIAL

PN-V601 Installation Guidelines <Rev1.4 > September.30, 2010

CONFIDENTIAL 5

Temperature inside the display will heat up if the air clearance space is not enough.

- If the temperature is too high Electronic components and the fan’s life time will be shortened or breakdown.

- If the heat gets trapped inside the display, the temperature will rise. Hence, the brightness of back-light will be

lowered and the screen will be darkened

Moreover, if the temperature gets too high, the power of LCD display will be turned off and the display will be set

to the standby mode.

The thermal influence

The heat impact on LCD surface

The effect of high temperature Monitors will break down or uniformity issue will occur

Precautions for temperature and clearance space 1

CONFIDENTIAL

PN-V601 Installation Guidelines <Rev1.4 > September.30, 2010

CONFIDENTIAL 6

Space requirement 1

Top 20 ｃｍ

Bottom 10 ｃｍ

Left/

Right 10 ｃｍ

Behind Clearance space and surrounding

temperature should be maintained (refer to

next page)

Surface Consult us separately

Temperature control and clearance space conditions

PN-V601(Main unit), PN-ZR01(Remote-control signal

receiving kit) temperature condition requirement

- Usable temperature range

0 degree C to 40 degree C *

*: Maximum temperature when multi-display system is operating

- Clearance space

1)Space should be taken between front/ back/

above/ below/right/left side of the display

2) Due to configurations of multi-display and

clearance space at the back side,

surrounding temperature must be carefully

controlled.

- Temperature of LCD surface

Under 60 degree C

Please follow these requirements when setting multi- display.

Refer to the measures and install the display according to its

requirements. (Same with peripheral devices, please follow the

specifications )

Securing space at the Top/ Bottom/ Left/ Right/ Behind /

Surface of display is necessary regardless of wall-hanging or

stand type installation.

A point for measuring temperature

Please measure the temperature at 1m away from the

centre of LCD surface.

Surface of LCD multi-display

Side view

Precautions for temperature and clearance space 2

Note: However, please separately inquire in following cases:

1)when you install with outer casing, 2)When using protection panel,

or 3) Closed installation like In-wall installation, etc. that

surroundings are not opened.

CONFIDENTIAL

PN-V601 Installation Guidelines <Rev1.4 > September.30, 2010

CONFIDENTIAL 7

Space requirement 2

*1 In the case of clearance space at the back side, Use “Setting 1” without using “Auto” at the “Fan rotation speed”.

When the clearance space of back side is small, if the fan works at the setting 4, the heat release effect becomes worse than that at

Setting 2. Because heat accumulates between LCD monitor and wall.

*2 The timing of fan replacement is used as a guideline.

The actual life may vary depending the operating time, change of ambient temperature, environment such as amount of dust, or regular

maintenance.

Even if a fan on the LCD monitor has trouble, the neighbor fan supplements its operation. Therefore, the LCD monitor correctly works.

Above life is described as rough guide and it shall not warrant the life. Even within the warranty period, the replacement of fan caused

by failure is charged. The warranty does not include pre-mature fan failure.

3.5cm or more 10cmor more 20cmor more 30cmor more 40cmor more 50cmor more 60cmor more 70cmor more

Auto (Variable: default setting) 30.5 32 32.5 36 38

Setting 1 (Rotation speed: 50%) 29 30 30 30.5 30.5 31 32 33

3.5cmor more 10cmor more 20cmor more 30cmor more 40cmor more 50cmor more 60cmor more 70cmor more

Auto (Variable: default setting) 30 31 31.5 34

Setting 1 (Rotation speed: 50%) 21.5 27.5 29 29.5 29.5 30 30 30.5

For case of 5 x 5 multi-screen displays

Use at Setting 1.*1

For case of 3 x 3 multi-screen displays (Unit: degree celsius)

Clearance space at the back side

"Fan rotation speed" Setting

"Fan rotation speed" Setting Clearance space at the back side

Use at Setting 1.*1

Note: The necessary clearance space is set when the front side (front cover) is opened.

Remarks: The following shows the fan rotation speed. Setting 1: 50 %, Setting 2; 60%, Setting 3: 70%, Setting 4: 100%

Precautions for temperature and clearance space 3

1.Relationship between the rear clearance space and operating temperature

The timing of fan replacement (*2) is 5 years in the above condition of clearance space and operating temperature.

CONFIDENTIAL

PN-V601 Installation Guidelines <Rev1.4 > September.30, 2010

CONFIDENTIAL 8

Space requirement 3

*2 The timing of fan replacement is used as a guideline.

The actual life may vary depending the operating time, change of ambient temperature, environment such as amount of dust, or regular

maintenance.

Even if a fan on the LCD monitor has trouble, the neighbor fan supplements its operation. Therefore, the LCD monitor correctly works.

Above life is described as rough guide and it shall not warrant the life. Even within the warranty period, the replacement of fan caused

by failure is charged. The warranty does not include pre-mature fan failure.

3.5cm or more

10cm or more 20cmor more 30cmor more 40cmor more

Auto (Variable: default setting)

33 26 38 39 40

3.5cmor more 10cmor more 20cmor more 30cmor more 40cmor more 50cmor more 60cmor more

Auto (Variable: default setting)

24.5 30.5 33 35 37.5 39 40

For case of 3 x 3 multi-screen displays (Unit: degree celsius )

"Fan rotation speed" Setting

"Fan rotation speed" Setting Clearance space at the back side

For case of 5 x 5 multi-screen displays

Clearance space at the back side

Precautions for temperature and clearance space 4

2.The case of reducing clearance space and operating temperature

The timing of fan replacement (*2) becomes shorter to 2.5 years in the following condition of clearance space and operating

temperature.

CONFIDENTIAL

PN-V601 Installation Guidelines <Rev1.4 > September.30, 2010

CONFIDENTIAL 9

Space requirement at the back-side

3X3 multi-display

Temperature under operation

VS. Clearance space

Clearance space

Temperature

Note : Space requirements for this displays is reported under the condition where

there is open space in front of the surface.

5X5 multi-display

Temperature under operation

VS. Clearance space

Temperature

Clearance space

Precautions for temperature and clearance space 4

20.0℃

25.0℃

30.0℃

35.0℃

40.0℃

3.5cm 10cm 20cm 30cm 40cm 50cm 60cm 70cm

Life time of fan: 5 years

Setting: Automatic

Life time of fan: 5 years

Setting: Setting 1

Life time of fan: 2.5 years

Setting: Automatic

20.0℃

25.0℃

30.0℃

35.0℃

40.0℃

3.5cm 10cm 20cm 30cm 40cm 50cm 60cm 70cm

Life time of fan: 5 years

Setting: Automatic

Life time of fan: 5 years

Setting: Setting 1

Life time of fan: 2.5 years

Setting: Automatic

Otros manuales para PN-V601

Tabla de contenidos

Otros manuales de Caja registradora de Sharp

Sharp

Sharp XE-A203 - Cash Register Thermal Printing Graphic Logo... Manual de usuario

Sharp

Sharp ER-A440 Manual de usuario

Sharp

Sharp UP-700 Manual de usuario

Sharp

Sharp ER-A310 Manual de usuario

Sharp

Sharp ER-A440 Manual de usuario

Sharp

Sharp XE-A302 Manual de usuario

Sharp

Sharp ER-A310 Manual de usuario

Sharp

Sharp XE-A107 Manual de usuario

Sharp

Sharp XE-A203 - Cash Register Thermal Printing Graphic Logo... Manual de usuario

Sharp

Sharp XE-A505 - Cash Register, Thermal Printing Manual de usuario

Sharp

Sharp XE-A110 Manual de usuario

Sharp

Sharp ER-A320 Manual de usuario

Sharp

Sharp XE-A506 Manual de usuario

Sharp

Sharp XE-A202 - Electronic Cash Register Manual de usuario

Sharp

Sharp ER-A520 Manual de usuario

Sharp

Sharp ER-A520 Manual de usuario

Sharp

Sharp XE-A206 Manual de usuario

Sharp

Sharp XEA401 - Cash Register W/THERMAL Printer Manual de usuario

Sharp

Sharp XE-A107 Guía de configuración

Sharp

Sharp XE-A42S Manual de lista de piezas

Sharp

Sharp ER-A250 Manual de usuario

Sharp

Sharp UP-820N Manual de usuario

Sharp

Sharp ER-2386S Manual de usuario

Sharp

Sharp UP-3301 Manual de usuario

Manuales populares de Caja registradora de otras marcas

Royal

Royal 480nt Manual de usuario

Olivetti

Olivetti ECR 8200 S Manual de usuario

TEC

TEC TEC FS-3600 Manual de usuario

Integrated System Laboratory

Integrated System Laboratory ISL 4006 Manual de usuario

Sam4s

Sam4s ER-380 Guía de solución de problemas

Samsung

Samsung ER 5215 Manual de usuario

Toast

Toast Toast Manual de usuario

TEC

TEC MA-600-1 series Manual de usuario

QUORION

QUORION CR 1200 Manual de usuario

Olivetti

Olivetti ECR 7700 LD eco Plus Manual de usuario

TEC

TEC TEC MA-1060 Manual de usuario

Casio

Casio PCR-408 Instrucciones de montaje

ELCOM

ELCOM Euro-2100TE Manual de usuario

American Changer

American Changer CLASSIC Series Manual de usuario

Sam4s

Sam4s ER-180 Manual de usuario

Sam4s

Sam4s ER-5100? SERIES Manual de usuario

Casio

Casio PCR-T273 Manual de usuario

Casio

Casio PCR-T2100 Manual de usuario
